AZZA 6IFB User manual

PT-6IFB
SYSTEM BOARD
( VER. 2.x )
OPERATION MANUAL

PT-6IFB SYSTEM BOARD TABLE OF CONTENTS
i
TABLE OF CONTENTS
Chapter & Section Page
1 INTRODUCTION ................................................................................................ 1
1.1 SYSTEM OVERVIEW ................................................................................. 1
1.2 FEATURES.................................................................................................... 1
2 SPECIFICATIONS .............................................................................................. 1
3 SYSTEM BOARD LAYOUT ............................................................................ 1
3.1 PT-6IFB VER. 2.x......................................................................................... 1
4 HARDWARE SETUP ......................................................................................... 1
4.1 UNPACKING ................................................................................................ 1
4.2 HARDWARE CONFIGURATION............................................................ 1
4.2.1 DRAM INSTALLATION..................................................................... 1
4.2.2 CONNECTORS...................................................................................... 3
4.2.3 JUMPERS ............................................................................................... 9
5 AWARD BIOS SETUP ...................................................................................... 1
5.1 GETTING STARTED ................................................................................. 1
5.2 MAIN MENU................................................................................................ 1
5.3 CONTROL KEYS ........................................................................................ 2
5.4 STANDARD CMOS SETUP......................................................................2
5.5 BIOS FEATURES SETUP ......................................................................... 3
5.6 CHIPSET FEATURES SETUP ................................................................. 5
5.7 POWER MANAGEMENT SETUP........................................................... 7
5.8 PNP/PCI CONFIGURATION .................................................................... 8
5.9 INTEGRATED PERIPHERALS................................................................ 10
5.10 LOAD SETUP DEFAULTS ..................................................................... 11
5.11 SUPERVISOR PASSWORD / USER PASSWORD............................ 12
5.12 IDE HDD AUTO DETECTION ............................................................. 12
5.13 HDD LOW LEVEL FORMAT ............................................................... 12
5.14 SAVE & EXIT SETUP ............................................................................ 12
5.15 EXIT WITHOUT SAVING...................................................................... 12
6 Installing and Removing the Processor .............................................................. 1
6.1 Installing the Boxed Processor ..................................................................... 1
6.2 Removing the Processor................................................................................ 3

PT-6IFB SYSTEM BOARD
ii
TRADEMARKS
All trademarks used in this manual are the property of their respective owners.
NOTE
The "LOAD SETUP DEFAULTS" function loads the default settings directly from
BIOS default table, these default settings are the best-case values that should optimize
system performance and increase system stability . This function will be necessary
when you accept this system board, or the system CMOS data is corrupted.
By pressing "Enter" key, while "LOAD SETUP DEFAULTS" is highlighted, then
presses "Y" and "Enter" key. the SETUP default values will be loaded. (Please refer to
the Chapter 5 AWARD BIOS SETUP procedures in this manual.)
NOTICE
Information presented in this manual has been carefully checked for reliability;
however, no responsibility is assumed for inaccuracies. The information contained in
this manual is subject to change without notice.
WARRING !
The "Static Electricity" might cause damage to the components on the system board, for
this reason, please eliminate all static electricity on your body before you touch this
system board.

Printed in Taiwan
Date : May/31/1997

PT-6IFB SYSTEM BOARD INTRODUCTION
1
I. INTRODUCTION
A. SYSTEM OVERVIEW
ThePT-6IFBPentium II PCI Local Bus system board is an ATX form-factor
system board. It is designed based on the Intel 82440FX PCIset system chipset and
Winbond I/O chipset. It built-in two channel PIO and Bus Master Enhanced PCI IDE
ports, one Floppy Disk control port, two high speed Serial ports (UARTs) and one
multimode Parallel port and also supports PS/2 mouse, IR and USB ports. It is designed
to fit a high performance, Pentium II (S.E.C. Cartridge) processor 233 MHz, 266 MHz
and upon based solution for high-end and true GREEN-PC computer systems.
Due to the Pentium II Processor is a 64-bit processor with RISC technology, which
offers several key features such as built-in 256KB/512KB L2 cache, 12-stage
superpipeline architecture, out of order execution .... etc, in order to optimize its
capabilities and performances, the Pentium II Processors require 32-bit Operating
Systems (such Windows NT and OS/2) and applications.
This system board supports the Peripheral Component Interconnect (PCI) Local Bus
standard (PCI Spec. Rev. 2.1 compliant). It not only breaks through the I/O bottlenecks
of the traditional ISA main board, but also provides the performance needs for
networking and multi-user environments.
A. FEATURES
The PT-6IFB system board contains the following features:
Supports wide range Pentium II family CPUs from 233 MHz and 266 MHz ,
fully IBM PC/AT compatible system board with ISA Bus and PCI Local Bus.
Built-in 3 set voltage regulator circuits to support all low-voltage components
include CPU, chipset ..., so that no VRM (Voltage Regulator Module) is needed.
DRAM Memory : Supports fast page mode (FPM), Extended Data Out (EDO)
and Burst Extended Data Out (BEDO) memory. Supports
ECC/Parity functions.

PT-6IFB SYSTEM BOARD INTRODUCTION
2
Cache Memory : Supports Pentium II CPU's built-in 256KB/512KB L2 cache.
System BIOS : Supports Plug and Play System BIOS.
IDE ports : Supports two channel PIO and Bus Master Enhanced PCI IDE
ports, up to Mode 4 timing, and up to 22 MBytes/s transfer rates.
I/O ports : Supports two high speed serial ports (UARTs), One multimode
parallel port for standard (SPP), enhanced (EPP) and high speed
(ECP) modes. One Floppy Disk Control port. And also supports
PS/2 mouse connector on board.
IR Port : Supports IR (Infrared Rays) functions. Both HPSIR and ASKIR
are supported.
USB Ports : Supports two Universal Serial Bus (USB) ports.
ACPI : Supports a part of ACPI (Advanced Configuration and Power
Interface) functions, such as "Software Power Off".

PT-6IFB SYSTEM BOARD SPECIFICATIONS
1
I. SPECIFICATIONS
CPU
Intel Pentium II (S.E.C. Cartridge) processor 233 MHz, 266 MHz and maybe upon.
CPU VCC
Voltage Regulator circuits on board, supports +1.80V DC through +2.80V DC CPU
Core Voltage.
WORD SIZE
Data Path : 8-bit, 16-bit, 32-bit, 64-bit
PC SYSTEM CHIPSET
Intel 82440FX PCIset (82441FX, 82442FX, 82371SB)
SUPER I/O CHIPSET
Winbond W83977F
BUS FREQUENCY
60/66.6 MHz adjustable.
MEMORY
DRAM : Three banks, each bank could be single or double sided, 8MB up to 1024
MB. Supports fast page mode (FPM), Extended Data Out (EDO) and
Burst
Extended Data Out (BEDO) memory. (Using 72-pin SIMM x8).
CACHE : Supports Intel Pentium II (S.E.C. Cartridge) CPU's built-in
256KB/512KB L2 cache.
BIOS
AWARD Plug & Play System BIOS. (128KBx8, Flash ROM)
EXPANSION SLOTS
PCI Slots : 32-bit x 4 (All Master/Slave, PCI Spec. Rev. 2.1 Compliant)
ISA Slots : 16-bit x4 (One slot PCI/ISA shared)

PT-6IFB SYSTEM BOARD SPECIFICATIONS
2
IDE PORTS
Two channel PIO and Bus Master Enhanced PCI IDE ports, maximum could be
connected up to 4 IDE Hard Disk and ATAPI CD-ROM device. BIOS supports IDE
CD-ROM boot-up.
SUPER I/O PORTS
1. Two high speed NS16C550 compatible serial ports (UARTs).
2. One parallel port, supports SPP/EPP/ECP mode.
3. One Floppy Disk Control port.
IR PORT
One HPSIR and ASKIR compatible IR transmission connector (5-pin).
MOUSE AND KEYBOARD
One PS/2 mouse connector, One PS/2 keyboard connector.
USB PORTS
Two Universal Serial Bus (USB) ports.
DIMENSION
Width & Length : 305 mm x 244 mm.
Height : 3/4 inches with components mounted, but without expansion
boards and cables.
PCB Thickness : 4 layers, 0.05 inches normal.
Weight : 20 ounces.
ENVIRONMENT
Operating Temperature : 10to 40. (50to 104)
Required Airflow : 50 linear feet per minute across CPU.
Storage Temperature : - 40to 70. (- 40to 158)
Humidity : 0 to 90% noncondensing.
Altitude : 0 to 10,000 feet.

PT-6IFB SYSTEM BOARD HARDWARE SETUP
1
I. SYSTEM BOARD LAYOUT
A. PT-6IFB VER. 2.x
Explanation : All connectors, jumpers and components which marks by a black point on
the corner means the pin-1 side of the connector, jumper and component.
Intel
82371SB
BAT 1
SPEAKER
KEYLOCK
HL
SL
SS
PW
RS
Winbond W83977F
SL4
82442FX
Intel
82441FX
Intel
JP9
USB2
USB1
SL3
SL2
SL1
PCI 1
PCI 2
PCI 3
PCI 4
CN3 POWER CON.
CN13
CN14
CN6 COM B CN1 COM A
CN2
PS/2 MS.
PS/2
KB.
COOLING FAN CON.
CN11 IR
JP10
CN4
CN5 LPT
SYS. BIOS
CN10 IDE1
CN9 IDE2
CN8 FDC
JP6 JP5 JP4
+
_
SIMM 1
SIMM 2
SIMM 3
SIMM 4
SIMM 5
SIMM 8 SIMM 6 SIMM 7
SLOT 1
CN7

PT-6IFB SYSTEM BOARD HARDWARE SETUP
1
I. HARDWARE SETUP
A. UNPACKING
The system board package should contain the following parts :
The PT-6IFB system board.
OPERATION MANUAL.
Cable set for IDE and Floppy device.
A. HARDWARE CONFIGURATION
Before the system board is ready to operate, the hardware must be configured to allow
for various functions within the system. To configure the PT-6IFB system board is a
simple task, only a few jumpers, connectors, cables and sockets needs to be selected and
installed. (For the detailed locations of each component please refer to page 3-1 "system
board layout" figure )
1. DRAM INSTALLATION
The PT-6IFB system board will support four banks main memory on board (bank0 :
SIMM1, SIMM2. bank1 : SIMM3, SIMM4. bank2 : SIMM5, SIMM6. Bank3 : SIMM7,
SIMM8), each bank could be single-sided or double-sided, 8MB up to 1024 MB of
local memory can be attained. It supports three types of DRAM memory either standard
fast page mode (FPM), Extended Data Out (EDO) or Burst Extended Data Out (BEDO)
memory. (Both Symmetrical and Asymmetrical DRAM addressing are supported.)
DRAM bank can be populated in any order (in other words, bank 0 does not have to be
populated before bank 1). Within any given bank, two SIMMs must be same size.
Among the two banks, SIMMs' densities could be mixed in any order. EDO, FPM and
BEDO DRAMs could be mixed between Banks, a given SIMM must contain only one
type of DRAM. When DRAM types are mixed, each SIMM runs optimized for that
particular type of DRAM.
The speed of FPM DRAMs must be used 70ns or faster than 70ns, the speed of EDO
DRAMs and BEDO DRAMs must be used 60ns or faster than 60ns.

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 2
There is no jumper needed for DRAM configuration, DRAMs' type and size will be
detected by system BIOS automatically.
In DRAM memory subsystem, ECC and Parity can be checked on the DRAM interface
(Functions selected by BIOS via CMOS setup, please refer to Chapter 5, the default
status is parity selected.) All SIMMs must be populated with true parity bit to
implement ECC or Parity functions.
ECC is an optional data integrity feature provided by the system. This feature provides
single-bit error correction, multiple-bit error detection, and detection of all errors
confined to single nibble for DRAM memory subsystem.
The usable DRAM modules are : (Note : S = Single-sided , D = Double-sided)
1MBx32(36)-S ( 4MB) ,
2MBx32(36)-D ( 8MB) ,
4MBx32(36)-S ( 16MB) ,
8MBx32(36)-D ( 32MB) ,
16MBx32(36)-S ( 64MB) ,
32MBx32(36)-D (128MB) .
The following table is an example for DRAM memory installation, it contains several
modules combination, but not all combination, they are for reference only.
Bank 0 Bank 1 Bank 2 Bank 3 Total
SIMM1, SIMM2 SIMM3, SIMM4 SIMM5, SIMM6 SIMM7, SIMM8 Size
4MB, 4MB 4MB, 4MB 4MB, 4MB 4MB, 4MB 32 MB
8MB, 8MB 8MB, 8MB 8MB, 8MB 8MB, 8MB 64 MB
16MB, 16MB 16MB, 16MB 16MB, 16MB 16MB, 16MB 128 MB
32MB, 32MB 32MB, 32MB 32MB, 32MB 32MB, 32MB 256 MB
64MB, 64MB 64MB, 64MB 64MB, 64MB 64MB, 64MB 512 MB
128MB, 128MB 128MB, 128MB 128MB, 128MB 128MB, 128MB 1024 MB

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 3
1. CONNECTORS
A connector is two or more pins those are used make connections to the system standard
accessories (such as power, mouse, printer,...etc.) The following is a list of connectors
on board and as well as descriptions of each individual connector.
(A) BAT1 Battery Socket (Using 3 Volts Lithium battery : CR2032)
Pin # Assignment
Battery Positive
Ground
(B) CN1 COM A (Serial Port 1) connector
COM1/2/3/4, selected by BIOS setup, using IRQ4 or 3
1 6 Pin#
Assignment Pin # Assignment
 1 DCD (Data Carrier Detect) 6 DSR (Data Set Ready)
 2 RD (Received Data) 7 RTS (Request To Send)
 3 TD (Transmit Data) 8 CTS (Clear To Send)
 4 DTR (Data Terminal
Ready)
9 RI (Ring Indicator)
5 Ground
5 9
(C) CN2 PS/2 Mouse connector
Pin # Assignment Pin # Assignment Pin # Assignment
1 Mouse Data 3 Ground 5 Mouse Clock
2 No Connection 4 + 5VSB DC 6 No Connection

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 4
(D) CN3 Power connector
11 1 Pin # Assignment Pin # Assignment
 11 + 3.3V DC 1 + 3.3V DC
 12 12V DC 2 + 3.3V DC
 13 Ground 3 Ground
 14 PS-ON 4 + 5V DC
 15 Ground 5 Ground
 16 Ground 6 + 5V DC
 17 Ground 7 Ground
 18 5V DC 8PW-OK
 19 + 5V DC 9 + 5V SB
 20 + 5V DC 10 + 12V DC
20 10
(E) CN4 PS/2 Keyboard connector
Pin # Assignment Pin # Assignment Pin # Assignment
1 Keyboard Data 3 Ground 5 Keyboard Clock
2 No Connection 4 + 5V DC 6 No Connection

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 5
(F) CN5 Parallel Port connector
(Supports SPP/EPP/ECP mode, selected by BIOS setup,using IRQ7 or
IRQ5,ECP using DMA channel 3 or 1)
114 Pin#
Assignment Pin # Assignment
 1STROBE14 AUTO FEED
 2 Data Bit 0 15 ERROR
 3 Data Bit 1 16 INIT
 4 Data Bit 2 17 SLCT IN
 5 Data Bit 3 18 Ground
 6 Data Bit 4 19 Ground
 7 Data Bit 5 20 Ground
 8 Data Bit 6 21 Ground
 9 Data Bit 7 22 Ground
 10 ACK23 Ground
 11 BUSY 24 Ground
 12 PE 25 Ground
13 SLCT
13 25
(G) CN6 COM B (Serial Port 2) connector
COM1/2/3/4, selected by BIOS setup, using IRQ3 or 4
1 6 Pin#
Assignment Pin # Assignment
 1 DCD (Data Carrier Detect) 6 DSR (Data Set Ready)
 2 RD (Received Data) 7 RTS (Request To Send)
 3 TD (Transmit Data) 8 CTS (Clear To Send)
 4 DTR (Data Terminal
Ready)
9 RI (Ring Indicator)
5 Ground
5 9
(H) CN7 Cooling Fan Power Connector
12 Pin#
Assignment Pin # Assignment
 1+12VDC 2Ground
(I) CN8 Floppy Disk Control Port connector (Using IRQ6, DMA channel 2)

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 6
(J) CN9 IDE 2 connector (Primary IDE Port, I/O address is 1F0H, using IRQ14)
(K) CN10 IDE 1 connector (Secondary IDE Port, I/O address is 170H, using
MIRQ0)
(L) CN11 IR (Infrared Rays) connector
1Pin#
Assignment
1 + 5V DC
2 No Connection
3 IR Receive
4 Ground
5IRTransmit
5
(M) CN12 Consumer IR connector (option)
1Pin#
Assignment
1 + 5V DC
2IRTransmit
3 Consumer IR Receive
4 Ground
4
(N) CN13 USB 1 (Universal Serial Bus port1) connector
1Pin#
Assignment
1 + 5V DC
2DATA 
3DATA 
4 Ground
4

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 7
(O) CN14 USB 2 (Universal Serial Bus port2) connector
1Pin#
Assignment
1 + 5V DC
2DATA 
3DATA 
4 Ground
4
(P) RS Reset Button connector
Pin # Assignment Pin1&2 Function
1 Ground Open No action
2 Reset Control Short System Reset
(Q) HL IDE HDD LED connector
Pin # Assignment
1 Pullup (+ 5V DC)
2 Signal Pin
(R) SL Sleep LED connector
Pin # Assignment
1 Ground
2 Signal Pin
(S) SS External SMI button connector
Pin # Assignment Pin1&2 Function
1 Signal Pin Open Normal operation
2 Ground Short Get into Suspend mode
(T) PW Front Panel Power Switch connector
Once pressed : Power On
Next pressed : Power Off

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 8
(U) SPEAKER Speaker connector
1Pin#
Assignment
1 + 5V DC
2 No Connection
3 No Connection
4 Speaker Data Signal
5 No Connection
5
(V) KEY LOCK Front Panel Power LED & Key-Lock connector
1Pin#
Assignment
1 Pullup (+ 5V DC for Power LED)
2 No Connection
3 Ground
4 Keyboard Lock
5 Ground
5
Explanation : ( For next section : JUMPERS )
open
1-2
1
2-3
1
1
11
short
,
,

PT-6IFB SYSTEM BOARD SPECIFICATIONS
I. 9
1. JUMPERS
A jumper is two, three or more pins which may or may not be covered by a plastic
connector plug (mini-jumper). A jumper is used for selecting different system options.
Please make sure all jumpers at correct position before this system board used.
(A) JP4-JP6 CPUs Frequency and Ratio selection quick setting
CPU
(MHz) JP4 JP5 JP6 Remark
233 MHz open open short
266 MHz short short open
300 MHz open short open
(B) JP9 Clear CMOS button
Pin # Function
1-2 Normal operation
2-3 Clear CMOS
(Note : 1. Before you clear CMOS, you must pull out the power supply
plug from the wall first.
2. Don't forget to turn this jumper return 1-2 within 3 to 5
seconds then re-plug the power supply plug in the wall. )
(C) JP10 ROM BIOS Selection
Pin # Function
1-2 For +5V FLASH ROM
2-3 For +12V FLASH ROM

PT-6IFB SYSTEM BOARD AWARD BIOS SETUP
1
I. AWARD BIOS SETUP
A. GETTING STARTED
When the system is first powered on or reset, the BIOS will enter the Power-On Self
Test routines ( POST : Display a copyright message on the screen followed by a
diagnostics and initialization procedure.) (If an EGA or VGA card is installed, the
copyright message of the video card maybe displayed on the screen first.) The BIOS
will indicate any error or malfunction by a series of beeps or display the error message
on screen.
Normally, the simulate figure 5-1 will display on the screen when the system is powered
on.
Fig. 5-1 Initial Power-On screen.
During the POST routines are progress, the following message appears :
" Press DEL to enter SETUP "
To execute the Award BIOS Setup program, press DEL key. The simulate screen in
figure 5-2 MAIN MENU will be displayed at this time.
A. MAIN MENU
ROM PCI / ISA BIOS (2A69HXXX)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
STANDARD CMOS SETUP SUPERVISOR PASSWORD
BIOS FEATURES SETUP USER PASSWORD
CHIPSET FEATURES SETUP IDE HDD AUTO DETECTION
POWER MANAGEMENT SETUP HDD LOW LEVEL FORMAT
PNP/PCI CONFIGURATION SAVE & EXIT SETUP
INTEGRATED PERIPHERALS EXIT WITHOUT SAVING
LOAD SETUP DEFAULTS

PT-6IFB SYSTEM BOARD AWARD BIOS SETUP
I. 2
ESC : Quit  : Select Item
F10 : Save & Exit Setup (Shift)F2 : Change Color
Time, Date, Hard Disk Type ...
Fig. 5-2 CMOS SETUP MAIN MENU screen.
A. CONTROL KEYS
Listed below is an explanation of the keys displayed at the bottom of the screens
accessed through the BIOS SETUP program :
Arrow Keys : Use the arrow keys to move the cursor to the desired item.
Enter : To Select the desired item.
F1 : Display the help screen for the selected feature.
(Shift)F2 : To change the screen color, total 16 colors.
ESC : Exit to the previous screen.
PgUp(-)/PgDn(+) : To modify the default value of the options for the highlighted
feature.
F5 : Retrieves the previous CMOS values from CMOS, only for the
current option page setup menu.
F7 : Loads the SETUP default values from BIOS default table, only for
the current option page setup menu.
F10 : Save all changes made to CMOS RAM, only for the MAIN
MENU.
The following pages will show the simulate screens of CMOS SETUP, each figure
contains the setup items and the default settings of them. Below each figure may or may
not contain a lists of function description for commonly used settings. For the other
settings' function description if you still needed, please feel free to contact with your
supplier.
A. STANDARD CMOS SETUP
ROM PCI / ISA BIOS (2A69HXXX)
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
Date (mm : dd : yy) : Sat, May 31 1997
Time (hh : mm : ss) : 15 : 43 : 55
