1.2.1. The KM266-MVB Mainboard
The KM266-MVB mainboard is a Socket A DDR platform for AMD Athlon XP,
Athlon and Duron processors. It provides two DDR DIMM sockets (support
DDR200/266). The supported FSB clock is 200/266 MHz. Onboard it has two
IDE interfaces which support ATA 33/66/100/133. Additionally, it comes with
Onboard Audio (AC’97 2 channels) and Onboard VGA.
1.2.2. Mainboard Dimensions
Width 244 mm
Length 200 mm
1.2.3. Environmental Limitations
Operating Temperature: 10°C to 40°C (50°F to 104°F)
Required Airflow: 50 linear feet per minute across the CPU
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 0 to 90% non-condensing
Altitude: 0 to 10 000 feet
Introduction
!"#$!
Processor
The KM266-MVB mainboard supports Socket A CPUs such as AMD Athlon XP,
Athlon and Duron processors.
Chipsets
Northbridge: VIA KM266
Southbridge: VIA VT8235(CD)
I/O Chipset: Winbond W83697HF
PC 99 ATX External Connector
CN2: MS
CN1: KB
CN5: LPT CN18: GAME/MIDI
CN7: USB2
CN6: USB1 CN19: VGA
CN3: COM1 SPK-OUT
LINE-IN
MIC-IN
The KM266-MVB Mainboard Page 7
CPU Switching Voltage Regulator
The mainboard is equipped with a switching voltage regulator that automati-
cally detects a DC power supply from +1.10V to +1.85V.
System Memory
The mainboard uses Double Data Rate Dual Inline Memory Modules (DDR
DIMM). Each mainboard has two 184-pin DIMM sockets which support 2.5V
(power level) single-sided or double-sided PC1600 (DDR200) or PC2100
(DDR266) DDR DIMM modules.
Expansion Slots
The mainboard is equipped with three dedicated PCI slots and one 1.5V
2X/4X AGP slot.
Onboard Audio Feature
The mainboard supports Microsoft DirectSound/DirectSound 3D and AC97 2
channels. The AC’97 Codec is ALC202A.
WOL (Wake-On-LAN) Connector
The mainboard supports Wake-On-LAN functionality.
Word Size
Data Path: 8-bit, 16-bit, 32-bit, 64-bit
Address Path: 32-bit
Front Side Bus Frequency (FSB)
The Front Side Bus Frequency (FSB) clock is 200/266 MHz.
BIOS
!Award BIOS, Windows 95/98 Plug and Play (PnP) compatible
!Supports SCSI sequential boot-up
!2 Mb flash ROM for easy BIOS upgrades
!Supports DMI2.0 function
Desktop Management Interface (DMI)
The mainboard comes with DMI2.0 built into the BIOS. The DMI utility in the
BIOS will automatically record different information about your system
configuration and store this information in the DMI pool, which is a part of the
system board's Plug and Play BIOS. DMI, along with the appropriately
networked software, is designed for easy inventory, maintenance and the
simplified troubleshooting of computer systems.
Introduction
The KM266-MVB Mainboard
Page 8
Connectors
!Two IDE connectors (support ATA 33/66/100/133)
!One Floppy Drive connector supports up to two 2.88 MB floppy drives
!One power supply connector
!Two fan connectors
!One CD-IN connector, one AUX-IN connector
!One WOL (Wake-On-LAN) connector
!One front audio connector
!Four USB2.0 port connectors (Intel type)
ATX Double Deck Ports (PC 99 color-coded connectors)
!Two USB2.0 ports
!One external DB-9 serial port connectors: COM1(UART)
!One SPP/ECP/EPP DB-25 parallel port
!One mini-DIN-6 PS/2 mouse port
!One mini-DIN-6 PS/2 keyboard port
!One VGA port
!One GAME port
!Three audio jacks: SPK-OUT, LINE-IN and MIC-IN
PCI Bus Master IDE Controller
!Two PCI IDE interfaces support up to four IDE devices.
!This mainboard supports ATA 33/66/100/133 hard drives.
!PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up to
16.6MB/sec.).
!Bus mastering reduces CPU utilization during disk transfer.
!Supports ATAPI CD-ROM, LS-120 and ZIP.
Introduction
USB2.0 Ports
USB allows data exchange between your computer and a wide range of
simultaneously accessible external Plug and Play peripherals. The mainboard is
equipped with six USB (version 2.0) connectors. USB1 and USB2 are external
connectors. They can be found on the PC 99 ATX connector. The other USB
connectors are internal connectors and can be used to connect other USB
devices. (Cables for the internal connectors are sold separately).
!"
The KM266-MVB Mainboard Page 9
Introduction
Hardware Monitoring System Utility
The mainboard comes with the Hardware Monitoring System utility contained
on the CD. It is capable of monitoring the system’s hardware conditions such
as the temperature of the processor, voltage, and the speed of both the CPU
and chassis fans. You are allowed to manually set a range to the items being
monitored. If the values are over or under the set range a warning message
will automatically pop up. We recommend that you use the Default Settings,
which are the ideal settings that will maintain the system in a good working
condition. To install this utility, please insert the CD into the CD-ROM drive.
The auto run screen (Driver Utility) will automatically appear. Click the Hard-
ware Monitoring button, choose the chipset, model number and the OS that is
installed. Please refer to the CD “Readme” file for further installation instruc-
tions.
Note: Only use this utility in Windows operating systems.
The mainboard is capable of monitoring the following health conditions of your
system:
1. Processor temperature. It has an overheat alarm.
2. VCORE/3.3V/5V/12V/-12V voltages and failure alarm.
3. Processor and chassis fan speeds. It has a failure alarm for these fans.
4. Read back capability that displays temperature, voltage and fan speed.
%"!&'( !
Dual Function Power Button
Depending on the setting in the Soft-Off By Power-Button field of the Power
Management Setup, this switch allows the system to enter the Soft-Off or
Suspend mode.
RTC Timer to Power-on the System
The RTC installed on the system board allows your system to automatically
power-on at a set date and time.
Wake-On-LAN Ready
The Wake-On-LAN function allows the network to remotely wake up a Soft
Power Down (Soft-Off) PC. Your LAN card must support the remote wakeup
function. The 5V SB power source of your power supply must be at least
720mA.
ACPI Ready
The mainboard is designed to meet the ACPI (Advanced Configuration and
Power Interface) specification. ACPI has energy saving features that support
OS Direct Power Management (OSPM) for round the clock PC operation.
)"!&*+
The KM266-MVB Mainboard
Page 10
The following is a checklist of all the expansion slots, jumpers and connectors
that should be configured on your mainboard before you can run your PC.
*!(,!
Installation Checklist
Expansion Slots and Sockets
CPU Socket
DIMM Slots
PCI Slots
AGP Slot
Socket A CPUs
Two 184-pin Slots
Three 32-bit PCI Slots
One 1.5V 4X/2X Accelerated Graphics Port Slot
Internal Connectors
CN8
CN9
CN10
CN13
CN15-A
CN16
CN17
CN21
CN30/31
CN32/38
CN39
CN45
Floppy Drive Connector
Primary IDE
Secondary IDE
CPU Fan
ATX Power Supply
Wake-On-LAN Connector
Chassis Fan
CD Audio In
Universal Serial Bus 3/4
Universal Serial Bus 5/6
Front Audio Connector
Auxiliary In Connector
FDC
IDE1
IDE2
FAN1
ATX
WOL
FAN2
CD-IN
USB3/4
USB5/6
Front Audio
AUX-IN
CN1
CN2
CN3
CN5
CN6
CN7
CN18
CN19
PS/2 Keyboard Connector
PS/2 Mouse Connector
Serial Port 1
Parallel Port
Universal Serial Port 1
Universal Serial Port 2
Audio/GAME Port
VGA Connector
KB
MS
COM1
LPT
USB1
USB2
AUDIO/GAME
VGA
External Connectors
Hardware Installation
The KM266-MVB Mainboard Page 11
You need to complete the following installation steps before you can use your
PC. !Check and set the mainboard settings;
!Install the Central Processing Unit (CPU);
!Install the memory modules;
!Install the expansion cards;
!Connect the ribbon cables, panel wires and power supply;
!Setup the system BIOS.
Before you start installing your mainboard we strongly recom-
mend that you use a grounded anti-static mat. We further rec-
ommend that you attach an anti-static wristband, which is
grounded at the same location as the mat, to your wrist.
*!"#!
Hardware Installation
Installation Checklist (Continued)
Speaker and Power LED Connectors
PW
HL
RS
Power On/Off and Suspend Switch Connector
HDD LED Connector
Reset Button Connector
Speaker and Power LED Connectors
PWLD
SPK Power LED
Speaker Connector
Jumpers and Switches
JP1
JP3 KB/MS Power
Clear CMOS
The KM266-MVB Mainboard
Page 12
Hardware Installation
#!"!-.&#!*!
!"##$
%&"'
(
)
*
+
!"
!"##$
!"##$
%&"'
(
)
*
+
*
+
!"
The KM266-MVB Mainboard Page 13
2.4.2. Memory Modules
The mainboard has two 184-pin DDR DIMM slots which are located on the
right-hand side of the board. The maximum supported memory is 2 GB. To
install the DIMMs into these slots, make sure the white lever at each side of
the slot has been pulled down to an angle of approximately 45. Make sure
that the DIMM is in the correct orientation. Place the DIMM on the slot and
push down firmly.The white levers will come back up and lock the module in
place.
Hardware Installation
2.4.1. Installation of the CPU
To install your processor, please complete the following set of instructions:
1. Locate a small dot marked on the top of the CPU. This mark indicates Pin
of the CPU.
2. Locate Pin 1 for the Socket on the mainboard.
3. There is a lever on the side of the socket. First push this lever sideways
and then lift it to a 90-degree angle.
4. Insert the CPU into the Socket. Please make sure that Pin 1 for the CPU is
inserted into Pin 1 of the Socket.
5. When the CPU is installed correctly push the lever back into place.
6. Install a proper heat sink with cooling fan for proper heat dissipation.
Failing to install a heat sink with cooling fan may cause overheating which
will burnout your CPU and damage your mainboard.
IMPORTANT: CPU COOLING FAN
Please ensure that you have an approved heat sink with cooling fan.
Without a proper heat sink with cooling fan you will damage both the
mainboard and the CPU.
%/-&#!"!
Important: The DIMM’s can only be fitted into the slots in one orienta-
tion. Make sure that the DIMM’s are in the correct orientation and the
pins are correctly aligned before you insert them.
* *
Top View of a 184-pin DIMM Slot
The KM266-MVB Mainboard
Page 14
2.4.3. PCI Slots
The mainboard comes with three PCI slots. They are located on the left-hand
side of the board. Both PCI and PCI expansion cards may require IRQ’s. This
mainboard complies with Plug and Play (PnP) specifications. Whenever a PnP
compliant card is added the system will automatically be configured and the
IRQ’s will be assigned automatically.
Hardware Installation
#$6<&$C)3/0
$73/8%)73/ 83/#$#:0
*) # */ #* * C $ $
%04%/#$$C3/)*$#**0
C/3/C
*$*9
+ <$)$#>))$6#C:0
, )C%#
+ " %# C$ "# $) $ # 3/
$6
+ <$)##$)*$6
*)))$&)'*)!(&'!+*$
* *
Top View of a 32-bit PCI Slot
2.4.4. AGP (Accelerated Graphics Port) Slot
AGP is a dedicated bus slot. It operates at 66 MHz and transfers data at a rate
up to 2133 MB/s. This allows 3D applications to run more smoothly. The main-
board comes with a 1.5V AGP slot which is able to support 2X/4X AGP cards.
Top View of an AGP Slot
* *
The KM266-MVB Mainboard Page 15
Hardware Installation
2.5.1. Floppy Disk Drive Connector
Connector: CN8 (FDC)
Type: 34 pin block
The FDC connector can support two floppy drives. To connect, use the ribbon
cable that has been provided. Make sure that the red strip is connected to Pin
1 of the connector.
)*!
2.5.2. Primary and Secondary IDE Connectors
Connector: CN9 (IDE1)/CN10 (IDE2)
Type: 40 pin block
The mainboard has two IDE connectors: a primary and secondary. Each IDE
connector can support two IDE drives. The mainboard each can therefore sup-
port up to four IDE devices. If you install two hard drives, you need to config-
ure the second drive to Slave mode in the BIOS setup. Please refer to your
hard drive manual for the appropriate jumper settings.
Top View of an
IDE Connector
*
Pin 1
Top View of a Floppy
Disk Drive Connector !
5*
2.5.3. CPU Fan and Chassis Fan Connectors
Connector: CN13 (FAN1)/CN17 (FAN2)
Type: 3 pin
The cooling fans must be connected to their respective power connectors. If
you have installed the hardware-monitoring feature you will be able to monitor
the rotating speed of the CPU cooling fan in your Windows operating system.
Fan Signal +12V DC
Ground
1 Ground
2 +12V DC
3 Fan Signal
Top View of a Fan Connector Front View of a Fan Connector
The KM266-MVB Mainboard
Page 16
Hardware Installation
2.5.5. CD-IN/AUX-IN Connector
Connector: CN21/CN45
Type: 4 pin un-housed
The mainboard has one CD-IN connector and one AUX-IN connector. The CD-
IN connector is used to connect the CD ROM audio out and allows the system
to receive audio input from the CD ROM. The AUX-IN connector allows the
system to receive signals from other audio devices like a radio or tape.
2.5.4. ATX Power Supply Connector
Connector: CN15-A
Type: 20 pin block
The mainboard comes with an onboard power supply connector labeled CN15-
A. CN15-A is a regular ATX power supply connector. This must be connected to
an ATX power supply. The plug from the power supply can only be inserted in
one orientation. Make sure the pins are correctly aligned. Find the correct ori-
entation and push the plug down firmly.
ATX Power Supply Connector
Pin 1
+3.3VDC
+3.3VDC
COM
+5VDC
COM
+5VDC
COM
PWR_OK
+5VSB
+12VDC
+3.3VDC
-12VDC
COM
PS_ON#
COM
COM
COM
-5VDC
+5VDC
+5VDC
Pin 11
1 Left Channel CD/AUX-IN
2 Ground
3 Ground
4 Right Channel CD/AUX-IN
Top View of a CD/AUX-IN
Connector Front View of a CD/AUX-IN
Connector
RightChannel
CD-IN/
AUX-IN
Left Channel
CD-IN/
AUX-IN
Ground Ground
The KM266-MVB Mainboard Page 17
Hardware Installation
2.5.6. WOL (Wake-On-LAN) Connector
Connector: CN16 (WOL)
Type: 3 pin
The mainboard has a WOL (Wake-On-LAN) connector. This connector must be
connected to a LAN card that has Wake-On-LAN (WOL) output. This connector
powers up the system when a wakeup packet or signal is received through the
LAN card.
In order to use the WOL LAN card to trigger the power on the PC system, the
switching power supply must have the ability to provide a driving current of at
least 720 mA and be connected to a “5V standby” voltage.
WOL
5V_SB
Ground
1 5V_SB
2 Ground
3 WOL
Top View of a WOL Connector Front View of a WOL Connector
2.5.7. USB3, USB4, USB5, USB6 Connectors
Connector: CN30 (USB3)/CN31 (USB4)/CN32 (USB5)/CN38 (USB6)
Type: 5 pin
You already have two USB2.0 ports available, USB1 and 2 (see external con-
nectors). The internal USB connectors allow you to add on an optional kit to
expand the total number of USB ports available. The mainboard has four inter-
nal USB2.0 connectors (CN30/CN31/CN32/CN38). This enables you to use ex-
tra four USB devices. Cable for these additional connectors needs to be pur-
chased separately.
Note: The PIN assignment of the internal USB 2.0 connectors (CN30,
CN31, CN32 and CN38) follows the specifications of Intel standard.
Top View of USB Ports Front View of USB Ports
7 Ground
5 Data+
3 Data-
1 VCC 2 VCC
4 Data-
6 Data+
8 Ground
10NC
USB3/5 USB4/6
1 VCC
3 Data -
5 Data +
7 Ground
2 VCC
4 Data -
6 Data +
8 Ground
10 NC
USB3/5 USB4/6
The KM266-MVB Mainboard
Page 18
Hardware Installation
2.5.8. Front Audio Connector
? 1
(? *
The front audio connector is an innovative development. This connector is de-
signed to be used with a Front-Utility Panel. The utility panel was developed so
that a user is able to bring the speaker out, microphone in connectors to the
front of their PC. This makes things like plugging in speakers and earphones
much less troublesome.
10
9
8
7
6
5
4
3
2
1
Pin Pin
1 MIC-IN (Left) 2 Ground
3 MIC-IN (Right) 4 NC
5 LINE-OUT R 6 NC
7 NC 8 Key
9 LINE-OUT L 10 NC
Front Audio Connector
0"!&1!2!
The following System Panel Buttons
and LED Connectors (2 x 4 pins) can
be found at the front of the main-
board on the left hand side.
PW= Power On/Off and Suspend
Switch Connector
HL = HDD LED Connector
RS = Reset Button Connector
2.6.1 PW: Power On/Off and External Suspend Switch Connector
The Power On/Off connector has two functions. It can be the Power Switch or
Suspend Switch of your PC system. You can either choose “Delay 4 Sec” or
“Instant OFF” .
Option 1: If you choose “Delay 4 Sec.” In the BIOS CMOS Setup, the func-
tion of “PW” will be:
A. When the system power is "OFF", press this switch, the system will
power on.
B. When system power is "ON”, you can select two different modes:
Top View of the System Panel
and LED Connectors
!1
D> !$"*
!/ '$
'$
<
%C!
The KM266-MVB Mainboard Page 19
Mode 1: Press and hold the Power ON button for less than 4 seconds and then
release it. The system will be turned into Suspend mode (turned into the
GREEN mode) When the system is in the Suspend mode:
!""Press the Power on button (less than 4 seconds), the system will return
to Full-ON mode.
!""Press and hold the Power On Button for more than 4 seconds, the sys-
tem will be powered off.
Mode 2: Press and hold the Power ON button for more than 4 seconds, the
system will be completely powered off.
Option 2: If you choose “Instant OFF.” In the BIOS CMOS Setup, the power
switch will operate like a normal ON / OFF Power button.
2.6.2. HL: IDE HDD LED Connector
Any read and write activity by the HDD will turn this LED on.
2.6.3. RS: Reset Button Connector
If you connect this connector, you will be able to reset you computer by press-
ing the reset button at the front of the chassis.
Hardware Installation
3"#,2!
2.7.1. Speaker Connector
(SPK)
Connect your chassis speaker to
this four-pin connector. It allows
you to hear systems beeps and
warnings sound.
2.7.2. Front Panel Power LED
(PWRLED)
The chassis power LED connector
can be connected to the four-pin
connector. When you turn your
system on, this LED will also be
turned on.
PIN 1
SPK
+5V DC
Speaker Signal
Ground
NC
PWRLED
Top View of the Power LED
and Speaker Connectors
+5V DC
Speaker Signal
Speaker Signal
NC
PIN 1
The KM266-MVB Mainboard
Page 20
Hardware Installation
4!
2.8.1. PS/2 Keyboard Connector
This connector only supports a PS/2 keyboard plug. If you have a standard AT
size (large DIN) keyboard plug, you need to use a mini DIN adapter.
Connector: CN1 (KB)
Type: 6 pin female
2.8.2. PS/2 Mouse Connector
This connector only supports a PS/2 mouse plug. If a PS/2 mouse is de-
tected then IRQ 12 will be directed to CN2.
Connector: CN2 (MS)
Type: 6 pin female
Connector: CN3 (COM1)
Type: 9 pin male
One serial port is available for a mouse and
other serial devices. (I/O addresses used are
3F8H/2F8H/3E8H/2E8H and IRQ3/IRQ4,
selected by CMOS setup.)
2.8.3. Serial Port Connector
2.8.4. VGA Connector
Connector: CN19
Type: 15 pin female.
Connect your VGA monitor adapter to this
connector.
Connector: CN5 (LPT)
Type: 25 pin female.
This parallel port is used by printers which
support the SPP, EPP and ECP modes IRQ7
or IRQ5 can be selected. The ECP mode will
use either DMA 3 or DMA 1 (which can be
selected by the BIOS setup program).
2.8.5. Parallel Port Connector
Table of contents
Other AZZA Motherboard manuals
Popular Motherboard manuals by other brands
Texas Instruments
Texas Instruments INA219EVM user guide
Texas Instruments
Texas Instruments ADS54J69EVM user guide
iWave
iWave iW-RainboW-G33D Hardware user's guide
BeagleBone
BeagleBone Black Reference manual
Fujitsu Siemens Computers
Fujitsu Siemens Computers D1961 Technical manual
Asus
Asus Z97-PRO GAMER manual
