Arconic 2015 series User manual

Patent Pending
February 8, 2017
HK958
Instruction Manual
2015 series
Pneudraulic Installation Tools
Makers of Huck®, Marson®, Recoil®
Brand Fasteners, Tools & Accessories
Declaration of Conformity
2
Safety Instructions
3
Description
4
Principle of Operation
4
Specifications
4-6
Preparation for Use
7
Operating Instructions
8
Maintenance
9
Disassembly Instructions
10-11
Assembly Instructions
12
Fill and Bleed
13-14
Measuring Tool Stroke
15
Components Drawings
16-20
Troubleshooting
21
Kits and Accessories
21-22

2
2015 series Pneudraulic Installation Tools (HK958)

3
2015 series Pneudraulic Installation Tools (HK958)
I. GENERAL SAFETY RULES:
1. A half hour long hands-on training session with qualified personnel is
recommended before using Huck equipment.
2. Huck equipment must be maintained in a safe working condition at all times.
Tools and hoses should be inspected at the beginning of each shift/day for
damage or wear. Any repair should be done by a qualified repairman trained
on Huck procedures.
3. For multiple hazards, read and understand the safety instructions before
installing, operating, repairing, maintaining, changing accessories on, or
working near the assembly power tool. Failure to do so can result in serious
bodily injury.
4. Only qualified and trained operators should install, adjust or use the assembly
power tool.
5. Do not modify this assembly power tool. This can reduce effectiveness of
safety measures and increase operator risk.
6. Do not discard safety instructions; give them to the operator.
7. Do not use assembly power tool if it has been damaged.
8. Tools shall be inspected periodically to verify all ratings and markings required,
and listed in the manual, are legibly marked on the tool. The employer/
operator shall contact the manufacturer to obtain replacement marking labels
when necessary. Refer to assembly drawing and parts list for replacement.
9. Tool is only to be used as stated in this manual. Any other use is prohibited.
10. Read MSDS Specifications before servicing the tool. MSDS specifications are
available from the product manufacturer or your Huck representative.
11. Only genuine Huck parts shall be used for replacements or spares. Use of any
other parts can result in tooling damage or personal injury.
12. Never remove any safety guards or pintail deflectors.
13. Never install a fastener in free air. Personal injury from fastener ejecting may
occur.
14. Where applicable, always clear spent pintail out of nose assembly before
installing the next fastener.
15. Check clearance between trigger and work piece to ensure there is no pinch
point when tool is activated. Remote triggers are available for hydraulic
tooling if pinch point is unavoidable.
16. Do not abuse tool by dropping or using it as a hammer. Never use hydraulic
or air lines as a handle or to bend or pry the tool. Reasonable care of
installation tools by operators is an important factor in maintaining tool
efficiency, eliminating downtime, and preventing an accident which may
cause severe personal injury.
17. Never place hands between nose assembly and work piece. Keep hands clear
from front of tool.
18. Tools with ejector rods should never be cycled with out nose assembly
installed.
19. When two piece lock bolts are being used always make sure the collar
orientation is correct. See fastener data sheet for correct positioning.
II. PROJECTILE HAZARDS:
1. Risk of whipping compressed air hose if tool is pneudraulic or pneumatic.
2. Disconnect the assembly power tool from energy source when changing
inserted tools or accessories.
3. Be aware that failure of the workpiece, accessories, or the inserted tool itself
can generate high velocity projectiles.
4. Always wear impact resistant eye protection during tool operation. The grade
of protection required should be assessed for each use.
5. The risk of others should also be assessed at this time.
6. Ensure that the workpiece is securely fixed.
7. Check that the means of protection from ejection of fastener or pintail is in
place and operative.
8. There is possibility of forcible ejection of pintails or spent mandrels from front
of tool.
III. OPERATING HAZARDS:
1. Use of tool can expose the operator’s hands to hazards including: crushing,
impacts, cuts, abrasions and heat. Wear suitable gloves to protect hands.
2. Operators and maintenance personnel shall be physically able to handle the
bulk, weight and power of the tool.
3. Hold the tool correctly and be ready to counteract normal or sudden
movements with both hands available.
4. Maintain a balanced body position and secure footing.
5. Release trigger or stop start device in case of interruption of energy supply.
6. Use only fluids and lubricants recommended by the manufacturer.
7. Avoid unsuitable postures, as it is likely for these not to allow counteracting of
normal or unexpected tool movement.
8. If the assembly power tool is fixed to a suspension device, make sure that
fixation is secure.
9. Beware of the risk of crushing or pinching if nose equipment is not fitted.
IV. REPETITIVE MOTION HAZARDS:
1. When using assembly power tool, the operator can experience discomfort in
the hands, arms, shoulders, neck or other parts of the body.
2. When using tool, the operator should adopt a comfortable posture while
maintaining a secure footing and avoid awkward or off balanced postures.
3. The operator should change posture during extended tasks to help avoid
discomfort and fatigue.
4. If the operator experiences symptoms such as persistent or recurring
discomfort, pain, throbbing, aching, tingling, numbness, burning sensations or
stiffness, these warnings should not be ignored. The operator should tell the
employer and consult a qualified health professional.
V. ACCESSORIES HAZARDS:
1. Disconnect tool from energy supply before changing inserted tool or
accessory.
2. Use only sizes and types of accessories and consumables that are
recommended. Do not use other types or sizes of accessories or consumables.
VI. WORKPLACE HAZARDS:
1. Be aware of slippery surfaces caused by use of the tool and of trip hazards
caused by the air line or hydraulic hose.
2. Proceed with caution while in unfamiliar surroundings; there could be hidden
hazards such as electricity or other utility lines.
3. The assembly power tool is not intended for use in potentially explosive
environments.
4. Tool is not insulated against contact with electrical power.
5. Ensure there are no electrical cables, gas pipes, etc., which can cause a hazard
if damaged by use of the tool.
VII. NOISE HAZARDS:
1. Exposure to high noise levels can cause permanent, disabling hearing loss
and other problems such as tinnitus, therefore risk assessment and the
implementation of proper controls is essential.
2. Appropriate controls to reduce the risk may include actions such as damping
materials to prevent workpiece from ‘ringing’.
3. Use hearing protection in accordance with employer’s instructions and as
required by occupational health and safety regulations.
4. Operate and maintain tool as recommended in the instruction handbook to
prevent an unnecessary increase in the noise level.
5. Select, maintain and replace the consumable / inserted tool as recommended
to prevent an unnecessary increase in noise.
6. If the power tool has a silencer, always ensure that it is in place and in good
working order when the tool is being operated.
VIII. VIBRATION HAZARDS:
1. Exposure to vibration can cause disabling damage to the nerves and blood
supply to the hands and arms.
2. Wear warm clothing when working in cold conditions and keep hands warm
and dry.
3. If numbness, tingling, pain or whitening of the skin in the fingers or hands,
stop using the tool, tell your employer and consult a physician.
4. Support the weight of the tool in a stand, tensioner or balancer in order to
have a lighter grip on the tool.
IX. PNEUMATIC / PNEUDRAULIC TOOL SAFETY INSTRUCTIONS:
1. Air under pressure can cause severe injury.
2. Always shut off air supply, drain hose of air pressure and disconnect tool
from air supply when not in use, before changing accessories or when making
repairs.
3. Never direct air at yourself or anyone else.
4. Whipping hoses can cause severe injury, always check for damaged or loose
hoses and fittings.
5. Cold air should be directed away from hands.
6. Whenever universal twist couplings (claw couplings) are used, lock pins shall
be installed and whip-check safety cables shall be used to safeguard against
possible hose to hose or hose to tool connection failure.
7. Do not exceed maximum air pressure stated on tool.
8. Never carry an air tool by the hose.
Safety Instructions
GLOSSARY OF TERMS AND SYMBOLS:
- Product complies with requirements set forth by
the relevant European directives.
- Read manual prior to using this equipment.
- Eye protection is required while using this
equipment.
- Hearing protection is required while using this
equipment.
Notes: are reminders of required procedures.
Bold, Italic type, and underline: emphasize a specific
instruction.
WARNINGS: Must be understood to avoid
severe personal injury.
CAUTIONS: Show conditions that will damage
equipment or structure.

4
2015 series Pneudraulic Installation Tools (HK958)
Description
The 2015 series tools are lightweight, high-speed production
tools that install 3/32” and 1/4” nail-type blind fasteners. An
integral nose assembly increases reliability and simplifies use of
this tool.
The 2015V model has a Tubing & Slide Assembly - a ribbed
“ON/OFF” vacuum-regulating slider that enhances the tool
capabilities by expelling broken pintails into the pintail
collector, and holding fasteners firmly in the nose assembly,
with the tool in any position.
When the tool is not in use, the OFF position (slider forward)
will prevent air loss. See Figure 5 for the location of this
assembly (pictured in the ON position) on the tool.
The pulling action of the pull piston is provided by a
pneumatic-hydraulic (pneudraulic) intensifier system that
is powered by 90 psi (6.2 bar) air pressure. The air inlet is
equipped with a connector with 1/4”-18 female pipe threads to
accept your air hose or quick-connect fitting. The piston return
stroke is spring actuated.
Specifications
STROKE: 0.683 in (1.73 cm)
WEIGHT: 2015: 4.9 lbs (2.22 kg)
2015B & 2015V: 5.2 lbs (2.36 kg)
MAX AIR PRESSURE: 90 psi (6.2 bar)
MAX FLOW RATE: 4.3 scfm (121.76 l/min)
POWER SOURCE: 90 psi (6.2 bar) maximum shop air
MAX OPERATING TEMP: 125° F (51.7° C)
PULL CAPACITY: 2670 lbs @ 90 psi
(11.88 kN @ 6.2 bar)
SPEED / CYCLES: 30 per minute
HOSE KITS: Use only genuine Huck Hose Kits rated @ 10,000
psi (689.5 bar) working pressure.
HYDRAULIC FLUID: Hydraulic fluid shall meet DEXRON®III,
DEXRON VI, MERCON®, Allison C-4 or equivalent Automatic
Transmission Fluid (ATF) specifications. Fire-resistant fluid may
be used if it is an ester-based fluid such as Quintolubric®HFD
or equivalent. Water-based fluid shall NOT be used as serious
damage to equipment will occur.
DEXRON is a registered trademark of General Motors Corp.
MERCON is a registered trademark of Ford Motor Corp.
Quintolubric is a registered trademark of Quaker Chemical Corp.
PULL STROKE:
When tool is connected to the air supply, the
air pressure holds the throttle valve in the up
(RETURN) position; air pressure is directed
to the top of the air piston, keeping it down.
When the trigger is pressed, the throttle
valve moves down to the PULL position, and
pressurized air is directed to the bottom of
the air piston, causing it to move upward.
The air above the air piston is exhausted and
directed through the center of the throttle
valve and out the bottom of the tool (through
the muffler). As the hydraulic piston rod
moves upward, a column of pressurized fluid
is forced into head, which moves the pull
piston rearward. The attached nose assembly
moves with the pull piston to start fastener
installation.
RETURN STROKE:
When fastener installation is completed, the
trigger is released. Air pressure, with the
assistance of a spring, sends the throttle valve
to the up (RETURN) position. Pressurized air
is re-directed to the top of the air piston (see
above), causing it and the hydraulic piston rod
to move downward. The air from below the
piston is exhausted through the bottom of the
tool. The piston and hydraulic piston rod move
downward, hydraulic pressure is reversed, and
the pull piston is returned forward.
Principle of Operation

5
2015 series Pneudraulic Installation Tools (HK958)
SpecificationS (continued)
4.8
(12.4)
4.8
(12.4)
12.0
(30.5)
12.0
(30.5)
Ø
3.4
(8.8)
Ø
3.4
(8.8)
Ø
0.7
(1.9)
Ø
0.7
(1.9)
0.8
(2.0)
0.8
(2.0)
3.4
(8.8)
1.1
(2.8)
3.4
(8.8)
2.6
(6.7)
2.6
(6.7)
1.0
(2.8)1.5
(4.0)
10°
1.2
(3.2)
2.4
(6.3)
Ø
11.4
(29.0)
11.4
(29.0)
1.5
(4.0)
2015B
2015
Models
2015 & 2015B
INCHES
(cm)

6
2015 series Pneudraulic Installation Tools (HK958)
SpecificationS (continued)
Ø
3.4
(8.8)
4.8
(12.4)
12.0
(30.5)
1.5
(4.0)
3.4
(8.8)
1.0
(2.8)
10°
2.6
(6.7)
12.1
(31.0)
2.4
(6.3)
1.2
(3.2)
Ø
Ø
0.8
(2.0)
0.7
(1.9)
Model
2015V
INCHES
(cm)

7
2015 series Pneudraulic Installation Tools (HK958)
preparation for uSe
The 2015 tools ship with a plug in the air inlet
connector. The connector has 1/4”-18 female pipe
threads to accept the air-hose tting. Huck recommends
quick-disconnect ttings and a 1/4” inside-diameter
air hose. The air supply should have a lter-regulator-
lubricator unit and access to 90 psi (6.2 bar), capable of
a ow rate of 2.9 CFM (170 l/m).
NOTE: Quick-disconnect ttings and air hoses are
not available for purchase from Huck International,
Inc. Huck includes an air hose (P/N 115436) to
facilitate immediate tool use.
1. Remove the shipping plug from air inlet connector
and add a few drops of an approved hydraulic uid.
2. Screw the quick-disconnect tting into the air inlet
connector.
3. Set the air pressure on the regulator to 90 psi (6.2
bar), and connect the air hose to the tool and the air
inlet connector.
4. Press and release the trigger a few times to cycle
the tool.
5. Disconnect the air hose from the tool, and remove
the retaining nut. Select the proper nose assembly
for the fastener being installed.
6. Connect the air hose to the tool and install fasteners
in a test plate of proper thickness with proper size
holes. Inspect the fasteners.
If the fasteners do not pass inspection, consult the
TroubleshooTing section to investigate possible causes.
Threadmate is a registered trademark of Parker Intangibles, LLC.
TEFLON is a registered trademark of E. I. du Pont de Nemours and
Company.
WARNING:
To avoid pinch points, be sure there is
adequate clearance for tool and operator’s
hands before proceeding. Tool moving
toward structure may crush hands or
ngers between tool and structure if
clearance is limited.
WARNING:
As applicable, do not use without
deectors or pintail bottles.
If deectors are removed or damaged,
separated pintails may eject forcibly from
rear of tool. Unshielded eyes, especially,
may be permanently injured. Other severe
injuries can be caused by ying pintails.
If there is any chance of a projectile-like
ejection, always point rear of tool in a
safe direction, or be sure there is some
structure that will stop ejecting pintails.
CAUTION: Do not use TEFLON®tape on
pipe threads. Tape can shred and break free
into uid lines, resulting in malfunctions.
Threadmate®is available in a 4oz. tube from
Huck (P/N 508517).

8
2015 series Pneudraulic Installation Tools (HK958)
operating inStructionS
Read all of these instructions in order to ensure the safe operation of this equipment.
This section details installing Huck Blind Fasteners.
Review all CAUTIONs and WARNINGs prior to installing
these fasteners. If the tool malfunctions, consult the
TroubleshooTing section before attempting any repairs.
NOTE: Reasonable care of tools by operators is
an important factor in maintaining efciency and
reducing downtime.
TO INSTALL A HUCK BLIND FASTENER:
1. Place a fastener in the workpiece or in the end of
the nose assembly.
NOTE: The tool or nose assembly must be
held against, and at a right angle (90°) to, the
workpiece.
2. Press and hold the trigger until the fastener is
installed and the pintail breaks.
3. Release the trigger; the tool will perform its
RETURN stroke.
The pressure is re-directed; the piston moves forward;
and the tool is pushed off the fastener and ready for the
next installation cycle.
CAUTION:
• BOM blind fasteners will jam in the
nose assembly if they are pulled when
not in a workpiece.
• To avoid structural and tooI damage, be
sure there is sufcient clearance for the
nose assembly at full stroke.
• Remove excess gap from between
the sheets to permit proper fastener
installation and prevent jaw damage.
ALL jaw teeth must engage the pintail
to avoid damaging the teeth.
CAUTION: Ensure the tool has been
properly re-assembled prior to use.
WARNINGS:
• Wear approved eye and hearing
protection.
• Ensure adequate clearance for
operator’s hands before installing
fasteners.
• Be sure that pintail deector is attached
to the tool and directed away from all
personnel.
• Do not pull on a pin without placing a
fastener in a workpiece. Make sure that
the collar chamfer is out, toward the
tool. Pins eject with great velocity when
pintails break off or teeth/grooves strip,
which could cause serious injury.
WARNINGS:
Inspect tools for damage and wear before
using. Do not use if damaged or worn;
serious personal injury may occur.
Pulling a pin without a collar, or with collar
chamfer against workpiece, may result in
the pin becoming a high-speed projectile
when the pin grooves are stripped or the
pintail breaks off. Serious personal injury
may occur to anyone in the pin’s “ight
path.” This includes pin ricochet.
Broken pintails eject from the deector
with speed and force. To reduce the risk of
serious personal injury, be sure the pintail
deector is properly attached and directed
away from all personnel.
Pintail bottles must always be used with
models 2015B and 2015V. To reduce the risk
of serious personal injury, do not operate
tool with a damaged pintail deector or
pintail bottle; replace these parts if they are
damaged.

9
2015 series Pneudraulic Installation Tools (HK958)
GENERAL
The operating efciency of the tool is directly related to
the performance of the entire system. Regular inspection
and the immediate correction of minor problems will
keep the tool operating efciently and prevent downtime.
A schedule of “preventive” maintenance of the tool,
nose assembly, hoses, trigger and control cord, and
POWERIG®will ensure your tool’s proper operation and
extend its life.
NOTE: This Huck tool should be serviced only
by personnel who are thoroughly familiar with its
operation.
• Service the tool in a clean, well-lighted area. Take
special care to prevent contamination of pneumatic
and hydraulic systems.
• Have available all necessary hand tools (standard and
special), a brass drift and wood block, and a soft-jaw
vise. See KiTs & Accessories.
• Carefully handle all parts. Before reassembly,
examine them for damage and wear.
• Disassemble and assemble tool components in a
straight line. Do NOT bend, cock, twist, or apply
undue force.
• Have the appropriate Spare Parts Service Kit
(2015KIT or 2015VKIT) available when servicing
the tool; it includes important perishable parts. Other
components, as experience dictates, should also be
available. See KiTs & Accessories.
• Apply Loctite® 243 Threadlocker (Huck P/N 508567)
to gland threads. Apply Loctite®271-05 (Huck P/N
503657) to nuts and locknut (P/N 505420); torque to
25–30 ft.-lbs.
• Smear LUBRIPLATE® 130-AA (Huck P/N 502723) or
SUPER-O-LUBE® (Huck P/N 505476) on rings and
mating parts to ease assembly.
• Apply Parker Threadmate®, Loctite®567, or Slic-Tite®
(per manufacturer’s instructions) to male pipe threads
and quick-disconnect ttings.
For supplementary information, see TroubleshooTing,
and the DisAssembly and Assembly procedures in this
manual.
DAILY
• Huck recommends using a lter-regulator-lubricator
unit. If one is not being used, uncouple the air
disconnects and add a few drops of hydraulic uid or
a light-weight oil to the air inlet of the tool.
NOTE: If the tool is in continuous use, add a few
drops of uid every 2–3 hours.
• Before connecting an air hose to the tool, clear the air
lines of dirt and water.
• Check all hoses and couplings for damage and air
leaks; tighten or replace if necessary.
• Check the tool and nose assembly for damage and
air or hydraulic leaks; tighten, repair, or replace if
necessary.
• Inspect the tool, hoses, and POWERIG during
operation to detect abnormal heating, leaks, or
vibration.
• Clean nose assemblies in mineral spirits to clear jaws
and rinse metal chips and dirt. For a more thorough
cleaning, disassemble the nose assembly. Use a
pointed “pick” to remove imbedded particles from the
pull grooves of the jaws.
Clean all parts of any assembly with UNITIZEDTM
Jaws in mineral spirits or isopropyl alcohol only; do
not let jaws come in contact with other solvents.
Do not let jaws soak; dry them immediately after
cleaning. Huck recommends drying other parts before
re-assembling.
WEEKLY
• Disassemble, clean, and re-assemble nose assembly
in accordance with applicable instructions.
• Check the tool and all connecting parts for damage
and uid/air leaks; tighten or replace if necessary.
Loctite is a registered trademark of Henkel Corporation, U.S.A.
LUBRIPLATE is a registered trademark of Fiske Brothers Rening
Co.
SUPER-O-LUBE is a registered trademark of Parker Hannin Corp.
Threadmate is a registered trademark of Parker Intangibles, LLC.
E Z BREAK is a trademark of the LA-CO Industries Inc.
Maintenance
CAUTION: Replace all seals, wipers, and
rings when the tool is disassembled
for any reason, and at regular intervals,
depending on severity and duration of use.
CAUTION: Damaged jaw teeth, or debris
packed between teeth, will result in fastener
not being installed or being improperly
installed.
CAUTION: Do not use TEFLON®tape on
pipe threads. Tape can shred and break free
into uid lines, resulting in malfunctions.
Threadmate®is available in a 4oz. tube from
Huck (P/N 508517).

10
2015 series Pneudraulic Installation Tools (HK958)
diSaSSeMbly
This procedure is for complete disassembly of the tool.
Disassemble only those components necessary to
replace damaged O-rings, Quad-rings, Back-up rings,
and worn or damaged components. For component
identication, see Figures 4–7.
1. Disconnect the tool from the air source.
2. Remove air hose from cylinder.
3. Unscrew the retaining nut and remove the nose
assembly. (Follow the instructions on the Nose
Assembly Data Sheet.)
4. Unscrew the bleed plug, including O-ring. Drain
the uid into a container. The tool can be cycled to
clear more completely. Discard the uid.
5. Model 2015: Pull the pintail deector off end cap.
6. Remove the throttle arm pivot screw and lift out the
throttle arm. Disconnect the ball end of the cable
assembly from the throttle arm. Remove the spring
from the throttle valve. (Figure 7)
7. Secure the tool upside-down in a soft-jaw vise; use
a 1/8” hex key to remove three button-head screws
from the mufer end cap.
8. Remove the mufer end cap and bottom exhaust
gasket. Remove the mufer from the end cap. Tap
the cylinder head down into the cylinder assembly
and remove the retaining ring.
9. Screw the button-head screws into the cylinder
head, and carefully pry on them to remove the
cylinder head. (Figure 7)
10. Use pliers to grip the self-locking nut and pull out
the air piston and rod assembly from the handle and
cylinder assemblies.
NOTE: Do NOT disassemble the air piston and
rod assembly. If the locknut loosens, apply
Loctite® 271-05; tighten to 25–30 ft.-lbs.
11. Remove bumper from gland sssembly. Unscrew the
gland with a 1-3/8” socket wrench and extension.
12. Remove the retaining ring from the gland. Pull out
the spacer and Polyseal.
13. Model 2013V: (Figure 5) Press the ring on the tube
connector downward to release the tube.
14. Lift cylinder assembly from the handle assembly.
15. Turn over the handle assembly and drain uid into
container. Discard the uid.
16. Pull the throttle valve out of the cylinder assembly.
NOTE: The throttle valve bushings do not
typically require service.
17. Press out lower and upper bushings. Use square-
ended brass rods at least six inches in length. With
a proper diameter rod, press out lower bushing, and
then press out upper bushing using a larger rod.
18. Secure the handle in a vise, and continue with the
“gland assembly removal” procedure.
Model 2015: (Figure 4) Remove the end cap with
a 15/16” open-end wrench. Remove the spring,
washer, and wiper seal.
REMOVING THE PISTON AND FRONT GLAND
ASSEMBLIES (Figures 4 & 5)
a. Thread Polyseal Insertion Tool (P/N 121694-202)
into the handle/head. Slide spacer (P/N 123112-3)
onto the piston. Thread the Piston Assembly Tool
(P/N 123111-4) onto the piston.
b. Use a brass drift to push out the piston from the
front. Allow clearance, with stand-off, as the piston
leaves the tool.
c. Remove the Piston Assembly Tool, spacer, and
Polyseal Insertion Tool.
NOTE: Inspect the piston for wear, scoring, and
damage. Replace if necessary.
d. Unscrew the adapter (P/N 125132) with a
wrench, and inspect all seals and parts; replace if
necessary. (Figure 4)
e. Remove the trigger cable assembly by driving out
the pin with a punch. Remove the trigger pin to
disconnect the cable from the trigger.
WARNING: Disconnect the air hose from
the tool before:
• Removing or attaching the nose assembly
• Performing maintenance on the tool or
nose assembly
• Replacing tool components
If the tool is connected to a pressurized
cylinder, it could activate; serious injury
could result.
CAUTION: Always use a soft-jaw vise to
avoid damaging the tool.
CAUTION: Do NOT scratch, nick, or ding
piston rod. This will cause permanent
hydraulic leakage.
CAUTION: The bushings in the cylinder
must be replaced only if new throttle valve
seals cannot correct an air leak.
Send the unit to an authorized repair
center to have the bushings replaced.
CAUTION: If piston and gland assembly
seals must be reused: during disassembly,
install the Polyseal Insertion Tool (P/N
121694-202) in the rear of the handle/head
to prevent damaging the seals.

11
2015 series Pneudraulic Installation Tools (HK958)
diSaSSeMbly (continued)
1
5
67
8
2
3
4
figure 1
1. Secure the head/handle in a vise.
Remove the vacuum tube from the
cylinder. (2015V only)
2. Rotate the pintail bottle until the
retaining-ring holes are visible. Reach
through the bottle window with 0100
TRUARC pliers (P/N 502857) and
remove the retaining ring and the
washer.
3. Remove the pintail bottle.
4. Remove the bottle adapter and
vacuum ON/OFF slide (2015V only).
5. Remove the end cap assembly and
spring.
6. Remove the washer and O-ring from
the spring side of the end cap.
7. Remove the retaining ring on the
bottle side of the end cap. Remove
the spacer, wiper seal, washer, and
O-ring.
8. Remove the O-rings from the ON/OFF
slide. (2015V only)
Special diSaSSeMbly inStructionS for 2015b &2015V

12
2015 series Pneudraulic Installation Tools (HK958)
aSSeMbly
This procedure is for the assembly of the tool. For
component identication, see Figures 4–7.
BEFORE RE-ASSEMBLING THE TOOL:
• Clean components with mineral spirits or a similar
solvent. Inspect for wear/damage and replace as
necessary.
• Use the O-rings, Quad-rings, and Back-up rings
from the appropriate Huck Spare Parts Service Kit
(P/N 2015KIT or 2015VKIT). When assembling the
tool, take care not to damage O-rings, Quad-rings,
Back-up rings.
Smear LUBRIPLATE® 130-AA (Huck P/N 502723)
or SUPER-O-LUBE® (Huck P/N 505476) on rings
and mating parts to ease assembly.
IF THE BUSHINGS WERE REMOVED FROM THE
CYLINDER:
• Use an arbor press and apply Loctite®#609,
(503377) on the bushings before pressing them into
the cylinder. Place the chamfered end of the upper
bushing in the top of the cylinder. Carefully press
the bushing squarely into the cylinder. Repeat the
procedure for the lower bushing.
TO RE-ASSEMBLE THE TOOL:
1. Assemble the gland assembly. Replace the
Polyseal, spacer, and retaining ring. Install the
adapter into the cylinder handle/head.
NOTE: Note the orientation of the Polyseal in the
Assembly Drawings in this manual.
2. Thread the Polyseal Insertion Tool (P/N 121694-
202) into the handle assembly.
3. Thread the Piston Assembly Tool (P/N 123111-
4), onto the piston assembly. Push the front gland
assembly (except for wiper seal) onto the piston.
Then slide the wiper seal onto the piston.
4. Use a press, or a soft mallet and wood or brass
drift, and gently push the assembled components
into the handle assembly from the rear.
5. Remove the Piston Assembly Tool and Polyseal
Insertion Tool.
6. Model 2015: (Figure 4) Assemble the spring,
spacer, rear wiper seal, and end cap into handle/
head.
Models 2015B & 2015V: Reverse the instructions
in speciAl DisAssembly insTrucTions for 2015b AnD
2015V in the DisAssembly section.
7. Position cable assembly in trigger slot and push
the dowel pin through holes in trigger and cable
assembly. Position assembled trigger in handle and
drive roll pin through holes in handle and trigger.
8. Secure the handle assembly upside-down in a soft-
jaw vise. Place the inverted cylinder assembly on
the base of the handle. The cylinder pin maintains
the orientation.
9. Apply Loctite®243™to the threads of the gland
assembly. Screw the gland assembly into the
handle assembly. Use a 1-3/8” socket wrench to
tighten and torque to 36–66 ft.-lbs.
10. Push the bumper rmly over the gland. (The slots
must face the bottom of the tool.)
11. Clean the piston rod threads and apply Loctite®
243™. Carefully press the assembled air piston and
piston rod into the cylinder just enough to allow
installation of the cylinder head assembly.
12. Secure the head upside-down in a vise. Push the
cylinder head squarely into the cylinder, taking care
not to damage O-ring. Install the retaining ring; align
the screw holes with the mufer end cap. (Figure 6)
13. Position mufer in the center of the cylinder head.
Position the gasket on the cylinder assembly, taking
care to note the direction of the lip in Figure 6.
14. Carefully position the mufer end cap on the
cylinder, making sure that it is properly positioned in
the recess of the bottom plate. Secure the mufer
end cap with the three button head screws using a
1/8” hex key.
15. Place the tool upright on a level surface. Drop the
spring into the throttle valve bore in the cylinder,
and push the throttle valve assembly into the
cylinder.
16. Place the ball end of the cable assembly in the
end of throttle arm. Slide throttle arm into slot on
cylinder.
17. Insert the pivot screw into the cylinder to retain the
throttle arm.
18. Screw anvil insert into anvil holder. (Figures 4 & 5)
19. Assemble the collet with all necessary components,
and screw the assembled collet onto the piston rod;
tighten securely.
20. Screw the anvil holder into the adapter.
The tool is now assembled and must be lled with
hydraulic uid prior to use. See the fill AnD bleeD
section. NOTE: Install the bleed plug and O-ring
assembly after that process.
Loctite is a registered trademark of Henkel Corporation, U.S.A.
LUBRIPLATE is a registered trademark of Fiske Brothers Rening
Co.
SUPER-O-LUBE is a registered trademark of Parker Hannin Corp.
CAUTION: Always replace all seals, wipers
and rings of disassembled components;
these parts wear out over time.
Replacement minimizes problems.

13
2015 series Pneudraulic Installation Tools (HK958)
fill and bleed
This section documents the “bleed-&-ll” procedure. For
component identication, see Figures 2–2B.
REQUIRED EQUIPMENT
• DEXRON® III or equivalent ATF (See specificATions
for more information.)
• Shop air-line with 90 psi (6.2 bar) max.
• Air regulator
• Fill Bottle Assembly (P/N 120337, included with
tool)
• Large at-blade screwdriver
• Nose assembly or optional stall nut (P/N 125340)
and stop (P/N 125341)
NOTE: The stall nut is used to load the tool
during bleeding and for measuring tool stroke.
See KiTs & Accessories.
• Fasteners (optional)
PREPARATION
• Install air regulator in
the air-line and set
the pressure to 20–40
psi (1.4–2.8 bar).
• Add an approved
hydraulic uid to the
ll point of the ll
bottle. (Figure 2)
TO BLEED AND FILL THE TOOL:
1. Connect tool to the air supply to seat the air piston
at the bottom of the air cylinder; then disconnect.
Lay tool on its side with ll port facing up.
2. Remove the bleed plug from the ll port. Screw the
ll bottle into the ll port. (Figure 2A)
3. Connect tool to the air supply and stand it upright.
4. Hold the ll bottle at a right angle (90°) to the tool
(Figure 2B); cycle the tool 20–30 times; watch for air
bubbles escaping into the bottle.
NOTE: Rock the tool to free trapped air. Do not
allow air to re-enter the tool. Always hold the ll
bottle as shown in order to prevent drawing in
air.
4. When air bubbles stop accumulating in the ll
bottle, stop cycling the tool. When the trigger is
released, the pull
piston returns to the
idle (full forward)
position. Disconnect
the tool from the air
supply.
5. Lay the tool on its
side, and remove
the ll bottle.
Carefully add uid
to “top off” the uid
in the ll port. Insert
and tighten the
bleed plug.
6. Connect the tool to the air supply to check the tool
stroke. NOTE: There are two procedures for
measuring tool stroke: with and without a stall
nut. See meAsuring Tool sTroKe.
If the stroke is less
than recommended
minimum, remove
the bleed plug and
add uid. Then
re-insert the plug
and re-check the
stroke.
If the uid level
drops, repeat steps
until the uid level
does not drop when
the tool is cycled.
NOTE: This usually requires 3 or 4 repetitions.
When the tool stroke is as recommended:
a. Increase air pressure according to specications.
b. Install two fasteners to check function and
installation in a single stroke (or cycle the tool with
the stall nut fully threaded onto the piston).
c. Re-measure the stroke.
Repeat this process until stroke is at minimum
requirement.
continued...
WARNING: Avoid contact with hydraulic
uid. Hydraulic uid must be disposed of
in accordance with local regulations. See
MSDS for hydraulic uid shipped with tool.


figure 2a
CAUTION: Purge all uid from the tool
before relling. The tool stroke will be
diminished if the uid is aerated.
figure 2b
WARNING: Air pressure must be at 20–40
psi (1.4–2.8 bar) to prevent possible injury
from high-pressure spray.
Before cycling the tool, make sure the:
• bleed plug is tightened in the ll port, or
• ll bottle is securely attached to the tool
(if the bleed plug has been removed), or
• ll port is held over a container. (Figure
2A)
120336
Fill Bole
Fill Point
120004
Cap
120337 Fill Bole Assy
figure 2

14
2015 series Pneudraulic Installation Tools (HK958)
BLEED PROCEDURE FOR PARTIALLY FILLED
TOOL IN FIELD USE
1. Disconnect the tool from the air supply. Lay tool on
its side with ll port facing up.
2. Remove the bleed plug from the ll port, and
position ll port over suitable container. (Figure 2A)
3. Connect the tool to the air supply and cycle it
several times to drain uid, air, and foam.
4. Screw the ll bottle into the ll port.
5. Connect the tool to the air supply, with the pressure
set at 20–40 psi (1.4–2.8 bar).
6. Stand tool upright. While slowly actuating the trigger
(20–30 cycles), attach the ll bottle at a right angle
(90°) to the tool (Figure 2B) and watch for escaping
air bubbles.
7. When air bubbles stop accumulating in the ll bottle,
stop cycling the tool. When the trigger is released,
the pull piston returns to the idle (full forward)
position. Disconnect the tool from the air supply.
8. Lay the tool on its side, and remove the ll bottle.
Carefully add uid to “top off” the uid in the ll port.
Insert and tighten the bleed plug.
9. Connect the tool to the air supply to check the tool
stroke.
NOTE: There are two procedures for measuring
tool stroke: with and without a stall nut. See
meAsuring Tool sTroKe.
If the tool stroke is less than the recommended
minimum length, remove the bleed plug and add uid.
Then re-insert the bleed plug and re-check the stroke.
The uid level may drop slightly. If so, repeat these steps
until the uid level does not drop when the tool is cycled.
NOTE: This usually requires 3 or 4 repetitions.
When the tool stroke is as recommended:
a. Increase the air pressure according to the tool
specication.
b. Install two fasteners to check function and
installation in a single stroke (or cycle the tool with
the stall nut fully threaded onto the piston).
c. Re-measure the stroke.
Repeat this process until the tool stroke is at the
recommended minimum length.
fill and bleed (continued)
WARNING: Air pressure must be at 20–40
psi (1.4–2.8 bar) to prevent possible injury
from high-pressure spray.
Before cycling the tool, make sure the:
• bleed plug is tightened in the ll port, or
• ll bottle is securely attached to the tool
(if the bleed plug has been removed), or
• ll port is held over a container. (Figure
2A)

15
2015 series Pneudraulic Installation Tools (HK958)
MeaSuring tool Stroke
figure 3b
WITH A STALL NUT
1. Disconnect the tool from the air-line and remove the
nose assembly.
2. Reconnect the tool to the air-line. Press and hold
the trigger to cycle the piston fully to the rear of
the tool (the end of the PULL stroke). Thread the
stall nut onto the piston until it contacts the adapter
bushing.
3. Release the trigger. The stall nut wilI move forward
with the piston. (Figure 3a)
4. Measure the Xdimension. (This is the tool stroke.)
If the stroke is less than 0.683 in (1.73 cm), follow the
steps at the end of the fill AnD bleeD procedure.
NOTE: Remove the Nose Assembly from the tool for both of the following procedures.
figure 3a
WITHOUT A STALL NUT
1. Disconnect the tool from the air-line and remove the
nose assembly.
2. Reconnect the tool to the air-line. Press and hold
the trigger to cycle the piston fully forward (the end
of the RETURN stroke). Measure and record the X
dimension. (Figure 3b)
3. Press and hold the trigger; the piston is now fully
to the rear of the tool (the end of the PULL stroke).
Measure and record the Y dimension. (Figure 3b)
4. Subtract Xfrom Y.
Stroke = Y-X (This is the tool stroke.)
If the stroke is less than 0.683 in (1.73 cm), follow the
steps at the end of the fill AnD bleeD procedure.

16
2015 series Pneudraulic Installation Tools (HK958)
Head/Handle 2015 &2015b
125156 Piston Assy
* Note orientaon of Wipers
and Polyseals.
NOTE: When replacing the
Handle Assembly, or if scker
590240-1 becomes damaged,
worn, missing, or unreadable,
it MUST be ordered and
replaced as shown.
NOTES:
Piston Assembly 125156 includes:
---- Piston (not sold separately)
506160 Polyseal
506653 Retaining Ring
506654 Washer
Front Gland Assembly 123775 includes:
---- Front Gland (not sold separately)
122432 Gland Cap
505818 Polyseal
500816 O-Ring
501110 Back-up Ring
505817 Wiper
2
2
2
2
2
2
figure 4

17
2015 series Pneudraulic Installation Tools (HK958)
Head/Handle 2015V
NOTES: Piston Assembly 125156-1 includes: ---- Piston (not sold separately) 506160 Polyseal 506653 Retaining Ring 506654 Washer Front Gland Assembly 123775 includes: ---- Front Gland (not sold separately) 122432 Gland Cap 505818 Polyseal 500816 O-Ring 501110 Back-up Ring 505817 Wiper
125156-1 Piston Assy
2
2
2
2
2
2
When replacing the Handle Assembly, or if scker 590240-1 becomes worn, damaged, missing, or unreadable, it MUST be ordered and placed as shown.
124245 Tubing & Slide Assembly
figure 5

18
2015 series Pneudraulic Installation Tools (HK958)
tool baSe (all ModelS)
130727
Bottom Plate
**
*
NOTES:
Cylinder Head Assembly 123778-1 includes:
---- Cylinder Head (not sold separately)
500864 O-Ring
Throle Valve Assembly 125472-2 includes:
---- Throle Valve (not sold separately)
507396 O-Ring (qty. 3)
* Note orientaon of Polyseal.
** When replacing the Cylinder Assembly,
these sckers MUST be ordered and placed
as shown.
Detail of scker locaons
Tighten and torque to 36–66 .-lbs.
figure 6
figure 7

19
2015 series Pneudraulic Installation Tools (HK958)
tool Head, top View
104293
Bleed Plug Assembly
506576
Plug & Gasket Assembly
125116 Guard 505438 O-ring
figure 8

20
2015 series Pneudraulic Installation Tools (HK958)
piSton and front gland aSSeMblieS
figure 9
piSton and front gland
aSSeMblieS - reMoVal
figure 10
piSton and front gland
aSSeMblieS - inStallation
