AURES TRX 3000 User manual

TRX 3000
Quickstart Guide
REL1.1 October22
Model Number TRX3000-151B TRX3000-156B
CPU Intel®Elkhart Lake J6412 (2.0 GHz)
Quad-core processor
Storage M.2 2242 Nvme SSD X2 & SATA
Memory 1 x SO-DIMM DDR4-3733
SDRAM 4GB and 8GB
Graphic Intel HD Graphics
Display 15” TFT LCD 1024 x
768 resolution
15,6” TFT LCD 1366 x
768 resolution
Touch Projective Capacitive Touch
TPM TPM 2.0
External I/O
USB-A 6Port (USB3.0*2 / USB2.0*4)
RS-232 COM1, COM2, COM3
with DTR/12V Power output
LAN Gigabit LAN (10/100/1000M BASET LAN)
Audio HD Audio
C-type Support ALT DP/USB3.0
Mini DP MINI-DP(DP+COM5)
Cash Drawer Self Define RJ12 Connector
Speaker Embedded
Power Supply 12V/5A Adaptor
OS Support Windows 10 64bit
Operating Temperature 0°C ~ 40°C at 10% ~ 80% humidity
Storage Temperature -20°C ~ 60°C at 10% ~ 80% humidity
2Stand
3ON/OFF touch button
15" XXxXXxXXmm
15,6" XXxXXxXXmm
