Bay Tek Games SINK IT SHOOTOUT! User manual

1

2
FACTORY CONTACT INFORMATION
BAY TEK GAMES INC.
Pulaski Industrial Park
1077 East. Glenbrook Drive
Pulaski, WI 54162 USA
JOIN OUR SERVICE FIRST NETWORK!
This free service is intended to keep you up to date on the latest
game information, early notication of parts specials, pertinent
technical bulletins, updates on retro t parts, software upgrades,
and much more.
Log on to: www.baytekgames.com/parts
then click on the Parts N’ Service tab, or scan the QR code to
the right with your Smartphone to jump straight to this game’s
parts page!
PARTS
P: 920.822.3951 X 1101
F: 920.822.1496
E: [e-mail]
MON - FRI
8 AM - 5 PM C.S.T.
SERVICE
P: 920.822.3951 X 1102
F: 920.822.1496
E: [e-mail]
SALES
P: 920.822.3951
F: 920.822.8936
E: [e-mail]
All games are proudly manufactured at our factory in Pulaski, Wisconsin, USA
Scan here!
GAME INSPECTION
Inspect the game for any damaged, loose, or missing parts. If damage is found, please
contact your freight carrier rst. Then, contact Bay Tek Games’ Service Department at
920.822.3951 or e-mail them at [email protected] for further assistance.

3
TABLE OF CONTENTS
FACTORY CONTACT INFORMATION ..............................2
WELCOME TO: Sink It ..........................................4
HOW TO PLAY ................................................5
SPECIFICATIONS..............................................6
SAFETY PRECAUTIONS ........................................6
QUICK SETUP GUIDE ..........................................7
HEAD TO HEAD CONNECTION ...............................8-10
DIP SWITCH SETTINGS .......................................11
MAIN MENU FUNCTIONS ......................................12
CLEAR CREDITS ........................................12
GAME SETUP ...........................................13
TICKET PATTERNS ......................................14
DIAGNOSTICS MENU ....................................15
LOCATION NAME & ADVERTISING..........................16
MACHINE SETUP- HEAD TO HEAD .........................17
MACHINE SETUP- SINGLE GAME ..........................18
REPORTS- HEAD TO HEAD ...............................19
REPORTS- SINGLE GAME ................................20
SOFTWARE UPDATE .....................................21
MAINBOARD PINOUT ......................................22-24
MINIGEN PINOUT.............................................25
WIRING DIAGRAMS........................................26-30
TROUBLESHOOTING GUIDE ................................31-37
POWER SUPPLY DIAGNOSTICS ................................38
BILL ACCEPTOR DIAGNOSTICS.................................39
HOW TO: ACCESS MAINBOARD ................................40
HOW TO: REMOVE BALL SENSOR ..............................41
HOW TO: REMOVE CUP ASSEMBLY .............................42
HOW TO: ACCESS CAMERA/ LIGHT .............................42
CREDIT CARD READER .......................................43
PARTS LISTS .............................................44-46
MAINTENANCE LOG ..........................................47
TECHNICAL SUPPORT ........................................48
WARRANTY .................................................49

4
WELCOME TO: Sink It!
Congratulations on your Sink ItTM purchase!
A family-friendly twist on our original Beer Pong Master game, Sink It is the perfect
addtion to any ticket redemption game room.
The fun ball-tossing action and competive nature of Sink It will have players lining up!
Please take a moment to read through this manual and be sure to contact our factory if
you have any questions or would like some more information.
Thank you for your purchase! Your business is important to us and we hope you enjoy
this game as much as we do!
Your Friends at Bay Tek Games
GAME INSPECTION
Inspect the game for any damaged, loose, or missing parts.
If damage is found, please contact your freight carrier rst.
Then, contact Bay Tek Games’ Service Department at 920.822.3951
or e-mail them at [email protected] for further assistance.

5
HOW TO PLAY
Insert credits and select 1- or 2-player with the
buttons on the front of the games.
(Single games will not have the
2-player button)
Toss or bounce the balls into the cups, trying
to hit all 10 cups and turn o the blue lights
inside before your opponent!
Win tickets for your skills!

6
GAME SPECIFICATIONS
SAFETY PRECAUTIONS
WEIGHT
NET WEIGHT 475 LBS.
SHIP WEIGHT 525 LBS.
DIMENSIONS
WIDTH 30”
DEPTH 71”
HEIGHT 77”
OPERATING TEMPERATURE
FAHRENHEIT 80-100
CELSIUS 26.7-37.8
POWER REQUIREMENTS
INPUT VOLTAGE
RANGE
100 to 120
VAC /220 to 240 VAC
INPUT FREQUENCY
RANGE 50 HZ / 60 HZ
MAX START UP
CURRENT
OPERATING
CURRENT
1 AMPS @ 115 VAC 1.5 AMPS @ 115 VAC
0.5 AMPS @ 230 VAC .75 AMPS @ 230 VAC
DANGER
DO NOT perform repairs or maintenance on this game with the power ON.
Unplug the unit from the wall outlet or shut off the power strip located inside the cabinet.
!!
NOTICE
Modications to the mechanical, electrical and structural components of this game
may void its compliance certications.
!!
WARNING
Use of ammable subtances can cause sever burns or serious injury.
Always use NON-FLAMMABLE solvents for cleaning. DO NOT use gasoline kerosene or thinners.
!!
CAUTION
Lifting heavy objects can cause back, neck or other injuries. Be sure adequate lifting and moving
devices are available when unloading, unpacking and moving this game.
!!
ATTENTION
Be sure the electrical power matches the game requirements. See the serial number located on the
back of the game cabinet. Always plug into a grounded circuit. If the supply cord is damaged, it must
be replaced by an approved cord or assembly provided by the manufacturer.
!!
IN CASE OF EMERGENCY
UNPLUG THE POWER CORD.
The power cord must be accessible at all times in case of an emergency.
!!

7
QUICK SET UP GUIDE
Place the game near its nal location. Open the stor-
age compartment by unlocking the front metal and
sliding the bounce platform forward.
Ensure the balls didn’t bounce out of the trough
during transport.
No more than 20 balls should be in the
machine at a time for proper function
Sink It uses 38-40 mm
ping pong balls
Plug the power cord (located in the storage compart-
ment) into the game and a standard 110v outlet, then
switch the power strip inside the front door to the on
position.
The game may require a camera calibration after
shipping. See page 15 for instructions.

8
HEAD TO HEAD CONNECTION
Place two games next to each other and pull out the
bounce platforms.
Locate the grey phone cables inside each compart-
ment connected to the auxillary board shown. The
boards are connected to the motherboard via USB.
Feed the cable through the hole in the back of the
cabinet, and repeat in other cabinet
Plug the cables from each game into each other, then
push the cabinets together.

9
HEAD TO HEAD CONNECTION
Secure the cabinets together with included bolts,
washers and locknuts.
One set of holes is located inside the coin door of
the left game and the ticket door of the right game.
The other set of holes is inside the back doors.

10
HEAD TO HEAD CONNECTION
Place the marquee on top of the two games,
centering it between them.
Secure with included wood screws.
Run the cable down between the cabinets and
plug in to housing near bottom of the right side
game.

11
DIP SWITCH SETTINGS
The dip switch bank is located on the minigen board
under the bouncing platform; open the front door, then
slide the platform towards you.
*factory default settings are highlighted below
SWITCH DESCRIPTION OFF ON
1Enable Tickets
2 New Jersey compliance
3 Do Not Adjust
4 Do Not Adjust

12
MAIN MENU
Press the MENU BUTTON inside the
front door to enter the main menu.
Scroll through the options by pressing
the MENU BUTTON and make your
selection with the MENU SELECT button.
The blue and red player buttons also scroll
through the menus.
CLEAR CREDITS & TICKETS
START TEST GAME AFTER EXIT
CLEAR HIGH SCORES
Press MENU/SELECT when Clear Credits is highlighted to reset the available credits and
tickets owed to 0.
Selecting this option will start a test game after exiting the menu.
Selecting this option will start clear the high scores screen.

13
GAME SETUP
SETTINGS OPTIONS & FACTORY DEFAULTS
Credits per Play 0 1 2 3 4 5 6 7 8
DBA Additional Games Gives additional games for $ bill denominations (default is 0-o)
CC Charge Games/Swipe OFF ON
CC Add Games/Swipe 012345678
Game Time
(seconds) 30 60 90 120 150 180
Balls Per Game 10 20 30 40 50 60
Extra Last Ball Delay
(seconds) never 10 15 20 25 30
Ticket Patterns see next page
Divide Tickets by 2 OFF ON
(pays out 1 paper ticket per 2 tickets won)

14
TICKET PATTERNS
PATTERN
NUMBER OF CUPS HIT
0-3 4-6 7-9 10
TICKETS
12 6 8 16 (+1 per remaining ball)
22 4 10 16 (+1 per remaining ball)
34 6 10 18 (+1 per remaining ball)
410 14 20 30 (+1 per remaining ball)
510 14 20 32 (+1 per remaining ball)
612 16 22 36 (+1 per remaining ball)

15
DIAGNOSTICS MENU
7 8
4
9
5
2
10
6
3
1

16
LOCATION NAME & ADVERTISING
Insert a USB stick containing your advertise-
ments and text le into the USB port next to
the menu buttons under the bounce platform.
LOCATION NAME:
Your location name can be entered manually
with the on-screen keyboard and the player
buttons, OR it can be uploaded from the USB
stick (name.txt).
ADVERTISEMENTS:
The ideal size of an advertisement is 1280 x
960, in .png format. Ads must be named ad1.
png, ad2.png, ad3.png and ad4.png to upload
correctly.
You can add up to 4 dierent advertisements
to the machine, which display in rotation dur-
ing attract mode. The ads can be changed out
at any time.
One USB stick can be used to program mul-
tiple machines to the same settings.
LOCAL CURRENCY SYMBOL:
Choose between $, £ or none; this aects both
price per play and earning reports.

17
MACHINE SETUP- HEAD TO HEAD
SETTINGS OPTIONS & FACTORY DEFAULTS
Game Volume 0 1 2 3 4 5 6 7 8 9 10 11 12
Attract Volume 0 1 2 3 4 5 6 7 8 9 10 11 12
Attract Timing o 30 sec 1 min 5 min 10 min 15 min
Next Player Start
Timeout o 30 sec 1 min 2 min 3 min 5 min
Timed Game
Countdown Delay o 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
Cheat Detect
End Game o never end for cheat detection 1 warning
2
warnings
3
warnings
Head to Head
Machine ID o
left
(Player 2)
right
(Player 1)
Set according to game designation
H2H- Reg Game
Select Delay 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
H2H- Wait time 2nd
Player 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
H2H- Winner Extra
Tickets 0 1 2 3 4 5 6 7 8 9 10

18
MACHINE SETUP- SINGLE GAME
SETTINGS OPTIONS & FACTORY DEFAULTS
Game Volume 0 1 2 3 4 5 6 7 8 9 10 11 12
Attract Volume 0 1 2 3 4 5 6 7 8 9 10 11 12
Attract Timing o 30 sec 1 min 5 min 10 min 15 min
Next Player Start
Timeout o 30 sec 1 min 2 min 3 min 5 min
Timed Game
Countdown Delay o 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
Cheat Detect
End Game o never end for cheat detection 1 warning
2
warnings
3
warnings
Head to Head
Machine ID o left (Player 2)
right
(Player 1)
H2H- Reg Game
Select Delay 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
H2H- Wait time 2nd
Player 5 sec 10 sec 15 sec 20 sec 25 sec 30 sec
H2H- Winner Extra
Tickets 0 1 2 3 4 5 6 7 8 9 10

19
REPORTS MENU- HEAD TO HEAD
These reports will help you to determine the earmings, payout and overall
number of plays generated by your Beer Pong game.

20
REPORTS MENU- SINGLE GAME
These reports will help you to determine the earmings, payout and overall
number of plays generated by your Beer Pong game.
