Argos 497/1630 User manual

Assembly Instructions - Please keep for future reference
Width - 117.2cm
2 Door 3 Drawer Sideboard
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 38.8cm
Height - 73.6cm
Rev A - 28.09.15
041 xx 6006
MADE IN
GREAT BRITAIN
497/1630

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top (117.2x38.8cm)
9990
Bottom (110.2x35.2cm)
9991
Left End Panel
(72x38.2m)
9992
Plinth (110.2x7.6cm)
9164
Right End Panel
(72x38.2cm)
9993
Left Door x 2
(63.6x35.9cm)
7293
Backpanel
(111.2x64.6cm)
7419 Left Divider
(62.7x35.2cm)
9994
Right Divider
(62.7x35.2cm)
9995
Shelf Panel x2
(35.5x33cm)
9997
Draw Front x3
(37.2x21cm)
9996
Drawer Bottom x3
(33.8x29.8cm)
2601
Left drawer side x3 (30x15cm)
Drawer back x3 (32.7x15cm)
Right drawer side x3 (30x15cm)
622xx7000
624xx7019
623xx7000
684xx6530
Trim x2
(72cm long)

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 16
Code 760001103
Metal dowel x 28
Code 760003004
ABC
E
Drill
Bradawl
D
Panel pin x 14
Code 760001012
18mm bolt x 10
Code 700002021
12mm screw x 8
Code 690001008
F
Hinge x 4
Code 652001120
H
Hingeplate x 4
Code 653006000
GI
J
Panel Pin Locator
Code 684004501
Small cam x 12
Code 760003005
Runner x 6
Code 760001040
L
Assembly Screw x4
Code 690001075
K
M
8mm screw x 12
Code 700003510
N
9mm bolt x 6
Code 690001078
O
PQ
Wooden dowel x 4
Code 770001006
Handle x 5
Code 644003511
Shelf stud x 8
Code 681003001
Panel Holder x 3
Code 680003505

Please check you have all the fittings listed below
Exploded View
4
622xx7000
623xx7000
9996
624xx7019
2601
9164
9991 9997
9997
9992
9993
7419
9994 9995
7293
7293
684xx6530
684xx6530
9990

Step 1
Assembly Instructions
5
B
x8
Note: Tighten metal
dowels up fully against
the panel.
Do not over tighten.
B
A
x4
Fitting dowels to top
panel.
Fitting cams to the
bottom panel
Step 2
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
A
A
A
A
9991
B
B
B
B
B
B
9990
B
B
Step 5
Step 3
A
A
A
A
Fitting cams to the
plinth panel.
A
x4
9164
Insert 8 metal dowels
into the top panel 9990
A
Insert 4 cams into the
bottom panel 9991
A
Insert 4 cams into the
plinth panel 9164

Step 5
Assembly Instructions
6
Fitting cams & dowels
to the end panels.
B
B
B
B
A
A
B
x8
A
x4
B
B
B
B
A
A
9992
Step 4
Fitting hingeplates to
the end panels.
Note: Ensure that the
hinge points towards the
grooved edge of the
panel.
G
x4
G
G
9992
G
G
9993
9993
a: Insert 2 hinges into
left end panel
G
9992
b: Insert 2 hinges into
right end panel
G
9993
a: Insert 4 metal dowels
and 2 cams into
left end panel
BA
9992
b: Insert 4 metal dowels
and 2 cams into
right end panel
BA
9993
A
B
A
B
Edge of panel

Step 6
Assembly Instructions
7
Step 7
Attaching runners to
the division panels.
Position the runner so
that the second hole
from the front of the
runner lines up with the
pre-drilled hole nearest
to the edge of the panel.
Use screws to secure
the runner.
Slide the runner forward
revealing the back of the
runner. The second hole
to the back of the runner
will now line up with
the second pre-drilled
hole.
M
Front of runner
Fitting cams and
wooden dowels to the
division panels.
a: Insert 2 wooden
dowels into the two
inner holes at the bottom
of panel . Insert
2 cams
O
K
x6
M
x12
9994
K
M
K
M
Front of Runner
Back of Runner
M
M
M
M
M
M
M
M
M
M
M
M
9995
9994
9995
A
x4
O
x4
A
A
A
AA
O
O
O
O
A
B
9995
b: Insert 2 wooden
dowels into the two
inner holes at the bottom
of panel . Insert
2 cams
O
A
9994

Assembly Instructions
8
Step 8
Attach hinges and
handles to 2 doors
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
b: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
Important:
H
H
Bradawl
F
F
c: Secure hinges to
doors using screws .
H
F
d: Secure handle to
doors using bolts
I
D
H
x4
D
x4
F
x8
I
x2
7293
7293
7293
7293
D
D
F
F
F
F
H
H
H
H
A
B
C
D
I
90
H
Correct
98
H
Incorrect
Repeat on the second
door
7293

Assembly Instructions
9
x12
A: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
Right hand side
623xx7000
622xx7000
623xx7000
A
C
Step 9
B: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
623xx7000
624xx7019
622xx7000
B
x12
B
Left hand side
622xx7000
C
C: Insert 4 metal dowels
into the the drawer
front .
9996
B
C
C
C
C
Left hand side
622xx7000
Right hand side
623xx7000
Drawer Back
624xx7019
B
B
B
B
9996
Drawer assembly

Assembly Instructions
10
Fitting the handles
to drawer front.
Drawer assembly
continued....
Secure the handle with
2 bolts .
D: Slide drawer bottom
into grooves in the left
and right drawer sides
and the drawer back.
E:Locate the metal
dowels (already inserted)
in the drawer front into the
small cams in the left and
right hand drawer sides.
Ensure drawer sides are
pressed against drawer
front.
Turn cams 180 degrees to
lock.
D
E
Step 10
x6
D
D
x3
I
I
SLIDE!
2601
Foil surface facing upwards.
Plain chipboard surface
to underside.
9996
I
9996
D
D
Repeat on all drawers.

Locate cams in panels
, and
onto dowels in top
panel .
Then lock.
B
A
Turn cam 180 degrees
to lock
A
11
Attach right hand end
panel, left hand
division and right
hand divsion to the top
panel
Assembly Instructions
Step 11
Attach bottom panel
to right hand end
panel
Step 12
9993 9995
Front grooved edge
9994
9993
9995
9990
Front finished edge
9994
9990
9993
9991
Locate cams in panel
onto dowels
in right hand end panel
.
Then lock.
B
A
Turn cam 180 degrees
to lock
A
9991
9993

12
Secure bottom panel
to left and right hand
divisions
Assembly Instructions
Step 13
Attach plinth to
right hand end panel
Step 14
Turn cam 180 degrees
to lock
A
L
L
L
Locate wooden dowels
already inserted in
divisions and
into holes in bottom
panel .
Now locate screw
through holes in bottom
panel and screw
into holes in divisions
. and .
O
9994
9991
L
9991
9994
L
L
L
L
9995
9991
9994
9995
9995
Locate cams in panel
onto dowels
in right hand end panel
.
Then lock.
B
A
9164
9993
9993
9164
x4
Cams to reverse

13
Assembly Instructions
Step 15
Locate backpanel
into grooves in left
and right hand end
panels and top panel
Step 16
Attach left hand end
to top, bottom and
plinth
Turn cam 180 degrees
to lock
A
Locate dowels in
left hand end panel
into cams
in bottom and
plinth .
Then lock.
A
B
9992
9164
9991
9992
9990
9991
9164
Locate cams in panel
onto dowels
in top panel .
Then lock.
B
A
9992
9990
Locate backpanel
into grooves in left hand
end and right hand
end slide the
backpanel into
groove in top .
7419
9993
9992
7419
9990
Important:
2 people required
9990
7419
9992
9993
Important:
You do not have
to turn your
unit round it is
shown this way
just to show how
backpanel is
located.
Plain chipboard
surface

14
Lay unit down to
square unit up
Assembly Instructions
Step 17
Step 18
DIAG 1
DIAG 2
DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
Measure to external corners
Ensure a tape measure
is used to square up
unit! YY
YY
XX
Important:
Fittings you will need for this step:
(x1)
E
F
(x14)
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
9160
7397
Warning:
2 people to lift.
Lift with care.
XX
9161
E
7419
Secure backpanel
to bottom panel.
E
F
Secure backpanel
to bottom panel and
divisions using panel
pins .
Use the panel pin guide
when locating the
panel pins . This will
hold the panel pins
vertical and ensure the
correct distance from the
edge. You cannot use
panel pin guide when
securing backpanel to
divisions.
E
7419
7398
E
F
7398
E
E
50mm 50mm
365mm 365mm

Assembly Instructions
Step 19
15
Step 20
7419
Q
x3
Add stability blocks.
Slide the thin point of the
stability blocks
between the back panel
and the grooves.
Once inserted fully,
tighten the screws in the
stability blocks.
Q
7419
Q
Q
Q
Q
Fittings you will need for this step:
Turn unit over.
Remove protective film
from silver trim.
Locate the notch on
silver trim into
groove on left and
right ends.
Ensure the silver
trims are positioned
correctly.
To insert silver trims
use a hammer, place a
cardboard packing piece
between the hammer
and silver trims to
protect the silver
trims.
Attach silver trim
9992
9993
Warning:
2 people to lift.
Lift with care. 9992
9993
(x2)
Silver Trims

Assembly Instructions
16
Step 21
For this step we
recommend you follow
the helpful hints page.
2nd Hole
Detailed View
(x6)
N
N
Lift unit up and
locate drawers
Warning:
2 people to lift.
Lift with care.

Assembly Instructions
17
Step 21.....cont
a: Pull sliding part of
drawer runners out
so they are fully
extended.
Locate drawers helpful
hints
K
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
d: Keeping screwdriver
in place push the drawer
in until the screwdriver
pushes against the
panel.
Remove the screwdriver.
e/f: Pull drawer out slowly
and line the front hole in the
drawer side with the 2nd
threaded hole in runner .
Holding runner and
drawer side together
insert bolts through the
drawer side and
into threaded hole in
runner .
N
J
Now repeat these
steps for the other
side of the drawer.
J
D
EF
AB
C
2nd Hole
H
2nd Hole
J
L
L
L
L
L
N
K
K
K
K
K
K

18
Locate shelf studs
Assembly Instructions
Step 22
Step 23
Push shelf studs
into panels , ,
and .
P
Locate shelves onto
shelf studs
9992 9993
9995
Locate shelves
onto shelf studs
P
9997
9994
P
9992
9993
9995
P
P
P
x8
9997
9997

Assembly Instructions
Step 24
19
a: With help, slot door
hinges onto hinge
plates .
Ensure screw on hinge
slides into the slot
on hingeplate .
See Diagrams 1,2 and 3.
Hanging doors
H
b: Tighten screw shown
to lock hinges in
position.
Repeat a and b for
opposite door.
See ‘Hinge adjustment’
in step 25 if the doors
need adjusting.
a:
b:
B
B
B
HH
H
G
G
G
H
G
Underside view
Ensure the underside of screw
B slides into slot on hingeplate.
Hinge correctly attached to
hingeplate.
Hinge incorrectly attached to
hingeplate.
Diagram 1
Diagram 2
Diagram 3
7293
H
9993
G
G
