RADIO-CONTROLLED WALL CLOCK
RADIO-CONTROLLED WALL CLOCK
Operation and Safety Notes

GB / IE / NI Operation and Safety Notes Page 5

KINGVY
SET
1.5V
AA LR6
R6P
REC
RESET
NO(O)JEWELS UNADJUSTED
DCF
KV2008
QUARTZ
2
3
4
A
1
5

B
1

5GB/IE/NI
List of pictograms used .................................. Page 6
Introduction ............................................. Page 6
Intended use............................................ Page 7
Scope of delivery ........................................ Page 7
Description of parts ...................................... Page 7
Technical data .......................................... Page 7
Safety instructions....................................... Page 8
General safety information ................................ Page 8
Safety instructions for batteries/rechargeable batteries .......... Page 9
Before initial use ........................................ Page 10
Operation ............................................... Page 12
Receiving the DCF / MSF radio time signal.................... Page 12
Setting the time manually .................................. Page 13
Resetting the settings ..................................... Page 13
Cleaning and care ....................................... Page 13
Disposal................................................. Page 14
Simplified EU declaration of conformity .................. Page 15
Simplified UKCA declaration of conformity
(in Great Britain only)....................................Page 15
Warranty and service.................................... Page 16
Warranty .............................................. Page 16
Warranty claim procedure................................. Page 16
Service ................................................ Page 17

6 GB/IE/NI
List of pictograms used
Direct current/voltage
Fragile
Radio control
Battery included
CE mark indicates conformity with relevant EU directives
applicable for this product.
UKCA mark indicates conformity with relevant Great Britain
regulations applicable for this product. (The UKCA mark logo
is valid in Great Britain only.)
RADIO-CONTROLLED WALL CLOCK
Introduction
We congratulate you on the purchase of your new product. You have chosen
a high quality product. The instructions for use are part of the product. They
contain important information concerning safety, use and disposal. Before using
the product, familiarise yourself with all of the safety information and instructions
for use. Only use the product as described and for the specified applications.
If you pass the product on to third parties, ensure that you also pass on all the
documentation with it.

7GB/IE/NI
Intended use
The product is intended for use indoors at normal room temperatures only. The
product is not intended for commercial use. The product shows time and indoor
temperature and humidity.
Scope of delivery
Immediately after unpacking, check the package contents for completeness and if
the product and all parts are in good condition.
1 Radio-controlled wall clock
1 Battery 1×1.5 V AA, LR6 (included)
1 Instructions for use
Description of parts
1Mounting hole
2SET button
3REC button
4RESET button
5Battery compartment
Technical data
Temperature display: –40 to 60 °C (functional range: 10 °C to 40 °C)
Humidity display: 0 to 100 % (functional range: 20 % to 80 %)
Battery type: 1×1.5 V AA, LR6
Quartz movement: Radio signal for HG06544A/B-DCF: DCF77
Radio signal for HG06544A/B-MSF: MSF60
Frequency band: 77.5 kHz (HG06544A/B-DCF);
60 kHz (HG06544A/B-MSF)

8 GB/IE/NI
Safety instructions
WARNING! Read all safety information and instructions. Failure to comply
with the safety information and instructions may result in fire and severe injuries.
General safety information
WARNING! DANGER TO LIFE AND ACCIDENT
HAZARD FOR TODDLERS AND SMALL CHILDREN! Never
allow children to play unsupervised with the packaging material.
There is a danger of suffocation from the packaging material. Children
frequently underestimate the dangers.
This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the product in a safe way and understand the hazards
involved. Children shall not play with the product. Cleaning and user
maintenance shall not be made by children without supervision.
WARNING! DANGER TO LIFE! Batteries can be swallowed, which
may represent a danger to life. If a battery has been swallowed, medical help is
required immediately.
Do not use the product if it is damaged.
Repairs must be carried out by specialist personnel only.

9GB/IE/NI
Safety instructions for batteries/rechargeable
batteries
mDANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of
children. If accidentally swallowed seek immediate medical attention.
Swallowing may lead to burns, perforation of soft tissue, and death. Severe
burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION! Never recharge non-rechargeable
batteries. Do not short-circuit batteries/rechargeable batteries nor open
them. Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures, which could affect
batteries/rechargeable batteries, e.g. radiators/direct sunlight.
If batteries/rechargeable batteries have leaked, avoid contact of skin, eyes
and mucous membranes with the chemicals! Immediately flush the affected
areas with fresh water and seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or damaged batteries/
rechargeable batteries can cause burns upon contact with the skin. Wear
suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries, immediately
remove them from the product to prevent damage.
Remove batteries/rechargeable batteries if the product will not be used for a
longer period.

10 GB/IE/NI
Risk of damage to the product
Only use the specified type of battery/rechargeable battery!
Insert batteries/rechargeable batteries according to polarity marks (+) and (–)
on the battery/rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery/
rechargeable battery and in the battery compartment before inserting!
Remove exhausted batteries/rechargeable batteries from the product
immediately.
Before initial use
1. Remove the battery from the box and plastic wrapper.
2. Insert the battery into the battery compartment 5, placing first the –contact
and then pushing down at the +contact.
Replacing the battery
1. Turn the product over. Place it on a soft underlay to avoid scratching the
surface.
2. Remove the battery and then insert a new battery according to the polarity
marks.
3. Insert the battery into the battery compartment 5, placing first the –contact
and then pushing down at the +contact.
4. The product is now ready for use.
Mounting the product
NOTE: You will require a screw and a dowel to mount the product as
these are not included with your product. You will also need an electric drill and
screwdriver.
NOTE: Make sure that the screw and dowel are suitable for the wall.

11GB/IE/NI
Before drilling the drill hole, ensure that there are no gas, water or electrical
lines that could be drilled into or damaged in the area where you will be
drilling.
1. Mark the drill hole on the wall.
2. Drill the hole with an electric drill.
3. Insert the dowel into the drilled hole.
4. Using a screwdriver, screw the screw ¾ of the way into the dowel.
5. Hang the product on the screw using the mounting hole 1at the back of the
product.
Radio Signal (DCF for HG06544A/B -DCF, MSF for HG06544A/B-MSF):
HG06544A/B-DCF:
The DCF signal (time signal transmitter) consists of time pulses emitted by one of
the most accurate clocks in the world. This clock is located close to Frankfurt/Main,
Germany and it can usually achieve an accuracy within a hundredth of a second
relative to the time standard.
The product receives these signals under ideal conditions up to a distance of
approx. 1,500 km around Frankfurt/Main. Reception of the radio signal generally
takes approx. 3 to 12 minutes.
HG06544A/B-MSF:
The MSF signal (time signal transmitter) consists of time pulses emitted by one of
the most accurate clocks in the world. This clock is located in Anthorn, UK and it
can usually achieve an accuracy within a hundredth of a second relative to the
time standard.
The product receives these signals under ideal conditions up to a distance of
approx. 1,500 km Anthorn, UK. Reception of the radio signal generally takes
approx. 3 to 12 minutes.

12 GB/IE/NI
NOTE: Reception may be considerably reduced by obstructions (e.g. concrete
walls) or sources of interference (e.g. other electrical products). In the event of
reception problems, change the position of the product (e.g. to somewhere near a
window).
Operation
Receiving the DCF/MSF radio time signal
1. Insert a 1.5 V AA/LR6 battery according to the polarity marks into the battery
compartment 5on the back of the product.
2. The product automatically starts to search for the DCF/MSF radio time signal.
This process takes about 3 to 12 minutes to complete.
Within 4 minutes, the hands will move to 12 o’clock. The radio signal reception
is initiated once all the hands have moved to the 12 o’clock position. After 3 to
10 minutes, the clock will receive the signal and set itself to the exact time.
The reception of the DCF/MSF radio time signal by the product can also be
started manually:
Press and hold the REC button 3using a pointed object (e.g. pencil) for at
least 5 seconds. The product attempts to receive the DCF/MSF radio time
signal. This process takes a few minutes to complete.
NOTE: If the product was not able to receive the DCF/MSF radio time signal
because of errors, e.g. due to your location being too great a distance from the
transmitter or for other reasons, you can set the time manually. The manually set
value is overwritten as soon as reception of the DCF/MSF radio time signal is
successful.
NOTE: For products intended for Romania, Cyprus, Bulgaria, Finland and
Greece, the display stops at “01:00”.

13GB/IE/NI
Setting the time manually
1. Press and hold the SET button 2using a pointed object (e.g. pencil) for at
least 3 seconds. The product switches into manual mode.
2. Press and hold the SET button again until the hands reach the correct position
for you to set the time.
3. Briefly pressing the SET button moves the hands forward in one minute steps to
enable you to set the current time manually.
NOTE: After 8 seconds without pressing the SET button, the product switches
out of manual mode and keeps the time as normal. The manually set value
is overwritten as soon as the reception of the DCF / MSF radio time signal is
successful.
Resetting the settings
Press the RESET button 4using a pointed object (e.g. pencil) to reset the
product settings. Alternatively, remove the battery from the product and insert it
again. The product now automatically starts to search for the DCF/MSF radio
time signal.
Cleaning and care
Only clean the product on the outside, using a soft dry cloth.
If the product is not going to be used, remove the battery.
NOTE: When the battery voltage is depleted after about 9 months
(depending on reception quality), the second hand will stop moving. However, the
hour and minute will keep on showing the right time until the battery voltage is too
low, after which the product will stop completely.
Change to a new battery as soon as this occurs.

14 GB/IE/NI
Disposal
The packaging is made entirely of recyclable materials, which you may dispose of
at local recycling facilities.
Observe the marking of the packaging materials for waste separation,
which are marked with abbreviations (a) and numbers (b) with following
meaning: 1 – 7: plastics / 20 – 22: paper and fibreboard / 80 – 98:
composite materials
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please dispose of the product properly
when it has reached the end of its useful life and not in the household
waste. Information on collection points and their opening hours can be
obtained from your local authority.
Faulty or used batteries/rechargeable batteries must be recycled in accordance
with Directive 2006/66/EC and its amendments. Return the batteries/
rechargeable batteries and the product to the available collection points.
Environmental damage through incorrect disposal of the
batteries rechargeable batteries!
Batteries/rechargeable batteries may not be disposed of with the usual domestic
waste. They may contain toxic heavy metals and are subject to hazardous waste
treatment rules and regulations. The chemical symbols for heavy metals are as
follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose
of used batteries/rechargeable batteries at a local collection point.

15GB/IE/NI
Simplified EU declaration of conformity
Hereby, OWIM GmbH & Co. KG, Stiftsbergstraße 1, 74167 Neckarsulm,
GERMANY, declares that the product RADIO-CONTROLLED WALL CLOCK,
HG06544A,B-DCF / HG06544A,B-MSF, is in compliance with Directives
2014/53/EU and 2011/65/EU.
The full text of the EU declaration of conformity is available at the following internet
address: www.owim.com
PSimplified UKCA declaration of conformity (in Great
Britain only)
Hereby, OWIM GmbH & Co. KG, Stiftsbergstraße 1, 74167 Neckarsulm,
GERMANY declares that the product RADIO-CONTROLLED WALL CLOCK,
HG06544A,B-DCF / HG06544A,B-MSF, is in compliance with Radio Equipment
Regulations 2017, The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012 and The Ecodesign
for Energy-Related Products and Energy Information (Amendment) (EU Exit)
Regulations 2019.
The full text of the UKCA declaration of conformity is available at the following
internet address: www.owim.com

16 GB/IE/NI
Warranty and service
Warranty
The product has been manufactured to strict quality guidelines and meticulously
examined before delivery. In the event of product defects you have legal rights
against the retailer of this product. Your legal rights are not limited in any way by
our warranty detailed below.
The warranty for this product is 3 years from the date of purchase. The warranty
period begins on the date of purchase. Keep the original sales receipt in a safe
location. This document is required as your proof of purchase.
Should this product show any fault in materials or manufacture within 3 years from
the date of purchase, we will repair or replace it – at our choice – free of charge
to you. This warranty becomes void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material or manufacture. This warranty does not
cover product parts subject to normal wear, thus possibly considered consumables
(e.g. batteries) or damage to fragile parts, e.g. switches, rechargeable batteries or
glass parts.
Warranty claim procedure
To ensure quick processing of your case, observe the following instructions:
Have the till receipt and the item number (IAN 405669_2201) available as proof
of purchase.
You will find the item number on the rating plate, an engraving, the front page of
the instructions for use (bottom left), or as a sticker on the rear or bottom of the
product.
If functional or other defects occur, contact the service department listed either by
telephone or by e-mail.
You can return a defective product to us free of charge to the service address that

17GB/IE/NI
will be provided to you. Ensure that you enclose the proof of purchase (till receipt)
and information about what the defect is and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: o[email protected]
Service Ireland
Tel.: [phone]
E-Mail: o[email protected]
Service Northern Ireland
Tel.: [phone]
E-Mail: o[email protected]

OWIM GmbH & Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
Model No.: HG06544A-MSF / HG06544B-MSF
Version: 06/2022
IAN 405669_2201
