Argos 906/4023 User manual

Pair Floating Corner Shelves
Assembly Instructions - Please keep for future reference 906/4023
906/4047
Dimensions
Depth - 25cm
Width - 25cm
Height - 3.8cm
Important
Version 3 Date: 20/07/15
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please read these instructions fully before starting assembly

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
Handy Hints
• Warning: Maximum allowable
weight for this shelf is 2kgs.

2
Components - Panels
Note: The quantities below are the correct amount to complete the assembly. in some cases mor
may be supplied than are required.
Components - Fittings
ABC
Wall plug x 8
40mm Screw x 8 30 4xwercSmm
1Shelf x 2 (25 x 25cm) 2Support x 2 (15.2 x 14.8cm)
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Phillips screwdriver
(medium & large)
Small
hammer
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
The screws length is measured from the head to the point (30mm screw shown).
Pencil Gradienter
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6400800

3
Assembly Instructions
Step 1
a:
b:
c:
a: Take out Support
from the Shelf .
2
1
Wall mounting
wall
1
2
Note: Wall plugs supplied are
for solid wall only.
be used for your wall, seek
professional advice if in doubt.
wall
2
CA
2
Important:
When drilling
into walls always check
that there are no hidden
wires or pipes etc. Make
wall plugs supplied are
suitable for supporting the
tradesperson if you are
not sure.
sure that the screws and
b: Position Support in
the desired location and
the wall.
and remove Support .
2
2
l
X 4
c: Using a drill, predrill a
hole according to the
Support at the desired
hight.
Use the Wall plugs and
Support onto the wall.
2
2
C
A
Note:
the Support always
toward underside.
2
Deeper holes underside
Important:
please make sure the
arrowhead direction aways
toward underside.
Arrowhead underside
The deeper holes on

4
Assembly Instructions
Step 2
Assembly is complete.
Finished the unit
a: Insert the Shelf
1
.
1
2
b:
the Shelf onto the
Support .
B
1
2
a:
b:
wall
wall
Repeat with remaining
Shelf.
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
1
B
B
2
2

A Guide to -Wall Mounting & Fixings
Revision 2 - 7/10/09
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5:
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
responsibility of the installer.
