Argos Washington 02BS User manual

Dimensions
Assembly Instructions - Please keep for future reference
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
Height - 54.7cm
Depth - 37.3cm
Width - 43.8cm
Washington - 02BS
392/3342
427/1433
427/1433 WARM OAK
Issue 1 - 02/07/15
DR82534
392/3342 SMOKEY OAK
Important–Please read these instructions fully before starting assembly
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: [email protected] (quoting your original order number)

1
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
•
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
• Regularly check and ensure
that all bolts and fi ttings are
tightend properly.
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical
advice immediately.
Glue safety - Take care when using glue, please follow the advice below•
Important – Please read these instructions fully before starting assembly
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• Check you have all the
components and tools listed
on the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• We do not
recommend the
use of power drill/
drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
Safety and Care Advice

Please check you have all the panels listed below
Components - Panels
2
Left side
(37.1 x 51.3cm)
P2018
1Right side
(37.1 x 51.3cm)
P2093
2Foldy back
(42.9 x 44.9cm)
B03609
3
Top
(43.8 x 37.3cm)
P1830
4Bottom
(36.7 x 37cm)
P1831
5Drawer bottom x 2
(32.8 x 34.4cm)
BO3607
6
Drawer front x 2
(36.1 x 18.9cm)
P4648
7
Left drawer x 2
(35 x 14cm)
LA1614
8Drawer back x 2
(317 x 14cm)
LA1618
9Right drawer x 2
(35 x 14cm)
LA1615
10
For damaged or missing parts, please visit:
www.argos-support.co.uk or email: [email protected]
ID-hole

For damaged or missing parts, please visit:
www.argos-support.co.uk or email: [email protected]
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
0102030405060708090 100 110 120 130 140 150
0123456
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
The screwslength ismeasured from thehead to the point (30mm screw shown).
3
Locking screw x 12 (5x24mm)
FK1011
12mm
Locking nut x 4 (12x10mm)
FK1010
15mm
Large locking nut x 8 (15x12mm)
FK1012
Screw x 28 (3x15mm)
FK1311
Fixing screw drawer x 24 (6.3x10mm)
FK1301
Screw x 4 (4x25mm)
FK1985
Nail x 12
FK1515
Drawer handle x 2
GR1855
Peg, brown x 1
FK1234
Nail holder x 1
FK1415
Glue x 1
FA1510
Runner left part A x 2
PM1515 LA
Runner left part B x 2
PM1515 LB
Runner right part A x 2
PM1515 RA
Runner right part B x 2
PM1515 RB
Drawer base support x 4
FK1250
P
O
NM
L
KJ
IHG
F
E
D
CB
A

Assembly Instructions
4
Step 1
Finished
front edge
a:
b:
a: Screw 24mm locking
screw Ainto left side 1.
Note: Insert 24mm locking
screw Aas far as shown.
Do not over tighten.
Insert large locking nuts C
into left side 1.
Make sure the ‘arrow’ on
locking nuts Cpoints
towards the hole in the
edge of left side 1.
Finished
front edge
Attaching runners
b: Fix runner left part A M
on left side 1as shown
usesing fixing screw
drawer Dinto left side 1.
Note: look carreful for the
right postion.
Insert 15mm screw E
as shown into left side 1
to fix runner left part A M.
A
A
C
C
A
C
D D
E E E
M
M
M
D
D
D
D
1
1

Assembly Instructions
5
Step 2 a:
b:
a: Screw 24mm locking
screw Ainto right side 2.
Note: Insert 24mm locking
screw Aas far as shown.
Do not over tighten.
Insert large locking nuts C
into right side 2.
Make sure the ‘arrow’ on
locking nuts Cpoints
towards the hole in the
edge of right side 2.
Attaching runners
b: Fix runner right part A O
on right side 2as shown
usesing fixing screw
drawer Dinto right side 2.
Note: look carreful for the
right postion.
Insert 15mm screw E
as shown into right side 2
to fix runner right part A O.
Finished
front edge
Finished
front edge
O
O
O
D
DD
D
A
A
C
C
A
C
D D
E E E
2
ID-hole

Assembly Instructions
6
Step 3
Step 4
Step 5
Finished
front edge
Finished
front edge
Finished
front edge
Attaching panels
Position left side 1and
right side 2onto bottom
5.
Use a screwdriver to turn
locking nuts Cclockwise
to lock.
Insert large locking nuts C
into bottom 5.
Make sure the ‘arrow’ on
locking nuts Cpoints
towards the hole in the
edge of bottom 5.
Screw 24mm locking
screw Ainto top 4.
Note: Insert 24mm locking
screw Aas far as shown.
Do not over tighten.
A
A
A
A
A
C
C
C
C
C
I
4
5
5
2
1

Assembly Instructions
7
Step 6
Step 7
Fitting back panel
Attach foldy back 3to the
back with the coloured
surface facing the inside
using nails G.
Use nail holder Kto hold
the nails Gvertical and at
correct distance as you
secure the foldy back 3.
Nails Gshould be spaced
about 150mm apart.
Attaching panels
Position top 4onto left
side 1and right side 2.
Use a screwdriver to turn
locking nuts Cclockwise
to lock.
Important:
Furniture MUST
be ‘square’ when
back is attached.
G
K
G
G
G
G
G
K
Finished
front edge
C
1
25
4
3
25

Assembly Instructions
8
Step 8
Step 9
Screw 24mm locking
screw Ainto drawer front
7.
Note: Insert 24mm locking
screw Aas far as shown.
Do not over tighten.
Preparing drawer
Insert locking nuts Binto
left drawer side 8and
right drawer side 0.
Make sure the ‘arrow’ on
locking nuts Bpoints
towards the hole in the
edge of 8and 0.
Put drop of glue Qinto the
3 holes of left drawer side
8and right drawer side 0.
Attach left drawer side 8
and right drawer side 0
onto drawer back 9.
Insert drawer bottom 6.
2x
2x
A
A
A
B
B
B
L
L
L
8
9
10
6
7

Assembly Instructions
a: Turn over drawer.
Fix runner left part B N
on left drawer side 8as
shown using screw E.
Fix runner right part B P
on right drawer side 0as
shown using screw E.
b: Fix runner left part B N
and runner right part B P
using screw E.
Slide drawer base support
Jin corner as shown and
fix them, using the attached
screw.
Position drawer front 7
onto drawer.
Use a screwdriver to turn
locking nuts Bclockwise
to lock.
Note: look carefully to the
positions of drawer front 7.
Fix drawer handle Honto
drawer front 7using
screw F.
2x
2x
2x
a:
b:
9
Step 10
Step 11
J
J
J
B
H
F
E
P
N
E
F
P
N
E
E
E
E
E
E
8
9
10
7
9
10
11
6
6
89
6
8

Assembly Instructions
Use peg Ito square your
furniture. Knock peg Iin,
as far as you require, under
the end of the side of the
forniture. Then snap off
flush with the side.
Inserting drawers
as shown.
For adjusting the drawers
see ‘adjustment’ on page
‘drawer adjustment’.
10
Step 12
Step 13
!
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos 03456 400 800
I
I
I
1
4
7
7

A Guide to - Drawer adjustment
11
Adjustment
Note: Each drawer can be
adjust for approximately
1mm up or down on each
site of the drawer.
Remove drawer, adjust the
wheel from runner left
part A and runner right part
A as shown.
Insert drawer.
Repeat above steps until
the desired result is
achieved.
0
+1 mm
-1 mm
Runner left part A x 2
M
Runner right part A x 2
O
