Automationdirect.com Productivity 2000 P2-04DA User manual

1
Sales 800-633-0405 www.productivity2000.com
Terminal Block sold separately, (see wiring options on page 5).
Warranty: Thirty-day money-back guarantee. Two-year limited
replacement. (See www.productivity2000.com for details).
1+0.100V
2 4.00
3 13.78
4-4.741V
2000
WARNING: To minimize the risk of potential safety problems, you should
follow all applicable local and national codes that regulate the installation
and operation of your equipment. These codes vary from area to area and
it is your responsibility to determine which codes should be followed, and
to verify that the equipment, installation, and operation are in compliance
with the latest revision of these codes.
Equipment damage or serious injury to personnel can result from the
failure to follow all applicable codes and standards. We do not guar-
antee the products described in this publication are suitable for your
particular application, nor do we assume any responsibility for your
product design, installation, or operation.
If you have any questions concerning the installation or operation of this
equipment, or if you need additional information, please call Technical
Support at 770-844-4200.
This publication is based on information that was available at the time it
was printed. At AutomationDirect.com®we constantly strive to improve
our products and services, so we reserve the right to make changes to
the products and/or publications at any time without notice and without
any obligation. This publication may also discuss features that may not be
available in certain revisions of the product.
Removable Terminal Block Specifications
Part Number P2-RTB P2-RTB-1
Number of
positions 18 Screw Terminals 18 Spring Clamp Terminals
Wire Range
30 - 16 AWG (0.051 - 1.31 mm²)
Solid / Stranded Conductor
3/64 in. (1.2 mm) Insulation Maximum
1/4 in (6 - 7 mm) Strip Length
28-16 AWG (0.081 - 1.31 mm²)
Solid / Stranded Conductor
3/64 in (1.2 mm) Insulation Maximum
19/64 in (7 - 8 mm) Strip Length
Conductors “USE COPPER CONDUCTORS, 75ºC” or equivalent.
Screw Driver
Width 1/8 in (3.8 mm) Maximum
Screw Size M2 N/A
Screw Torque 2.5 lb·in (0.28 N·m) N/A
P2-04DA Analog Output
The P2-04DA Voltage/Current Analog Output
Module provides four channels of ±10VDC or 4-20 mA
sink/source selectable outputs for use with the
Productivity2000 System
Warning .................................. 1
Removable Terminal Block Specifications. . . . . . . . 1
General Specifications ...................... 2
Output Specifications ....................... 2
Wiring Diagram and Schematic................ 3
Module Installation Procedure................. 4
QR Code ................................. 4
Hot Swap Information ....................... 4
Wiring Options............................. 5
Module Configuration ....................... 5
Linear Scaling ............................. 6
Non-Linear Scaling ......................... 6
OLED Panel Display Menus .................. 7

2Tech Support 770-844-4200www.productivity2000.com
General Specifications
Operating Temperature 0º to 60ºC (32º to 140ºF)
Storage Temperature -20º to 70ºC (-4º to 158ºF)
Humidity 5 to 95% (non-condensing)
Environmental Air No corrosive gases permitted
Vibration IEC60068-2-6 (Test Fc)
Shock IEC60068-2-27 (Test Ea)
Field to Logic Side Isolation 1800VAC applied for 1 second
Insulation Resistance > 10MΩ @ 500VDC
Heat Dissipation 3.6W
Enclosure Type Open Equipment
Agency Approvals UL508 File E139594, Canada & USA
CE (EN61131-2*)
Module Keying to Backplane Electronic
Module Location Any I/O slot in a Productivity2000 System
Field Wiring Use ZIPLink Wiring System or removable terminal block
(not included). See “Wiring Options” on page 5.
EU Directive
See the “EU Directive” topic in the Productivity2000
Help File. Information can also be obtained at:
www.productivity2000.com
Connector Type (not included) 18-position removable terminal block
Weight 90g (3.2 oz)
Output Specifications
Output Channels 4
Module Signal Output Ranges 1) ±10VDC
2) 4-20 mA (sink or source per channel)
Signal Resolution 16-bit
Resolution Value of LSB
(least significant bit)
±10V = 305μV/count
4-20 mA = 0.244 μA/count
1 LSB = 1 count
Data Range 0 to 65535 counts uni-polar and
-32768 to +32767 counts bi-polar
Output Type Voltage outputs sources/sinking at 10mA max, or
Current outputs sink or source at 20mA max.
Output Value in Fault Mode Voltage outputs 0V or 0mA current outputs
Load Impedance
(Minimum External Power Supply)
>1000Ω voltage outputs (19.2 - 30 VDC)
0 - 755Ω Sinking, 0 - 600Ω Sourcing (19.2 VDC)
0 - 875Ω Sinking, 0 - 700Ω Sourcing (21.6 VDC)
0 - 1000Ω Sinking, 0 - 855Ω Sourcing (24VDC)
0 - 1110Ω Sinking, 0 - 970Ω Sourcing (26.4 VDC)
0 - 1350Ω Sinking, 0 - 1150Ω Sourcing (30VDC)
Maximum Capacitive Load 0.01μF maximum voltage outputs
Maximum Inductive Load 1mH maximum current outputs
Allowed Load Type Grounded
Maximum Inaccuracy (% of range) 0.1% voltage, 0.1% current (including temperature drift)
Maximum Full Scale Calibration
Error (not including offset error)
±0.025% of range maximum voltage outputs
±0.025% of range maximum current outputs
Maximum Offset Calibration Error ±0.025% of range maximum
Accuracy vs. Temperature ±25ppm/°C max f.s. calibration change
(±0.0025% of range/°C)
Max Crosstalk -80dB, 6 LSB
Linearity Error (End to End) ±16 LSB maximum (±0.025% of full scale)
Monotonic with no missing codes
Output Stability and Repeatability ±10 LSB after 10 minute warm-up (typical)
Output Ripple 0.05% of Full Scale
Output Setting Time 0.3 ms max, 5μs min (full scale change)
All Channel Update Rate 0.6 ms
Maximum Continuous Overload Voltage Outputs current limited to 35mA typical
Current Outputs open circuit protected
Type of Output Protection 15VDC Peak Output Voltage
Current outputs current limited to <=20mA
Output Signal (power-up,-down) 0V voltage outputs, 0mA current outputs
External DC Power Required
94mA voltage operation 4 channels
130mA current operation 4 channels
24VDC -20% / +25%
*Meets EMC and Safety requirements. See the D.O.C. for details.

3
Sales 800-633-0405 www.productivity2000.com
- +
24 VDC User
Supplied Power
- +
24 VDC User
Supplied Power
AC or DC
AC or DC
AC or DC
±10 VDC
Load
V+
COM
0 - 10
VDC Load
V+
COM
Voltage Output Current Source Output
(Field device is sinking)
Current Sink Output
(Field device is sourcing)
I+
4 - 20mA
Load COM
I+
COM
I-
I-
COM
NOTE: Shield is connected to
common at the source device.
4-wire
4 - 20mA Load
2-wire
4 - 20mA Load
I+
I+
COM
24VDC+
Install
Jumper
Install
Jumper
+24VDC User
Supplied Power
Transmitter
Power Supply
AC or DC
4-wire
4 - 20mA Load
Transmitter
Power Supply
I-
I-
V1+
I1-
I1+
COM
V2+
I2-
24VDC+
I2+
24VDC+
24VDC-
24VDC+
- +
24 VDC User
Supplied Power
CH1
DAC
CH2
DAC
ANALOG
CIRCUIT
POWER
ANALOG
CIRCUIT COMMON
INTERNAL
MODULE CIRCUITRY
voltage sink/source
4-20 mA current sinking
4-20 mA current sourcing
voltage sink/source
4-20 mA current sinking
4-20 mA current sourcing
V3+
CH3
DAC
CH4
DAC
I3-
I3+
COM
V4+
I4-
I4+
voltage sink/source
4-20 mA current sinking
4-20 mA current sourcing
voltage sink/source
4-20 mA current sinking
4-20 mA current sourcing
1234567891011121813 14 15 16 17
Wiring Diagram Schematic

4Tech Support 770-844-4200www.productivity2000.com
QR Code
Use any QR Code reader application to
display the module’s product insert.
Important Hot-Swap Information
The Productivity2000 System supports hot-swap!
Individual modules can be taken offline, removed, and
replaced while the rest of the system continues con-
trolling your process. Before attempting to use the hot-
swap feature, be sure to read the hot-swap topic in the
programming software’s help file or our online documen-
tation at AutomationDirect.com for details on how to plan
your installation for use of this powerful feature.
1 Align
with slot
2rotate
to seated
position
Module Installation
WARNING: Do not apply field power until
the following steps are completed. See
hot-swapping procedure for
exceptions.
WIRE STRIP
LENGTH
WIRE STRIP
LENGTH
Step One: Align module
catch with base slot and
rotate module into
connector.
Locked Unlocked
Step Two: Pull top locking tab
toward module face. Click indi-
cates lock is
engaged.
Step Three: Attach field wiring using the removable
terminal block or ZIPLink wiring
system.
Caution: If possible, remove field power prior to
proceeding. If not, then EXTREME care MUST be taken
to prevent damage to the module, or even personal injury
due to a short circuit from the live terminal block.

5
Sales 800-633-0405 www.productivity2000.com
Using the Hardware Configuration tool in the
Productivity Suite programming software, drag
and drop the P2-04DA module into the base
configuration.
Select Automatic Module Verification or No
Verification and Enable Hot Swap. If desired,
assign a User Tagname to each output point
(channel) selected and to each Status Bit Item.
Range with sink/source option and Stop Mode
Value may also be assigned.
Wiring Options
1ZIPLink Connection System
Cable + ZIPLink Module = Complete System
ZIPLink pre-wired
terminal block cables
0.5 m (1.6 ft) cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZIPLink Modules
Feed through
ZL-P2-CBL18
ZL-P2-CBL18-1
ZL-P2-CBL18-2
ZL-RTB20
2Terminal Block with pigtail cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZL-P2-CBL18-1P
ZL-P2-CBL18-2P
3Screw Terminal Block only
P2-RTB
(Quantity 1)
4Spring Clamp Terminal Block only
P2-RTB-1
(Quantity 1)
Module Configuration

6Tech Support 770-844-4200www.productivity2000.com
65535
220
12500
Tank Level
0
Control Valve
Select the Input and Output tags appropriate
for the application. Convert raw input signals
to engineering units for use in the program, or
convert engineering units to output signals for
control purposes
max
min
min max
0
.5
1
1.55
2.25
3
4.55
6.75
7
0
0
0
0
0
0
0
0
1
2
3
4
5
6
6.5
7
0
0
0
0
0
0
0
Level Transmitte
rT
ank Level
7
0
0
0
0
0
0
0
Select the minimum and maximum
values of the raw input signal.These
values will relate to the minimum
and maximum scaled values.
7
6
5
4
3
2
1
01 2 3 4 5 6 7
The Scale (Linear) function can be used to:
• Convert an application specific range to a range which is native to the
analog output module.
• Make other linear conversions in ranges appropriate to the application.
The Scale (Non-Linear) function can be used for Non-Linear applications.
Linear Scaling Non-Linear Scaling

7
Sales 800-633-0405 www.productivity2000.com
Momentarily Press
SEL button to
toggle through
secondary displays
Hold SEL button down to cycle through primary screens. Release button to select screen.
Power On
Appears
initially
These screens will
then auto cycle
Error Messages:
An existing error will
be inserted into the
cycling Status Info
screen.
This screen will
auto cycle with
status information
PASSED
SELF
TEST
P2-04DA
Fw. Rev.
1.00
1 +/-10V
2 mA SRC
3 mA SNK
4 +/-10V
DISPLAY
SETUP
INFO
DISPLAY
UNITS
DECIMAL
COUNTS
DISPLAY
UNITS
HEX
COUNTS
DISPLAY
STATUS
INFO
DISPLAY
UNITS
VOLT OR
MILLIAMP
1 00000
2 00000
3 00000
4 00000
1 0000H
2 0000H
3 0000H
4 0000H
1 0.000V
2 4.00
3 13.90
4-4.741V
End of
Status
Menu
List
MISSING
EXTERNAL
24VDC
MISSING
CONFIG
DATA
End of
Status
Menu
List
SELFTEST
FAIL
REPLACE
MODULE
OLED Panel Display

8Tech Support 770-844-4200www.productivity2000.com
Document Name Edition/Revision Date
P2-04DA-DS 1st Ed. 3/9/2015
Copyright 2015, AutomationDirect.com Incorporated/All Rights Reserved Worldwide
