Bosch MAP 5000 User manual

MAP 5000
ICP‑MAP5000‑2 / ICP‑MAP5000‑COM / ICP‑MAP5000‑S /
ICP‑MAP5000‑SC
en Installation manual

MAP 5000 Table of contents | en 3
Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332
Table of contents
1Introduction 5
1.1 Short information 5
1.2 Listings and approvals 5
1.3 Battery handling 5
1.4 Installation considerations 5
1.5 Planning the system 6
1.5.1 Planning the system with IPP-MAP0005 power supply 7
1.5.2 Planning the system with ICP-MAP0012 CAN splitter module 11
1.6 System overview 12
2Installation 15
2.1 Removing the enclosure knockouts 15
2.2 Installing the tamper switch rail 16
2.3 Mounting the enclosure 17
2.4 Checking the AC connection 19
2.5 Installing the power supply and power supply accessories 19
2.6 Installing the TAE box 23
2.7 Installing the accessory mounting plate 24
2.8 Installing the 12 V converter 26
2.9 Installing the fuse plate (SIV) 27
2.10 Installing the AT 2000 communicator 28
2.11 Installing the hinged mounting plate 33
2.12 Mounting the main panel 36
2.13 Installing the ICP-COM-IF relay module 37
2.14 Installing and connecting the ITS-MAP0008 wireless modem 38
2.15 Antennas 40
3Connections 41
3.1 Connecting the data bus 41
3.1.1 Internal / external data bus 43
3.1.2 Topology of the external data bus 43
3.1.3 Splitting the external data bus with a CAN splitter module 44
3.2 Connecting the control center 44
3.3 Connecting the main panel 45
3.4 Connecting the power supply 46
3.5 Connecting the LSN gateway 47
3.6 Optional connections 49
3.7 Installing and connecting the tamper switch 51
3.8 Installing the ICP-MAP0060 enclosure lockset 53
3.9 Installing the control center 55
3.10 Final power connections 55
3.11 IP Interface 56
4Initial set-up and programming 57
4.1 Initial set-up 57
4.2 Programming 57
4.2.1 Help for the programming software 58
4.2.2 Standard-compliant programming 58
4.3 Panel software 58
4.3.1 Checking the software version 58
4.3.2 Software updates 59

4en | Table of contents MAP 5000
2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
4.3.3 Manufacturer authorization 59
4.4 Completing the installation 59
4.5 Point types and point evaluation 59
4.6 Output functions 60
4.6.1 Programmable output signals 60
4.6.2 Sirens and communicator in accordance with EN50131 grade 3 62
5Enclosure options 64
5.1 ICP-MAP0115 power enclosure 64
5.2 Rack mount option for ICP-MAP0120 expansion enclosure 65
6Maintenance and service 66
6.1 General information 66
6.2 Installer button 66
7Technical Specifications 68
8Appendices 71
8.1 Requirements in accordance with VdS class C 71
8.1.1 Selecting the default setting 71
8.1.2 Power supply for areas 71
8.1.3 Control centers 71
8.1.4 Connection to a management system 71
8.1.5 Printer connection 71
8.1.6 Access levels 71
8.2 Requirements in accordance with EN 50131 grade 3 74
8.2.1 Selecting the default setting 74
8.2.2 Connectable peripherals 74
8.2.3 Arming / disarming without entry / exit delay 74
8.2.4 Arming / disarming with entry / exit delay 74
8.2.5 Arming with automatic bypass 76
8.2.6 Automatic arming / disarming 76
8.2.7 Alarm output via siren and communicator 77
8.2.8 Connection to a management system 77
8.2.9 Printer connection 77
8.2.10 Access levels 77
8.2.11 Additional functions of the main panel 80
8.3 Requirements in accordance with SES 80
8.3.1 Selecting the default setting 80
8.3.2 Automatic arming / disarming 81
8.3.3 Areas with blocking time 81
8.3.4 Access Levels 81
8.3.5 Tamper surveillance of the main panel 84
8.4 Alarm reporting 85
8.5 History log 86

MAP 5000 Introduction | en 5
Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332
1 Introduction
1.1 Short information
This manual describes the installation, wiring, initial set-up and maintenance of the MAP 5000
system.
It is applicable for all MAP 5000 kits and the following main panels including all accessory
MAP 5000 products:
– MAP Main Panel (ICP-MAP5000-2)
– MAP Main Panel with IP Communicator (ICP-MAP5000-COM) including the MAP GSM
module (ITS-MAP0008).
– MAP Main Panel Small (ICP-MAP5000-S)
– MAP Main Panel Small with IP Communicator (ICP-MAP5000-SC) including the MAP GSM
module (ITS-MAP0008).
1.2 Listings and approvals
The system is designed to comply with the certifications and approvals listed here.
Region Agency Certification
Germany VdS Class C, VdS G 111040
Europe CE Conformité Européene
Europe EN EN 50131-1:2006 + A1:2009
EN 50131-3:2009
EN 50131-6:2008
EN 50136-2/SP4/DP3
EN 50131-10
Switzerland SES Association of Swiss Installers of Security Systems
Edition V3 / 01.01.2011-d
France AFNOR / CNPP
Cert.
NF&A2P Grade 3
Certificate Number ICP-MAP5000-2: 1133400003
Certificate Number ICP-MAP5000-COM: 1230200016
According to NF324-H58
1.3 Battery handling
The battery terminals must be covered after installation in order to avoid short circuits.
Suitable terminal covers are included in the scope of delivery of the power supply.
Danger!
Electrictity
Do not short-circuit the battery in the host alarm system. A short-circuited battery can deliver
large currents that might result in serious burns or create a fire hazard.
Further information is available at http://www.boschsecurity.com/standards.
1.4 Installation considerations
– When installing this system, ensure that all local and national wiring codes are met.
– Only authorized service personnel is allowed to install this system.
– Use only the installation material recommended by BOSCH Security Systems to ensure
error-free operation.

6en | Introduction MAP 5000
2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
– Follow anti-static procedures when handling system components. Ensure that you are
properly grounded to discharge any static charge before you work with system
components.
– Install all components in dry, maintained interior rooms.
– Install the system in a centrally located room that is near the AC Power MAINS.
– Because the panel is permanently connected equipment, a readily accessible disconnect
device must be included into the building installation wiring.
Danger!
Electric shock
Danger of electric shock if live parts are touched. The alarm system is designed for an IT-
power distribution system (230 V). Switch off the power supply of the alarm system before
carrying out maintenance or installation work.
1.5 Planning the system
MAP control panel enclosure kit
The ICP-MAP0111 panel enclosure kit is the main system enclosure. This enclosure is designed
to contain the following components:
– ICP-MAP5000 main panel1
– ICP-MAP0007 DE module1
– ICP-MAP0010 LSN gateway1
– ICP-MAP0012 CAN splitter1
– AT 2000 communicator2
– IPP-MAP0005 power supply3
– ICP-MAP0065 AC terminal block4
– ICP-MAP0050 control panel enclosure tamper switch
– Two batteries (maximum 45 Ah each)
Use the ICP-MAP0120 expansion enclosure kit when the system requirements for power and /
or other remote devices exceed the capacity provided by the ICP-MAP0111 panel enclosure
kit6.
MAP expansion enclosure kit
The ICP-MAP0120 expansion enclosure kit is designed to contain the following components:
– IPP-MAP0005 power supply3
– ICP-MAP0010 LSN gateway5
– ICP-MAP0012 CAN splitter1
– ICP-MAP0065 AC terminal block4
– ICP-MAP0055 expansion enclosure tamper switch
– Two batteries (maximum 18 Ah each)
Use the ICP-MAP0115 power enclosure kit when system power requirements exceed the
power capacity of the ICP-MAP0111 panel enclosure kit6.
MAP power enclosure kit
The ICP-MAP0115 power enclosure kit is designed to contain the following components:
– IPP-MAP0005 power supply3
– ICP-MAP0065 AC terminal block4
– ICP-MAP0050 control panel enclosure tamper switch
– Four batteries (maximum 40 Ah each)

MAP 5000 Introduction | en 7
Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332
1 This module mounts on the ICP-MAP0025 hinged mounting plate.
2 This module mounts on the ICP-MAP0020 accessory mounting plate, which mounts to the
back of the enclosure.
3 When determining the number of power supplies, it is also necessary to take into account
the inrush current of loads (refer to Planning the system with IPP-MAP0005 power supply, page
7).
4 This assembly is only required if the IPP-MAP0005 power supply is installed.
5 When one or more ICP-MAP0010 LSN gateways are operated remotely, there must be one
IPP-MAP0005 power supply in the same enclosure.
6 Mount the enclosure directly under or at the side (top edge flush) of the control panel
enclosure.
1.5.1 Planning the system with IPP-MAP0005 power supply
Number of power supplies
To guarantee a reliable system booting, take into account the following:
– Inrush current of the connected loads
– Current limit of the IPP-MAP0005 power supply
– Current limit of the ICP-MAP5000 main panel
Notice!
The normal operating condition is not the subject of these considerations.
Load inrush current
– IUI-MAP0001-2 control center: max. 800 mA
– ICP-MAP0010 LSN module: max. 1000 mA, AUX is switched on later
– ICP-MAP0007-2 DE module: negligible
Current limitation
– Power supply per output A / B (short-time): 3.2 A
– Main panel at external BDB: 1.6 A
Refer to Typical configuration with ICP-MAP0111 panel enclosure, page 8.
Definition of power supply segment
A power supply segment is a power supply with all loads supplied by the power supply.
Power supply segment
4-wire cables are used for load connection within the power supply segment.
The following conditions must be taken into account when planning in order to guarantee a
reliable system booting:

8en | Introduction MAP 5000
2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
Condition 1
3-wire cables are always used for connections between power supply segments (without +28
V, red wire)
Figure1.1: Wiring of power supply segments
Condition 2
Charged batteries must be connected to the power supply to ensure reliable system start-up.
Figure1.2: Batteries for system booting
Condition 3
To ensure reliable system start-up, it is necessary to take into account the cable length and
wire gauge:
– between power supply and first control center
– between control centers
Refer to , page 10.
Typical configuration with ICP-MAP0111 panel enclosure
Main panel - DE module - 3 LSN gateway modules - max. 2 control centers

MAP 5000 Introduction | en 9
Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332
ICP-MAP0111
Figure1.3: Wiring with ICP-MAP0111
Key Description
1 Current limitation
2 4-wire connection, take into account cable length
3 3-wire connection to the next power supply segment
4 Short-time current limitation to 3.2 A per output A / B
5 Current limitation to 1.6 A between internal and external BDB
Remote operation with ICP-MAP0120 expansion enclosure
Figure1.4: 2 LSN modules with up to 4 control centers

10 en | Introduction MAP 5000
2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
Figure1.5: Up to 8 control centers
Key Description
1 Current limitation
2 4-wire connection, take into account cable length, refer to , page 10
3 3-wire connection to the next power supply segment
4 Short-time current limitation to 3.2 A per output A / B
Cable length
The maximum number of control centers that can be supplied by one power supply depends
greatly on the length and diameter of the cable used.
Wire diameter Wire cross-
section
Length A Length B Length C Length D
0.8 mm 0.503 mm2 . 325 m - - - - - - - - -
0.8 mm 0.503 mm2 . 100 m 135 m - - - - - -
0.8 mm 0.503 mm2 . 50 m 225 m - - - - - -
0.8 mm 0.503 mm2 . 50 m 50 m 50 m - - -
1.0 mm 0.785 mm2 . 500 m - - - - - - - - -
1.0 mm 0.785 mm2 . 175 m 175 m - - - - - -
1.0 mm 0.785 mm2 . 100 m 325 m - - - - - -
1.0 mm 0.785 mm2 . 100 m 75 m 75 m - - -
1.0 mm 0.785 mm2 . 50 m 400 m - - - - - -
1.0 mm 0.785 mm2 . 50 m 125 m 125 m - - -
1.0 mm 0.785 mm2 . 50 m 50 m 50 m 50 m
Tab.1.1: Cable lengths
The following applies for VdS
For remote operation of the IPP-MAP0005 power supply, a control center assigned to the
same area must be provided for indication of power supply trouble (trouble in mains supply /
battery).
