BLUM CLIP top 110 User manual

Assembly instructions
Step 1 — Remove door
Remove hinge from CLIP mounting plate.
Step 2 — Rotate hinge arm
Rotate hinge arm to closed position.
Step 3 — Insert angle restriction clip
Insert angle restriction clip (70T3553) into
base of hinge arm and secure.
Step 4 — Rotate hinge arm
Rotate hinge arm to open position.
Step 5 — Reattach door
Align door and reattach to CLIP mounting plate.
Restricts opening angle to 86°
CLIP top 110° angle restriction clip
Subject to technical modifications without notice. © 2011 Blum, Inc.
LIT.HNG5201.07.11
NOTE: For use with all CLIP top 110° and 110°+ hinges (this includes CLIP top BLUMOTION)

Three-dimensional adjustment
Depth adjustment
Rotate rear spiral tech cam screw to adjust
door gap (+3 mm, -2 mm).
Side adjustment
Rotate front screw to increase or decrease
door overlay (±2 mm).
Height adjustment
Rotate cam screw on mounting plate to
adjust door position (±2 mm).
On non-cam mounting plates, loosen
screws, adjust door and retighten screws.
CLIP top BLUMOTION
Subject to technical modifications wihtout notice. © 2010
LIT.HNG5100.08.10

Cam wing mounting plate
Rotate cam screw on
the mounting plate to
adjust door position
(+/- 2 mm).
Height adjustment
CLIP mounting plate adjustments
Technical specifications subject to change without notice.
LIT.HNG6200.10.15 © 2015 Printed in USA
