BDI LINEA 6220 User manual

LINEA™6220
MULTIFUNCTION CABINET
DESIGN MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL

BDIUSA.COM | 3NEED ASSISTANCE? [e-mail]
Congratulations on the purchase of your Linea Multifunction Cabinet 6220 from BDI.
Your multifunction cabinet has been designed to provide a lifetime of enjoyment. This
manual will provide you with assembly instructions and other helpful information to
ensure that you get the most out of your product. Please save it for future reference.
Your Linea Multifunction Cabinet has been engineered for simple assembly. Please follow
these directions carefully to prevent any damage.
Should you need further assistance, contact BDI at customerservic[email protected].
ENJOY!

4 | BDIUSA.COM LINEA 6220
PART # H6
DESCRIPTION File Bar
QUANTITY 2
PART # H7
DESCRIPTION File Bar Clip
QUANTITY 4
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at
customerservic[email protected]om.
Do not use power tools for the assembly of this product.
For all other concerns, please contact your BDI retailer.
TOOL REQUIRED (NOT INCLUDED)
Phillips Screwdriver
PART # T1
DESCRIPTION Hex Wrench
QUANTITY 1
PART # H3
DESCRIPTION M6 x 20mm Screw
QUANTITY 6
PART # H1
DESCRIPTION M6 x 12mm Screw
QUANTITY 4
PART # H4
DESCRIPTION M4 x 20mm Screw
QUANTITY 6
PART # H2
DESCRIPTION M6 x 50mm Screw
QUANTITY 6
PART # H5
DESCRIPTION Push-in Shelf Pin
QUANTITY 4

BDIUSA.COM | 5NEED ASSISTANCE? [e-mail]
PART # C3
DESCRIPTION Spanner Tube
QUANTITY 2
PART # C2
DESCRIPTION Leg Frame
QUANTITY 2
PART # C4
DESCRIPTION Pull
QUANTITY 3
PART # C6
DESCRIPTION Removable Back Panel
QUANTITY 1
PART # C5
DESCRIPTION Adjustable Shelf
QUANTITY 1
HARDWARE AND COMPONENTS
PART # C1
DESCRIPTION Cabinet
QUANTITY 1

6 | BDIUSA.COM LINEA 6220
Position (C2) Legs perpendicular to the
(C3) Spanner Tubes. Slide the flange on the
(C2) Legs into the (C3) Spanner Tubes.
Fasten the (C2) Legs to the (C3) Spanner Tubes
using 4 (H1) Screws.
NOTE: Leave the screws loose until final base to
case assembly.
STEP 1. ASSEMBLE THE BASEASSEMBLY
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H1-SCREW 4
C3
C3
C2
C2
C2
C2
C3
C3
H1
C2
C3

BDIUSA.COM | 7NEED ASSISTANCE? [e-mail]
ASSEMBLY
STEP 2. ATTACH BASE TO CABINET
With help from another person, place the
(C1) Cabinet upside down on a non-marring
surface (carpet).
NOTE: Do not tighten until all the screws are in place.
Place the Base on the bottom side of the
(C1) Cabinet and thread in 6 (H2) Screws thru
the (C3) Spanner Tubes into the (C1) Cabinet.
Thread in 6 (H3) Screws thru the (C2) Base
Legs into the (C1) Cabinet.
Use (T1) Hex Wrench to tighten all screws.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H2-SCREW 6
H3-SCREW 6
2 PERSON TASK
C1
H2
C2 C3
H2
H2
H2
H2
H2
H3
H3
H3
H3
H3
H3

8 | BDIUSA.COM LINEA 6220
With help from another person, rotate the
Cabinet upright onto its Base. Install door and
bottom (C4) Pulls using 4 (H4) Screws and a
#2 Phillips Head Screwdriver (not included).
NOTE: Drawers have an interlocking mechanism
to prevent both drawers from being open at the
same time.
Close the bottom drawer,
then open the top drawer
and install the (C4) Pull.
PART/DESCRIPTION QTY
H4-SCREW 6
NOT INCLUDED
Phillips Screwdriver 1
STEP 3. INSTALL PULLSASSEMBLY
2 PERSON TASK
C4
C4
H4
H4
H4
H4
C4
H4
H4

BDIUSA.COM | 9NEED ASSISTANCE? [e-mail]
ASSEMBLY
ASSEMBLY
STEP 4. INSTALL ADJUSTABLE SHELF
STEP 5. INSTALL REMOVABLE BACK PANEL
Install the (C5) Adjustable Shelf. You may adjust the (C5) Adjustable Shelf position by pulling the
4 (H5) Shelf Pins out and relocating them.
Install the (C6) Removable Back Panel by positioning the panel under the grooves on the
underside of the cabinet top panel. Lift the (C6) Removable Back Panel up and position the
bottom of the panel above the grooves in the cabinet bottom panel then drop the panel in place.
Shelf pins
C5
H5
2
1
C6

10 | BDIUSA.COM LINEA 6220
FINE TUNING
Your Linea Multifunction Cabinet is equipped with built-in levelers. Dial down one or more levelers
(by hand) until you attain a level stance.
Dial down
For forward facing files, attach (H7) File Bar Clips
to each end of the (H6) File Bars. Slide the bars
onto the rails so that the (H7) File Bar Clip goes
into the groove.
PART/DESCRIPTION QTY
H6-FILE BAR 2
H7-FILE BAR CLIP 4
For letter files facing sideways,
skip this step altogether and hang file
folders directly on front and back rails.
H7
H7
H6
Letter/A4
Legal
Grooves
H7
H6
H7
H7
H6
H6
