AZZA 810T Series User manual

The AZZA 810T Mainboard Series
Cover Click Here
Table Of Contents Click Here
Introduction Click Here
Hardware Installation Click Here
BIOS Management Click Here
R

1
Document NO: 8102ET-E1
Revision: 1.0V
Creation Date: 2001-08-01
Socket 370 AT Mainboard
8102T
810E2T
8102T USER’S MANUAL

2
User’s Notice
User’s Notice
Copyright
Copyright
This publication contains information that is protected by copyright. No part of it may be reproduced in
any form or by any means or used to make any transformation adaptation without prior written permission
from the copyright holders. This publication is provided for informational purposes only. The manufacturer
makes no representations or warranties with respect to the contents or use of this manual and specifically
disclaims any express or implied warranties of merchantability or fitness for any particular purpose. The
user will assume the entire risk of the use or the results of the use of this document. The manufacturer
reserves the right to revise this publication and make changes to its contents at any time, without prior
notice. 2001. All Rights Reserved.
Trademarks
Trademarks
Microsoft®MS-DOS®, WindowsTM, Windows®95, Window®98 and Windows®ME are registered
trademarks of Microsoft Corporation. Intel Pentium !!!TM and Intel Celeron TM are registered trademarks of
Intel Corporation. Award is a registered trademark of Award Software, Inc. Other trademarks and
registered trademarks of products appearing in this publication are the properties of their respective
holders.
Package Checklist
Package Checklist
This package contains the following items:
•Mainboard Users manual
•One IDE cable support ATA/33, ATA/66 or ATA100 IDE drives
•One 34-pin floppy disk drive cable
•One Driver Utility CD
•One COM Port 1 and 2 Cable with bracket
•One print port and PS/2 Cable with bracket
•One Game and Audio Cable with bracket
•One VGA Cable with bracket.
If any of these items are missing or damaged, please contact your dealer or sales representative for
assistance.
Technical Support
Technical Support
If you require additional information, assistance during installation, please contact your dealer. Your
dealer will be able to provide the latest information. If you need additional help, please visit our web site
for technical support or e-mail to us.
User's
Notice

3
Chapter 1:- Introduction Page 5
1.1. Overview................................................................................................... 5
1.1.1. Mainboard Series ................................................................................... 6
1.1.2. Mainboard Dimensions ........................................................................... 6
1.1.3. Environmental Limitations ...................................................................... 6
1.2. Features and Specifications ...................................................................... 6
1.3. System Intelligence .................................................................................. 9
Chapter 2:- Hardware Installation
Page 10
2.1. Installation Checklist................................................................................ 10
2.2. Installation Steps...................................................................................... 11
2.3. CPU, Memory and Expansion Slots............................................................ 13
2.3.1. Installation of Processor (CPU) ............................................................... 13
2.3.2. Memory Modules ................................................................................... 13
2.3.3. PCI Slots ............................................................................................... 14
2.4. Internal Connectors.................................................................................. 14
2.4.1. AT Keyboard Connector.......................................................................... 14
2.4.2. PS/2 Mouse Connector ........................................................................... 15
2.4.3. Serial Port Connectors: COM1 and COM2................................................. 15
2.4.4. Parallel Port Connector: LPT1 ................................................................. 15
2.4.5. USB Connectors: USB1, USB2, USB3 and USB4........................................ 15
2.4.6. Floppy Disk Drive (FDD)......................................................................... 16
2.4.7. Primary and Secondary IDE Connectors .................................................. 16
2.4.8. Standard Infrared Connector .................................................................. 16
2.4.9. CPU and Chassis Fan Connectors ............................................................ 17
2.410. AT Power Supply Connector.................................................................... 17
2.4.11. ATX Power Supply Connector.................................................................. 17
2.4.12. WOL (Wake-On-LAN) Connector ............................................................ 18
2.4.13. Audio/Game Port Connector.................................................................... 18
2.4.14. VGA Connector ...................................................................................... 18
2.4.15. CD Audio In Connector........................................................................... 19
2.4.16. AIR Bus Connector................................................................................. 19
2.4.17. Front Audio Connector............................................................................ 19
2.5. System Panel Buttons and LED Connectors.............................................. 20
2.5.1. PW: Power On/Off and External Suspend Switch Connector........................ 20
2.5.2. TL: Turbo LED Connector ......................................................................... 21
2.5.3. HL: IDE HDD LED Connector .................................................................... 21
2.5.4. RS: Reset Button Connector ..................................................................... 21
2.6. Speaker, Power LED and Key-Lock Connector.......................................... 21
2.6.1. Speaker Connector................................................................................... 21
2.6.2. Front Panel LED and Key-Lock Connector .................................................. 21
Table Of Contents
Table Of Contents
Table Of Contents

4
2.7. Jumper Settings.........................................................................................22
2.7.1. JP 1: OnNow Function ..............................................................................22
2.7.2. JP 2: Clear CMOS .....................................................................................23
2.7.3. JP 3: Clear Keyboard Password..................................................................23
Chapter 3:- Managing The PC BIOS Page 24
3.1. AWARD BIOS CMOS Setup Utility...........................................................24
3.2. Main Menu ..............................................................................................25
3.3. Standard CMOS Setup.............................................................................26
3.4. ADVANCED BIOS FEATURES ...................................................................28
3.5. ADVANCED CHIPSET FEATURES .............................................................31
3.6. INTEGRATED PERIPHERALS...................................................................33
3.7. Power Management Setup......................................................................37
3.8. PNP/PCI Configuration...........................................................................40
3.9. Frequency/Voltage Control ....................................................................42
3.10. Load Optimized Defaults.........................................................................43
3.11. Set Supervisor Password........................................................................43
3.12. Set User Password..................................................................................44
3.13. SAVE & EXIT SETUP/EXIT WITHOUT SAVING ........................................45
Table Of Contents
Table Of Contents
Table Of Contents

5
1.1
1.1
1.1
MAINBOARD LAYOUT
MAINBOARD LAYOUT
MAINBOARD LAYOUT
Introduction
Introduction
Chapter 1
Chapter 1
Chapter 1 -
-
-Introduction
Introduction
Introduction
CN 9 : IDE 1 CN 10: IDE 2 CN 8: FDC
DIMM 1 DIMM 2
Socket 370
CN 14: AT Power Connector
CN 15: ATX Power Connector CN 2: M/S CN 1: K/B JP1: OnNow Function CN 13: CPU Fan 1 CN 5: LPT
CN 4 : COM 2 CN 18: Game/ Audio
CN 3 : COM 1 CN 19: VGA
CN16: WOL PCI 1 PCI 2 PCI 3
USB 2 USB 1 USB 4 USB 3
CN 17: CPU Fan 2
LED 1
SPK (speaker)
PWR LED/KBLOCK System Panel and
LED Connectors
CN 12: IR
JP2: Clear CMOS
JP3: Clear K/B Password
CN 21: CD-IN
Introduction

6
1.1.1. Mainboard Series
The 810 mainboard series has two models. They are:
1. 8102T
2. 810E2T
1.1.2. Mainboard Dimensions
Width & Length: 222 mm x 210 mm. 8.27 inches x 8.74 inches
Height: 1 1/2 inches
PCB Thickness: 1.6 mm
Weight: 18 ounces.
1.1.3. Environmental Limitations
Operating Temperature: 10°C to 40°C . (50°Fto 104°F)
Required Airflow: 50 linear feet per minute across CPU.
Storage Temperature: - 40°C to 70°C. (- 40°F to 158°F)
Humidity: 0 to 90% non-condensing.
Altitude: 0 to 10,000 feet
Processor
Supports Intel® Socket 370 0.25 ц Celeron, 0.18 ц Celeron, 0.18 ц Pentium III or
VIA Cyrix C3
Chipset
Intel FW82810 (for 8102T) or Intel FW82810E (for 810E2T) and FW82801BA
Super I/O
Winbond W83627SF
CPU Switching Voltage Regulator
Equipped with a switching voltage regulator that automatically detects +1.30V to
+3.50V DC power supply.
System Memory
•8MB to 512MB of 3.3V SDRAM memory.
•Two 168-pin DIMM sockets.
•Supports PC-100 SDRAM DIMM and PC-133 SDRAM DIMM.
Introduction
Introduction
Introduction
1.2
1.2 Features and Specifications Features and Specifications

7
Expansion Slots
Three dedicated PCI slots, and one (optional) CNR (Communication Network
Riser) slot. The CNR slot provides the opportunity to install a flexible and cost
reduced method of implementing LAN, home networking, DSL, USB, wireless,
audio and modem subsystems widely used in today's "connected PCs".
Onboard Audio Features
•Supports Microsoft ® DirectSound/DirectSound 3D.
•AC97 supported full duplex, independent sample rate converter for audio
recording and playback.
Front Audio Port (Optional)
For use with a Front Utility Panel that connects Ear Phone, Microphone and Audio-
in. For more details, please consult your dealer.
Word Size
Data Path: 8-bit, 16-bit, 32-bit, 64-bit.
Address Path: 32-bit.
FRONT SIDE BUS FREQUENCY
Supports 66 MHz, 100 MHz and 133 MHz FSB. Refer to the following table:
8102T
8102T
8102T
CPU SDRAM CPU SDRAM
66 MHz 100 MHz 66 MHz 100 MHz
100 MHz 100 MHz 100 MHz 100 MHz
133 MHz 133 MHz 133 MHz 100 MHz
810E2T
810E2T
810E2T
BIOS
•Award BIOS, Windows ® 95/98 Plug and Play compatible.
•Supports SCSI sequential boot-up.
•Flash EPROM for easy BIOS upgrades (2 Mbit).
•Supports DMI 2.0 function.
Desktop Management Interface (DMI)
The mainboard comes with a DMI 2.0 built into the BIOS. The DMI utility in the
BIOS will automatically record different system configuration information and
store this information in the DMI pool, which is a part of the system board's Plug
and Play BIOS. DMI, along with the appropriately networked software, is designed
for easy inventory, maintenance and simplified troubleshooting of computer sys-
tems.
Introduction
Introduction
Introduction

8
WOL (Wake-On-Lan) Port (optional)
One WOL connector supports Wake-On-LAN functionality.
USB Ports
The mainboard is equipped with four internal USB connectors. USB allows data
exchange between your computer and a wide range of simultaneously accessible
external Plug and Play peripherals. ( Cable set for two connectors are optional and
is sold separately).
IrDA Interface (optional)
The mainboard is equipped with an IR and CIR IrDA connector for wireless
connectivity between your computer and peripheral devices. It supports peripheral
devices that meet the HPSIR or ASKIR standard.
Connectors
•One connector for SIR and one connector for CIR IrDA interface.
•One floppy drive interface supports up to two 2.88MB floppy drives.
•One ATX and one AT power supply connector.
•One CPU and one chassis fan connector.
•One CD audio-in connector.
•One Front Audio Connector supports a Front Utility Panel.
•Two NS16C550A-compatible DB-9 serial port connectors (UARTs).
•One SPP/ECP/EPP DB-25 parallel port.
•One internal PS/2 mouse port connector.
•One AT keyboard port.
•One Audio/Game connector.
•One VGA connector.
PCI Bus Master IDE Controller
•Two PCI IDE interfaces support up to four IDE devices.
•Support ATA/33, ATA/66 and ATA100 hard disk drives.
•PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up to 16.6MB/
sec.).
•Bus mastering reduces CPU utilization during disk transfer.
•Supports ATAPI CD-ROM, LS-120 and ZIP
Introduction
Introduction
Introduction

9
Dual Function Power Button
 Depending on the setting in the Soft-Off By Power-Button field of the Power
Management Setup, this switch allows the system to enter the Soft-Off or Suspend
mode.
External Modem Ring-on (optional)
 The Modem Ring-on feature allows the system that is in the Suspend mode
or Soft Power Off mode to wake-up/power-on to respond to incoming calls. This
feature supports external modem only.
RTC Timer to Power-on the System
 The RTC installed on the system board allows your system to automatically
power-on on the set date and time.
Wake-On-LAN Ready (optional)
 The Wake-On-LAN function allows the network to remotely wake up a Soft
Power Down (Soft-Off) PC. Your LAN card must support the remote wakeup
function. The 5VSB power source of your power supply must be at least 720mA.
ACPI Ready
 The mainboard is designed to meet the ACPI (Advanced Configuration and
Power Interface) specification. ACPI has energy saving features supporting OS
Direct Power Management (OSPM) for round the clock PC operation.
Introduction
Introduction
Introduction
1.
1.3 3Intelligence Intelligence
