Belden HIRSCHMANN BRS20 User manual

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Technical support
https://hirschmann-support.belden.com
User Manual
Installation
Industrial Ethernet Industrial Ethernet BOBCAT Rail Switch
BRS20/22/30/32/40/42/50/52

1/20/22 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2022 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at:
https://www.doc.hirschmann.com
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 3
Contents
Important information 6
Safety instructions 8
About this manual 22
Key 23
1 Description 24
1.1 General device description 24
1.2 Device name and product code 25
1.3 Device views 30
1.3.1 Front view 30
1.3.2 Rear view 33
1.4 Power supply 34
1.4.1 Supply voltage with characteristic value T 34
1.4.2 Supply voltage with characteristic value F 34
1.4.3 Supply voltage with characteristic value U 34
1.4.4 Supply voltage with characteristic value P 34
1.5 Ethernet ports 35
1.5.1 10/100 Mbit/s twisted pair port 35
1.5.2 10/100/1000 Mbit/s twisted pair port 35
1.5.3 100/1000/2500 Mbit/s twisted pair port 35
1.5.4 100 Mbit/s F/O port 37
1.5.5 100/1000 Mbit/s F/O port 37
1.5.6 100/1000/2500 Mbit/s F/O port 37
1.5.7 Support of PoE(+) 38
1.6 Display elements 39
1.6.1 Device state 39
1.6.2 Port status 40
1.7 Management interfaces 43
1.7.1 Signal contact 43
1.7.2 USB-C interface 44
1.7.3 Digital input 45
1.7.4 Hardware revision 46

4Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
2 Installation 47
2.1 Checking the package contents 47
2.2 Installing and grounding the device 47
2.2.1 Installing the device onto the DIN rail 47
2.2.2 Grounding the device 49
2.2.3 Connecting the ferrite (optional) 49
2.3 Installing an SFP transceiver (optional) 50
2.4 Connecting the terminal blocks 50
2.4.1 Power supply 50
2.4.2 Signal contact (optional) 55
2.4.3 Digital input (optional) 56
2.5 Operating the device 57
2.6 Connecting data cables 58
2.7 Filling out the inscription label 58
3 Making basic settings 59
3.1 First login (Password change) 59
4 Monitoring the ambient air temperature 61
5 Maintenance and service 62
6Disassembly 63
6.1 Removing an SFP transceiver (optional) 63
6.2 Removing the device 64
7 Technical data 65
7.1 General data 65
7.2 Temperature ranges 72
7.3 Supply voltage 76
7.4 Power consumption/power output 79
7.5 Signal contact 80
7.6 Digital input 81
7.7 Climatic conditions during operation 82
7.8 Climatic conditions during storage 83

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 5
7.9 Dimension drawings 84
7.9.1 Device variants with casing with characteristic
value C (plastic casing) 84
7.9.2 Device variants with casing with characteristic
value E/D (metal casing) 87
7.10 Immunity 90
7.11 Electromagnetic compatibility (EMC) 90
7.12 Network range 92
7.12.1 10/100/1000 Mbit/s twisted pair port 92
7.12.2 Fast Ethernet SFP transceiver 92
7.12.3 Gigabit Ethernet SFP transceiver 94
7.12.4 2.5 Gigabit Ethernet SFP transceiver 96
7.12.5 Bidirectional Fast Ethernet SFP transceiver 97
7.12.6 Bidirectional Gigabit Ethernet SFP transceiver 97
7.13 Derating due to SFP transceiver 98
7.13.1 Fast Ethernet SFP transceiver 98
7.13.2 Gigabit Ethernet SFP transceiver 99
7.13.3 2.5 Gigabit Ethernet SFP transceiver 100
7.13.4 Bidirectional Fast Ethernet SFP transceiver 101
7.13.5 Bidirectional Gigabit Ethernet SFP transceiver 101
8 Scope of delivery 102
9 Accessories 103
9.1 General accessories 103
9.2 Order numbers for standard variants 103
9.3 Fast Ethernet SFP transceiver 105
9.4 Gigabit Ethernet SFP transceiver 106
9.5 2.5 Gigabit Ethernet SFP transceiver 107
9.6 Bidirectional Fast Ethernet SFP transceiver 107
9.7 Bidirectional Gigabit Ethernet SFP transceiver 108
10 Underlying technical standards 109
A Further support 110

6Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Important information
Note: Read these instructions carefully, and familiarize yourself with the
device before trying to install, operate, or maintain it. The following notes may
appear throughout this documentation or on the device. These notes warn of
potential hazards or call attention to information that clarifies or simplifies a
procedure.
Symbol explanation
This is a general warning symbol. This symbol alerts you to
potential personal injury hazards. Observe all safety notes that
follow this symbol to avoid possible injury or death.
If this symbol is displayed in addition to a safety instruction of the
type “Danger” or “Warning”, it means that there is a danger of
electric shock and failure to observe the instructions will
inevitably result in injury.
This symbol indicates the danger of hot surfaces on the device.
In connection with safety instructions, non-observance of the
instructions will inevitably result in injuries.
DANGER
DANGER draws attention to an immediately dangerous situation, which will
inevitably result in a serious or fatal accident if not observed.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a possible danger which, if not avoided, may result in
minor injuries.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 7
NOTICE
NOTE provides information about procedures that do not involve the risk of
injury.

8Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful
operation and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Certified usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 65.
Connect to the product only components suitable for the requirements
of the specific application case.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 9
Installation site requirements
Install this device only in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
When you are selecting the installation location, make sure you
observe the climatic threshold values specified in the technical data.
Use the device in an environment with a maximum pollution degree
that complies with the specifications in the technical data.
See “Technical data” on page 65.
Strain relief
Note: If the strain relief is insufficient, there is a potential risk of torsion,
contact problems and creeping interruptions.
Relieve the connection points of cables and lines from mechanical
stress.
Design strain reliefs in such a way that they help prevent any
mechanical damage to cables, wires or conductors caused by external
influences or their own weight.
To help prevent damage to device connections, connectors and
cables, follow the instructions for proper installation in accordance with
DIN VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.
WARNING
FIRE HAZARD
If you connect the device to a power supply that does NOT meet the
requirements for Limited Power Source, NEC Class 2 or PS2 according to
IEC/EN 62368-1 and is NOT limited to 100 W output power, the device
must be installed in either a switch cabinet or other fire enclosure.
The fire enclosure can be made of metal or plastic with fire-protection
properties of at least V-1 according to IEC 60695-11-10. Bottom openings
of the fire enclosure must NOT exceed 2 mm in diameter.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

10 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
Device casing
Only technicians authorized by the manufacturer are permitted to open
the casing.
Shielding ground
The shielding ground of the connectable twisted pair cables is connected
to the ground connection as a conductor.
Beware of possible short circuits when connecting a cable section with
conductive shielding braiding.
Grounding the device
The device is grounded via the separate ground screw. The grounding
screw is located on the front right side of the device for narrow casing
sizes. For the medium and wide casing sizes, the grounding screw is
located at the bottom left of the front side of the device.
See “Dimension drawings” on page 84.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.
Requirements for connecting electrical wires
Before connecting the electrical wires, always verify that the
requirements listed are complied with.
The following requirements apply without restrictions:
The electrical wires are voltage-free.
The cables used are permitted for the temperature range of the application case.
Only use power supply cables that are suitable for a temperature 20 °C (36 °F)
higher than the maximum ambient air temperature at which the device is used.
Only use copper wire.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 11
Requirements for connecting the signal contact
Before connecting the signal contact, always verify that the requirements
listed are complied with.
Requirements for connecting the supply voltage
Before connecting the supply voltage, always verify that the requirements
listed are complied with.
The following requirements apply without restrictions:
The voltage connected complies with the requirements for a safety extra-low voltage
(SELV) as per IEC 60950-1 or ES1 as per IEC/EN 62368-1.
The connected voltage is limited by a current limitation device or a fuse.
Observe the electrical threshold values for the signal contact.
See “Technical data” on page 65.
Prerequisites:
All of the following requirements are complied with:
The supply voltage corresponds to the voltage specified on the type plate of the device.
The power supply complies with the requirements for a safety extra-low voltage (SELV)
according to IEC 60950-1 or ES1 according to IEC/EN 62368-1.
The power supply has an easily accessible disconnecting device (for example a switch or
a plug). This disconnecting device is clearly identified. So in the case of an emergency, it is
clear which disconnecting device belongs to which power supply cable.
The wire diameter of the power supply cable is at least 0.75 mm² (North America: AWG18)
on the supply voltage input.
The wire diameter of the power supply cable is at least 1 mm² (North America: AWG16) on
the supply voltage input for PoE device variants.
The cross-section of the ground conductor is the same size as or bigger than the cross-
section of the power supply cables.
Depending on the voltage input used (characteristic value F, T, U, P) and the supply voltage
used (DC, AC), the following additional requirements apply:
Device variants
featuring supply
voltage with
characteristic
value F, T, U
All of the following requirements are complied with:
Supply with DC voltage:
There are fuses suitable for DC voltage in the positive conductors of
the supply lines, or the voltage sources are appropriately current-
limited. Regarding the properties of this fuse: See “Technical data”
on page 65.
The negative conductors of the voltage inputs are on ground
potential.
Device variants
featuring supply
voltage with
characteristic value F
All of the following requirements are complied with:
Supply with AC voltage:
There are fuses in the supply lines, or the voltage sources are
appropriately current-limited. Regarding the properties of this fuse:
See “Technical data” on page 65.
The power sources are electrically isolated from the ground
potential.

12 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Note: The devices can be supplied either via one voltage input or
redundantly via both voltage inputs.
Supply voltage
The supply voltage is connected to the device casing through protective
elements exclusively.
LED or laser components
LED or LASER components according to IEC 60825-1 (2014):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
Relevant for use in explosion hazard areas (Hazardous
Locations, Class I, Division 2)
This equipment is exclusively suitable for use in Class I, Division 2,
Groups A, B, C, and D or non-hazardous locations.
This device is an open-type device that is to be installed in an enclosure
suitable for the environment and accessible exclusively with the use of a
tool.
Exclusively use the device for the application cases specified by the
manufacturer. Failure to follow these instructions can impair device
protection.
WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE
AREA IS KNOWN TO BE NON-HAZARDOUS.
Avertissement - Risque d'explosion - Ne pas débrancher tant que le
circuit est sous tension à moins que l'emplacement soit connu pour ne
contenir aucune concentration de gaz inflammable.
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF ANY
COMPONENT MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.
Device variants
featuring supply
voltage with
characteristic value P
All of the following requirements are complied with:
There are fuses suitable for DC voltage in the positive conductors of
the supply lines, or the voltage sources are appropriately current-
limited. Regarding the properties of this fuse: See “Technical data”
on page 65.
The power sources are electrically isolated from the ground
potential. According to specification IEEE 802.3, the insulation
voltage must be 1500 V AC or 2250 V DC.
Prerequisites:

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 13
Avertissement - Risque d'explosion - La substitution de tout composant
peut rendre ce matériel incompatible pour une utilisation en classe I,
division 2.
The storage medium ACA22-USB-C (EEC) is mechanically secured to
prevent the connection from being disconnected.
Le dispositif de sauvegarde ACA22-USB-C (EEC) est fixé
mécaniquement pour éviter toute déconnexion de la connexion.
In hazardous areas, exclusively operate the ACA22-USB-C (EEC) on the
USB interface.
En environnement explosible, seul l'ACA22-USB-C (EEC) peut être utilisé
sur l'interface USB-C.
A USB cable for configuring the device may only be used in a non-
explosive area.
Un câble USB pour la configuration de l'équipement ne doit être utilisé
que dans une zone non explosive.
WARNING!
Connection or disconnection in an explosive atmosphere could result in
an explosion.
Avertissement - Le branchement ou le débranchement dans une
atmosphère explosive peut entraîner une explosion.

14 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Control Drawing for BRS devices according to Class I, Division 2 Hazardous Locations
Rev.: 3 Document No.: 000217023DNR Page 1/2
Ordinary Location,
Non-Hazardous Area,
Non-Explosive Atmosphere
Explosive Atmosphere
Class I, Division 2, Groups A, B,
C, D, T4 (**)
Hazardous Location
BRS - Industrial Ethernet
BOBCAT Rail Switch
(**) Temperature Code: T4
Ambient Temperature rating:
Ta: 0 °C to +60 °C for “S“ or “C“ temperature types
7Dí&WR&IRU³7³RU³(³WHPSHUDWXUHW\SHV
(Refer to the type designation on the device.)
(*) Associated apparatus:
7KHQRQLQFHQGLYH¿HOGZLULQJFLUFXLWFRQFHSWDOORZVLQWHUFRQQHFWLRQ
RIQRQLQFHQGLYH¿HOGZLULQJDSSDUDWXVDQGDVVRFLDWHGQRQLQFHQGLYH
¿HOGZLULQJDSSDUDWXVXVLQJDQ\RIWKHZLULQJPHWKRGVSHUPLWWHGIRU
XQFODVVL¿HGORFDWLRQVZKHQFHUWDLQSDUDPHWULFFRQGLWLRQVDUHPHW
Capacity: Ca&i+ CCable;Inductivity: La/i+ LCable
The ACA22-USB-C (EEC) storage medium is mechanically secured
to prevent disconnection.
$86%FDEOHIRUFRQ¿JXUDWLRQWKHGHYLFHPD\H[FOXVLYHO\EHXVHGLQ
non-hazardous locations.
WARNING!
&RQQHFWLRQRUGLVFRQQHFWLRQLQDQH[SORVLYHDWPRVSKHUH
FRXOGUHVXOWLQDQH[SORVLRQ
7KHPD[LPXPFDEOHOHQJWKKDVWREHGHWHUPLQHGDVIROORZV
DPD[FDEOHOHQJWK< (Laí/i) / CableL
(“CableL“ denotes the inductance per unit length of used cable)
and
EPD[FDEOHOHQJWK< (Caí&i) / CableC
(“CableC“ denotes the capacitance per unit length of used cable)
The lower value of (a) and (b) is to apply.
Relay contacts:
(TXLSPHQWZLWKQRQLQFHQGLYH¿HOGZLULQJSDUDPHWHUV
Polarity is not relevant.
The relay terminals are dependent upon the following entity parame-
ters (*):
9PD[ ,PD[ CiLi
30 V 90 mA 2 nF 1 μH
USB
Relay
The earth conductor
must be at least
the same wire size
(mm² or AWG) as the
supply conductors of
the supply voltage.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 15
Control Drawing for BRS devices according to Class I, Division 2 Hazardous Locations
Rev.: 3 Document No.: 000217023DNR Page 2/2
For use in Hazardous Locations Class I, Division 2, Groups A, B, C, D:
([FOXVLYHO\DOORZHGIRU%56PRGHO1RVZKLFKDUHLQGLYLGXDOO\ODEHOHG
“FOR USE IN HAZARDOUS LOCATIONS“.
7KLVHTXLSPHQWLVH[FOXVLYHO\VXLWDEOHIRUXVHLQ&ODVV,'LYLVLRQ*URXSV$%&DQG'RUQRQKD]DUGRXV
locations.
1RQLQFHQGLYH¿HOGZLULQJFLUFXLWVPXVWEHZLUHGLQDFFRUGDQFHZLWKWKH1DWLRQDO(OHFWULFDO&RGH
(NEC), NFPA 70, article 501.
WARNING – EXPLOSION HAZARD
6XEVWLWXWLRQRIDQ\FRPSRQHQWVPD\LPSDLUVXLWDELOLW\IRUKD]DUGRXVORFDWLRQVRUH[SORVLYHDWPRVSKHUHV
WARNING – EXPLOSION HAZARD
'RQRWGLVFRQQHFWHTXLSPHQWXQOHVVSRZHUKDVEHHQVZLWFKHGRႇRUWKHDUHDLVNQRZQWREHQRQKD]DUGRXV
7ˑ˒˜˒˜ˊ˗˘˙ˎ˗˝ˢ˙ˎˍˎ˟˒ˌˎ˝ˑˊ˝˒˜˝˘ˋˎ˒˗˜˝ˊ˕˕ˎˍ˒˗ˊ˗ˎ˗ˌ˕˘˜˞˛ˎ˜˞˒˝ˊˋ˕ˎ
ˏ˘˛˝ˑˎˎ˗˟˒˛˘˗˖ˎ˗˝ˊ˗ˍˊˌˌˎ˜˜˒ˋ˕ˎˎˡˌ˕˞˜˒˟ˎ˕ˢˠ˒˝ˑ˝ˑˎ˞˜ˎ˘ˏˊ˝˘˘˕

16 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
ATEX directive 2014/34/EU – specific regulations for safe
operation
The following applies to BRS devices if you operate them in areas with
explosive gases according to ATEX directive 2014/34/EU:
List of standards:
EN IEC 60079-0:2018
EN 60079-7:2015 + A1:2018
EN IEC 60079-15:2019
Make sure that the device has the following label:
II 3G Ex ec nC IIC T4 Gc DEKRA 20ATEX0134 X
T4: 0 °C ≤Ta ≤+60 °C (+32 °F ≤Ta ≤+140 °F) for device types “S”
or “C”
(Position 16 of the product code) or
T4: -40 °C ≤Ta ≤+70 °C (-40 °F ≤Ta ≤+158 °F) for device types
“T“, “E“ or “G”
(Position 16 of the product code)
The equipment is suitable for use in an area with maximum pollution
degree 2, as defined in IEC 60664-1.
The modules shall be installed in a suitable enclosure in accordance
with IEC 60079-0 providing a degree of protection of at least IP54
according to IEC 60529, taking into account the environmental
conditions under which the equipment will be used.
When the temperature under rated conditions exceeds +70 °C
(+158 °F) at the cable or the conduit entry point, or +80 °C (+176 °F)
at the branching point of the conductors, take measures so that the
temperature specification of the selected cable and cable entries is in
compliance with the actual measured temperature values.
Connectors shall be connected or disconnected exclusively in dead-
voltage state.
When using ACA22-USB-C (EEC) on the USB interface, verify
that the ACA22-USB-C (EEC) is mechanically secured with the
fastening screw. Exclusively connect or disconnect the ACA22-
USB-C (EEC) when it is voltage-free. In hazardous areas,
exclusively operate the ACA22-USB-C (EEC) on the USB
interface.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 17
UK regulation S.I. 2016:1107
(as amended by S.I. 2019:696) - Schedule 3A, Part 6
The following applies to BRS devices if you operate them in areas with
explosive gases:
List of standards:
EN IEC 60079-0:2018
EN 60079-7:2015 + A1:2018
EN IEC 60079-15:2019
Make sure that the device has the following label:
II 3G Ex ec nC IIC T4 Gc DEKRA 21UKEX0040X
T4: 0 °C (+32 °F) ≤Ta ≤+60 °C (+140 °F) for "S" or "C"types
(position 16 of nomenclature breakdown)
T4: −40 °C (−40 °F) ≤Ta ≤+70 °C (+158 °F) for "T", "E" or "G"
types
(position 16 of nomenclature breakdown)
The equipment is suitable for use in an area with maximum pollution
degree 2, as defined in IEC 60664-1.
The modules shall be installed in a suitable enclosure in accordance
with IEC 60079-0 providing a degree of protection of at least IP54
according to IEC 60529, taking into account the environmental
conditions under which the equipment will be used.
When the temperature under rated conditions exceeds +70 °C
(+158 °F) at the cable or the conduit entry point, or +80 °C (+176 °F)
at the branching point of the conductors, take measures so that the
temperature specification of the selected cable and cable entries is in
compliance with the actual measured temperature values.
Connectors shall be connected or disconnected exclusively in dead-
voltage state.
When using the ACA22-USB-C (EEC) storage medium on the
USB interface, verify that the ACA22-USB-C (EEC) is
mechanically secured with the fastening screw. The ACA22-
USB-C (EEC) shall be connected or disconnected exclusively in
dead-voltage state. In hazardous areas, exclusively operate the
ACA22-USB-C (EEC) on the USB interface.

18 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
IECEx – Certification Scheme for Explosive Atmospheres
For BRS devices labeled with an IECEx certificate number, the following
applies:
List of standards:
IEC 60079-0:2017
IEC 60079-7:2017
IEC 60079-15:2017
Make sure that the device has the following label:
Ex ec nC IIC T4 Gc IECEx: DEK 20.0079 X
T4: 0 °C ≤Ta ≤+60 °C (+32 °F ≤Ta ≤+140 °F) for device types “S“
or “C“
(Position 16 of the product code) or
T4: -40 °C ≤Ta ≤+70 °C (-40 °F ≤Ta ≤+158 °F) for device types
“T“, “E“ or “G”
(Position 16 of the product code)
The equipment is suitable for use in an area with maximum pollution
degree 2, as defined in IEC 60664-1.
The modules shall be installed in a suitable enclosure in accordance
with IEC 60079-0 providing a degree of protection of at least IP54
according to IEC 60529, taking into account the environmental
conditions under which the equipment will be used.
When the temperature under rated conditions exceeds +70 °C
(+158 °F) at the cable or the conduit entry point, or +80 °C (+176 °F)
at the branching point of the conductors, take measures so that the
temperature specification of the selected cable and cable entries is in
compliance with the actual measured temperature values.
Connectors shall be connected or disconnected exclusively in dead-
voltage state.
Bei ACA22-USB-C (EEC)When using ACA22-USB-C (EEC) on
the USB interface, verify that the ACA22-USB-C (EEC) is
mechanically secured with the fastening screw. ACA22-USB-C
(EEC) Exclusively connect or disconnect the ACA22-USB-C
(EEC) when it is voltage-free. In hazardous areas, exclusively
operate the ACA22-USB-C (EEC) on the USB interface.

Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022 19
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2011/65/EU and 2015/863/EU (RoHS)
Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in electrical and
electronic equipment.
2014/30/EU (EMC)
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to
electromagnetic compatibility.
2014/34/EU (ATEX)
Directive of the European Parliament and the council on the
harmonisation of the laws of the Member States relating to equipment
and protective systems intended for use in potentially explosive
atmospheres.
The ATEX Directive applies exclusively to the device variants labeled
with an ATEX certificate number:
See “ATEX directive 2014/34/EU – specific regulations for safe
operation” on page 16.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be available to the relevant authorities at the following
address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
You find the EU conformity declaration as PDF file for downloading on the
Internet at: https://www.doc.hirschmann.com/certificates.html
The device can be used in industrial environments.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
You find more information on technical standards here:
“Technical data” on page 65
The assembly guidelines provided in these instructions must be strictly
adhered to in order to observe the EMC threshold values.

20 Installation BRS20/22/30/32/40/42/50/52
Release 12 01/2022
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
UKCA marking
The labeled devices comply with the following UK regulations:
S.I. 2012 No. 3032
Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronical Equipment Regulations
S.I. 2016 No. 1091
Electromagnetic Compatibility Regulations 2016
S.I. 2016 No. 1107
Equipment and Protective Systems Intended for use in Potentially
Explosive Atmospheres Regulations 2016
Note:The regulation applies exclusively to the device variants labeled
with a UKEX certificate number: See “UK regulation S.I. 2016:1107
(as amended by S.I. 2019:696) - Schedule 3A, Part 6” on page 17.
The UKCA conformity declaration will be available to the relevant
authorities at the following address:
Belden UK Ltd.
1 The Technology Centre, Station Road
Framlingham, IP13 9EZ, United Kingdom
You find the UKCA conformity declaration as PDF file for downloading on
the Internet at: https://www.doc.hirschmann.com/certificates.html
