Automationdirect.com Productivity 1000 P1-16CDR User manual

1
Sales 800-633-0405 www.productivity1000.com
P1-16CDR
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C2
C1
INPUTSOUTPUTS
24VAC/VDC IN
RELAY OUTPUT
1000
P1-16CDR Discrete Input / Relay
Output
The P1-16CDR Discrete Input / Relay Output
Module provides eight 24VAC/VDC inputs
and eight relay outputs for use with the
Productivity1000 system.
Output
Specifications . . . . . . . . . . . . . . . . . . . . . . . . .
.1
Module
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .
.2
QR
Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.2
Wiring
Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.3
Schematic
& Wiring Diagram . . . . . . . . . . . . . . . . . . .
.3
General
Specifications . . . . . . . . . . . . . . . . . . . . . . . .
.4
Te
rminal Block Specifications . . . . . . . . . . . . . . . . . . .
.4
Wa
rning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.4
T
erminal Block sold separately, (see wiring options on page 3).
Wa
rranty: Thirty-day money-back guarantee. Two-year limited
replacement (See www
.productivity1000.com for details).
Input Specifications
Inputs per Module
8 (sink/source)
Rated Voltage
24VAC/VDC
Operating Voltage Range
20.4–27.6 VAC/VDC, Max 27.6 VAC, 30VDC
AC Frequency
47–63 Hz
Input Current
8mA @ 24VAC/VDC
Maximum Input Current
10mA @ 27.6 VAC, 30VDC
Minimum ON Current
2.5 mA
Maximum OFF Current
0.5 mA
ON Voltage Level
>9.5 VDC, >8VAC
OFF Voltage Level
<4.5 VDC, <4VAC
OFF to ON Response
AC: 10ms DC: 6ms
ON to OFF Response
AC: 20ms DC: 10ms
Status Indicators
Logic Side (8 points)
Commons
1 (8 points/common)
Output Specifications
Outputs per Module 8
Rated Voltage 6–30 VDC
6–120 VAC
Operating Voltage Range 5–30 VDC
5–144 VAC
Output Type Relay, Form A (SPST)
AC Frequency 47–63 Hz
Maximum Output Current
1A / point, 8A / common for both AC and DC
1A / point, 8A / common for both is used with
ZIPLink Cable
Minimum Load Current 5mA @ 5VDC
Maximum Inrush Current 5A for 10ms
OFF to ON, ON to OFF Response 10 ms
Status Indicators Logic Side (8 points)
Commons
1 (8 points/common)
Maximum Applicable Fuse 8A

2Tech Support 770-844-4200www.productivity1000.com
QR Code
Use any QR Code reader application to
display the module’s product insert.
P1-08TD1
P1-08TD1
12345678910
L
L
L
L
L
L
L
L
24V
1
2
3
4
0V
5
6
7
8
12- 24VDC
+ -
+ -
12345678910
L
L
L
L
L
L
L
L
24V
1
2
3
4
0V
5
6
7
8
12- 24VDC
+ -
DualPower Source
SinglePower Source
3.3- 24VDC
P1-08TD1 Wiring Diagram
Module Installation
WARNING: Do not add or remove modules with
field power applied.
Step One: With latch
in “locked” position, align
connectors on the side of
each module and stack
by pressing together.
Click indicates lock is
engaged.
Step Three: To unstack modules, pull
locking latch up into the unlocked position
and then pull modules apart.
Step Two: Attach field wiring using
the removable terminal block or ZIPLink
wiring system.
WIRE STRIP
LENGTH
MIN
MAX
P1-08TD1
UNLOCK
LOCK
Check all latches are
secure after modules
are connected.

3
Sales 800-633-0405 www.productivity1000.com
Wiring Options
1ZIPLink Feed Through Modules and Cables¹
0.5 m (1.6 ft) cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZL-RTB20
ZL-RTB20-1
ZL-P1-CBL18
ZL-P1-CBL18-1
ZL-P1-CBL18-2
Terminal Block with pigtail cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZL-P1-CBL18-1P
ZL-P1-CBL18-2P
3Screw Terminal Block only
P2-RTB
(Quantity 1)
4Spring Clamp Terminal Block only
P2-RTB-1
(Quantity 1)
5Accessories²
ZL-RTB-COM
TW-SD-SL-1
TW-SD-MSL-1
ZL-RTB20
ZL-RTB20-1
2
1.Cable + ZIPLink Module = Complete System
2. ZL-RTB-COM provides a common connection point for power or ground
= Complete S
y
ste
m
acommon connec
ti
on p
oi
nt
f
or pow
P1-16CDR Schematic and Wiring Diagram
C1
1
2
3
4
5
6
7
8
C2
1
2
3
4
5
6
7
8
24VAC
50–60 Hz
L
L
L
L
L
L
L
L
EXTERNAL
FUSE
RECOMMENDED
6–24 VDC
6–120 VAC
50–60 Hz
12345678910 11 12 1813 14 15 16 17
+
+
-
-
24VDC
6–24 VDC
6–120 VAC
50 –60 Hz
8A
User Supplied
External Fuse
INPUT
COM
Internal Module Circuitry
Optical Isolator
24VDC
+
+
24VAC
Equivalent Input Circuit
Equivalent Output Circuit

4Tech Support 770-844-4200www.productivity1000.com
Document Name Edition/Revision Date
P1-16CDR-DS 3rd Edition 9/17/2019
Copyright 2018, AutomationDirect.com Incorporated/All Rights Reserved Worldwide
Terminal Block Specifications
Part Number P2-RTB P2-RTB-1
Positions 18 Screw Terminals 18 Spring Clamp Terminals
Wire Range
30–16 AWG (0.051–1.31 mm²)
Solid / Stranded Conductor
3/64 in (1.2 mm) Insulation Max.
1/4 in (6–7 mm) Strip Length
28–16 AWG (0.081–1.31 mm²)
Solid / Stranded Conductor
3/64 in (1.2 mm) Insulation Max.
19/64 in (7–8 mm) Strip Length
Conductors “USE COPPER CONDUCTORS, 75ºC” or equivalent.
Screw Driver 0.1 in (2.5 mm) Maximum*
Screw Size M2 N/A
Screw Torque 2.5 lb·in (0.28 N·m) N/A
WARNING: To minimize the risk of potential safety problems, you should
follow all applicable local and national codes that regulate the installation
and operation of your equipment. These codes vary from area to area and
it is your responsibility to determine which codes should be followed, and
to verify that the equipment, installation, and operation are in compliance
with the latest revision of these codes.
Equipment damage or serious injury to personnel can result from
the failure to follow all applicable codes and standards. We do not
guarantee the products described in this publication are suitable for
your particular application, nor do we assume any responsibility for your
product design, installation, or operation.
If you have any questions concerning the installation or operation of
this equipment, or if you need additional information, please call Technical
Support at 770-844-4200.
This publication is based on information that was available at the time
it was printed. At AutomationDirect.com®we constantly strive to improve
our products and services, so we reserve the right to make changes to
the products and/or publications at any time without notice and without
any obligation. This publication may also discuss features that may not be
available in certain revisions of the product.
*Recommended Screw Driver TW-SD-MSL-1
*See CE Declaration of Conformance for details.
General Specifications
Operating Temperature 0° to 60°C (32° to 140°F)
Storage Temperature -20° to 70°C (-4° to 158°F)
Humidity 5 to 95% (non-condensing)
Environmental Air No corrosive gases permitted
Vibration IEC60068-2-6 (Test Fc)
Shock IEC60068-2-27 (Test Ea)
Field to Logic Side
Isolation 1800VAC applied for 1 second
Insulation Resistance >10M@ 500VDC
Heat Dissipation 2730mW
Enclosure Type Open Equipment
Module Location Any I/O position in a Productivity1000 System.
Field Wiring Use ZIPLink Wiring System or removable terminal block
(sold separately). See “Wiring Options” on page 3.
EU Directive
See the “EU Directive” topic in the Productivity Suite Help
File. Information can also be obtained at:
www.productivity1000.com
Connector Type
(sold separately) 18-Position Removable Terminal Block
Weight 88g (3.2 oz)
Agency Approvals
UL 61010-1 and UL 61010-2-201 File E139594, Canada
& USA
CE (EN 61131-2 EMC, EN 61010-1 and EN 61010-2-201
Safety)*
