Asus PadFone Station User manual

Quick Start Guide
Station

E7191
First Edition
March 2012
Copyright © 2012 ASUSTek Computers, Inc.
All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUS
Telecom (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless such repair, modication of alteration is authorized in
writing by ASUS; or (2) the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF
ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY
FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only
for identication or explanation and to the owners’ benet, without intent to infringe.

Camera lens
Light sensor
Touchscreen display
1
2
3
1
3
2
Thank you for purchasing another cool ASUS product!
Before you start, ensure that you have read all the safety information and operating instructions in the Important
Notices bundled with your PadFone to prevent injury or damage to your device.
NOTE: This bundled Quick Start Guide is for reference only and is subject to change without prior notice. For the latest updates and more
detailed information, please visit www.asus.com.
Getting to know your PadFone Station
Overview

PadFone door latch
LED indicator
Power key
4
5
6
Air vent
PadFone bay
PadFone ashbulb hole
7
8
9
PadFone camera hole
Speaker
Audio jack
10
11
12
Volume key
Microphone
Hinge holes
13
14
15
45 6
78
9 10
11 12
13
15 16 15
Overview
14
40-pin USB port
16

41
2
3
CAUTION! Double-check the connections and ensure that the
power plug is securely attached to the AC Adapter to prevent
overheating and damage to the cables, adapter, or device.
IMPORTANT The 40-pin connector/port is used for charging
your PadFone Station only. It can not be used for transferring
data.
Charging your PadFone Station
We strongly recommend that you charge your PadFone Station fully before you use it with your PadFone.
To charge your PadFone Station:
1. Connect the power plug into the USB charger. Ensure that the power plug is attached securely in place.
2. Connect the USB connector into the USB charger’s USB port.
3. Connect the micro USB connector into your PadFone Station.
4. Insert the power plug into a wall socket.
NOTICE
• Use only the power adapter that comes with your device. Using
a different power adapter may damage your device.
• Using the provided USB charger and USB cable to connect
your PadFone Station to a power outlet is the best way to
charge your PadFone Station.
• The input voltage range between the wall outlet and this
adapter is AC 100V - 240V; the output voltage through the
40-pin USB cable is DC 15V, 1.2A.

Bay latch
Inserting your PadFone into the PadFone Station
To insert your PadFone into your PadFone Station:
1. Hold your PadFone Station upside-down then push the latch to open the PadFone bay.

Sliding track
Sliding track
Silhouette guide
2. Align your PadFone into the PadFone bay sliding track. Orient your PadFone so that it matches the silhouette
guide in the bay.

NOTE Your PadFone Station briey vibrates when the
connection is secured.
3. Firmly insert your PadFone into the PadFone Station until the PadFone is secured in place.

4. Close the PadFone bay door and ensure that the latch rmly locks in place.

After successfully inserting your PadFone into the PadFone Station, Android automatically adjusts the screen
and apps to work on a tablet environment.
If an app was designed for a smaller screen, a zoom control will appear beside the clock.
NOTE: The following screen is for reference only and may appear differently from your device.

Bay latch
Removing your PadFone from the PadFone Station
To remove your PadFone from the PadFone Station:
1. Hold your PadFone Station upside-down then push the bay latch to open the PadFone bay.

2. Push the PadFone bay door up to a ninety-degree (90o) angle until the PadFone detaches completely from the
connectors.
90oangle
IMPORTANT: Pushing the PadFone bay door up to a
ninety-degree (90
o
) angle allows the specially designed
push levers to eject the PadFone properly from the
PadFone Station.
WARNING: DO NOT use any tool or your hands to
manually remove the PadFone from the PadFone Station,
to prevent injury to self or damage to the devices.
Right push lever
Left push lever

3. Gently remove the PadFone out (A) then close the PadFone bay door (B).
A
B

15060-05S00000
