Bosch AMAX 2100 Instruction manual

AMAX 2100 / 3000 / 4000
en Quick Start Manual

Table of contents
1Graphics 4
2Safety 6
3Short information 8
4Connecting Modules and Devices 9
5Programming and Operating the AMAX System 10
5.1 Option: Changing Menu Language 10
5.2 Accessing the Menus 10
5.3 Menu Navigation 10
5.4 Programming the AMAX System via Keypad 11
5.4.1 Setting Date and Time 11
5.4.2 Deleting a Zone 11
5.4.3 Enabling the RF Receiver for Wireless Communication 12
5.4.4 Setting up a Zone for an RF Device 12
5.5 Programming the AMAX Sytem via PC and USB 13
5.5.1 Installing the Programming Software 13
5.5.2 Connecting the PC and the AMAX Panel 13
5.5.3 Starting the Programming Software 13
5.5.4 Setting the COM Port 14
5.5.5 Option: Creating a New Customer 16
5.5.6 Configuring the Control Panel 17
5.5.7 Establishing a Direct Connection 20
5.6 Menu Programming 21
6Technical Data 31
AMAX 2100 / 3000 / 4000 Table of Contents | en 3
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Graphics
Figure 1.1: Wiring diagram for AMAX panel 2100 / 3000
1
4en | Graphics AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Program Key Port
GND
-
+
A C
AC
Transformer
Battery
Tamper
L2 COM COM COM
L1a L3 L4 L5 L6 L7 L8
L9
COM
COM
COM
COM
L10
L11
L12
L13
L14
L15
L16
P0+4
R
B
G
Y
AUX1
-
AUX2
-
AUX1
+12V
Y
G
B
R
RINGRHTHTIP
L1b
P0+3
P0+
P0-2
P0-1
Zones
Bosch Option
Bus2 < 900mA
+12V
+0 V
1
2
3
3
1 Tamper Switch
2 Zone Switch
3 EOL 2,2 k
4 NO + NC
3
2
3
2
Fuse 1 A
PO+4: < 750mA
PO+3: < 750mA
PO -2: < 500mA
PO -1: < 500mA
230V ~50Hz
230mA
Wachdog
output
<100mA
12V < 18Ah
18VAC@50VA
Zones
AUX 1: < 900mA
AUX 2: < 900mA
AUX Power
Fire
Intrusion
3
3
2
Slow flash: Normal state
On: Trouble state
Off: Trouble state
_
_
_
_
_
_
_
_
+12V
+12V
+12V
COM
_
12V 7Ah
AUX2
+12V
_
COM
supervised
PO-5
Z1
2
23
3
Keypads:
IUI-AMAX4-TEXT
IUI-SOL-TEXT
IUI-AMAX3-LED16
IUI-AMAX3-LED8
Keypads:
IUI-AMAX-LED8
IUI-AMAX-LCD8
I/O Moduls:
DX2010 Adr. 103 - 108
DX3010 Adr. 150 - 151
DX4010 Adr. 253
Communicators:
DX4020G Adr. 134
B426 Adr. 134(6) / 250(9)
RF Receiver:
RF3227E 1=
RFRC-OPT 1= (1)
1 =
2=
3 =
4 =
1=
2=
Bosch Option
Bus1 < 900mA
COM
R
BGY
R
B
G
Y
R
B
G
Y
♥
IUI-AMAX3 +4 Keypad
3
1
2
1
Factory
Default
5-16 Inst. Guide
I
2000mA
100 Ω - 2,2 k
_
<
∑
3
Figure 1.2: Wiring diagram for AMAX panel 4000
AMAX 2100 / 3000 / 4000 Graphics | en 5
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Safety
Danger!
Electricity
Injuries due to electricity are possible if the system is not operated correctly or if the system
is opened or modified not accordingly to this manual.
– Disconnect all Telecommunication Network Connectors before switching off the power.
– To switch off the power, make sure to have a circuit breaker available.
– Make sure that the system is switched off during the installation and wiring process.
– Only open or modify the system accordingly to this manual.
– Make sure to connect the system to a socket-outlet with a protective grounding contact.
– Only qualified installers /service personnel are allowed to install this system.
Danger!
Battery
Injuries due to electric shock, fire or explosion are possible if the battery is handled or
connected incorrectly.
– Always handle the battery carefully and replace it carefully.
– Make sure that the grounding terminal is always connected and that N, L1 or xx are
connected correctly.
– Make sure to first disconnect the positive wire of the battery when removing it from the
system.
– Be careful when connecting the positive (red) wire and the "BATT +" port of the system.
Make sure not to short-circuit with the "BATT +" port of the AMAX panel or the housing to
prevent electric arc from occurring.
Danger!
Electrostatic-sensitive components
Injuries due to electric shock are possible if anti-static steps are not followed.
– Always contact the grounding terminal before installing the system to discharge the
possibly carried static electricity.
!
Caution!
Sensitive components
Damage of sensitive components is possible if the system is not handled carefully or if the
system is opened or modified not accordingly to this manual.
– Always handle the system carefully.
– Only open or modify the system accordingly to this manual.
!
Caution!
Battery
Damage or contamination of the system is possible if the battery is not handled correctly or if
the battery is not replaced on a regular basis.
– Only use a non-spillable battery.
– Place a label with the last replacement date on the battery.
2
6en | Safety AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

– Under normal conditions of use, replace the battery every 3-5 years.
– Recycle the battery after replacement according to local regulations.
!
Caution!
Installation
Damage or malfunction of the system is possible if the system is not mounted and installed
correctly.
– Place the system inside the monitored area on a stable surface.
– Make sure to mount keypads on the inner side of the monitored area.
– Once the system is tested and ready to use, secure the enclosure door and additional
enclosures with screws.
!
Caution!
Maintenance
Damage or malfunction of the system is possible if it is not maintained on a regular basis.
– It is recommended to test the system once a week.
– Make sure to get the system maintained four times a year.
– Only qualified installers /service personnel are allowed to maintain this system.
AMAX 2100 / 3000 / 4000 Safety | en 7
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Short information
This Quick Start Guide contains information on how to get the system into operation easily
and quickly. The guide describes the main steps required for basic system installation and
setup of an AMAX panel together with one IUI-AMAX4-TEXT keypad and one RFRC-OPT
RADION receiver. The program tree structure is provided at the end of this guide.
Detailed information about installation of other modules and devices, advanced settings and
programming can be found in the Installation Guide. For detailed operation information,
please refer to the User Guide.
3
8en | Short information AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Connecting Modules and Devices
The AMAX panel provides BOSCH option bus 1 and option bus 2 (only for AMAX 4000) to
connect modules and devices. Each module can be connected to each bus.
A maximum of 14 modules (8 keypads) can be connected to each bus.
The following overview displays the maximum number of modules that can be connected.
Module AMAX panel
2100
AMAX panel
3000
AMAX panel 4000
Keypads 4 8 16
DX2010 3 6
DX3010 1 2
B426 or DX4020 2 / 1 if DX4020G is used
B450 with B442 1
DX4020G 1
DX4010 1
RF receiver 1
Table 4.1: Maximum number of modules
How to connect a keypad and a RADION receiver:
1. Connect the keypad to the option bus on the AMAX panel according to the wiring diagram
(refer to Graphics, page 4).
2. Connect the RFRC-OPT RADION receiver to the option bus on the AMAX panel according
to the wiring diagram (refer to Graphics, page 4).
3. Connect the red and black wires supplied with the battery to the AMAX panel and the
battery.
4. Connect the power adapter and battery to the mains.
4
AMAX 2100 / 3000 / 4000 Connecting Modules and Devices | en 9
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Programming and Operating the AMAX System
The AMAX system can be programmed and operated with menus by using keypads and/or the
A-Link Plus remote programming software on a PC.
When all modules and devices are installed, the AMAX panel indicates the system status with
the LED status indicator on the system main board. A slow flashing in red (repeating on and
off with an interval of 1 second) indicates normal system operation.
The AMAX panel begins charging the battery. The green MAINS indicator on the keypad
indicates that the power supply is switched on and the keypad beeps.
4Press any key on the keypad.
The keypad stops beeping and you are prompted to enter a code.
The AMAX system provides two types of default access codes:
–Installer Code: [1234]
–User Code: [2580]
Option: Changing Menu Language
If necessary, the menu language can be changed. If not, proceed to section Accessing the
Menus, page 10.
1. Enter the installer code [1234] + [58] or the user code [2580] + [58] and press [#].
The available menu languages are displayed.
2. Select the desired language on the keypad.
3. Press [#].
PThe menu language is changed.
Accessing the Menus
Accessing the Programming Menu
1. Confirm that the system is disarmed.
2. Enter the installer code. The default setting for the installer code is [1234].
The system displays [958] PROGR. MODE [-EXIT].
3. Enter [958] + press [#].
PYou have now access to the programming menu for configuring the AMAX system.
PThe STAY and AWAY indicators flash to indicate the programming mode.
Accessing the User Menu
4Enter the user code. The default setting for the user code is [2580].
PThe system displays [▼/▲] USER MENU *STAY #AWAY [-] INFO.
PYou have now access to the user menu for operating the AMAX system.
Menu Navigation
This section provides an overview of how to navigate the programming menu of a text keypad.
Selecting a Menu
1. Select the menu and operate according to the menu prompt.
2. Press [▼] or [▲] to navigate to the desired menu.
3. Press [#] to enter a menu.
Exiting a Menu
4Press [–] to get back to the previous menu.
5
5.1
5.2
5.3
10 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Confirming the Input
4Press [#] to confirm the input.
Switching between Settings
4Press and hold [*] for 3 seconds to switch between settings.
Operating a Menu
1. Operate according to the menu prompt.
Select the menu and enter data for specific programming items according to the display
on the keypad to complete the programming, step by step.
2. Press [#] to confirm each step.
Exiting the Programming Menu
1. Complete all programming input by repeating the programming steps above and press [–]
to get back to the current main menu level by level.
2. Press [–] to get to the EXIT PROG. +SAVE menu.
It is optional to save or not to save the programming data.
1. Select EXIT PROG. +SAVE and press [#] to save the data and to exit the programming
mode.
2. Select EXIT PROG. UNSAVED and press [#] to exit programming mode without saving
the data.
Programming the AMAX System via Keypad
If the keypad is in standby mode, it gets enabled as soon as the first digit of a code is entered.
Setting Date and Time
After the system is powered up, date and time must be set. Otherwise, the system displays a
fault.
1. Make sure that the system is in a disarmed status (the STAY and AWAY indicators are
disabled).
2. Enter the installer code [1234] + [51] and press [*] to get to CHANGE DATE / TIME.
3. Enter the current date and time by using the numeric keys and press [*] to confirm.
PDate and time are set.
Deleting a Zone
The zones 1-8 are enabled by default. The zone type for zone 1 is set as 03-delay 1, for zones
2-8 as 01-instant by default. Perform the following steps if you want to delete a zone.
1. Enter the installer code [1234] + [958] and press [#].
2. Select 3 ZONE MANAGER and press [#].
3. Select ADD/DELETE ZONES and press [#].
The system displays the next menu item: INPUT ZONE No.
4. Enter the number of the zone you want to delete (example: 1) and press [#].
The system displays the next menu item: ZONE NAME INPUT.
5. Optionally enter a name for the zone. Therefore, the numbers on the text keypad function
as an alphabetical input.
6. Press [#] to confirm.
The system displays the next menu item: ZONE MODULE SEL.
7. Select the correct zone module (default is 0-on board zone) and press [#].
The system displays the next menu item: ZONE FUNCTION.
8. Enter 00 for the zone function 00-not used and press [#].
5.4
5.4.1
5.4.2
AMAX 2100 / 3000 / 4000 Programming and Operating the AMAX System | en 11
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

The system displays the next menu item: ZONE IN AREA. There is no need to proceed to
the following menu items for deleting a zone.
9. Press [–] four times to get to the EXIT PROG. +SAVE menu.
10. Press [#] to save the data end exit the programming mode.
PThe selected zone is deleted (example: zone 1 is deleted).
Enabling the RF Receiver for Wireless Communication
1. Enter the installer code [1234] + [958] and press [#].
2. Select 7 RF MANAGER and press [#].
3. Select RF SETTING and press [#].
4. Select RF RECEIVER and press [#].
5. Select 1-enable and press [#].
6. Press [#] to confirm.
7. Press [–] three times to get to the EXIT PROG. +SAVE menu.
8. Press [#] to save the data end exit the programming mode.
PThe RF receiver for wireless communication is enabled.
Setting up a Zone for an RF Device
1. Enter the installer code [1234] + [958] and press [#].
2. Select 3 ZONE MANAGER and press [#].
3. Select ADD/DELETE ZONES and press [#].
The system displays the next menu item: INPUT ZONE No.
4. Enter the number of the zone to which you to assign the RF device and press [#].
The system displays the next menu item: ZONE NAME INPUT.
5. Optionally enter a name for the zone. Therefore, the numbers on the text keypad function
as an alphabetical input.
6. Press [#] to confirm.
The system displays the next menu item: ZONE MODULE SEL.
7. Select the correct zone module depending on the RF device:
For RFUN / RF3401E (Zone input only) select 5-RF RFUN no magn
For RFGB / RF1100E (Glass Break Detector) select 4-RF RFGB glassb.
For all other RF devices (Zone input only) select 3-RF all
8. Press [#] to select and [#] again to confirm.
The system displays the next menu item: ZONE FUNCTION.
9. Enter 01 for the zone function 01-instant and press [#].
The system displays the next menu item: ZONE IN AREA.
10. Enter the number of the area you want to assign to this zone and press [#].
The system displays the next menu item: ZONE RFID: MANUAL.
11. Enter the RF ID manually (9 digits).
Or
Press and hold [*] for three seconds to switch to the ZONE RFID: AUTO menu.
Trigger the RF device to give alarm once.
The RF ID will be entered automatically.
12. Press [#] to confirm.
13. Press [–] four times to get to the EXIT PROG. +SAVE menu.
14. Press [#] to save the data end exit the programming mode.
PThe selected zone is set up for an RF device.
5.4.3
5.4.4
12 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

4Test the zones after finishing programming. Trigger the zone and verify that the keypad
indicates the zone as open.
Programming the AMAX Sytem via PC and USB
By using the A-Link Plus remote programming software on a PC, the AMAX panel configuration
can be remotely programmed or controlled. For direct communication, the PC and the AMAX
panel have to be connected with the USB cable (male A / male A).
Installing the Programming Software
4Double-click on the A_Link_setup.exe file to install the programming software on the PC.
PAn installation wizard guides you through the installation.
Connecting the PC and the AMAX Panel
1. Connect the USB cable to the USB port on the AMAX panel and to one of the USB ports
on the PC.
2. Follow the operating system instructions to install the USB driver.
You will find the device driver in the A-Link Plus program path for installation
(example: C:\Programme\Bosch Security System\A-Link Plus\USB_DRIVER).
3. Open the Device Manager in the operating system control and check if the USB driver
has been installed and which COM port has been assigned to it.
4. If the USB driver has not been installed automatically, install it manually.
PThe installation creates an additional COM device on the PC.
Starting the Programming Software
1. Select Start – All Programs – Bosch Security Systems – A-Link Plus – A-Link Plus
vn.n.n.
n.n.n = current program version
Or
Double-click the A-Link Plus vn.n.n shortcut on your computer desktop.
2. When the Login dialog opens, enter the Operator name and Password.
The default entries are ADMIN for both the Operator and Password fields.
3. Click OK to log in to A-Link Plus.
5.5
5.5.1
5.5.2
5.5.3
AMAX 2100 / 3000 / 4000 Programming and Operating the AMAX System | en 13
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Setting the COM Port
The COM port that has been assigned to the additional COM device (here COM4) has to be set
in the A-Link Plus program.
4Select File – Communication Settings from the menu bar of the A-Link Plus program.
Figure 5.1: Selecting Communication Settings
The Communication Settings dialog opens.
4Set the COM port assigned to the additional COM device (here COM4) as Direct Link
Port.
5.5.4
14 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Figure 5.2: Communication Setting – Selecting the direct link port
AMAX 2100 / 3000 / 4000 Programming and Operating the AMAX System | en 15
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Option: Creating a New Customer
If necessary, create a new customer.
4Select Customer – New Customer from the menu bar.
The Customer Information index sheet opens.
Figure 5.3: Customer Information – Creating a new customer
1. Enter the customer name in the Customer Group entry field to create a new customer.
2. Enter other relevant customer information. The Customer Number is mandatory.
3. Save and close.
5.5.5
16 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Configuring the Control Panel
1. Select Customer – Open Customer from the menu bar of the A-link Plus program.
The Customer Information dialog opens.
2. Select the Control Panel Configuration index sheet.
3. Select the Control Panel Type.
Figure 5.4: Control Panel Configuration - Selecting the control panel type
1. Select the item Communication and Report manager – Receiver setting in the same
index sheet.
2. Make sure that the value for subscriber number 1 is the same as currently programmed in
AMAX panel as receiver 1.
3. The value is 000000, when the firmware of the AMAX panel was upgraded or when the
AMAX panel has factory settings.
5.5.6
AMAX 2100 / 3000 / 4000 Programming and Operating the AMAX System | en 17
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Figure 5.5: AMAX panel configuration – subscriber number
1. Select the item Code manager in the same index sheet.
2. Make sure that the value for the parameter Installer code is the same as currently
programmed in the AMAX panel.
The value is 1234, when firmware of the AMAX panel was upgraded or when the AMAX panel
has factory settings.
18 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH

Figure 5.6: AMAX panel configuration – installer code
AMAX 2100 / 3000 / 4000 Programming and Operating the AMAX System | en 19
Bosch Sicherheitsysteme GmbH Quick Start Manual 2014.11 | 02 | F.01U.309.297

Establishing a Direct Connection
4Select the Link index sheet to establish a connection between the A-Link Plus program
and the AMAX panel.
Figure 5.7: Link – Selecting Direct Connect
1. Select Direct Connect as communication model.
2. Click on the Connect button to connect to the AMAX panel.
PIf the connection is successful, the status changes to Connected and the AMAX panel
type and version is displayed.
5.5.7
20 en | Programming and Operating the AMAX System AMAX 2100 / 3000 / 4000
2014.11 | 02 | F.01U.309.297 Quick Start Manual Bosch Sicherheitsysteme GmbH
