Argos 626/9728 User manual

Romantic Coffee Table
Assembly Instructions - Please keep for future reference 626/9728
Dimensions
Width - 80cm
Depth - 45cm
Height - 45cm
Issue 1 - Nov/20/16
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800

1
Safety and Care Advice
Important –Please read these instructions fully before starting assembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
the following pages.
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
• Parts of the assembly will be
easier with 2 people.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
• Regularly check and ensure
tightend properly.
Handy Hints

Components - Panels
Please check you have all the panels listed below
2
Legs x 4 (42.5 x 4cm)
2
Table Top (80 x 45cm)
1
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6400800
Frame shelf (75 x 40cm)
3

3
A
50mm Bolts x 8
B
Allen key x 1
C
Note:
may be supplied than are required.
16mm Flat washer x 8
D
Components - Fittings
10mm Spring washer x 8
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Phillips screwdriver
(medium& large)
Flatblade screwdriver
(medium)
Ruler/tape
measure
The screws length is measured from the head to the point (30mm screw shown).
E
20mm Pads x 4

4
Assembly Instructions
Step 1
Assembly legs
Attach Legs to
Table Top
Using bolts
spring washer and
flat washer .Tighten
with supplied allen key
Do not over tighten.
B
A
D
1
2
2
1
2
C
A
B
C
D
Step 2
Assembly frame shelf
Position frame shelf
into the legs
Using bolts
spring washer and
flat washer .Tighten
with supplied allen key
Do not over tighten.
B
A
23
C
D
3
D
C
A
B

5
Assembly Instructions
Step 3
Assembly legs
Position leg
to table top & frame shelf
Using bolts
spring washer and
flat washer .Tighten
with supplied allen key
Do not over tighten.
B
A
2
C
D
2
D
C
A
B
D
C
A
B
Step 4
Attach the pad
Remove cover paper on the
pad . Attach the pad
into under the legs.
With help stand the coffee
table upright.
E
E
E
Remove
E
