Benning PV 1-1+ User manual

BENNING PV 1-1+
Operating manual
Translation of the German original version
5290 / 06/2023 en

Legal notice
5290 / 06/2023 enBENNING PV 1-1+2
Legal notice
Notes concerning the documentation
Ensure that the applicable documentation is used for this product. For safe handling, knowledge
that is provided in these instructions is required.
The product may only be handled while following this documentation, particularly the safety
instructions and warnings it contains. The personnel must be qualified for the respective task
and have the capability to recognise risks and prevent possible dangers.
Manufacturer and holder of rights
BENNING Elektrotechnik und Elektronik GmbH&Co.KG
Münsterstraße135–137
46397 Bocholt
Germany
Phone: +492871/93‑0
E‑mail: [email protected]
Internet: www.benning.de
Commercial register Coesfeld HRAno.4661
Copyright
© 2023, BENNING Elektrotechnik und Elektronik GmbH&Co.KG
All rights reserved.
This document– particularly all of the contents, texts, photographs and graphics that it
contains– are protected by copyright.
No part of this documentation or the associated contents may be reproduced or edited, copied
or distributed using electronic media in any form (printed, photocopied or using any other
method) without express written permission.
Disclaimer
The contents of the documentation has been checked to ensure that it corresponds to the
hardware and software described. Nevertheless, deviations cannot be ruled out, so Benning
cannot guarantee complete correspondence. The contents of this documentation are checked
at regular intervals, and any corrections that are needed are contained in the versions that
follow.
General non-discrimination
Benning is aware of the importance of language with regard to the gender equality and
endeavors to take this into account at all times. To improve readability, we have refrained from
consistently using differentiating formulations.

Table of contents
Table of contents
1 Introduction................................................................................................................................................7
1.1 General notes........................................................................................................................7
1.2 History ...................................................................................................................................8
1.3 Service & support..................................................................................................................9
2 Safety........................................................................................................................................................10
2.1 Warning system ..................................................................................................................10
2.2 Standards applied ...............................................................................................................10
2.3 Symbols used......................................................................................................................11
2.4 Intended use .......................................................................................................................12
2.5 Special types of risks ..........................................................................................................14
3 Scope of delivery.....................................................................................................................................15
4 Device description...................................................................................................................................16
4.1 Device structure ..................................................................................................................16
4.2 Functions.............................................................................................................................18
4.2.1 Measured value memory.....................................................................................................19
4.2.2 Installing the data logger and driver ....................................................................................20
4.2.3 Reading out measured values via the USBinterface..........................................................20
4.2.4 Error messages...................................................................................................................21
4.2.5 BENNINGSUN2 ................................................................................................................21
4.3 Measuring ranges ...............................................................................................................22
4.3.1 Resistance ranges ..............................................................................................................22
4.3.2 Voltage ranges ....................................................................................................................23
4.3.3 Current ranges ....................................................................................................................23
5 Operation..................................................................................................................................................24
5.1 Requirements for tests and measurements ........................................................................24
5.2 Connecting the safety measuring lines ...............................................................................25
5.3 Configuration.......................................................................................................................26
5.3.1 Setting the “Auto-Power-Off”(APO) function ......................................................................26
5.3.2 Setting the date and the time ..............................................................................................26
5.3.3 Null balancing of the 4mm safety measuring lines.............................................................27
5.4 Protective conductor resistance measurement ...................................................................28
5.5 Automatic PV measurement ...............................................................................................30
5.6 DC and AC voltage measurement ......................................................................................32
5.7 Current measurement using the optional BENNINGCC3 .................................................33
5.8 Measuring several identical PV modules/ PV strings.........................................................34
5.9 BENNINGSUN2 (optional) ................................................................................................35
5290 / 06/2023 en BENNING PV 1-1+ 3

Table of contents
5.9.1 Pairing the device with the BENNINGSUN2 .....................................................................35
5.9.2 Unpairing the device from the BENNINGSUN2 ................................................................36
5.9.3 Enabling/ disabling the radio transmission of the BENNINGSUN2..................................37
6 Maintenance.............................................................................................................................................38
6.1 Maintenance schedule ........................................................................................................38
6.2 Making the device free of voltage .......................................................................................38
6.3 Cleaning the device.............................................................................................................39
6.4 Replacing the batteries .......................................................................................................40
6.5 Calibrating the device..........................................................................................................41
6.6 Replacing the fuse ..............................................................................................................41
7 Technical data..........................................................................................................................................42
8 Disposal and environmental protection ................................................................................................44
Index .........................................................................................................................................................45
5290 / 06/2023 enBENNING PV 1-1+4

Table of figures
Table of figures
Figure 1 BENNING PV 1-1+ device structure ............................................................................................ 16
Figure 2 Digital display............................................................................................................................... 17
Figure 3 Null balancing of the 4mm safety measuring lines ..................................................................... 27
Figure 4 Protective conductor resistance................................................................................................... 28
Figure 5 Automatic PV measurement ........................................................................................................ 30
Figure 6 DC and AC voltage measurement ............................................................................................... 32
Figure 7 Current measurement using the optional BENNING CC 3 .......................................................... 33
Figure 8 Automatic PV measurement ........................................................................................................ 34
Figure 9 Radio connection to the BENNING SUN 2 .................................................................................. 37
Figure 10 Battery replacement (exemplary)................................................................................................. 40
5290 / 06/2023 en BENNING PV 1-1+ 5

List of tables
List of tables
Table 1 History.......................................................................................................................................... 8
Table 2 Symbols on the device................................................................................................................. 11
Table 3 Symbols used in the operating manual........................................................................................ 11
Table 4 Symbols (warnings) on the digital display.................................................................................... 17
Table 5 Symbols (measuring functions) on the digital display.................................................................. 18
Table 6 Error messages............................................................................................................................ 21
Table 7 Measuring range for measuring the protective conductor resistanceRPE.................................. 22
Table 8 Measuring range for measuring the insulating resistanceRISO ................................................. 22
Table 9 Preset limits of the insulating resistance...................................................................................... 22
Table 10 Measuring range for measuring the open-circuit voltage VOC of the PVmodule or PVstring ... 23
Table 11 Measuring range for measuring the voltage via the 4mm test sockets....................................... 23
Table 12 Measuring range for measuring the short-circuit current ISC of the PVmodule or PVstring...... 23
Table 13 Measuring range for measuring the current using the current clamp adapter BENNINGCC3
(optional)...................................................................................................................................... 23
Table 14 Maintenance schedule................................................................................................................. 38
Table 15 Technical data ............................................................................................................................. 42
5290 / 06/2023 enBENNING PV 1-1+6

Introduction
1.1 General notes
5290 / 06/2023 en BENNING PV 1-1+ 7
1 Introduction
The battery-operated PV tester BENNINGPV1‑1+ described here (in the following only referred
to as “device”) is intended for commissioning tests and periodic inspection of grid-connected
photovoltaic systems in compliance with IEC/ DINEN62446‑1 (VDE0126‑23‑1) and IEC/
DINEN62446‑2 (VDE0126‑23‑2). The device enables you to perform the following tests and
measurements:
• Protective conductor resistance measurement with a testing current of 200mA‑DC
• Automatic display of the voltage polarity with acoustic/ visual warning in case of wrong
polarity
• Open-circuit voltage measurement on the PVmodule/ PVstring up to 1 000V‑DC
• Short-circuit current measurement on the PVmodule/ PVstring up to 15A‑DC
• Insulating resistance measurement with testing voltages of 250V‑DC, 500V‑DC or
1 000V‑DC
• Functional test by current measurement using the optional current clamp adapter
BENNINGCC3 with up to 40A‑AC/A‑DC
• Measurement of the insolation, PVmodule temperature and ambient temperature by means
of the optional insolation and temperature measuring instrument BENNINGSUN2
Further information
http://tms.benning.de/pv1-1
On the Internet, you will find the following additional information directly at the specified link or
at www.benning.de (product search):
• Operating manual of the device in several languages
• Further information depending on the device (e.g. brochures, technical reports, FAQs)
1.1 General notes
Target group
This operating manual is intended for the following groups of people:
• Qualified electricians and qualified technical personnel
Required basic knowledge
To understand these operating manual, you will need general knowledge of testing and
measuring equipment. Moreover, you will need basic knowledge of the following issues:
• General electrical engineering

1.2 History
Introduction
5290 / 06/2023 enBENNING PV 1-1+8
Purpose of the operating manual
This operating manual describes the device and provides you information about how to handle
it.
Keep this operating manual in a safe place for later use. Read this operating manual before
handling the device and follow the instructions.
NOTE
Disclaimer of liability
Please make sure that any person using the device has read and understood the instructions of
this operating manual before handling the device and that the instructions are adhered to in all
points. Non-observance of this operating manual might result in product damage, property
damage and/or personal injury.
Benning assumes no liability for damage and malfunctions resulting from the failure to observe
the instructions in this operating manual.
The devices are subject to continuous further development. Benning reserves the right to make
changes to the device’s design, configuration and technology. The information in this operating
manual corresponds to the state of technical knowledge at the time of printing. For this reason,
no claims for certain device characteristics can be derived from the contents of this operating
manual.
Information in this operating manual can be changed at any time without prior notice. Benning is
not obligated to make amendments to this operating manual or to keep it up to date.
Direct any technical questions to Technical Support [}page9].
Trademarks
All trademarks used are the property of their respective owners, even if they are not separately
marked as such.
1.2 History
Release number Amendments
06/2023 • Initial release
Table1: History

Introduction
1.3 Service & support
5290 / 06/2023 en BENNING PV 1-1+ 9
1.3 Service & support
Please contact your specialty retailer or the BENNINGServiceCenter for any repair or service
work that might be required.
Technical Support
Please contact our Technicalsupport for technical questions on handling the device.
Phone: +49287193-555
Fax: +49287193‑6555
E-Mail: [email protected]
Internet: www.benning.de
Returns management
Easily and conveniently use the BENNING returns portal for a quick and smooth returns
processing:
https://www.benning.de/service-de/retourenabwicklung.html
Phone: +49287193-554
E-Mail: [email protected]
Return address
BENNING Elektrotechnik und Elektronik GmbH&Co.KG
Retourenmanagement
Robert-Bosch-Str. 20
D- 46397 Bocholt

2.1 Warning system
Safety
5290 / 06/2023 enBENNING PV 1-1+10
2 Safety
2.1 Warning system
This operating manual contains notes that must be taken into consideration for your personal
safety and in order to avoid injuries and damage to property. Warnings about your personal
safety and to prevent personal injuries are marked with a warning triangle. Warnings on sole
prevention of material damage are shown without a warning triangle. The warnings are shown
in descending order depending on the hazard level as follows.
DANGER
Extremely dangerous situation for humans
If you do not pay attention to this warning, irreversible or deadly injuries will occur.
WARNING
Hazard to humans
If you do not pay attention to this warning, irreversible or deadly injuries could occur.
CAUTION
Minor hazard to humans
If you do not pay attention to this warning, minor or moderate injuries could occur.
NOTICE
Danger to property, not to persons
If you do not pay attention to this warning, material damage could occur.
If multiple hazard levels occur, the warning for the highest respective hazard level will be used.
In addition, a warning about personal injuries can also include a warning about material
damage.
2.2 Standards applied
The device has been built and tested in compliance with the following standards and has left the
factory in perfectly safe condition.
• IEC/ DINEN61010-1 (VDE0411‑1)
• IEC/ DINEN 61557-1 (VDE0413‑1)
• IEC/ DINEN 61557-2 (VDE0413‑2)
• IEC/ DINEN 61557-4 (VDE0413‑4)
• IEC/ DINEN 61557-10 (VDE0413‑10)

Safety
2.3 Symbols used
5290 / 06/2023 en BENNING PV 1-1+ 11
2.3 Symbols used
Symbols on the device
Symbol Meaning
Please observe the information provided in this operating manual in
order to avoid dangers.
Warning of electrical danger! Please observe the information provided
in this operating manual in order to avoid dangers.
CATI Measurement categoryI is applicable to testing and measuring circuits
which have no direct connection to the mains.
CATII Measuring categoryII is applicable to testing and measuring circuits
which are directly connected to user connections (e.g. sockets) of the
low-voltage mains installation.
CATIII Measuring categoryIII is applicable to testing and measuring circuits
connected to the distribution circuit of the low-voltage mains installation
of a building.
CATIV Measuring categoryIV is applicable to testing and measuring circuits
connected to the feeding point of the low-voltage mains installation of a
building.
The device complies with EUdirectives.
The device complies with directives applicable in GreatBritain.
At the end of product life, dispose of the unserviceable device via
appropriate collecting facilities provided in your community.
The device is provided with protective insulation (protection classII).
Please observe the operating manual.
This symbol indicates the inserted batteries.
This symbol indicates a built-in fuse.
(DC) direct voltage or direct current
(AC) alternating voltage or alternating current
Earth (voltage to earth)
Table2: Symbols on the device
Symbols used in the operating manual
Symbol Meaning
General warning
Warning of electric voltage!
Table3: Symbols used in the operating manual

2.4 Intended use
Safety
5290 / 06/2023 enBENNING PV 1-1+12
2.4 Intended use
Only use the device within the framework of the corresponding technical data. Any operating
conditions that deviate from this shall be considered as improper use. Solely the user of the
device shall be liable for any resulting damage.
Please note the following:
• In case of improper use, the liability and warranty claims become void. Solely the user of the
device shall be liable for any damage resulting from improper use. Uses not complying with
the intended use include e.g.:
– Use of components, accessories, spare or replacement parts that have not been
released and approved for the respective application by Benning
– Non-observance, manipulation, changes or misuse of the operating manual or the
instructions and notes contained therein
– Any form of misuse of the device
– Any use other than or beyond that described in this operating manual
• Warranty and liability claims are generally excluded if the damage is the result of force
majeure.
• If any prescribed services are not performed regularly or not on time, according to the
manufacturer’s specifications during the warranty period, a decision about a warranty claim
can only be made once the findings are available.
Direct any questions to Technical Support [}page9].
Using the device
Please observe the following basic obligations when using the device:
• Before carrying out tests and measurements, disconnect all poles of the PVgenerator from
the PVinverter. The PVgenerator must be isolated from the electric power supply! Neither
the positive nor the negative pole of the PVgenerator must be earthed!
• Make sure that all switching and disconnecting devices are open and all PVstrings are
insulated from each other.
• Please observe that the PVgenerator must not exceed the maximum open-circuit voltage of
1 000V, the maximum short-circuit current of 15A and the maximum DCpower
(P=VOCxISC) of 10kW.
• Carry out the tests and measurements only on individual PVstrings. Please observe that
the short-circuit currents (ISC) of PVstrings connected in parallel add up and might
additionally increase due to existing capacitances of the PVgenerator.
• Make sure that no power optimisers are installed in the PVgenerator. In the event of a
short-circuit, power optimisers might generate transient current peaks that significantly
exceed the specified short-circuit current (ISC) of the PV generator.
• The device may only be used in a technically perfect and safe condition. Always check the
device for damages before using it.
• The personnel must be qualified for the respective task.
• Observe relevant regulations on occupational safety and health as well as those on
environmental protection.
• The device may only be used in dry environments.
• Do not use the device in potentially explosive environments.
• Use suitable (approved) safety measuring lines.
• In order to prevent any danger due to incorrect measurements, replace discharged batteries
immediately.
• In order to prevent any danger, replace a defective fuse immediately.

Safety
2.4 Intended use
5290 / 06/2023 en BENNING PV 1-1+ 13
• Please observe that the device is not designed for continuous operation. The useful life of
the device is limited by software and via temperature monitoring. As soon as the internal
operating temperature has reached the maximum value, the function of the device will be
restricted in order to allow the device to cool down.
• Disconnect the device from the PVgenerator immediately after finishing the test or
measurement.
• Use the 4mm test sockets only in electric circuits up to overvoltage categoryCATIII with a
conductor for a maximum of 300V to earth. Before measurements in electric circuits of
overvoltage categoryCATIII, attach the enclosed protective caps onto the contact tips.
• Do not touch any metal parts of the test object during tests and measurements.
• If you want to use the device to prove the presence of a dangerous voltage, test the device
before and after this measurement on a known voltage source or test equipment.
WARNING
Dangerous voltage
Danger to life or serious injury is possible due to contact with high electric voltage in case of
incorrect operation.
• Do not touch the bare measuring probe tips of the safety measuring lines or the bare
contacts of the optional alligator clips, Only touch the safety measuring lines in the area
intended for your hands.
• Please note that dangerous testing voltages might be present at the device during insulating
resistance measurement. These might also be applied to the measuring circuit if safety
measuring lines are contacted.
• Connect the safety measuring lines to the correspondingly marked measuring jacks of the
device and check them for tight fit.
• Only use approved safety measuring lines.
• Attach the protective caps to the contact tips of the safety measuring lines (circuits of
overvoltage category CATIII orIV).
• When disconnecting the measuring circuit, first remove the live safety measuring line
(phase) and then the neutral safety measuring line from the measuring point.
WARNING
Opening the device
Danger to life or serious injury is possible due to contact with high electric voltage when opening
the device. The device might get damaged.
• Make sure that the device is free of voltage before opening the battery compartment.
• Do not open the device (except for the battery compartment).
• Please contact your specialty retailer or the returns management for any repairs [}page9].

2.5 Special types of risks
Safety
5290 / 06/2023 enBENNING PV 1-1+14
Securing the device
If the device is not in a technically perfect and operationally safe condition, safe operation is no
longer guaranteed. Make sure that the following measures are taken:
• Switch off the device.
• Remove the device from the measuring point.
• Secure the device against unintentional operation.
The following characteristics indicate that safe operation is no longer guaranteed:
• The device (housing or safety measuring lines) shows visible damage or is damp/wet.
• The insulation of the safety measuring lines is damaged.
• The device does not work properly in compliance with regulations (e.g. errors during
measurements).
• The device shows recognisable consequences of prolonged storage under inadmissible
conditions.
• The device shows recognisable consequences of extraordinary stress due to transport.
2.5 Special types of risks
DANGER
Bare conductors or main line carriers
Danger to life or serious injury is possible due to contact with high electric voltage when working
with bare conductors or main line carriers.
• Please observe relevant regulations on occupational safety and health.
• If necessary, use appropriate protective equipment.
WARNING
Dangerous voltage
Danger to life or serious injury is possible due to contact with high electric voltage when working
on live components or equipment. Even low voltages from 30V‑AC and 60V‑DC on can be
dangerous to human life!
• Please observe relevant regulations on occupational safety and health.
• If necessary, use appropriate protective equipment.

Scope of delivery
2.5 Special types of risks
5290 / 06/2023 en BENNING PV 1-1+ 15
3 Scope of delivery
The scope of delivery of the device includes the following components:
• 1x photovoltaic tester BENNING PV1‑1+ (itemno: 05042101)
• 1x carrying strap
• 1x transport and storage case
• 2x safety measuring lines with probe tip (l= 1.2m) (red/ black)
• 2x alligator clips (red/ black)
• 2x safety measuring lines for MC4connector (red/ black)
• 2x safety measuring lines for “Sunclix”connector (red/ black)
• 1x USB connecting cable (USB‑A plug to USB Micro‑B plug)
• 6x 1.5V batteries of type AA (IECLR6)
• 1x fuse (F500mA, 1 000V, 10kA, itemno: 749771, integrated into the device for initial
assembly)
• 1x quick reference guide
Optional accessories
• Current clamp adapter BENNINGCC3 (item no.: 044038)
ACrange: 0.2… 300A
DC range: 0.2… 300A
• Insolation and temperature measuring instrument BENNINGSUN2 (item no.: 050420)
Insolation measuring range: 100… 1 250W/m²
Temperature measuring range: -30... 125°C
• Temperature sensor with suction cup for BENNINGSUN2 for attachment to the rear of the
PVmodule (item no.: 050424)
• PVmodule holder for BENNINGSUN2 for safe attachment to the PVmodule (item no.:
050425)
• 40m measuring lines BENNINGTA5 (item no.: 044039)
Connection to Ø4mm safety test socket/ plug, l=40m, with rewinder and wrist strap
• Test badges “nexttest”, 300pieces (item no.: 756212)

4.1 Device structure
Device description
5290 / 06/2023 enBENNING PV 1-1+16
4 Device description
4.1 Device structure
1
14
13
9
11
8
15
12
2
4 356
10
77
77
Figure1: BENNING PV 1-1+ device structure
1 Front view of the device 2 Device top
3 Red 4mm test socket “+” 4 Black 4mm test socket “-”
5 Black PV test socket “-” 6 Red PV test socket “+”
7 Bracket für carrying strap 8 “Auto” key
9 “Save” key 10 USB Micro-B interface
11 “Measured value memory” key 12 “VISO” key
13 “NULL balance” key 14 “RPE” key
15 Digital display
Rear panel of the device
• Battery compartment
• Notes and information about the device
• Serial number (label, on inside of battery compartment cover)

Device description
4.1 Device structure
5290 / 06/2023 en BENNING PV 1-1+ 17
Digital display
The digital display is divided into different sections:
1 2 3
4
5
7
8
9 6
Figure2: Digital display
1 Warning symbols 2 Display of measuring functions
3 Display of measured values and units 4 Battery status
5 U/Ideviation 6 Storage location of the measurement in
the measured value memory
7 Display of memory functions 8 Indication that there is an error
message
9 Insulation test voltage
Description of symbols (warnings):
Symbol Meaning
Warning of hot surfaces!
Immediately disconnect the device from the PVgenerator when the
symbol is displayed and do not reconnect it until the symbol has
disappeared.
Warning of dangerous voltage!
High-voltage control indicator: Flashes when the device detects the
presence of a dangerous voltage on the PV safety measuring lines
(>30V).
Please observe the information provided in this operating manual in
order to avoid dangers [}page24].
Table4: Symbols (warnings) on the digital display

4.2 Functions
Device description
5290 / 06/2023 enBENNING PV 1-1+18
Description of the measuring functions:
Symbol Designation Function
Null balance Null balance enabled
RPE Protective conductor resistance
measurement
Protective conductor resistance
measurement enabled
+/- Polarity indication Indicates reverse polarity of the
DCvoltage at the 4mm test sockets.
For ACvoltage, “+” and “-” are
displayed alternately.
Polarity indication PV Indicates reverse polarity of the
DCvoltage at the PVtest sockets.
VVoltage measurement Voltage measurement enabled
RPE LOCK Continuous protective conductor
resistance measurement enabled
IS/C Current clamp measurement Current clamp measurement enabled
RISO
Positive result of insulating
resistance measurement
The measured insulating resistance is
within the preset limits.
RISO
Negative result of insulating
resistance measurement
The measured insulating resistance is
outside the preset limits.
5% 5% deviation Indicates a deviation of the displayed
measured value (open-circuit voltage or
short-circuit current) by more than 5%
from the average value of the stored
measured values.
> / < Outside measuring range The measured value is outside the
measuring range [}page22].
Table5: Symbols (measuring functions) on the digital display
4.2 Functions
Switching the device ON/OFF
Press the “RPE“ and “Auto”keys to switch the device on or off (press and hold both keys
simultaneously for approx. 2seconds). The device confirms each switch-on or switch-off with an
acoustic signal.
The device switches off automatically after the set switch-off time (APO, Auto-Power-Off),
factory setting: 1minute) [}page26].
Date and time
The device is equipped with an integrated real-time clock which automatically adds a date and
time stamp to each storage processes or storage location.
You can set the date and time manually [}page26] or the values of the BENNINGSUN2 are
optionally taken over automatically.

Device description
4.2 Functions
5290 / 06/2023 en BENNING PV 1-1+ 19
4.2.1 Measured value memory
The device can store up to 200display indications. Depending on the measurement performed,
the protective conductor resistance, the open-circuit voltage, the short-circuit current, the
insulating resistance with testing voltage or the measured AC/DCcurrent are stored for each
memory location with a date and time stamp.
Storing measured values
Press the “Save”key to store the displayed measured values to the first free storage location.
Successful storage will be confirmed by the “STORE”symbol on the digital display.
Calling measured values
Press the “Measured value memory”key to recall the stored measured values with the
corresponding storage location number. The “RECALL”symbol appears on the digital display
and the storage location number is displayed.
Press the “Measured value memory”key again to switch to the next storage location and press
the “Save”key to switch to the previous storage location.
Deleting the measured value memory
Press the “Save”key and the “Measured value memory”key simultaneously to delete the entire
measured value memory.
Calling the average value
The device determines the average values of the open-circuit voltage and the short-circuit
current of the entire measured value memory and stores them in storage location0.
Switch to storage location0 to call the average values. The “RECALL”symbol appears on the
digital display and the average values of the open-circuit voltage and the short-circuit current
are displayed.
5% deviation from the average value
In case the displayed measured value deviates by 5% from the average value, the
“5%deviation”symbol flashes.

4.2 Functions
Device description
5290 / 06/2023 enBENNING PV 1-1+20
4.2.2 Installing the data logger and driver
To read the measured values of the device on a PC via the USBinterface, you must install the
hardware driver and the “BENNINGSOLARDatalogger” software on the PC once.
Requirements
• PC with USB-A port and sufficient storage space
• Download the hardware driver and the “BENNINGSOLARDatalogger” software from the
product page of the device
http://tms.benning.de/pv1-1
• Remove any connected safety measuring lines.
Procedure
1. Install the downloaded hardware driver on your PC.
2. Install the downloaded “BENNINGSOLARDatalogger” software on your PC.
3. Connect the device to your PC using the USBconnecting cable.
The hardware driver is installed automatically on a free COMport and confirms that the new
hardware can be used.
4.2.3 Reading out measured values via the USBinterface
You can read out the measured values of the device on a PC via the USBinterface and store
them as a CSV or TXTfile.
Requirements
• PC with USB-A port and sufficient storage space
• Installed data logger and driver
• Remove any connected safety measuring lines.
Procedure
1. Connect the device to your PC using the USBconnecting cable.
2. Start the “BENNINGSOLARDatalogger” program.
3. Go to “Tools”, click “RefreshPorts” and select the corresponding COMport.
The COMport used can be viewed by means of the Device Manager of your system.
4. Click “Download”.
5. Press and hold the “Measured value memory”key for approx.2 seconds until the download
takes place and the entire measured value memory is read out.
6. Store the read-out measured values as a CSV or TXTfile.
7. To open the measurement series, e.g. via a spreadsheet programme, click “Open”.
