ISTRUZIONI D’USO E DI INSTALLAZIONE INSTALLATION AND USER’S MANUAL INSTRUCTIONS D’UTILISATION ET D’INSTALLATION INSTALLATIONS-UND GEBRAUCHSANLEITUNG INSTRUCCIONES DE USO Y DE INSTALACION INSTALLATIEVOORSCHRIFTEN
RICEVITORE
RECEIVER
RÉCEPTEUR
EMPFÄNGER
RECEPTOR
ONTVANGER
Attenzione! Leggere attentamente le“Avvertenze” all’interno! Caution! Read “Warnings” inside carefully! Attention! Veuillez lire attentivement les Avertissements qui se trouvent à l’intérieur! Achtung! Bitte lesen Sie
aufmerksam die„Hinweise“ im Inneren! ¡Atención¡ Leer atentamente las“Advertencias”en el interior! Let op! Lees de“Waarschuwingen”aan de binnenkant zorgvuldig!
GSM RIC 24V
GSM RIC 24V
D811773 00100_01 17-11-10
8027908 384942

C
D
50 mm
1
54
mm
130 mm
B
GSM
4x0,75 mm2
4321 8765
OUT2-NC OUT2-NO
GND
OUT1-NO
max 120V 1A
IN - 12V
A
28 mm
107 mm
J9
SW1
POWER
ON
OFF
*
*non in dotazione, not provided, pas fournis,
nicht mitgeliefert, no incluido en el kit ,
niet meegeleverd
PREDISPOSIZIONE TUBI
TUBE ARRANGEMENT
AMÉNAGEMENT TUYAUX
VORBEREITUNG ROHRE
DISPOSICIÓN TUBOS
VOORBEREIDING BUIZEN
DIMENSIONI/ DIMENSIONS
DIMENSIONS / ABMESSUNGEN
DIMENSIONES / AFMETINGEN
ROTTURA PREFORI
PUNCHING OUT KNOCKOUT HOLES
RUPTURE PRÉ-TROUS
BRUCH VORBOHRUNGEN
ROTURA ORIFICIOS CIEGOS
VOORBEREIDE GATEN OPENEN
COLLEGAMENTO MORSETTIERA / TERMINAL STRIP WIRING
BRANCHEMENT BORNIER / ANSCHLUSS KLEMMLEISTE
CONEXIÓNTABLERO DE BORNES / AANSLUITING AANSLUITKAST
INSTALLAZIONE VELOCE-QUICK INSTALLATION-INSTALLATION RAPIDE
SCHNELLINSTALLATION-INSTALACIÓN RÁPIDA - SNELLE INSTALLATIE
2 - GSM RIC 24 V
D811773 00100_01

ITALIANO ENGLISH FRANÇAIS DEUTSCH ESPAÑOL
NEDERLANDS
E
FG
2
1
3
4
5
SW1
SMS
NO PIN/PUK
SIM
number
H
1 2
I
J
4321 8765
4321 8765
c
J9
43
OUT2-NC OUT2-NO
COM OUT 2
MAX 24V 1A 12V / 24V
4321 8
OUT2-NC OUT2-NO
COM OUT2
MAX 1A
87
GND
12V
+
-
6
SW1
/
1234554321
1234554321
1234554321
1234554321
#PWD123456
#WHL01
=0123456789
INSERIMENTO SIM / INSERTING THE SIM CARD/ INTRODUCTION CARTE SIM// EINSETZEN DER SIM // INTRODUCCIÓN SIM //
SIM AANBRENGEN
INSERIMENTO NUOVO NUMERO SU SIM/ADDING A NEW NUMBER TO SIM CARD/
I NTRODUCTION NOUVEAU NUMÉRO SUR CARTE SIM/
EINGEBEN EINER NEUEN NUMMER AUF DER SIM/
INTRODUCCIÓN NUEVO NÚMERO EN SIM/NIEUW NUMMER INVOEREN OP DE SIM
ATTIVAZIONE USCITA CONTATTO OUT 1
ACTIVATING THE OUT 1 CONTACT OUTPUT
ACTIVATION SORTIE CONTACT OUT 1
AKTIVIERUNG AUSGANG KONTAKT OUT 1
ACTIVACIÓN SALIDA CONTACTO OUT 1
ACTIVERING UITGANG CONTACT OUT 1
UTILIZZO INGRESSO“IN”
USE OF <IN> INPUT
UTILISATION ENTRÉE <IN>
VERWENDUNG EINGANG <IN>
USO ENTRADA <IN>
GEBRUIK INGANG <IN>
CONFIGURAZIONE OUT 2 / OUT 2 CONFIGURATION / CONFIGURATION OUT 2
KONFIGURIERUNG OUT 2 / CONFIGURACIÓN OUT 2 / CONFIGURATIE OUT 2
LISTA PERSONALE / PERSONAL LIST/ LISTE PERSONNELLE/ PERSONALLISTE / LISTA PERSONAL/ PERSOONLIJKE LIJST
* invia a...// Send to...// Envoyer à...// Senden an...// Enviar a ...// Stuurt naar....
invia a...*
Numero cell. 0123456789/
Mobile number 0123456789/
Numéro de cellulaire 0123456789/
Mobil-Nr. 0123456789 /
Número móvil 0123456789/
Nummer mobiele tel. [phone]
PASSWORD / MOT DE PASSE / PASSWORD / CONTRASEÑA
...............................
Numeri lista/ List of numbers/ Liste numéros/ Nummernliste/ Lista números / Lijst met nummers
01. 16. 31. 46. 61. 76. 91.
02. 17. 32. 47. 62. 77. 92.
03. 18. 33. 48. 63. 78. 93.
04. 19. 34. 49. 64. 79. 94.
05. 20. 35. 50. 65. 80. 95.
06. 21. 36. 51. 66. 81. 96.
07. 22. 37. 52. 67. 82. 97.
08. 23. 38. 53. 68. 83. 98.
09. 24. 39. 54. 69. 84. 99.
10. 25. 40. 55. 70. 85.
11. 26. 41. 56. 71. 86.
12. 27. 42. 57. 72. 87.
13. 28. 43. 58. 73. 88.
14. 29. 44. 59. 74. 89.
15. 30. 45. 60. 75. 90.
GSM RIC 24 V - 3
D811773 00100_01

ATTENZIONE! Importanti istruzioni di sicurezza. Leggere e seguire attentamente tutte le avvertenze e le istruzioni che accompagnano il
prodotto poiché un’installazione errata può causare danni a persone, animali o cose. Le avvertenze e le istruzioni forniscono importanti
indicazioni riguardanti la sicurezza, l’installazione, l’uso e la manutenzione. Conservare le istruzioni per allegarle al fascicolo tecnico e
per consultazioni future.
Questo prodotto è stato progettato e costruito esclusivamente per l’utilizzo indicato in questa documentazione. Usi diversi da quanto indicato
potrebbero essere causa di danni al prodotto e di pericolo.
La Ditta costruttrice di questo prodotto (di seguito “Ditta”) declina qualsiasi responsabilità derivante da un uso improprio o diverso da quello per
cui è destinato e indicato nella presente documentazione nonché dall’inosservanza della Buona Tecnica nella costruzione delle chiusure (porte,
cancelli, ecc.) e dalle deformazioni che potrebbero vericarsi durante l’uso.
L’installazione deve essere eseguita da personale qualicato (installatore professionale, secondo EN12635), nell’osservanza della Buona Tecnica e
delle norme vigenti.
Prima di iniziare l’installazione vericare l’integrità del prodotto.
Vericare che l’intervallo di temperatura dichiarato sia compatibile con il luogo destinato all’installazione dell’automazione.
Non installare questo prodotto in atmosfera esplosiva: la presenza di gas o fumi inammabili costituisce un grave pericolo per la sicurezza.
Togliere l’alimentazione elettrica, prima di qualsiasi intervento sull’impianto. Scollegare anche eventuali batterie tampone se presenti.
Usare esclusivamente parti originali per qualsiasi manutenzione o riparazione. La Ditta declina ogni responsabilità ai ni della sicurezza e del buon
funzionamento dell’automazione se vengono impiegati componenti di altri produttori.
Non eseguire alcuna modica ai componenti dell’automazione se non espres¬samente autorizzata dalla Ditta.
Smaltire i materiali di imballo (plastica, cartone, polistirolo, ecc.) secondo quanto previsto dalle norme vigenti. Non lasciare buste di nylon e poli-
stirolo alla portata dei bambini.
ATTENZIONE! i conduttori a bassissima tensione di sicurezza devono essere sicamente separati dai conduttori a bassa tensione.
Tutto quello che non è espressamente previsto nel manuale d’installazione, non è permesso. ll buon funzionamento dell’operatore è ga-
rantito solo se vengono rispettati i dati riportati. La ditta non risponde dei danni causati dall’inosservanza delle indicazioni riportate in
questo manuale. Lasciando inalterate le caratteristiche essenziali del prodotto, la Ditta si riserva di apportare in qualunque momento le
modiche che essa ritiene convenienti per migliorare tecnicamente, costruttivamente e commercialmente il prodotto, senza impegnarsi
ad aggiornare la presente pubblicazione.
WARNING! Important safety instructions. Carefully read and comply with all the warnings and instructions that come with the product
as incorrect installation can cause injury to people and animals and damage to property. The warnings and instructions give important
information regarding safety, installation, use and maintenance. Keep hold of instructions so that you can attach them to the technical
le and keep them handy for future reference.
This product has been designed and built solely for the purpose indicated herein. Uses other than those indicated herein might cause damage
to the product and create a hazard.
The Manufacturer of this product (hereinafter referred to as the “Firm”) disclaims all responsibility resulting from improper use or any use other
than that for which the product has been designed, as indicated herein, as well as for failure to apply Good Practice in the construction of entry
systems (doors, gates, etc.) and for deformation that could occur during use.
Installation must be carried out by qualied personnel (professional installer, according to EN 12635), in compliance with Good Practice and
current code.
Before commencing installation, check the product for damage.
Make sure the stated temperature range is compatible with the site in which the automated system is due to be installed.
Do not install this product in an explosive atmosphere: the presence of ammable fumes or gas constitutes a serious safety hazard.
Disconnect the electricity supply before performing any work on the system. Also disconnect buer batteries, if any are connected.
Only use original spare parts for any maintenance or repair work. The Firm disclaims all responsibility for the correct operation and safety of the
automated system if parts from other manufacturers are used.
Do not make any modications to the automated system’s components unless explicitly authorized by the Firm.
Dispose of packaging materials (plastic, cardboard, polystyrene, etc.) in accordance with the provisions of the laws in force. Keep nylon bags and
polystyrene out of reach of children.
WARNING! safety extra low voltage wires must be kept physically separate from low voltage wires.
Anything that is not explicitly provided for in the installation manual is not allowed. The operator’s proper operation can only be gua-
ranteed if the information given is complied with. The Firm shall not be answerable for damage caused by failure to comply with the
instructions featured herein. While we will not alter the product’s essential features, the Firm reserves the right, at any time, to make
those changes deemed opportune to improve the product from a technical, design or commercial point of view, and will not be required
to update this publication accordingly.
AVVERTENZE PER L’INSTALLATORE
INSTALLER WARNINGS
4 - GSM RIC 24 V
D811773 00100_01

INSTALLATION MANUAL
1) GENERAL INFORMATION
GSM receiver designed to command relay contacts through recognition of
authorized telephone numbers. The GSM receiver can store up to 99 telephone
numbers. These numbers activate the output OUT 1 through a call. You can
store up to 8 recipients who, if authorized, receive messages from the receiver.
Furthermore,thetwooutputscanbecontrolledeitheronatimedbasisorthrough
SMS text messages.
2) TECHNICAL SPECIFICATIONS
Power supply 12V/ 24V ~ + -10%
Operating temperature range -5 / +50°C
OUT 1 NO contact (Max. 120V~/24 1A)
OUT 2 NO/NC contact (Max. 24V 1A)
IP rating IP55
Band Tri-Band GSM/GPRS 900/1800/1900 MHZ
Max. telephone numbers stored in memory
99
GSM
SIM card type 3V / 1.8V
Antenna 3.5dB – 5dB
Typical standby power demand
Supply voltage Consumption (mA)
12 <120mA
12~ <200mA
24 <60mA
24~ <120mA
3) TUBE ARRANGEMENT FIG. A
4) DIMENSIONS FIG. B
5) PUNCHING OUT KNOCKOUT HOLES FIG. C
6) TERMINAL STRIP WIRING FIG. D
Terminal Description
1-2 Power supply 12V / 24 ~
8-3 OUT 2 NC contact (max. 24V 1A)
8-4 OUT 2 NO contact (max. 24V 1A)
5-6 OUT 1 NO contact (max. 120V ~ / 24V 1A)
7 Input <IN>
7) INSERTING THE SIM CARD FIG. E
Use SIM card without PIN/PUK number.
Note:youneedtoremovethe SIMcardPINrequestbeforeinsertingitintheboard,
otherwise the device will not work. To do this, insert the SIM card in a telephone
and disable the PIN request (there’s usually a security menu that allows you to
do this). If you don’t do this, after turning the phone on 3 times, you will be asked
for the PUK number again to reset the SIM card.
8) ADDING A NEW NUMBER TO SIM CARD FIG. F
9) ACTIVATING THE OUT 1 CONTACT OUTPUT FIG. G
10) OUT 2 CONFIGURATION FIG. H
Ref. 1 - Free contact (max. 24V 1A)
Ref. 2 - Powered contact (based on 12V/24V supply voltage)
11) USE OF <IN> INPUT FIG. I
Connect 12V to produce increased counter count.
12) PERSONAL LIST FIG. J
NOTE: the following convention is used herein:
- Activation OUT 1 --> 5-6 terminals output NC
- Activation OUT 2 --> OUT 2 --> 8-4 terminals output NC
The default password is 123456.The code to be sent MUST NOT contain spaces and must be written in UPPER CASE. Every time a text message is sent, the controller
answers the sender with a reply text.
GSM signal quality
Checking the GSM signal:
Excellent signal =31
Good signal =16
Sucient signal =12
Poor signal <12
Should the signal be lower than 12, nd a new location for the board or switch to a telephone provider with a better signal in the area in question.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#CSQ? #PWD123456#CSQ? CSQ=<23>
N.B. If you do not receive a reply text, it probably means you are not in an area covered by the telephone provider’s GSM signal.
Adding a new telephone number to the memory
Adding a new telephone number to the memory (maximum 99 numbers).
The telephone number must contain no more than 10 digits (no country code).
Code to be sent Sample text to be sent Sample text received
#PWDpassword#WHLposition in memory=telephone
number
#PWD123456#WHL01=0123456789
#PWD123456#WHL02=9876543210
……………………………………………
……………………………………………
#PWD123456#WHL99=xxxxxxxxxx
WHL01:
0123456789
WHL02:
9876543210
………………………………
WHL99:
xxxxxxxxxx
In the example, the telephone number 0123456789 is added in position 1; telephone number 9876543210 in position 2; and telephone number xxxxxxxxxx in
position 99.
How to activate output OUT1
Dial the telephone number of the SIM card inserted in the board from a telephone with a number entered in the memory. The call will automatically be
rejected, so there is no charge. The board activates output OUT1.
Changing the password
How to change the password to manage the various programming functions. The password must be made up of 6 digits.
The default password is 123456. All examples in this manual will have 123456 as the password.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#CAPnew password#CAPnew password #PWD123456#CAP321654#CAP321654 CAP: 321654
In the example, the password is changed to 321654. #PWD321654#……
OUT1 output activation time
Set the OUT1 output activation time in the range 1 to 99 sec. (default setting 1 sec.) when the controller receives a call from a number stored in the memory.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#GOTout1 output activation time in sections #PWD123456#GOT05 GOT: 05
In the example, output OUT1 is activated for 5 sec. whenever the controller receives a call from a number stored in the memory.
Checking a telephone number stored in a given position in the memory
Checking a stored mobile number based on its position in the memory.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#WHLposition in memory? #PWD123456#WHL02?WHL02: 9876543210
In the example, position 02 in the memory is queried.
ENGLISH
GSM RIC 24 V - 11
D811773 00100_01

INSTALLATION MANUAL
Deleting a number stored in the memory
To delete a telephone number stored in the memory.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#WHLposition in memoryD #PWD123456#WHL02DWHL02-OK
In the example, the telephone number stored in position 02 in the memory is deleted.
NB: to delete the number stored in position 99, send a text message like the one in the example:
#PWD123456#WHL99D=0000000000
Deleting all numbers stored in the memory
All telephone numbers stored in the memory are deleted.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#WHL99D #PWD123456#WHL99D DELALL-OK
Access mode
Free access. Access is granted to all telephone numbers that call, even those not stored in the memory
Code to be sent Sample text to be sent Sample text received
#PWDpassword#ACM0 (zero) #PWD123456#ACM0 ACM-OFF
Controlled access (default setting). Access is granted only to telephone numbers that are stored in the memory.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#ACM2 #PWD123456#ACM2 ACM-ON
Advanced functions
Enabling advanced functions
To enable input <IN> counter. To enable sending of messages.
1=ON
0=OFF (default setting)
Code to be sent Sample text to be sent Sample text received
#PWDpassword#CTR=on o #PWD123456#CTR=1CTR=<1>
In the example, the input <IN> counter and sending of messages are enabled.
Adding recipients to receive messages
Adding new recipients to the memory who, if authorized, will receive messages from the controller based on whichever functions are enabled below. (from 1 to 8)
Code to be sent Sample text to be sent Sample text received
#PWDpassword#TELrecipient position
number=telephone number programmed for receiving
messages
#PWD123456#TEL1=9876543210
……………………………………………..
#PWD123456#TEL6=xxxxxxxxxx
TEL1:
9876543210
TEL6:
xxxxxxxxxx
In the example, the telephone number 9876543210 is added in position 1 and xxxxxxxxxx in position 6.
Message recipient list query
Lists all telephone numbers stored in the memory authorized to receive messages.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#TEL? #PWD123456#TEL?
TEL1:
9876543210
………........
TEL8:
xxxxxxxxxx
END
Authorizing recipients to receive messages
The command to be sent is made up of 8 digits:
1=ON
0=OFF
Code to be sent Sample text to be sent Sample text received
#PWDpassword#RERN=on o on o #PWD123456#RERN=10011000 RERN:
10011000
In the example, the numbers stored in positions 1, 4 and 5 are authorized to receive messages.
Checking recipients to receive messages
Checks which recipients are authorized to receive messages.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#RER? #PWD123456#RER? RERN:
10011000
In the example, the numbers stored in positions 1, 4 and 5 are authorized to receive messages.
12 - GSM RIC 24 V
D811773 00100_01

INSTALLATION MANUAL
Warning message when <IN> contact is closed
Set the message that will be sent to authorized recipients in the memory when <IN> contact is closed.
The message must be no more than 100 characters long. Only use letters and numbers abc/ABC/123; do not use special characters (&, %,*, etc.).
Code to be sent Sample text to be sent Sample text received
#PWDpassword#STR=message text #PWD123456#STR=Gate closed String:
Gate closed
The message that will be sent is: GATE CLOSED.
Warning message when <IN> contact is opened
Set the message that will be sent to authorized recipients in the memory when <IN> contact is opened.
The message must be no more than 100 characters long. Only use letters and numbers abc/ABC/123; do not use special characters (&, %,*, etc.).
Code to be sent Sample text to be sent Sample text received
#PWDpassword#STO=message text #PWD123456#STO=Gate open String:
Gate open
The message that will be sent is: GATE OPEN.
Setting input <IN> partial counter
Set the number of times the <IN> contact is closed after which, or after multiples of which, a warning message is sent to authorized recipients.
Min. 1
Max. 65535
Default setting 500
The command to be sent is made up of 5 digits:
Code to be sent Sample text to be sent Sample text received
#PWDpassword#COA=number of times contact must be
closed before message is sent #PWD123456#COA=00005 COA=00005
In the example, message sending has been set to the 5th, 10th, 15th time etc. the <IN> contact is closed.
Setting advanced functions
Function 1: (default setting)
The board counts the number of times input <IN> changes state.- Every time the contact is closed.
The board sends the warning message when the counter reaches the value set by command #COA.-
Function 2:
The board counts the number of times input <IN> changes state.- Every time the contact is closed.
Output OUT2 is activated when input <IN> rst changes state.- See #RLOP function for instructions on de-energizing the relay.
The board sends the warning message when the counter reaches the value set by command #COA.-
Function 3:
The board counts the number of times input <IN> changes state.- Every time the contact is closed.
Output OUT2 is activated when input <IN> rst changes state.- See #RLOP function for instructions on de-energizing the relay.
The board sends the- #STR warning message every time input <IN> is closed.
The board sends the warning message when the counter reaches the value set by command #COA.-
Function 4:
The board counts the number of times input <IN> changes state.- Every time the contact is closed.
Output OUT 2 is activated for 1 sec. every time input <IN> is closed.-
The board sends the warning message when the counter reaches the value set by command #COA.-
Function 5:
The board sends the- #STR warning message every time input <IN> is closed.
Function 6:
The board sends the- #STR warning message every time input <IN> is closed.
The board sends the- #STO warning message every time input <IN> is opened.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#CTC=function number #PWD123456#CTC=4CTC=<4>
Function 4 is enabled in the example.
Checking the total number of times input <IN> has changed state
Checks the total number of times input <IN> has changed state.The number increases every time the contact is closed.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#COU? #PWD123456#COU? INC:
00143
In the example, the total number of times the input has changed state is 143.
Checking the partial number of times input <IN> has changed state
Checks the partial number of times input <IN> has changed state. The number increases every time the contact is closed and is reset when the value reaches the value set in #COA.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#COT? #PWD123456#COT? INC:
00004
In the example, the partial number of times the input has changed state is 4.
Counter reset
Both the total and partial counters are reset to 0.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#CLA #PWD123456#CLA RECO-OK
GSM RIC 24 V - 13
D811773 00100_01

MANUAL MODE:
Activation of outputs OUT1 and OUT2 for a given time
Outputs OUT1 and/or OUT2 are activated for a settable time. The outputs are independent.
Min. 1 sec., Max. 65535 sec.
Out1=1, Out2=2
The command to be sent to indicate the number of seconds is made up of 5 digits:
Code to be sent Sample text to be sent Sample text received
#PWDpassword#RLYoutput to be activated=length of time
output stays active in seconds.#PWD123456#RLY2=5400 RLY2=05400
In the example, output 2 stays active for 1 and a half hours.
Checking output state
Displays the seconds remaining, since relays were activated.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#RLY? #PWD123456#RLY?
RLY1:
00000
RLY2:
04800
In the example, output 2 stays active for another 1 hour 20 minutes.
Activating/deactivating outputs OUT1 and OUT2
The outputs are activated or deactivated. The outputs are independent.
Out1=1, Out2=2
1=ON; 0=OFF
Code to be sent Sample text to be sent Sample text received
#PWDpassword#RLOPoutput to be activated=command #PWD123456#RLOP2=1RLOP2-ON
In the example, output OUT2 is activated.
TIMED MODE
Special output functions
Function 0: (default setting)
Normally deactivated outputs. Special functions are disabled. Normal mode.-
Function 1:
Normally activated outputs. Every time a call is made from telephone numbers stored in the memory, output OUT1 is deactivated for 10 sec. and,-
after 30 seconds, output OUT2 is deactivated for 5 sec.
Function 2:
Normally activated outputs. Programming deactivation of outputs based on time of day. Calls from telephone numbers stored in the memory are-
disregarded.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#FTRY=function number #PWD123456#FTRY=2FTRY=<2>
Function 2 is enabled in the example
Programming deactivation of outputs OUT1 and OUT2 based on time of day
Determines at what time individual outputs are deactivated and for how long.
8 times can be programmed.
SS,MM,HH,TTT,G,R; BE CAREFUL TO GET THE COMMAS AND SEMI-COLON IN THE RIGHT PLACE.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#SMW=seconds,minutes,hour,output
deactivation time in seconds,number of times programmed,relay
programmed; #PWD123456#SMW=00,48,18,015,1,2; SMW:00,48,18,015,1,2
In the example, output OUT2 is deactivated at 18:48:00 for 15 sec.
Internal clock set
Set time in 24-hour format
SS,MM,HH,TTT,G,R; BE CAREFUL TO GET THE COMMAS AND SEMI-COLON IN THE RIGHT PLACE.
Code to be sent Sample text to be sent Sample text received
#PWDpassword#TSET=seconds,minutes,hour; #PWD123456#TSET=00,30,08; TIME:00,30,08
In the example, the clock is set to 08:30:00.
--------------------------------------------------------------------------------------------------------------------------------------------------
Board reset
Restores the controller’s factory settings.
N.B. the telephone numbers stored in the memory are not deleted.
Code to be sent Sample text to be sent Sample text received
*REST#password *REST#123456 REST-OK
Checking software and hardware version
Code to be sent Sample text to be sent Sample text received
#PWDpassword#EDI? #PWD123456#EDI? <WT-009_LIA>2009/8/08/10:45HW:1.0SW:1.0MW:2.3>
INSTALLATION MANUAL
14 - GSM RIC 24 V
D811773 00100_01
