en ULC Installation Manual

Control Panels ULC Installation Guide | en 3
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
1 ULC Installation Guide
During any ULC installation described within this document,
follow all rules for safe installation specified in the CEC
(Canadian Electrical Code).
Control panels
Use this guide with the following control panel models (unless
otherwise stated) and the model’s installation guide:
– B9512G/B9512G-E v3.02.006 and higher
– B8512G/B8512G-E v3.02.006 and higher
– B6512
– B5512/B5512E v3.02.007 and higher
– B4512/B4512E v3.02.007 and higher
– B3512/B3512E v3.02.007 and higher
The listed control panels are approved as ULC-S559 Fire Alarm
Signal Communicators.
Notice!
Control panel mounting
For mounting on the exterior of vault, safe, or stockroom, install
a vibration detector (s304, 8.1.5).
Combination ULC-S559 and ULC-S304 control panels
The following control panel models can be configured as
combination control panels:
– B9512G/B9512G-E v3.02.006 and higher
– B8512G/B8512G-E v3.02.006 and higher
When used a combination control panel, Fire and Burg points
must reside in separate areas.
Keypads
Use this guide with the following keypad models and the
model’s installation guide:
– B915/B915I v1.00.017 or higher
– B920 v1.05.004 or higher
Transformers
For transformers, use:

4en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
– B9512G/B9512G-E, B8512G/B8512G-E. Plug-in or hardwire
120 VAC primary, 16.5 VAC 37-40 VA secondary Class 2
Power Limited CSA/cUL listed.
– B6512, B5512/B5512E, B4512/B4512E, B3512/B3512E.
Plug-in 120 VAC primary, 18 VAC 22 VA secondary class 2
power limited CSA/cUL Listed. Hardwire 120 VAC primary,
16.5 VAC 40 VA secondary Class 2 Power Limited CSA/cUL
listed.
Refer to Compatible transformers, page 15.
Install with ULC Listed devices where applicable.
Wiring
Use unshielded cable only.
Copyright
This document is the intellectual property of Bosch Security
Systems, Inc. and is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document
are likely to be registered trademarks and must be treated
accordingly.
Bosch Security Systems, Inc. product manufacturing dates
Use the serial number located on the product label and refer to
the Bosch Security Systems, Inc. website at http://
www.boschsecurity.com/datecodes/.
1.1 Requirements
Key:
P = Programmable
R = Required
O = Optional
E = Enable

Control Panels ULC Installation Guide | en 5
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Requirements
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
Minimum battery
standby
24 hours 24
hours
24
hours
24 hours 4 hours 4
hours
Battery size1B6512/B5512/B4512/B3512: 1 x 12 V/7 Ah, 1 x 12 V/18
Ah, 2x 12 V/7 Ah B9512G/B8512G: 2x 12 V/18 Ah2
Entry delay ≤ 45 sec P N/A N/A ≤ 45
sec
≤ 45
sec
Exit delay ≤ 45 sec P N/A N/A ≤ 60
sec
≤ 45
sec
Minimum Bell
cutoff time
P P 5 min N/A34 min N/A
Communicator E E E E E E
AC power 4 4 4 5 4 4
Tamper
protection
R R O O O R
Enclosures For compatible enclosures, refer to Compatibilities,
page 9.
1 Select battery capacity based on calculated AUX current consumption for
the system, including all accessories.
2 Do not use 2 x 12 V/18 Ah with a Solex 16.5 VAC 37 VA transformer.
3 Bell should not sound.
4 Plug-in transformer, optional hardwired connection.
5 In ULC-S559 applications, the control panel AC input shall be hard-wired
in accordance with Sec. 32 of CSA C22.1, Canadian Electrical Code..

6en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Communication Channel Security (applicable to Commercial
Burglary/Financial installations)
Notice!
Active and passive communication
Systems are passive-only communication systems when the
only communication method is over PSTN using the B430
module.
Systems that use the on-board Ethernet, B426 module, or a
cellular module are active or passive communication systems
depending on the programmed poll rates.
Applicable for both IP and cellular communication.
Requirement Parameter
Supervision interval for IP and
Cellular communication is 200
seconds (UL)
Panel Wide Parameters > Enhanced
Communications > Receiver Supervision
Time set to 200 seconds
Supervision interval for IP and
Cellular communication is 180
seconds (ULC)
Panel Wide Parameters > Enhanced
Communications > Receiver Supervision
Time set to Custom, Poll Rate set to 89,
ACK Wait Time set to 15, and Retry Count
set to 5
Passive
levels*
Transmitters and supervision Receivers Risk
Levels
P1 For transmitters at the protected
premises and supervision of
communication channels, refer to the
figures in Fire monitoring communication
systems wiring diagrams, page 18.
D6600 or
D6100IPv6
Low
P2 Medium
P3 High
*Test the transmission on each communication channel every 24 hours.

Control Panels ULC Installation Guide | en 7
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Passive
levels*
Transmitters and supervision Receivers Risk
Levels
The telephone service should be of a type that provides for timed release
disconnect. In order to give the digital alarm communicator transmitter
(dialer) the ability to disconnect an incoming call to the protected
premises.
Active
levels*
Transmitters and
supervision
Receivers Risk
Levels
Backup
requirements
for network
equipment
A1 For transmitters at the
protected premises and
supervision of
communication channels,
refer to the figures in Fire
monitoring communication
systems wiring diagrams,
page 18.
D6600 or
D6100IPv6
Low 24 hr standby
or dialer as
backup
A2 Medium
A3 High
A4 Very
high
24 hr standby
*Check-in/polling signal required every 180 seconds.
For equipment used at the protected premises intended to facilitate
communications (hubs, routers, NIM, cable modems) 24-hour backup
power is required. Where such cannot be facilitated a secondary (backup)
communication channel is required.
For using private, corporate, and high speed data networks, network
access and domain access policies must restrict unauthorized network
access, and “spoofing” or “denial of service” attacks. Select the internet
service providers that have redundant servers/systems, backup power,
routers with firewalls enabled, and methods to identify and protect
against “denial of service” attacks.
For using public switched and wireless data networks, communication
channels must be facilitated such that the communicator will restrict
unauthorized access which could otherwise compromise security.

8en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Fire Monitoring Communication Systems
Refer to Wiring, page 15. The central station receiver must
receive fire alarms in 60 seconds and trouble signals in 90
seconds.
Type Transmitters and supervision Receivers
Passive1For transmitters at the protected premises
and supervision of communication
channels, refer to the figures in Fire
monitoring communication systems wiring
diagrams, page 18.
D6600 or
D6100IPv6
Active2
1Test the transmission on each communication channel every 24 hours.
2Check-in/polling signal required every 90 seconds.
To monitor a complete fire system, each ULC labeled intrusion system
must be connected to a ULC labeled fire alarm control panel. The system
must transmit system fire alarms, and supervisory and troubles signals to
the central station receiver.
Programming
You must follow the notes in the installation and programming
sections describing the system configurations for ULC Listed
installations.
Protecting the control panel – Burglary
The local control panel and local power supply must be
protected in one of the following ways:
– The control panel and power supply must be located within
the area of greatest protection on a tamper protected
circuit.
– When arming, each area must arm the area that is
protecting the control panel and any external power supply
running an audible device. This might require duplicate
protection armed by each area. Access to this protected
area, without causing an alarm, requires that all areas are
disarmed.

Control Panels ULC Installation Guide | en 9
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Additionally, the protected area for the control panel must be
programmed so that it cannot be bypassed, and must be
installed in accordance with CAN/ULC-S302 or CAN/ULC-S310.
User information
Inform the users of and note the following in the owner’s
manual:
– Service organization name and telephone number
– The programmed exit time
– The programmed entry time
– Safety precautions specified for the connected equipment.
1.2 Compatibilities
Accessory compatibility
The following table lists accessories that are compatible with
the control panel. An X in a column indicates the accessory is
compatible with the standard.
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
Keypads
B915/
B915I*
Basic X X X X X X
B920* 2-line X X X X X X
B921C*1Capacit
ive
X X
B925F* Fire/
Burg
X X X X X
B926F* Fire X

10 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
B930* ATM
style
X X X X X
B942/
B942W*
Touch
screen
X X X X X
Transformers, batteries, power supplies, etc.
B520 Power
supply
X X X X X
D122/
D122L
Battery
harnes
s
Suitable for use on approved applications.
D135A Low-
battery
discon
nect
Suitable for use on approved applications
D126
(12.0
VDC, 7
Ah)
Battery Suitable for use on approved applications.
D1218
(12 V,
18 Ah)
Battery Suitable for use on approved applications.
D1640-
CA
Transfo
rmer
Suitable for use on approved applications in Canada.

Control Panels ULC Installation Guide | en 11
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
ICP-
TR1822-
CAN
Transfo
rmer
Suitable for use on approved applications in Canada.
Enclosures
B10***2Mediu
m
X X X X X X
B112Small X X X X X X
B8103**
*
Large,
white
X X X X X X
D8103**
*
Large,
grey
X X X X X X
D8109**
*
Fire X X X X X X
D8108A*
**
Attack
resista
nt
X X X X X X
Expansion modules
B208 Octo-
input
X X X X
B299 POPEX X X X X X
B308 Octo-
output
X X X X

12 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
B600 ZONEX X X X X X
D125B3Dual
initiatin
g B
X X X X
D129 Dual
initiatin
g A
X X X
D192G NAC X X X
D8125 POPEX X X X X
D8125M
UX
Multipl
ex
X X X X
D8128D OctoP
OPIT
X X X X
D8129 Octo-
relay
X X X X
D8130 Door
release
X X X
D9127U
/T
POPIT X X X X
Communicators
B426 Ethern
et
X X X X X

Control Panels ULC Installation Guide | en 13
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
B430 PSTN X X X X X X
B4427Cellular X X X X X
B44x7Cellular X X X X X X
B450 SDI2
adapte
r
X X X X X X
Accessories
D130 AUX
relay
X X X
D132A Smoke
reversi
ng
X X
D161 Phone
switche
r
Suitable for use on approved applications.
D162 Phone
cord
Suitable for use on approved applications.
ICP-
SDI-911
4
SDI
splitter
X X X X
ICP-
EZTS
Tamper X X X X X
Door control (Access)

14 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Model
number
Desc-
ription
CAN/ULC S303 - Local Burglary CAN/ULC S304 - Signal Receiving Centre and Premise CAN/ULC S545 - Residential Fire ULC-ORD C1023 - Household Burglary ULC-ORD C1076 - Proprietary Burglary CAN/ULC S559 - Fire Signal Receiving Centres and Systems
B9018SDI2
door
control
ler
X X X X X
D9210C9SDI
door
control
ler
X X X X
*Approved for use on combination fire and burg systems when on a
different bus from fire devices.
**Combination fire and burg systems using SDI devices might require an
ICP-SDI-9114 to separate fire and intrusion devices onto separate circuits.
***In ULC-S559, the enclosure is certified for use with B9512G/B8512G
only.
1ULC listed for Proprietary Burglary and Residential Fire only.
2B6512/B5512/B4512/B3512 only.
3Refer to the Dual Class B Initiating Module (D125B) Installation Instructions
(P/N: F01U036340) for compatible D125B devices.
4Refer to the section within this section for compatible RADION devices.
5Refer to the section within this section for compatible Inovonics devices.
7Check for availability in your region.
8B9512G/B8512G/B6512 only.
9B9512G/B8512G only.

Control Panels ULC Installation Guide | en 15
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
1.3 Wiring
Notice!
When used in ULC-S559 installations, B6512/B5512/B4512/
B3512 control panels must have keypads installed in the same
room within 18 m and in metallic conduit.
B9512G and B8512G control panels are not required to have
keypad installed in the same room within 18 m.
For B6512/B5512/B4512/B3512 control panels, refer to the
D135A Installation Guide (P/N: 4998122704) for instructions.
Compatible transformers
Use one of the following transformers when wiring the system.
Model B8512G B6512 B4512 B3512 B5512 Manufacturer
B9512G
Bosch ICP-TR1640-CAN X X
Bosch ICP-TR1822-CAN X X X X
Bosch D1640-WI X X X X X X
Solex* TRI-WIT 1637C X X
*When using this transformer the max current of the control
panel is reduced to 1.0 A and battery back up is reduced to 18
Ah.
1.3.1 Input point wiring diagrams
Required control panel-to-fire alarm panel wiring
Wire three control panel points to the fire control panel outputs.
Recommended: Wire as described in this section and follow the
specific instructions for each point in Programming, page 26

16 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Notice!
Removable terminals
For FACP units with detachable terminals, wire the FACP points
as Form C relays.
Point
COM
Fire alarm
control unit
Bosch
control panel
C
NC
NO
1k
Wire control panel point 1 to the fire control panel's alarm
output.
Wire control panel point 2 to the fire control panel's trouble
output.
Wire control panel point 3 to the fire control panel's supervisory
output.
Control panel
(models
B9512G/B8512G/
B6512/B5512/
B4512/B3512)
Fire alarm
control unit
Fire Alarm
Fire Trouble
Fire Supervisory
Point 1
Point 3
Point 2
Dry contact outputs EOL supervised inputs
Demarkation box (optional)
Figure1.1: Fire alarm control unit dry contact outputs to control panel
points 1, 2, and 3

Control Panels ULC Installation Guide | en 17
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
ULC Listed seismic detector
Point
COM
NC
1
32
3
NC
2
Figure1.2: ULC Bank Safe and Vault installation
ULC commercial motion detector with tamper
Point
COM
NC
1
4
3
2
2
NC
Figure1.3: Double EOL input
ULC commercial door/window contact (1)
Point
COM
NC
NO
1
3
2
3
Figure1.4: Double EOL input for one Form C contact
Callout ᅳ Description
1 ᅳ Point sensor loop terminals
2 ᅳ Normally closed device (contact)
3 ᅳ EOL Resistor – 1.0 kΩ (2.0 kΩ and No EOL optional) at
device

18 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
1.3.2 Fire monitoring communication systems wiring
diagrams
These wiring diagrams are also representative for Commercial
Burglary Monitoring applications.
Notice!
ULC-S559 communication requirements
Passive systems must send alarm signals over both
communication devices programmed as primary.
All non-PSTN systems must send reports to the central station
using encryption.
Notice!
ULC-S559 for passive systems allows for any compatible
communication devices to be used in tandem for the
communication system (per section 5.4.2 of S559-13) with the
exceptions of S559-13, section 5.4.1. Where passive
communication systems are used, there shall be two or more
separate communication channels and at least two of the
passive communication channels shall use non-interdependent
types of communications. A communication channel is a path
extending from the protected premises.
Exception: If only one type of passive communication is
available at the protected premises, there shall be two channels
provided. Separate paths throughout the protected premises
and through any common carrier or third party communications
network to the fire signal receiving center shall be provided for
each communication channel.

Control Panels ULC Installation Guide | en 19
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Dual dialer passive communication system
Control panel
(models
B9512G/B8512G
B9512G-E/B8512G-E)
Keypad
(models
B915/B915I/B920)
PSTN Line 1
PSTN Line 2
Listed enclosure
Fire alarm
control unit
Outputs
Fire
Supervisory
Trouble
Inputs
B430
B430
Figure1.5: Control panel with 2 B430 (PSTN) modules
NOTE: Use of 2 B430 modules is permitted only when no other
technologies are available.
IP communication systems (on-board IP)
Control panel
(models
B9512G/B8512G/
B6512/B5512/
B4512/B3512)
Keypad
(models
B915/B915I/B920)
Internet/
Intranet
Listed enclosure
Fire alarm
control unit
Outputs
Fire
Supervisory
Trouble Router/
modem
Inputs
On-board IP
Figure1.6: Control panel with on-board IP
NOTES: The B9512G-E/B8512G-E/B5512E/B4512E/B3512E
control panels do not include on-board IP. Systems with single
communication channels must be active.

20 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
IP communication system (SDI2 IP)
Control panel
(models
B9512G-E/B8512G-E/
B5512E/B4512E/
B3512E)
Keypad
(models
B915/B915I/B920)
Internet/
Intranet
Listed enclosure
Fire alarm
control unit
Outputs
Fire
Supervisory
Trouble
Router/
modem
Inputs
B426
Bus connection,
supervised
Figure1.7: Control panel with a B426 module
NOTES: The B9512G-E/B8512G-E/B5512E/B4512E/B3512E
control panels require a B426 for IP. Systems with single
communication channels must be active.
PSTN/IP communication system (on-board IP)
Control panel
(models
B9512G/B8512G/
B6512/B5512/
B4512/B3512)
Keypad
(models
B915/B915I/B920)
Internet/
Intranet
Listed enclosure
Fire alarm
control unit
Outputs
Fire
Supervisory
Trouble
Router/
modem
On-board IP
B430
Inputs
Figure1.8: Control panel with on-board IP and a 430 (PSTN) module
NOTES: The B9512G-E/B8512G-E/B5512E/B4512E/B3512E
control panels do not include on-board IP.
