Berlin Gardens Harbor Table User manual

Step 1
Cordless Drill
7/16" Wrench
1
4
" x 2"
Bolt x16
1
4
" Flange
Nut x16
1
1
2
" Buglehead
Screw x8
3" Buglehead
Screw
5
8
" Panhead
Screw x16
Umbrella Knob x2
Dining Height x24
Counter Height x40
Bar Height x40
Open the box containing the Table top on all sides
but leave the top laying in the box. Next fasten
cross pieces to 1 base end and 1 base center
assembly by inserting cross piece tenons into
mortises on base assembly and fasten using
3" Buglehead Screws. (Center base assembly has
mortises on both sides of legs) Repeat base
assembly with remaining base assembly. You will
have 2 seperate base assemblies once completed.
NOTE: Dining Height will only have 1 set of cross pieces.
Counter and Bar Height Only
3" Buglehead Screws
Allen Wrench
(Included)
#2 Square Drive Bit
Harbor Table Assembly Guide
Step 1
Hardware Included
Dining Height Bar HeightCounter Height
Harbor Table Assembly 44"x96" (Dining, Counter & Bar Heights)
Tools / Items Needed

Step 2
Step 3
Begin by fastening the Umbrella Knobs to the
umbrella holder by turning them into the pre-
drilled holes. Next fasten the small cross supports
with the umbrella holder to the center base
assembly using 3" Buglehead Screws.
Place 2nd base assembly in the correct position
and fasten to table frame using 1/4"x2" Bolts and
1/4" Flange Nuts as shown. Next ensure the short
cross pieces are correctly positioned against the
center base and fasten using 3" Buglehead Screws.
3" Buglehead Screws
Umbrella Knob
5/8" Panhead Screws
1-1/2" Buglehead
Screws
Fasten 1 completed base assembly to the table frame as
shown by using 1/4x2" Bolts and 1/4" Flange Nuts.
1/4"x2" Bolts
Step 4
1/4" Flange Nuts
1/4"x2" Bolts
1/4" Flange Nuts
3" Buglehead Screws
Step 5
Start by placing a table brace against the bottom
of the table top and against the inside of a base
leg as shown. Fasten the brace against the leg
using 1, 1-1/2" Buglehead Screw. Next fasten the
aluminum piece against the top using 2, 5/8"
Panhead Screws. Note: The aluminum piece that
is fastened aginst the brace should be placed
against the table top.
Step 2
Step 5
Step 4
Bolts
Step 4
Screws
Umbrella Knob
Step 3
Screws
