Aries S223005-2 User manual

PAGE 1 • S223005-2-INS-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For stainless steel and aluminum, polish may be used to clear small scratches
and scuffs on the finish. Mild soap may be used also to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Level of Difficulty
Easy
Parts List
1Driver / left side bar
1Passenger / right side bar
2Mounting bracket,
driver / left
2Mounting bracket,
passenger / right
16 Hex bolt, M8 x 35mm
8Clip nut, M8
24 Flat washer, M8
16 Lock washer, M8
8Hex nut, M8
8Hex bolt, M10 x 25mm
8Flat washer, M10
8Lock washer, M10
Scan
for helpful
install tips
Front
Rear
INSTALLATION MANUAL S223005-2
Torque Specifications
METRIC
M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
SAE
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.

ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 800.798.0813 • S223005-2-INS-RA • PAGE 2
Step 1
Starting on the driver side,
locate the two mounting points
underneath the vehicle.
Place the front driver-side bracket onto
the vehicle. Be sure the cradle of the
bracket faces the rear of the vehicle.
Secure the top of the bracket by inserting
two clip nuts into the rectangular slots
and attaching with two M8 hex bolts,
lock washers and flat washers.
Snug the hardware,
but do not fully tighten.
Step 2
Secure the lower mounting points with
two M8 bolts, flat washers, lock washers
and hex nuts.
Repeat this process to secure
the rear mounting bracket.
Place the side bar onto the mounting
brackets and align the mounting points.
Step 3
Secure the side bar to the brackets using
an M10 hex bolt and flat washer at each
mounting point. Snug the hardware, but
do not fully tighten.
Adjust and level the side bar.
With the side bar in position, it is
recommended to tighten all brackets
to the vehicle first, followed by the
side bar connections.
Step 4
Repeat steps 1 through 3
on the passenger side of the vehicle.
Congratulations on the installation
of your ARIES 4" oval side bars.
With the side bars installed, periodic
inspections should be performed to ensure
all mounting hardware remains tight.
To protect your investment, see the
'Notes and Maintenance' section on
the first page of this instruction manual.
