Cordless glue pen GluePen
Weight according to
EPTA-Procedure 01:2014
kg 0.14
Rechargeable battery Li-ion
Rated voltage V= 3.6
Capacity Ah 1.5
Number of battery cells 1
Operating time per battery
charge approx. (according
toBosch testing procedures)
min 30B)
A) Limited performance at temperatures <0°C
B) Corresponds to approx. six glue sticks
Power supply
Article number 26091207..
Output voltage V 5.0
Output current A 1.0
Permitted battery tempera-
ture during charging
°C +5to+40
Charging time h 3−4
Protection class /
Additional technical data can be found at:
http://www.bosch-do-it.com/ecodesign
Assembly
Battery Charging (seefigureA)
uUse only the power supplies listed in the technical
data. Only these power supplies are matched to the lith-
ium-ion battery of your glue pen.
uPay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the power adaptor. Power adaptors
marked with 230V can also be operated with 220V.
Note: The battery is supplied partially charged. To ensure
full capacity of the battery, completely charge the battery
before the first use.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The Li-ion battery is protected against deep discharge. A
protective circuit switches the glue pen off when the battery
is drained, meaning the adhesive is no longer being heated.
If the LED indicator(5) flashes red, the battery has less than
30% capacity and should be charged. When the battery is
fully charged, the LED indicator is continuously lit red.
To charge the battery, connect the Micro-USB
connector(12) of the charging cable(9) to the charging
socket(8) and the USB charging connector(11) to the
power supply(10). Then plug the mains plug of the power
supply into the plug socket.
The LED indicator(5) will flash green during the charging
process. When the charging process is complete, the LED in-
dicator will be continuously lit green. Unplug the power sup-
ply from the mains.
The glue pen cannot be used during the charging process.
The lack of function during the charging process does not
mean that the tool is defective.
uProtect the power adaptor against moisture!
Operation
Starting Operation
Switching On and Off
To switch on the glue pen, press and hold the on/off
button(4) until the LED indicator(5) lights up green.
The LED indicator(5) will flash while the tool is warming up.
When it is continuously lit up, the glue pen is ready to use.
To switch off the glue pen, press and hold the on/off
button(4) until the LED indicator(5) goes out.
Note: The glue pen will switch itself off automatically after
ten minutes to save energy.
When switching on again, check the LED indicator(5): If it
briefly lights up red, the battery needs to be charged.
uPlace the glue pen down in a safe place after use and
let it cool down completely before packing it away.
The hot nozzle can cause damage.
Working Advice
uKeep people and animals away from the hot adhesive
and the nozzle tip. Adhesive and nozzle tip will heat up to
170°C, posing a risk of burns. If hot adhesive comes into
contact with skin, immediately hold the affected area un-
der a stream of cold water for several minutes. Do not try
to remove the hot adhesive from the skin.
Only use adhesives that have been recommended by the
manufacturer of the glue pen.
Adhesive bonds can become unstuck when they are affected
by moisture.
Preparing for gluing
The bonding locations must be clean, dry and free from
grease.
The materials to be glued together and the work surface
must not be easily ignited or flammable.
Test whether heat-sensitive materials are suitable before-
hand on a sample workpiece.
The ambient temperature and the workpieces to be glued
must not be colder than +5°C and not warmer than +50°C.
Materials that cool the adhesive down quickly should be
warmed first with a hot air gun.
Gluing (seefigureB)
Push the glue stick(6) suited to the material into the glue
stick compartment(7).
Switch the glue pen on and allow it to heat up. The LED indic-
ator (5) flashes.
As soon as the LED indicator (5) is continuously lit, the glue
pen is ready to use.
