Assa Abloy Corbin Russwin PED5000 DB Series User manual

Installation Instructions
End Cap Mounting Plate
PED4000/PED5000 Series Exit Devices
FM610 01/23
WARNING
This product can expose you to
lead which is known to the state of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65warnings.ca.gov.
Attention Installer: Improper
installation may result in damage
to the product and void the factory
warranty.
WARNING
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
1
Slide mounting plate into rail, until the mounting plate is firmly against the rail.
Rail
Mounting plate
Mounting screws
#10-24 Round head
Cover screws
#8-32 Oval head
End cap

FM610 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Mounting plate base should rest flat on door or
shims, without any overlap of the mounting plate
base and rail.
45
New installation shown
For new installation, use the inner mounting holes.
(For retrofit, use whichever holes are in-line with
the holes in the door.)
Inner
Mounting
Holes
Wire
Clearance
3
Inner
Mounting
Holes
2
Ensure mounting rail bracket is against
the rail without a gap.
