Argos Curve 377/3585 User manual

Curve - Changer Top White
377/3585
Assembly Instructions
- Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
Important – Please read these instructions fully before starting assembly
Dimensions
Width - 76cm
Depth - 41,5cm
Height - 14cm
Issue 1 - 01/03/13

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
1
. Check you have all the
components and tools listed on
pages 2 and 3.
. Remove all fittings from the
plastic bags and separate them
into their groups.
. Keep children and animals
away from the work area, small
parts could choke if swallowed.
. Make sure you have enough
space to layout the parts before
starting.
. Do not stand or put weight on
the product, this could cause
damage.
. Assemble the item as close
to its final position (in the same
room) as possible.
. Assemble on a soft level
surface to avoid damaging the
unit or your floor.
. We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
. Parts of the assembly will be
easier with 2 people.
. Dispose of all packaging
carefully and responsibly.
This product contain
Natural timber; you may
notice some variation in the grain
and colour of different component
parts which is normal for furniture
produced using natural wood and
is not the result of any
manufacturing fault.
.
Care and maintenance
.
. Avoid placing the furniture in
direct sunlight as this will cause
the timber to prematurely age.
Use an appropriate furniture
polish for natural wood
furniture and a dry cloth to
clean the product.
. From time to time check
that there are no loose
screws on this unit.
. This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
1 - DO NOT LEAVE THE CHILD UNATTENDED
2 - THIS PRODUCT IS INTENDED FOR CHILDREN WITH A MAXIMUM WEIGHT OF 15KG.
3 - PERIODICALLY CHECK AND ENSURE THAT ALL COMPONENTS ARE IN THEIR PROPER POSITION, FREE FROM
DAMAGE, AND THAT ALL ASSEMBLY FITTINGS ARE TIGHT.
4 - DO NOT USE THE PRODUCT WHEN ANY PART IS BROKEN, TORN OR MISSING.
5 - DO NOT USE SUBSTITUTE PARTS. CONTACT THE RETAILER FOR REPLACEMENT PARTS.
6 - BE AWARE OF THE RISK OF OPEN FIRES AND OTHER SOURCES OF STRONG HEAT, SUCH AS ELETRIC BAR FIRES,
GAS FIRES ETC. IN THE NEAR VICINITY OF THE CHANGING UNIT.
7 - PLEASE ENSURE THAT THE CHANGING PAD USED DOES NOT EXCEED
73,0 X39,5 X 8,5 CM AND FITS WITHIN THE
BARRIERS WITHOUT FOLDING.
EN 12221-1:2008
Note: if required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Warning !

Components - Panels
Please check you have all the panels listed below
2
01
02
03
04
Base panel (73 x 39.5cm)
Back panel (73 x 13cm)
Right side panel (41,8 x 11cm)
Left side panel (41,8 x 11cm)

3
2m
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Small
hammer
Ruler/tape
measure
A
8,0 x 30mm Wooden dowel X 4
If you have damaged or missing components,
call the Customer Helpline: 08456 400 800
BC
Allen key X 1
7,0 x 50mm Bolt X 6
D
G
1/4" x 40mm Bolt X 2
E
White strap 200mm X 1
F
3,0 x 12mm Screw X 2
Washer X 2

Assembly InstructionsAssembly InstructionsAssembly Instructions
Step 2
Step 1
Assembly Instructions
4
A
A
B
C
C
C
B
B
A
A
A
A
A
02
02
03
01
01
03
C
B
+
+
Insert wooden dowels
into back panel as
shown.
Fix right side panel to
base panel using bolts
and allen key
Make sure countersunk
hole is facing up!

Assembly Instructions
Step 3
Step 4
5
02
02
03
04
B
B
C
C
02
04
03
Attach back panel to the
right side panel using
bolt and allen key .
The warning label should
face inwards.
Attach left side panel
using bolts and allen
key as shown.
C
B
+
+
+
+
C
C
C
C
B
B
B
B
C
B

Assembly Instructions
Step 5
6
+
+
+
+
D
G
G
G
G
E
E
D
C
D
C
C
F
F
F
F
C
D
H
F
+
FH
the chest of drawers.
Position changer unit on
top of the chest and fix it
with bolt and allen
key .
Fix wall strap to the changer
unit as shown.
It is essential that this
product is fixed to the wall
using wall strap supplied
with chest of drawers.
Remove wall strap from
Fixing white strap
Remove first drawer from
the chest.
Fix white strap to the
changer unit using
washer and screw .
Then, pull the strap straight
over the front of the changer
and the top panel of the
chest of drawers and fix it
underneath the top panel
using washer and
screw .
Assemble is complete!
Step 6
E
G
G
F
F

Important note:
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
If plastic wall plugs
are supplied with your
product:
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fixings is the
responsibility of the installer.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualifed
tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Types of walls You can use one of the following types of wall plug if your
walls are made of brick, breeze block, concrete, stone or wood.
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can
be used.
For use with plasterboard partitions or
hollow wooden doors.
For use with walls stuck with
plasterboard. The hammer fixing allows
it to be fixed to the wall rather than the
plasterboard. Always check the fixing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
For use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
No.1 “General Purpose” wall plug No.3 “Cavity Fixing” wall plug No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
A Guide to - Wall Mounting & Fixings
Care &
Maintenance
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
