Bender LINETRAXX VMD461 User manual

1
Quickstart
Multifunctional voltage relay
Intended use
The multifunctional voltage monitoring relay VMD461 monitors frequen-
cies, undervoltages and overvoltages in DC, AC and 3(N)AC systems. The
phase voltages and/or line-to-line voltages are measured as r.m.s. value
and are continuously shown on the device display. The measured value re-
quired to trigger the alarm relay is stored. The VMD461 features additional
measuring functions for:
 ROCOF df/dt
 Vector shift monitoring
 Unbalance monitoring
 Phase sequence monitoring
The corresponding ANSI codes for all available measuring functions are provided.
Configurable delay times allow considering special installation-specific properties (e.g. device-specific
start-up procedures). The VMD461 requires an external supply voltage.
The optional use of a CD440 coupling device extends the voltage range that can be monitored to DC/
3AC 1200 V or 1AC/3NAC 690 V. Any other use than that described in this manual is regarded as impro-
per. The quickstart does not replace the manual of the device. Download: www.bender.de/manuals
Safety instruction
Dimension diagrams VMD461 (left) und CD440 (right) in mm
Danger of electrocution due to electric shock!
Touching live parts of the system carries the risk of:
 An electric shock
 Damage to the electrical installation
 Destruction of the device
Before installing and connecting the device, make sure that the installation has
been de-energised. Observe the rules for working on electrical installations.
DANGER
108
77
93
74
98
71,7
62,5
48,5
93,0
VMD461 with CD440
VMD461_D00314_00_Q_XXEN/10.2018
EN

2VMD461_D00314_00_Q_XXEN/10.2018
Mounting on DIN rail and screw mounting
Wiring
Depending on the application, connect the device according to the following wiring diagrams..
Legend wiring diagrams
* Explanation: NC (closed in non-operating state)
NO (open in non-operating state)
off (switched off)
The VMD461 can be opera-
ted without a CD440 in ap-
propriate power supply
systems (230/400 V).
Risk of unwanted device
failure!
Do not supply device from the
monitored system. Pay attention
to maximum supply voltage.
Element Funktion
A1, A2 Supply voltage Us(see ordering details)
L1, L2/DC+,
L3, N/DC- Power supply connection
11, 12, 14 Connection to alarm relay K1
21, 22, 24 Connection to alarm relay K2
DG1/2,
D1, D2
Contact monitoring
DG1/2: GND
D1: Feedback signal contact to alarm relay K1
D2: Feedback signal contact to alarm relay K2
(feedback signal contacts optionally NC/NO/off)*
RTG, RT1 RTG: GND
RT1: Remote-trip input (optionally NC/NO/off)*
A, B Connection to communication interface BMS bus
Ron/off Activate or deactivate the terminating resistor of the BMS bus (120 Ω)
2.
„Klick“
100 mm
B98060008
1.
4.
3.
M4
M4
77 mm
98 mm
M4
M4
1.
2.
4.
„Klick“
3.
VMD461 CD440
VORSICHT

3
VMD461_D00314_00_Q_XXEN/10.2018
Unearthed system
AC 3(N)AC
*
CD440 optional
L1
L2
PE
Un
L1 L2/DC+ L3 N/DC-
6 A
L1' L2'/DC+' L3' 11
21 24
12
22
A B RTGRT1
14
N'/DC-'
K1
K2
A1 A2
US
6 A 6 A
CD440
L1 L3 N/DC-L2/DC+
L1' L3' N'/DC-'L2'/DC+'
11 12 14 21 22 24
L3
L2/DC+
L1 D2 D1
DG1/2
RTG RT1
2
1
ON
ALARM
MENU
INFO
TEST
RESET
ESC
LINETRAXX®
VMD461 V
N/DC-
L1
L2/DC+
L3 N/DC-
6 A
*
CD440 optional
L1
L2
L3
N
PE
L1' L2'/DC+' L3' 11
21 24
12
22
A B RTGRT1
14
N'/DC-'
K1
K2
A1 A2
US
6 A 6 A
CD440
L1 L3 N/DC-L2/DC+
L1' L3' N'/DC-'L2'/DC+'
L1 L2/DC+ L3 N/DC-
6 A 6 A 6 A
11 12 14 21 22 24
L3 L2/DC+ L1 D2 D1
DG1/2
RTG RT1
2
1
ON
ALARM
MENU
INFO
TEST
RESET
ESC
LINETRAXX®
VMD461 V
N/DC-
L1
L2/DC+
L3 N/DC-
6 A

4VMD461_D00314_00_Q_XXEN/10.2018
Earthed system
AC 3(N)AC
*
CD440 optional
L1' L2'/DC+' L3' 11
21 24
12
22
A B RTGRT1
14
N'/DC-'
K1
K2
A1 A2
U
S
6 A 6 A
CD440
L1 L3 N/DC-L2/DC+
L1' L3' N'/DC-'L2'/DC+'
L1
L2
L3
N
L1 L2/DC+ L3 N/DC-
6 A 6 A 6 A
PE
11 12 14 21 22 24
L3 L2/DC+ L1 D2 D1
DG1/2
RTG RT1
2
1
ON
ALARM
MENU
INFO
TEST
RESET
ESC
LINETRAXX®
VMD461 V
N/DC-
L1
L2/DC+
L3 N/DC-
*
CD440 optional
L1
N
PE
L1 L2/DC+ L3 N/DC-
6 A
L1' L2'/DC+' L3' 11
21 24
12
22
A B RTGRT1
14
N'/DC-'
K1
K2
A1 A2
US
6 A 6 A
CD440
L1 L3 N/DC-L2/DC+
L1' L3' N'/DC-'L2'/DC+'
11 12 14 21 22 24
L3
L2/DC+
L1 D2 D1
DG1/2
RTG
RT1
2
1
ON
ALARM
MENU
INFO
TEST
RESET
ESC
LINETRAXX®
VMD461 V
N/DC-
L1
L2/DC+
L3 N/DC-

5
VMD461_D00314_00_Q_XXEN/10.2018
DC
Details regarding the digital
inputs (D1, D2, RT1)
*
CD440 optional
L+
L-
PE
L1 L2/DC+ L3 N/DC-
L1' L2'/DC+' L3' 11
21 24
12
22
A B RTGRT1
14
N'/DC-'
K1
K2
CD440
L1 L3 N/DC-L2/DC+
L1' L3' N'/DC-'L2'/DC+'
11 12 14 21 22 24
L3
L2/DC+
L1 D2 D1
DG1/2
N/DC-
RTG
RT1
2
1
ON
ALARM
MENU
INFO
TEST
RESET
ESC
LINETRAXX®
VMD461 V
L1
L2/DC+
L3 N/DC-
A1
A2
US
6 A 6 A
6 A
low : < 4 V DC
high : > 6 V DC
Umax = 30 V DC
V1
Dx
GND
12 V
DC
Source
I < 5 mA
Open
Collector
DGx
µC
Relais
Kontakt
Dx: D1, D2, RT1
DGx: DG1/2, RTG
Q1
24 V
1
2
R1

6VMD461_D00314_00_Q_XXEN/10.2018
Initial commissioning
When commissioning the device for the first time you have to:
 Select a language (English, German, French) (menu 4.2).
 Set date and time (menu 4.3).
You can only change settings in the menus after the settings listed above have been carried out
.
User interface
Legend
The contrast of the LC display can be adjusted to any ambient brightness.
Select the contrast ratio from an infinite loop display. Simultaneously press and hold
down the buttons "INFO" and "MENU" until the display text is clearly readable. After
reaching a black display, the contrast setting process starts again with a white dis-
play.
Element
Power On LED, green;
lights when the voltage supply is available and the device is in operation;
flashes when the device is being started or when an internal device error has occurred
ON Alarm LEDs, yellow: installation switched off
Only ALARM 1 lights: alarm relay K1 has tripped
Only ALARM 2 lights: alarm relay K2 has tripped
ALARM 1 and ALARM 2 light: response value violation of voltage or frequency, df/dt, vec-
tor shift detection, unbalance, phase sequence, remote trip
ALARM 1 and ALARM2 flash: internal device error or error in contact monitoring
ALARM1
ALARM2 Backlit LC display
INFO
ESC
Standard display: Toggle between standard display and device information
Menu display: Exit the parameter setting menu
without saving; switch to the next higher
menu level
TEST Standard display: Use the TEST button (< 1.5 s) to start a manual self test which triggers
both alarm relays (trigger test to check the switches/disconnectors). In addition, the
switch-off times are documented, .
Menu display: arrow-up button for parameter change and scrolling
RESET Standard display: (> 1.5 s) Acknowledge fault messages from contact monitoring
Menu display: arrow-down button for parameter change/scrolling
VMD461 V
LINETRAXX®

7
VMD461_D00314_00_Q_XXEN/10.2018
Toggling between the individual displays
You can toggle between the
different displays by using
the four device buttons. De-
pending on the type of dis-
play (standard display,
alarm display, menu display,
info display), the meaning
of the buttons is different.
The picture below illustrates
which button is to be
pressed for accessing the in-
dividual display. First, you
have to distinguish bet-
ween an alarm condition
and no alarm condition..
LEDs
The state of the VMD461 can be determined by means of the LEDs. The following table provides an over-
view of the possibilities.
MENU Standard display: Toggle between standard, menu and alarm display
Menu display: button
Jump to setting parameter; save the changed parameters
LED Meaning LED Meaning Action
Normal operation mode:
device in operation, all the
measured values are within
the specified limits
Alarm, limit value of
K1 violated
Alarm, limit value of K1 and
K2 violated
Error contact monitor-
ing or internal error
Check switches/dis-
connectors * ;
in case of int. errors:
contact service
Alarm, limit value of K2
violated
Device starts
(> 10 s): internal
device error
Wait (< 10 s)
Contact service
Standard
display
Info
display
Menu
display
ESC
INFO
Standard
display
Info
display
Menu
display
INFO
ESC
Alarm
display
MENU
MENUMENU
MENU
no alarm alarm
ESC
ESC
ESC MENU
2
ALARM
1
ON
2
ALARM
1
ON
2
ALARM
1
ON
2
ALARM
1
ON
2
ALARM
1
ON
2
ALARM
1
ON

©Bender GmbH & Co. KG
All rights reserved.
Reprinting only with permission of
the publisher.
Subject to change!
Photos: Bender Archiv
Bender GmbH & Co. KG
P.O. Box 1161 • 35301 Gruenberg • Germany
Londorfer Strasse 65 • 35305 Gruenberg • Germany
Tel.: [phone] • Fax: [phone]
E-Mail: [email protected] • www.bender.de
Menu
1. Alarm/meas. values
4. System
3. Settings
5. Info
History
1. General
2. Voltage
(59/27)
U>>> (59.S3), t
off
U>> (59.S2), t
off
U> (59.S1), t
off
U
(on)max
, U
(on)min
U< (27.S1), t
off
U<< (27.S2), t
off
U<<< (27.S3), t
off
Delete history, Language, Clock, Password, Interface, Alarm addresses,TEST,
RESET, Test communication, External devices, Service, Factory settings
2. History
U
(1-N)
, U
(2-N)
, U
(3-N)
, U
(1-2)
, U
(2-3)
, U
(3-1)
, Unbalance, Phase sequence,
Frequency, df/dt (81R), Vect.sh.(78), Status, t
on1
, t
on2
, t
off total
Coupling, System type, U
(L-N)
, t
start-up
, Remote trip
3. Frequency(81) f>>> (81>.S3), t
off
f>> (81>.S2), t
off
f> (81>.S1), t
off
f
(on)max
, f
(on)min
f< (81<.S1), t
off
f<< (81<.S2), t
off
f<<< (81<.S3), t
off
4. df/dt (81R) Function, Resp.value, Hysteresis, Meas.window, t
off,
t
on
5. Vect.sh. (78) Function, Resp.value, t
start-up
, t
on
7. Phase
sequence(47)
Function, Resp.value, Hysteresis, t
off
8. Relays Relay mode, t
on
, Fault memory, Start alarm,
Device error, TEST, U>>> (59.S3), U>> (59.S2),
U> (59.S1), U< (27.S1), U<< (27.S2, U<<< (27.S3),
f>>> (81>.S3),f>> (81>.S2), f> (81>.S1), f< (81<.S1),
f<< (81<.S2), f<<< (81<.S3), df/dt (81R), Vect.sh. (78),
Unbalance, Phase sequence, Remote trip
9. Dig. input Mode, t
start-up
Device type, Current date and time, BMS bus address, Software version
measurement technology, Software date measurement technology,
Software version display, Software date display, Manufacturer of the device,
Address of the manufacturer, Internet address of the manufacturer
6. Unbalance
(47)
Function, Phase sequence
