Batca LINK LD-4 User manual

www.batcafitness.com LD-4 Owner’s Manual
October 2020
LD-4 Leg Extension/ Seated Leg Curl
Owner’s Manual
Serial Number Here
Date of Purchase

Batca Fitness Systems 2LD-4 Owner's Manual
__________ Page
Instructions 2
Parts Listing 3-4
Main Assembly 5-18
Upholstery 13-14
Cable Routing 15-16
__________ Page
Final Assembly and Troubleshooting 19
Cable Tension and Adjustments 20
Maintenance 21
Warranty 22
Floor Plan Layout 23
Congratulations on the purchase of your new Batca LD-4 Leg Extension/Seated Leg Curl
machine. This gym will provide you with a lifetime of enjoyment to meet your strength training
needs. Batca Fitness Systems strives to build the best quality gyms and to package these
gyms in such a way to avoid any damage during shipping.
In order to get started with your assembly you should rst familiarize yourself with this
manual. It is recommended that you read through each step thoroughly before you begin.
Begin by opening your boxes and separating all of your parts. Verify that all parts are accounted
for and have no damage. When all parts are accounted for, you may begin your assembly.
Some items may have been pre-assembled for your convenience. Please note that hardware
quantities shown reect total quantities for your gym and may not reect actual quantities in
each bag. Assemble your gym on a solid level surface. This will ensure the best possible
performance, function, and safety for the gym and your workout.
Assemble your gym according to the step by step instructions found in this manual. Failure
to do so will void your warranty and may result in personal injury. After assembly, you should
check each station to ensure correct operation. If a problem arises, recheck your assembly with
these instructions to verify correct assembly. If you are unable to correct a problem or have
questions with your assembly please contact your authorized Batca dealer.
Batca Fitness Systems has built this gym to give you a safe, effective and enjoyable
workout. However, there is a risk assumed by individuals who use this type of equipment. It is
very important that all warnings and instructions are read and followed before beginning any
exercise program.
It is also very important to read and follow the preventative maintenance schedule
described in this manual. If any of the warning labels or stickers are worn, faded, torn,
scratched or missing they should be replaced immediately.
WARNING: There is a risk assumed by individuals who use this type of equipment. To
minimize risk always follow these rules.
1)It is essential that you consult with your physician before beginning any exercise program.
2)Inspect equipment before each use for loose, worn, or frayed parts (including cables, nuts
and bolts). Replace parts at rst signs of wear (use only genuine BATCA replacement parts).
Use of equipment that is damaged, worn, frayed or not completely assembled on a solid,
level surface may result in injury.
3)Make sure all adjustment pins are fully engaged before using equipment.
4)Keep all parts of the body and clothing outside the path of any moving parts of the gym. Be
alert to the possibility of injury. Do not be careless.
5)Minors and children should not be allowed to play on or around this gym.
6)If you have any questions on proper use or maintenance of this gym, do not hesitate to call
your local BATCA FITNESS SYSTEMS distributor or BATCA FITNESS SYSTEMS at (919) 255-
1233. www.batcatness.com
Table of Contents
Instructions
Warning

www.batcafitness.com 3LD-4 Owner’s Manual
Tools Required
• 9/16” Wrench/Ratchet
• Metric Allen Wrench Set (M8, M6, M4)
• 3/4” Wrench
• Tape Measure
Hardware Blister Pack

Batca Fitness Systems 4LD-4 Owner's Manual
Hardware Blister Pack

www.batcafitness.com 5LD-4 Owner’s Manual
Item # Part # Description Qty
1BFP-10866 LD-4 Cage 1
2BFP-10864 Connector Base 1
3BFP-10863 Leg Ext/Leg Curl Frame 1
4BFP-51861 Anti Deection Plate 1
58 BFP-51750 SHCS 3/8” x 2 3/4” 2
61 BFP-51748 SHCS 3/8” x 3 1/4 2
70 BFH-50146 3/8” Flat Washer 8
71 BFH-50157 3/8” Nylock 4
LD-4
Step 1:
Note: Please Position Hardware in the same direction as shown in the figure. This will
make future steps easier to assemble
PLEASE READ AND FOLLOW ALL DIRECTIONS VERY CAREFULLY FOR PROPER INSTALLATION.
All Flat Washers and Nylocks are 3/8” unless otherwise noted. Anywhere a washer is against the
round side of a tube there is to be a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
DO NOT TIGHTEN BOLTS UNTIL STEP 4

Batca Fitness Systems 6LD-4 Owner's Manual
Item # Part # Description Qty
5BFP-10874 Elbow Support 1
6BFP-51836 Curved Anti Deection Plate 1
60 BFP-51747 SHCS 3/8” x 3” 2
65 BFP-51756 SHCS 3/8” x 5 1/4” 2
67 BFH-50204 3/8” Curved Washer 4
70 BFH-50146 3/8” Flat Washer 4
71 BFH-50157 3/8” Nylock 4
Step 2: DO NOT TIGHTEN BOLTS UNTIL STEP 4
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Anywhere a washer is against the round side of a tube there is to be
a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.

www.batcafitness.com 7LD-4 Owner’s Manual
Make sure the two set
screws in the Guide Rod
Sleeve are facing towards the
front of the weight stack and the
sleeve is pushed up against the
rubber grommet of the Guide Rod
Plate. Once it is in place, tighten
the set screws to keep it in place.
Item # Part # Description Qty
7BFP-10839 Cable Lockout Plate 1
8BFP-10827 Guide Rod Plate 1
9BFP-53259 Guide Rod Sleeve 2
10 BFM-10413 Top Weight Plate 1
11 BFM-50632 Weight Plate 19
12 BFP-51827 Guide Rod 2
13 BFM-50529 Rubber Donut 2
40 BFM-51173 Weight Stack Pin with Lanyard 1
14 BFP-10873 Left Handle 1
15 BFP-10872 Right Handle 1
62 BFP-51760 SHCS 3/8” x 3 1/2” 2
63 BFP-51884 SHCS 3/8” x 4 1/4” 2
64 BFP-51850 SHCS 3/8” x 5” 2
67 BFH-50204 3/8” Curved Washer 6
70 BFH-50146 3/8” Flat Washer 6
71 BFH-50157 3/8” Nylock 6
Step 3: DO NOT TIGHTEN BOLTS UNTIL STEP 4
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Anywhere a washer is against the round side of a tube there is to be
a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.

Batca Fitness Systems 8LD-4 Owner's Manual
Item # Part # Description Qty
16 BFP-10865 Leg Ext./Curl J-Brace 1
17 BFP-51863 Anti Deection Plate 1
18 BFP-10948 Adjustment Tube 1
48 BFP-52371 5/16” x 1/2” 2
61 BFP-51748 SHCS 3/8” x 3 1/4” 2
64 BFP-51850 SHCS 3/8” x 5” 2
67 BFH-50204 3/8” Curved Washer 4
70 BFH-50146 3/8” Flat Washer 4
71 BFH-50157 3/8” Nylock 4
Step 4:
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Anywhere a washer is against the round side of a tube there is to be
a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
Make sure all bolts are tightened before moving on

www.batcafitness.com 9LD-4 Owner’s Manual
Item # Part # Description Qty
19 BFP-10867 Leg Ext/Leg Curl Cam 1
20 BFP-52177 Axle 1
21 BFP-10871 Knee Alignment Roller 1
52 BFH-50245 FHSCS 5/16” x 1” 2
68 BFH-50165 1” Snap Ring 2
Step 5: Make sure all bolts are tightened before moving on

Batca Fitness Systems 10 LD-4 Owner's Manual
Item # Part # Description Qty
22 BFP-10869 Knee Hold Down Adjustment Plate 1
23 BFP-10868 Leg Ext/Curl Arm 1
24 BFP-51885 Red Pivot Point Cap 1
25 BFP-51874 6” Counterweight 1
75 BFH-50620 BHSCS 3/8” x 1” 1
57 BFP-52372 SHCS 3/8” x 2 1/2” 2
66 BFP-52364 SHCS 3/8” x 6” 1
70 BFH-50146 3/8” Flat Washer 5
71 BFH-50157 3/8” Nylock 2
Step 6: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

www.batcafitness.com 11 LD-4 Owner’s Manual
Item # Part # Description Qty
26 BFP-10870 Knee Roller Assembly 1
27 BFP-51909 Axle 1
60 BFP-51747 SHCS 3/8” x 3” 1
52 BFH-50247 3/8” Thin Nylock 1
70 BFH-50146 3/8” Flat Washer 2
Step 7:
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Make sure all bolts are tightened before moving on

Batca Fitness Systems 12 LD-4 Owner's Manual
Item # Part # Description Qty
28 BFP-10857 Back Support Tube 1
29 BFP-52149 Anti Deection Plate 1
59 BFP-52374 FHSCS 3/8” x 2 3/4” 2
70 BFH-50146 3/8” Flat Washer 2
71 BFH-50157 3/8” Nylock 2
Step 8: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

www.batcafitness.com 13 LD-4 Owner’s Manual
Item # Part # Description Qty
41 BFP-52137 Head Pad 1
42 BFP-52136 Back Pad with Lumbar 1
43 BFP-52130 Large Bottom Pad 1
58 BFP-51750 SHCS 3/8” x 2 3/4” 4
61 BFP-51748 SHCS 3/8” x 3 1/4” 2
70 BFH-50146 3/8” Flat Washer 6
72 BFH-50147 3/8” Lock Washer 6
Step 9: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

Batca Fitness Systems 14 LD-4 Owner's Manual
Item # Part # Description Qty
30 BFH-50622 Large Aluminum End Cap 4
36 BFM-10588 Knee Hold Down Handle 1
44 BFU-10121 7” (Small) Upholstered Roller 4
45 BFU-10122 17” (Large) Upholstered Roller 1
50 BFP52373 BHSCS 3/8” x 3/4” 4
54 BDH-51759 SHCS 3/8” x 2” 1
67 BFH-50204 3/8” Curved Washer 2
71 BFH-50157 3/8” Nylock 1
73 BFH-50221 3” Plastic Washer 4
Step 9: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Anywhere a washer is against the round side of a tube there is to be
a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.

www.batcafitness.com 15 LD-4 Owner’s Manual
CAB-15010
50”
Note: The threaded bolt on
the end of the cable must
be threaded at least 1/2” the
Top Plate of the weight stack.
The bolt must also be secured
with a 1/2” Jam Nut to ensure a
safe and proper connection.
Item # Part # Description Qty
38 CAB-15010 Weight Stack to Lockout Cable 1
31 BFP-10838 Free Floater 1
46 BFH-50174 4 1/2” Pulley 1
47 BFH-50530 5” Pulley 1
56 BFP-51752 SHCS 3/8” x 2 1/4 2
53 BFH-50351 1 3/8” Shoulder Bolt 1
69 BFH-50267 5/16” Nylock 1
70 BFH-50146 3/8” Flat Washer 4
71 BFH-50157 3/8” Nylock 2
74 BFH-50227 Cable Strap End 1
1 3/8” Shoulder Bolt
Step 10: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

Batca Fitness Systems 16 LD-4 Owner's Manual
CAB-15005
74 7/16” Item # Part # Description Qty
39 CAB-15005 Free Floater to Leg Ext./Curl Cam 1
37 BFP-51883 Double Pulley Cover 1
46 BFH-50174 4 1/2” Pulley 5
53 BFH-50351 1 3/8” Shoulder Bolt 1
54 BFP-51759 SHCS 3/8” x 2” 1
55 BFP-52377 FHSCS 3/8” x 2” 2
56 BFP-51752 SHCS 3/8” x 2 1/4” 2
69 BFH-50267 5/16” Nylock 1
70 BFH-50146 3/8” Flat Washer 6
71 BFH-50157 3/8” Nylock 5
74 BFH-50227 Cable Strap End 1
1 3/8”
Shoulder
Bolt
Step 11: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Note: The threaded bolt on
the end of the cable must
be threaded at least 1/2” in the
Free Floating Pulley. The bolt
must also be secured with a 1/2”
Jam Nut to ensure a safe and
proper connection.

www.batcafitness.com 17 LD-4 Owner’s Manual
Item # Part # Description Qty
32 BFP-51740 Rear Weight Stack Shroud 1
33 BFP-51711 Placard Plate 1
50 BFP-52373 BHSCS 3/8” x 3/4” 4
49 BFH-50254 HCS 3/8” x 3/4” 2
70 BFH-50146 3/8” Flat Washer 4
Step 12: DO NOT tighten the four bolts for the Rear Weight Stack Shroud until next step
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

Batca Fitness Systems 18 LD-4 Owner's Manual
Item # Part # Description Qty
34 BFP-51741 (Left) Front Weight Stack Shroud 1
35 BFP-51742 (Right) Front Weight Stack Shroud 1
Step 13: Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.

www.batcafitness.com 19 LD-4 Owner’s Manual
Free Floater
Final Assembly and Troubleshooting
200lb Stack
Weight Stack Decals:
IMPORTANT - Check These Components Before Using
• Each Cable with a threaded bolt on either end must be
threaded at least 1/2” into its attachment, whether it be a
Free Floater, Lockout Free Floater, or the Top Plate of the
weight stack. Each must also be secured with a 1/2” Jam
Nut to ensure a safe and proper connection.
Top Plate
• Record your serial number on the front of this manual and keep for
your records. The serial number can be found on the side of the
cage as seen in the gure to the left.
Guide Rod
• Clean guide rods with a lint-free cloth and apply a thin layer of silicone lubricant (Part # BFH-50262)
to each guide rod. This will ensure a glass smooth performance from your weight stack.

Batca Fitness Systems 20 LD-4 Owner's Manual
• Adjust cables to proper tension from any of the locations shown below.
Note: All cables with threaded adjustable ends must have at least 1/2” of the threads threaded in to its counterpart.
It is very important that the 1/2” Jam Nut be wrench tightened to the counterpart to ensure that the threaded ad-
justable end of the cable does not back out of its counterpart.
• Note: If the top plate raises off of the second plate in the weight stack, then the cable tension is too tight. You will need
to take some of the tension out to lower the Top plate ush with the second plate.
Cable Adjustments
1
2
