Bosch Rexroth IndraControl XM21 User manual

IndraControl
XM21, XM22
Controls
Operating Instructions
R911340667
Edition 03
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Bosch Rexroth AG Controls
Change Record
Edition Release
Date
Notes
Edition 01 2014-07 First edition
Edition 02 2016-08 Revised edition
Edition 03 2017-03 Notes on the explosion protection (Atex) supplemented for XM22
Copyright
© Bosch Rexroth AG 2017
This document, as well as the data, specifications and other information set
forth in it, are the exclusive property of Bosch Rexroth AG. It may not be repro-
duced or given to third parties without its consent.
Liability
The specified data is intended for product description purposes only and shall
not be deemed to be a guaranteed characteristic unless expressly stipulated in
the contract. All rights are reserved with respect to the content of this documen-
tation and the availability of the product.
Editorial Department
Development automation systems, control platform HP (MK/MePe)
RS-dd09e598460fdd310a6846a501e7d658-3-en-US-3
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Table of Contents
Page
1 About this documentation..................................................................... 1
1.1 Overview on target groups and product phases.................................... 1
1.2 Scope..................................................................................................... 1
1.3 Related documents................................................................................ 2
1.4 Customer feedback................................................................................ 2
2 Product identification and scope of delivery......................................... 2
2.1 Product identification............................................................................ 2
2.2 Scope of delivery................................................................................... 3
3 Use of the safety instructions................................................................ 3
3.1 Structure of the safety instructions....................................................... 3
3.2 Explaining signal words and safety alert symbol................................... 3
3.3 Symbols used......................................................................................... 4
3.4 Signal graphic explanation on the device.............................................. 4
4 Intended Use.......................................................................................... 5
5 Spare parts, accessories and wear parts.............................................. 5
5.1 Power connectors, 24 V......................................................................... 5
5.2 Bus base module for IndraControl XM21/XM22.................................... 6
5.3 Bus base module for IndraControl S20 I/O........................................... 6
5.4 SD card.................................................................................................. 6
5.5 End clamp.............................................................................................. 6
5.6 Wear parts............................................................................................. 6
6 Ambient conditions................................................................................ 6
7 Technical data........................................................................................ 8
7.1 Voltage supply and current consumption.............................................. 9
8 Standards.............................................................................................. 9
8.1 Standards used.................................................................................... 10
8.2 CE marking........................................................................................... 10
8.2.1 Declaration of conformity.................................................................... 10
8.3 UL/CSA certified.................................................................................. 10
8.4 Explosion protection certification (XM2201.01-...).............................. 11
Controls Bosch Rexroth AG
Table of Contents
DOK-CONTRL-IC*XM2*****-IT03-EN-P I
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Page
8.4.1 Power matrix........................................................................................ 13
8.4.2 Standards used.................................................................................... 13
8.5 Marine and offshore certification (XM2201...).................................... 13
9 Interfaces............................................................................................. 14
9.1 Connection position............................................................................ 14
9.2 Extension bus...................................................................................... 15
9.3 S20 interface....................................................................................... 15
9.4 Control bus base module .................................................................... 15
10 Mounting, demounting and electric installation.................................. 16
10.1 Installation notes................................................................................. 16
10.2 Housing dimensions............................................................................. 18
10.3 Mounting the control........................................................................... 19
10.4 Mounting S20 I/O modules.................................................................. 20
10.5 Mounting extension modules............................................................... 21
10.6 Demounting the control and the control bus base module................. 22
10.6.1 Demounting steps................................................................................ 22
10.7 Electric installation.............................................................................. 24
10.7.1 External power supply unit ................................................................. 24
10.7.2 Voltage supply for the control.............................................................. 25
10.7.3 24 V voltage supply.............................................................................. 26
10.7.4 Grounding
............................................................................................................. 28
10.7.5 Shielding.............................................................................................. 29
11 Commissioning.................................................................................... 29
11.1 Commissioning steps........................................................................... 29
11.2 Establishing a connection to the engineering PC via the USB device
interface "XF31" .................................................................................. 30
12 Device description............................................................................... 33
12.1 LEDs and operating elements.............................................................. 34
12.1.1 LEDs in the XD1 plug........................................................................... 34
12.1.2 LED block of 10................................................................................... 35
12.1.3 Operation mode switches ................................................................... 36
12.1.4 Reset button........................................................................................ 37
12.2 Initial firmware..................................................................................... 38
12.2.1 License information............................................................................. 39
Bosch Rexroth AG
Table of Contents
Controls
II DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Page
12.2.2 LED states............................................................................................ 39
12.2.3 Starting and opening the initial firmware............................................ 40
12.2.4 Installing a backup from an external SD card...................................... 41
12.3 Booting................................................................................................ 42
12.4 Fallback and recovery.......................................................................... 42
12.5 IndraControl First Touch...................................................................... 43
12.5.1 Hardware data..................................................................................... 44
12.5.2 Network settings.................................................................................. 44
12.5.3 Firmware management........................................................................ 45
12.5.4 File manager........................................................................................ 50
12.5.5 Core dump........................................................................................... 51
12.6 Backing up remanent data................................................................... 52
12.7 Real-time clock.................................................................................... 52
13 Error causes and troubleshooting........................................................ 53
14 Maintenance........................................................................................ 54
14.1 Regular maintenance tasks.................................................................. 54
15 Ordering information........................................................................... 54
15.1 Type code............................................................................................. 55
15.2 Accessories and spare parts................................................................ 56
16 Disposal............................................................................................... 57
16.1 General Information............................................................................. 57
16.2 Return.................................................................................................. 57
16.3 Packaging............................................................................................. 57
17 Service and support............................................................................ 57
Index.................................................................................................... 59
Controls Bosch Rexroth AG
Table of Contents
DOK-CONTRL-IC*XM2*****-IT03-EN-P III
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Bosch Rexroth AG Controls
IV DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

1 About this documentation
1.1 Overview on target groups and product phases
In the following illustration, the framed activities, product phases and target
groups refer to the present documentation.
Example: In the product phase "Mounting (assembly/installation)", the target
group "mechanic/electrician" can execute the activity "install" using this docu-
mentation.
Presales Aftersales
Selection Mounting
(assembly/installation)
Engineering Commissioning Operation Decommissioning
Product
phases
Target
groups
Activities
Design engineer
Programmer
Technologist
Process
specialist
Select
Prepare
Design
Construct
Mechanic/
electrician
Unpack
Mount
Install
Programmer
Commissioning engineer
Parameterize
Program
Configure
Simulate
Technologist
Process specialist
Optimize
Test
Machine
operator
Maintenance
technician
Service
Operate
Maintain
Remove
faults
Create
the NC program
Mechanic/
electrician
Disposal company
Dismount
Dispose
Fig. 1-1: Assigning the present documentation to the target groups, product phases and ac-
tivities of the target group
This document instructs the technical staff of the machine manufacturer on how
to safely perform the mechanical and electrical installation and on how to com-
mission the device.
Required qualification: Individual who is able to assess the tasks assigned and
to identify possible safety risks owing to qualification in the subject, knowledge
and experience. The individual should also be familiar with the standards and
regulations.
1.2 Scope
This operating instructions is valid for all variants of the control, whose type co-
des start with:
XM21...
Controls Bosch Rexroth AG
About this documentation
DOK-CONTRL-IC*XM2*****-IT03-EN-P 1/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

XM22...
The type code specifications are located on the type plate of the device. Also re-
fer to chapter 2 "Product identification and scope of delivery" on page 2.
1.3 Related documents
Title Part number and document type
Rexroth IndraControl S20:
System and Installation
R911335988
Application Description
Rexroth IndraControl S20:
Diagnostic Tabs and Error Messages
R911344826
Application Description
Tab. 1-1: Related documents
The XM2x controls are provided as function package with the systems
IndraMotion MLC and IndraMotion MTX. The ordering data (type code, part
number) differ according to the selected function package (system functions).
The hardware characteristics described in this document apply to all available
function packages. For more information on the function packages, refer to the
respective system descriptions.
For related documents, go to the "Rexroth Media Directory" at http://
www.boschrexroth.com.
1.4 Customer feedback
Customer requests, comments or suggestions for improvement are of great im-
portance to us. Please email your feedback on the documentations to Feed-
[e-mail]. Directly insert comments in the elec-
tronic PDF document and send the PDF file to Bosch Rexroth.
2 Product identification and scope of delivery
2.1 Product identification
(7261)
MNR: R911173147
FD: 13W08
AA1
FI:001
SN: 7260007123456789
IND.CONT.EQ
CU
17YB
US LISTED
I-C-B-H-T-V
Bosch Rexroth AG, 97816 Lohr, Germany
Made in Germany
17
8
3
21 5
11
10
9
13 12
16
15
4 76
14
1 Wortmarke
2 Materialnummer
3 Typenbezeichnung
4 Prüfziffer
5 Fertigungsdatum jjWww
6 Änderungsstand
7 Schutzart des Gehäuses
8 CE-Konformitätskennezeichen
9 Werksnummer
10 Rexroth-Barcode
11 Seriennummer
12 UL-Kennzeichen
13 Bemessungsstrom
14 Bemessungsspannung
15 Firmenanschrift
16 MAC-Adresse, MAC-Adresse al Barcode
17 Functional Index
18 Herstellungsland
UN DC 24 V
IN 0,6 A
1Word mark
2Part number 3Type name (type code) 4Check digit
Bosch Rexroth AG
Product identification and scope of delivery
Controls
2/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

5Date of manufacture (yyWww)
6State of revision
7CE conformity marking
8Plant number
9QR code
10 Serial number
11 Underwriters Laboratories Inc. mark
12 Nominal current
13 Nominal voltage
14 Company address
15 MAC address, MAC address as barcode
16 Functional index
17 Manufacturing country
Fig. 2-1: Exemplary type plate
2.2 Scope of delivery
●IndraControl XM21 or IndraControl XM22
●24 V power connector XA-CN01
●Bus base module:
– XA-BS01 (for S20 connection right)
– XA-BS02 (for S20 connection right and extension modules left)
3 Use of the safety instructions
3.1 Structure of the safety instructions
The safety instructions are structured as follows:
Burns and chemical burns due to wrong
battery treatment!
CAUTION
Safety alert symbol
Signal word
Consequences and
source of danger
Avoiding danger
Do not open the batteries and do not heat them over 80 °C.
Fig. 3-1: Structure of the safety instructions
3.2 Explaining signal words and safety alert symbol
The safety instructions in this documentation contain specific signal words (dan-
ger, warning, caution, notice) and, if necessary, a safety alert symbol (according
to ANSI Z535.6-2006).
The signal word is used to draw attention to the safety instruction and also pro-
vides information on the severity of the hazard.
The safety alert symbol (a triangle with an exclamation point), which precedes
the signal words danger,warning and caution is used to alert the reader to per-
sonal injury hazards.
Controls Bosch Rexroth AG
Use of the safety instructions
DOK-CONTRL-IC*XM2*****-IT03-EN-P 3/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

DANGER
In case of non-compliance with this safety instruction, death or serious injury
will occur.
WARNING
In case of non-compliance with this safety instruction, death or serious injury
can occur.
CAUTION
In case of non-compliance with this safety instruction, minor or moderate injury
can occur.
NOTICE
In case of non-compliance with this safety instruction, material damage can oc-
cur.
3.3 Symbols used
Hints are represented as follows:
This is an information.
Tips are represented as follows:
This is a tip.
3.4 Signal graphic explanation on the device
krax
Prior to the installation and commissioning of the device, refer to the
device documentation.
Bosch Rexroth AG
Use of the safety instructions
Controls
4/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

4 Intended Use
Danger of device damage if not the expressly
stated accessories, mounting parts, compo-
nents, cables, lines, software and firmware are
used.
NOTICE
The IndraControl XM21/XM22 control may only be used with the accessories
and mounting parts listed in this documentation. Components that are not ex-
pressly mentioned must neither be attached nor connected. The same applies to
cables and lines.
Only to be operated with the component configurations and combinations ex-
pressly defined and with the software and firmware specified in the correspond-
ing functional description.
Typical areas of application of the IndraControl XM21/XM22 are:
●Handling systems and assembly systems
●Packaging and food processing machines
●Printing machines and paper converting machines
●Machine tools
●Wood working machines
The IndraControl XM21/XM22 control may only be operated under the mounting
and installation conditions, the position, and the ambient conditions (tempera-
ture, degree of protection, humidity, EMC etc.) specified in the related docu-
mentation.
5 Spare parts, accessories and wear parts
5.1 Power connectors, 24 V
Ordering code Part number Description
XA-CN01 R911173741 24 V plug
Tab. 5-1: Power connectors, 24 V
Controls Bosch Rexroth AG
Spare parts, accessories and wear parts
DOK-CONTRL-IC*XM2*****-IT03-EN-P 5/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

5.2 Bus base module for IndraControl XM21/XM22
Ordering code Part number Description
XA-BS01 R911342346 Bus base module for IndraControl S20 connection
(right)
XA-BS02 R911342347 Bus base module for IndraControl S20 connection
(right) and extension modules (left)
Tab. 5-2: Bus base modules IndraControl XM21/XM22
5.3 Bus base module for IndraControl S20 I/O
Ordering code Part number Description
S20-BS R911172540 Bus base module for wide IndraControl S20 I/O mod-
ules
S20-BS-S R911173203 Bus base module for narrow IndraControl S20 I/O mod-
ules
Tab. 5-3: Bus base modules for S20 I/O
5.4 SD card
Ordering code Part number Description
XA-SD01 R911173844 SD card 1 GB
Tab. 5-4: SD card
5.5 End clamp
Ordering code Part number Description
SUP-M01-ENDHALTER R911170685 2 pieces of snap-on end brackets for 35 mm NS 35/7.5
or NS 35/15 carrier plate; width: 9.5 mm
Tab. 5-5: End clamp
5.6 Wear parts
There are no wear parts in the controls IndraControl XM21 and XM22.
6 Ambient conditions
Ambient temperature in operation Up to 2,000 m: -25 °C to +60 °C
2,000 m to 3,000 m: max. +55 °C
3,000 m to 4,000 m: max. +50 °C
4,000 m to 4,700 m: max. +45 °C
Ambient temperature during storage and transport -30 °C to +85 °C
Bosch Rexroth AG
Ambient conditions
Controls
6/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Operating altitude Up to 4,700 m above sea level acc. to DIN 60204
Permitted air humidity 5 % to 95 % acc. to DIN EN 61131-2, no conden-
sation
Degree of protection IP20 acc. to DIN EN 60 529
Protection class III, DIN EN 61010-2-201
Overvoltage category 2
Contamination level 2, no condensation allowed
Mechanical tests
Vibration resistance acc. to DIN EN 60068-2-6①Oscillations, sinusoidal in all three axes
5 Hz - 9 Hz with 3.5 mm amplitude
9 Hz -150 Hz with 5 g peak acceleration
Shock test acc. to DIN EN 60068-2-27 Shock stress: Shock resistance in all three axes,
11 ms semi-sinusoidal 30 g
Broadband noise acc. to DIN EN 60068-2-64 5-20-150 Hz with 0.572 g, 5 h per axis
Electrostatic discharge
ESD resistance acc. to DIN EN 61131-2
●Test voltage
Criterion B
8 kV for air discharge
6 kV for contact discharge
①The vibration stress specifications assume the use of industrial-suited RJ45 plug connec-
tions. The "Industrial RJ45 plug" of the company Yamaichi is recommended (Y-Con-
Plug-41). The cables are available as accessories (RKB0020). To protect against vibration,
secure the cables with a short distance (< 20 cm). The USB interfaces XF30 and XF31
may only be used up to a vibration stress of 1 g.
Tab. 6-1: Ambient conditions
Failure of the product due to contaminated air
NOTICE
●The ambient air must not contain acids, alkaline solutions, corrosive agents,
salts, metal vapors and other electrically conductive contaminants in high
concentrations
●Housing and installation compartments must at least comply with the degree
of protection IP 54 according to DIN EN 60529
Defective product due to gases jeopardizing
functions
NOTICE
Due to the risk of corrosion, avoid sulphurous gases (e.g. sulphur dioxide (SO2)
and hydrogen suphide (H2S)). The product is not resistant against these gases.
Controls Bosch Rexroth AG
Ambient conditions
DOK-CONTRL-IC*XM2*****-IT03-EN-P 7/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Failure of the product due to overheating
NOTICE
To avoid overheating and to ensure a smooth operation of the product according
to the minimum distances specified in chapter 10.1 "Installation notes" on page
16, air has to circulate.
This is a product that corresponds to the limit values of the emitted
interference of class A (industrial environments), but not of class B
(residential area and small enterprises).
When using the product in residential areas or small enterprises, the
operator has to take actions to prevent radio interferences (also re-
fer to DIN EN 55022).
7 Technical data
Processor IndraControl XM21: Intel E620T 600 MHz (CPU frequency)
IndraControl XM22: Intel E660T 1300 MHz (CPU frequency)
RAM 512 MB DRAM
Connection for extension mod-
ules
Via the control bus base module XA-BS02
Extension bus
Number of possible modules 3
Connection for S20 I/O Via control bus base module XA-BS01 or XA-BS02
S20 bus parameters
Transmission rate
Number of connectable mod-
ules
Max. current for the S20 bus
(UBus)
100 MBit/s
Max. 63 (per station)
2 A
Communication interfaces RJ45 connections:
●1 × Ethernet connection (10 MB, 100 MB, 1 GB)
●2 × Sercos III master/slave interface
USB ports:
●1 × USB host, maximum cable length 3 m (for the functionality,
refer to the system description of the respective system)
●1 × USB device, maximum cable length 3 m (for the functionality,
refer to the system description of the respective system)
SD card Slot for SD card
Bosch Rexroth AG
Technical data
Controls
8/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Weight 0.38 kg (incl. supply connectors)
Dimensions Refer to chapter 10.2 "Housing dimensions" on page 18
Tab. 7-1: Technical data
7.1 Voltage supply and current consumption
The following values apply to the operating voltage acc. to DIN EN 61131-2:
Nominal voltage at ULS 24 V DC SELV/PELV
Maximum voltage range of the supply voltage al-
lowed ULS
18 V DC to 31.2 V DC (incl. all tolerances and rip-
ple)
Current consumption of the control incl. the con-
nected S20 I/O modules from ULS at nominal volt-
age
Maximum 1.5 A
Current consumption of the control without the
connected S20 I/O modules from ULS at nominal
voltage
Typically 1.0 A
Power consumption of the control incl. the con-
nected S20 I/O modules from ULS at nominal volt-
age
Maximum 36 W
Power consumption of the control without the con-
nected S20 I/O modules from ULS at nominal volt-
age
Typically 24 W
Reverse voltage protection of the supply voltage Diode
Fuse protection Internal protective fuse, 2.5 A
Transient protection
Pulse load up to 1,500 W
Present, suppressor diodes
Voltage dips at current supply interfaces PS2 < 10 ms, evaluation criterion A
Electrical isolation
24 V supply ULS to the functional earth
No separation between 0 V of the ULS and FE
(housing)
Tab. 7-2: Operating voltage and current consumption
Electronic damage due to polarity reversal or
due to a nominal current that is too low
NOTICE
The power supply unit has to be able to deliver the quadruple nominal current of
the protective fuse to ensure that the fuse reliably triggers in case of an error.
8 Standards
The products have been developed according to the German edition of the
standards published at the time of product engineering.
Controls Bosch Rexroth AG
Standards
DOK-CONTRL-IC*XM2*****-IT03-EN-P 9/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

8.1 Standards used
Standard Meaning Edition
IEC 60204-1 Electrical equipment of machines 2007
IEC 61131-2 Programmable controllers 2008
IEC 60529 Degrees of protection provided by enclosures (IP Code) 2014
IEC 61010-2-201 Safety requirements for electrical equipment for measure-
ment, control and laboratory use
2014
UL 61010-2-201 Safety requirements for electrical equipment for measure-
ment, control and laboratory use
2014
Tab. 8-1: Standards used
8.2 CE marking
8.2.1 Declaration of conformity
The electronic products described in the present operating instructions comply
with the requirements and the target of the following EU directive and with the
following harmonized European standards:
EMC directive 2014/108/EC
The electronic products described in the present operating instructions are in-
tended for use in industrial environments and comply with the following require-
ments:
Standard Title Edition
DIN EN 61000-6-4 Electromagnetic compatibility (EMC)
Part 6-4: Generic standards – Emission standard for indus-
trial environments
September
2011
DIN EN 61000-6-2 Electromagnetic compatibility (EMC)
Part 6-2: Generic standards – Immunity for industrial envi-
ronments
March 2006
Tab. 8-2: Standards for electromagnetic compatibility (EMC)
Loss of CE conformity due to modifications at the device.
CE marking applies only to the device upon delivery. After modifying
the device, verify the CE conformity.
8.3 UL/CSA certified
Bosch Rexroth AG
Standards
Controls
10/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

The devices are certified acc. to
●UL 61010-2-201 (Industrial Control Equipment) and
●CSA22.2 No. 61010-2-201 (CSA)
However, there can be combinations or extension stages with a limited or miss-
ing certification. Thus, verify the registration according to the UL marking on the
device.
Loss of UL/CSA conformity due to modifications at the device.
UL and CSA marking applies only to the device upon delivery. After
modifying the device, verify the UL and the CSA conformity.
To guarantee an UL/CSA-compliant operation, the following condi-
tions have to be fulfilled:
●Use only insulated copper wire suitable for at least 60/75°C
8.4 Explosion protection certification (XM2201.01-...)
II 3G
Ex ec IIC T4 Gc
TÜV 16 ATEX 7948 X
IECEx TUR 16.0048 X
Ex Explosion protection label
II Equipment group II: Explosive gas
atmospheres
3G Equipment category 3: Explosive at-
mosphere (zone 2)
Ex Explosion protection label
ec Type of protection "Increased safety"
IIC Gas group IIC, hydrogen
T4 Maximum surface temperature
135 °C
Gc Equipment protection level (EPL),
rare and momentary explosive at-
mosphere (zone 2): Flammable
gases, vapors, mists
TÜV... ATEX EU type examination certificate
IECEx... IECEx certificate number
...X Note on special conditions, refer to
the following note.
Fig. 8-1: Exemplary type plate
The approval numbers given on the type plate are marked at the end with an "X"
for devices and a "U" for components. "X" indicates special conditions to be ob-
served together with the safety and health regulations given in the standards.
"U" indicates a component (Ex component) that may not be used on its own.
Controls Bosch Rexroth AG
Standards
DOK-CONTRL-IC*XM2*****-IT03-EN-P 11/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

Observe the following special conditions for a safe operation of the
devices and components:
●The explosion protection approval applies only to the control
XM2201.01-....
●The explosion protection approval is only valid if the devices and
components approved by Bosch Rexroth are used as intended, re-
fer to chapter 4 "Intended Use" on page 5.
●The XM22 control may only be used together with the additional
components and accessories approved by Bosch Rexroth. Other-
wise, the explosion protection approval does not apply.
●In case of unintended modifications at the device or at the com-
ponents, the explosion protection approval does also not apply.
For maintenance and troubleshooting, refer to chapter 14 "Main-
tenance" on page 54 and chapter 13 "Error causes and trouble-
shooting" on page 53.
●The XM22 control may only be used in an area with the minimum
pollution degree 2 as defined in IEC 60991-1.
●For the permitted ambient temperature range, refer to chapter 6
"Ambient conditions" on page 6.
●The XM22 control may only be installed in a housing (control cabi-
net) providing at least an ingress protection of IP54 in compliance
with IEC 60079-0.
●Take suitable actions to ensure that the supply voltage outside the
device or the component is always within the permitted voltage
range (±10%) acc. to EN 60079-0.
●Maintenance and repair work may only be carried out by the certi-
fied Rexroth service.
●Always store and transport the device or the component in the
original package.
Explosion hazard
DANGER
Working at the device is only permitted if there is no explosive atmosphere.
Explosion hazard when exceeding or falling be-
low the ambient temperature
DANGER
Do not exceed the ambient temperature permitted, refer to chapter 6 "Ambient
conditions" on page 6
Bosch Rexroth AG
Standards
Controls
12/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

8.4.1 Power matrix
Devices and com-
ponents
Max. internal current consumption Max. internal power consumption
XM2201.01.-......
R911173148
1500 mA 36.0 W
XFE01.1-FB-03
R911173397
200 mA 4.8 W
XFE01.1-FB-20
R911173957
200 mA 4.8 W
S20-AI6-AO2-
SSI2
R911173120
100 mA 2.4 W
S20-PWM-4-T
R911173461
400 mA 9.6 W
Tab. 8-3: Power matrix of the XM22 control and the approved components
If the housing surface (control cabinet) is 1m2, up to 87 W of inter-
nal power consumption of the individual devices and components
are permitted.
8.4.2 Standards used
Standard Title
EN 60079-0:2012 + A11:2013
IEC 60079-0:2011, modified + Corr.:2012
+ Corr.:2013
Explosive atmospheres –
Part 0: Equipment –
General requirements
EN 60079-7:2015
IEC 60079-7:2015
Explosive atmospheres –
Part 7: Equipment protection by increased safety "e"
Tab. 8-4: Standard used for explosion protection
8.5 Marine and offshore certification (XM2201...)
The control XM2201 ... is suitable for the use in marine and offshore applica-
tions and was approved by the following certification organizations:
●DNV-GL Det Norske Veritas, Germanischer Lloyd DCTC_30826-001
●ABS American Bureau of Shipping DCTC_30826-002
●RINA Registro Italiano Navale DCTC_30826-003
●LR Lloyd's Register DCTC_30826-004
●BV Bureau Veritas DCTC_30826-005
Controls Bosch Rexroth AG
Standards
DOK-CONTRL-IC*XM2*****-IT03-EN-P 13/61
LSA Control S.L. www.lsa-control.com [email protected] ([phone]

●BSH Bundesamt für Seeschifffahrt und Hydrographie DCTC 30826-006
For more information, refer to www.boschrexroth.com/dcc/Vornavi-
gation/VorNavi.cfm?PageID=p650746.
9 Interfaces
9.1 Connection position
1 2
8
67
5
3
94
Fig. 9-1: Interfaces
Attaching and detaching connections under
voltage can damage the control!
NOTICE
Switch off the supply voltage before attaching or detaching any connections!
No. Name Connection type Connector type
(Integrated)
Mating connector and cable
(From outside)
①XF1 Ethernet
(Sercos)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair, 8-wire)
②XF2 Ethernet
(Sercos)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair, 8-wire)
③XF31 USB device
USB 2.0
Micro USB socket
4-pin
Micro USB plug
(4-wire)
Bosch Rexroth AG
Interfaces
Controls
14/61 DOK-CONTRL-IC*XM2*****-IT03-EN-P
LSA Control S.L. www.lsa-control.com [email protected] ([phone]
