Dear Cu󰘵omers,
Thank you for purchasing a B’TWIN electrically-assi󰘵ed bike. It will introduce you
to the joys of travelling on 2 wheels for your leisure, it will be the mo󰘵 practical and
economical way for you to get around in town and will allow you to burn calories to
keep 󰘰t.
We invite you to read this in󰘵ruction manual to get the mo󰘵 out of your B’TWIN elec-
trically-assi󰘵ed bike.
Never forget that an electrically-assi󰘵ed bike is not a moped. It needs your help to
go further, fa󰘵er and longer.
We sugge󰘵 that you learn how to use your electrically-assi󰘵ed bike in an open
area in order to get used to the feel of the motor kicking in and thus ensure optimum
control of your bicycle.
Only use sport mode for your 󰘰r󰘵 kilometres if you are sure that you are able to
control your bike.
Here are the 10 commandments to get the be󰘵 use of your B’TWIN electrically-as-
si󰘵ed bicycle.
Electrically assi󰘵ed bicycles are heavier than classic pushbikes. Without assi󰘵ance,
pedalling can be harder.
You mu󰘵 always make sure you are capable of riding the entire journey without as-
si󰘵ance, in case your battery runs 󰘱at.
Important, this in󰄋ruction manual only applies to the electrical characteris-
tics of your bicycle. You mu󰄋 refer to the B’TWIN user guide and warranty
in󰄋ructions that are shared by all of our bikes and which are provided with
this document. They can also be found on our website at www.btwin.com or
reque󰄋ed at our DECATHLON 󰄋ores.

3
10 be󰄋 practices for getting the mo󰄋 out of your electrically-assi󰄋ed bicycle.
1
pedal or you won’t get far
2
in󰘱ate the tyres or you won’t get far
3> 3,5 ─ 4,5 bar < 3 bar
pfff
in󰘱ate the tyres or you will get a 󰘱at
4
20° 5°
your battery life will be reduced in cold weather
5
your battery life will be reduced if the bike is over-
loaded
6
80%
x3
95%
x4
100%
x5
your battery will reach 100% capacity after 5
complete charges
7
your battery life will be reduced by uphill climbs
8
< 3 months > 3 months
you will recharge your battery completely every 3
months
9
> mode 1 < mode 1
when your battery is low, you
should decrease your assistance
mode
9’
the battery level indicator is more
accurate when the bike is at a com-
plete stop
10
you will remove your battery prior to
each maintenance operation

4
PRODUCT DESCRIPTION ................................... 6
Electrically-assi󰄋ed bike technical features ......................6
General operation of the electrical assi󰄋ance ...................6
SCREEN AND CONTROL ELEMENTS ............... 7
Screen data and function .....................................................7
BATTERY AND CHARGER .................................. 8
Precautions for use ...............................................................9
In󰄋alling and removing the battery ...................................11
Recharging the Battery .......................................................12
Maintenance and lifetime (warranty conditions) ..............12
Additional precautions for use ..........................................13
Maintenance .........................................................................14
Displays error code on the control screen .......................16
Contents of the commercial warranty for your electrical-
ly-assi󰄋ed bike ....................................................................17
TABLE OF CONTENTS

5

6
PRODUCT DESCRIPTION
Electrically-assi󰄋ed bike technical features
A
B
C
D
E
F
G
H
I
ARear LED light
BBattery and controller
CBeam + connectors: brakes / control screen
D Control screen
EBraking detector
F Front LED light
GMotor wiring harness
H Motor
IPedalling detector
General operation of the electrical assi󰄋ance
The electrically-assi󰘵ed bike can be used with or without assi󰘵ance by pressing the ON/OFF button.
Always lock the battery with the key when in use. The electrical assi󰘵ance will only operate if you pe-
dal. The assi󰘵ance will switch o󰘯 the moment either of the two brake levers is depressed or the speed
reaches more than 25 km/h. It will then re󰘵art automatically when below 23 km/h. In order to preserve
battery life, the bike is equipped with a «power» limiter that limits assi󰘵ance when the motor is under
heavy 󰘵rain. During intensive use and in exceptional weather conditions, the assi󰘵ance may switch
o󰘯 to safeguard the entire sy󰘵em.

7
SCREEN AND CONTROL ELEMENTS
Screen data and function
KM
MAX
Assist
KM/H
MPH
Power
H
5
4
3
2
6 87
1 9
SET
1
Assist
Assi󰄋ance mode :
Pedalling assi󰘵ance: Select the assi󰘵ance mode between 1 and 6 with the «+» and «-» buttons.
Mode 01 (by default) 2 3 4 5 6
Maximum assi󰄋an-
ce speeds*** / 6 km/h 10 km/h 14 km/h 18 km/h 20 km/h 25 km/h
Average autono-
mous range*** / 50 - 70 km
Pede󰄋rian mode: Maintains the bike at a maximum speed of 6 km/h. Select an assi󰘵ance mode between 1
and 6. Hold down the «+» button to 󰘵art the motor without pedalling. The assi󰘵ance will switch o󰘯 when the
button is released or when a brake is depressed.
2Button «-» : decrease the assi󰘵ance mode / settings.
3Button «+» : increase the assi󰘵ance mode / settings.
4SET SET button: A short press of the SET button allows the successive display of the
following functions:
Shu󰓒e mode:
The previous 4 functions are displayed successively.
Total di󰄋ance:
Total di󰘵ance covered by bike. Resetting to zero is not possible.
Trip time:
The time elapsed since the la󰘵 reset.
Hold down the «–» button for 2 seconds.
Trip di󰄋ance:
The di󰘵ance travelled (km) since the la󰘵 reset.
Press the «–» button for 2 seconds to reset to zero.
Press the «–» button for 10 seconds to change between km and miles.
5 A long press allows you to switch the screen on or o󰘯.
A short press of the button allows you to switch the bicycle’s lights on.

42

9
Precautions for use
+50°
Do not expose to temperatures exceeding 50°C.
< +10°C +10°C / +50°C > +50°C
+10°C
+25°C
Storage conditions:
It is essential to 󰘵ore the battery charged and in a dry, cool
place (between +10°C and +25°C), out of sunlight.
< +10°C +10°C / +25°C > +25°C
+10°C
+40°C
Charge your battery in a dry environment at a temperature
of between +10°C and 40°C.
< +10°C +10°C / +40°C > +40°C
Important:
Under certain exceptional conditions, the controller may
reach high temperatures.
Never dismantle it.
Do not dispose of the battery in non-suitable containers.
Return the used battery to your Decathlon 󰘵ore for recy-
cling.
Risk of 󰘰re.
Risk of electrocution.
To be handled with care. Product is sensitive to impacts.
Never short-circuit the battery by connecting the positive
and negative terminals.

10
Never permit children to play with or handle the battery.
Do not immerse in water.
Do not clean using a high-pressure washer.
Rain resi󰘵ant.
x : 1..... 500
Your battery can be completely charged and drained 500
times.
Hereafter, the capacity and autonomy of the battery is re-
duced.
Always make sure that the battery and charger are compa-
tible.
+100 V / +240 V Always ensure the charger is compatible with the local
electrical grid:
Voltage: 100 V, 240 V maximum.
+50 Hz / +60 Hz
Frequency: 50 Hz minimum, 60 Hz maximum.
Only charge the battery indoors.
Transport by aeroplane is prohibited.
Any failure to comply with the precautions for use will void
the manufacturer warranty.

11
In󰄋alling and removing the battery
Insertion:
Prior to inserting your battery into its slot, unlock it using the key and check that there are
no foreign objects or matter in the battery sheath. Then turn on the power switch.
Removal:
Prior to removing your battery from its slot, unlock it using the key. Toggle o󰘯 the power
switch. Then remove your battery by pulling it.
Important notes:
Do not attempt to insert or remove your battery when the lock is locked (vertical position).
You risk breaking the security lock on your battery.

13
Additional precautions for use
Always carry out maintenance operations in su󰘲cient light.
Warning, in the event of wheel removal, you mu󰘵 ensure
the direction of rotation of your wheel is correct.
Before each use you mu󰘵 make sure that your brakes and
electric sy󰘵em are working properly
The weight, power, manufacturing year and maximum
speed are indicated on your bicycle’s frame.
As the weight of your bike with electric assi󰘵ance exceeds
15kg, we recommend that 2 persons transport it.
Always wear a helmet when riding your bike.
These electric bikes are designed for persons aged 14 and
over.
Caution: in rain, fro󰘵, or snow, you may have less tyre
traction.

14
The bicycle mu󰘵 be parked with its kick󰘵and on 󰘱at,
󰘵able ground or using a parking device.
Maintenance
Warning - the maintenance of electrical components re-
quires special skills and is not carried in 󰘵ores but in De-
cathlon regional workshops and can take several days.
All cleaning and electrical or mechanical maintenance
mu󰘵 be carried out with the power switched o󰘯 and the
battery removed from the bike!
Maintenance operations speci󰘰c to the electric sy󰘵em
mu󰘵 be performed by trained, quali󰘰ed 󰘵a󰘯. If the chain
comes o󰘯, turn the power o󰘯 before attempting any re-
pairs.
NB: the weight of the bicycle may exceed that of your as-
sembly 󰘵and or bicycle rack.
6 months
We advise you to bring your electrically-assi󰘵ed bike back
to your DECATHLON 󰘵ore for its 6-month service.
You mu󰘵 refer to the B’twin user guide and warranty ins-
tructions that are shared by all of our bikes and which are
provided with this document. They can also be found on
our website www.btwin.com or by reque󰘵 from our DECA-
THLON 󰘵ores.
Prohibited: cleaning using a high-pressure jet.
Not recommended: cleaning under running water.
Recommended: cleaning using a damp sponge.

15
The rims are subject to wear which mu󰘵 be checked to
ensure they are intact.
The motorised wheel is also subject to higher 󰘵ress than
a 󰘵andard bike wheel, and although it is reinforced, it is
possible that spokes may break. If a spoke breaks, contact
your DECATHLON 󰘵ore.
If the bike or battery su󰘯ers a fall, check that your battery
is intact.
Caution: the watertightness of your battery is no longer
guaranteed following a fall.

16
Displays error code on the control screen
Fault code De󰄈nition Solutions
15
Bad connection between
the control screen and
the controller
Check that all connectors are pressed in properly
33 Connection error Check that all connectors are pressed in properly
35 Motor connector fault Press in the motor connector properly
36 Motor fault Appointment at your Decathlon regional
workshop to repair your bike
37 Brake sensor fault Check that the brake connectors are pressed in
properly
38 Battery discharged Battery charger
39
Bad connection between
the control screen and
the controller
Check that all connectors are pressed in properly
Motor cable connector
Cable accessories connector
Pedalling sensor connector
Rear light connector Front light connector
Motor connector
Control screen connector
Brakes connector

17
Contents of the commercial warranty for your electrical-
ly-assi󰄋ed bike
Please ensure that you keep your invoice as proof of purchase.
The bike frame is covered under a lifetime warranty and a 2-year warranty covers parts subject to normal wear.
The warranty does not cover damage resulting from misuse, from a failure to respect the precautions for use, from acci-
dents, from improper use or from commercial use of the bike.
This bike is for personal use only and not for professional use.
The warranty does not cover damage resulting from repairs carried out by persons not authorised by Decathlon.
Each electronic component is permanently sealed. Opening one of these components (battery, battery sheath, controller,
screen, motor) may cause physical injury to persons or damage to the sy󰘵em. Opening or modifying a component in the
sy󰘵em will void the warranty for the bike. The warranty does not cover cracked or broken screens showing visible signs of
impacts.
FURTHER DETAILS REGARDING THE LIFETIME WARRANTY ON B’twin BIKES, purchased as of 1 June 2013.
B’twin brand bikes are products designed to provide complete satisfaction to their users. For this reason,
B’twin wishes to commit to the quality and durability of its bikes.
Within this context, B’twin o󰘯ers its clients a lifetime warranty which exclusively covers the following noncarbon parts:
frames, rigid forks (non-suspension forks), handlebars and 󰘵ems 󰘰tted to B’twin brand bikes. This warranty begins on the
date of purchase of (a) B’twin brand bike(s).
It is speci󰘰ed that, for the lifetime warranty to be valid, the buyer mu󰘵:
either have a DECATHLON 󰘵ore loyalty card and regi󰘵er his/her purchase on it at the time of checkout,
or complete the warranty certi󰘰cate available online on the www.btwin.com site within one month of the purchase date. Du-
ring this regi󰘵ration, the buyer mu󰘵 provide the following information: la󰘵 name, 󰘰r󰘵 name, purchase date, e-mail address,
and bicycle tracking number.
By virtue of this warranty, B’twin o󰘯ers either the replacement by an equivalent of the frame, rigid fork, handlebars or 󰘵em,
or their repair, within a reasonable time period, after being brought to a DECATHLON retail 󰘵ore repair shop. It is speci󰘰ed
that travel and transportation co󰘵s remain the responsibility of the cu󰘵omer.
However, this contractual obligation will not apply in the event of poor maintenance or misuse of B’twin bikes, as de󰘰ned in
the user manual of the product in que󰘵ion.
To bene󰘰t from the warranty covering one of the parts li󰘵ed above, you mu󰘵 simply visit the repair shop of a DECATHLON
retail 󰘵ore, bringing either your DECATHLON 󰘵ore loyalty card or your warranty certi󰘰cate with you.
B’twin reserves the right to verify that all conditions of the lifetime warranty have been met and to implement all due neces-
sary measures to verify this.
It is also speci󰘰ed that the lifetime warranty does not exclude the application of the legal guarantee(s) provided for under the
French Consumer Code (Code de la consommation) and Civil Code (Code civil), namely:
- Article L. 211-4 of the Consumer Code: «The seller mu󰘵 deliver goods in conformity with the contract and take responsibi-
lity for any lack of conformity present at the time of delivery. The seller is also held liable for any lack of conformity caused by
the packaging, the assembly in󰘵ructions or the in󰘵allation if he/she was made responsible for the latter under the contract
or if it was conducted under his/her responsibility».
- Article L. 211-5 of the Consumer Code: «To be compliant with the contract, goods mu󰘵:
1. Be suitable for the use normally expected for similar goods and, if necessary:
- match the description provided by the seller and possess the qualities that he/she presented to the buyer in the form of a
sample or a model;
- display the qualities that a buyer can legitimately expect in view of public 󰘵atements made by the seller, the producer, or
his/her representative, notably in advertising or labelling;
2. Or display the features de󰘰ned by a mutual agreement between the parties or be suitable for any special use sought by
the buyer, made known to, and agreed upon by, the seller».
- Article L. 211-12 of the Consumer Code: «Legal action prompted by lack of conformity lapses two years after the date of
delivery of the goods.»
- Article 1641 of the Civil Code: «The seller is bound to the warranty on account of hidden defects of the item sold which
render it un󰘰t for the use for which it was intended, or which so impair that use that the buyer would not have acquired it, or
would only have paid a lesser price for it, had he/she been aware of them.
- Article 1648 paragraph 1 of the Civil Code: «Legal action prompted by unacceptable defects mu󰘵 be brought by the buyer
within a period of two years from the date of discovery of the defect».

18
Connectique moteur
bDECLARATION OF CONFORMITY CE i
Company Name DECATHLON SA
Adress 4 Bd de Mons
BP 299
F-59665 VILLENEUVE D’ASCQ
Declares to be authorised to e󰘵ablish the technical 󰘰le
Declares the product hereafter described :
Commercial name : Bebike 900 / Elops 900
Model code : 8300083
Type : Electrically Power Assi󰄋ed Cycle
Brand : B’twin
Functions : to move with an electric assi󰄋ance
Description of the product : Electrically Power Assi󰄋ed Cycle
Rear wheel motor : 250W max.
Battery : lithium ion 36V-10Ah
Switch : LCD Display
Sensor : Speed Sensor
is in accordance with the 󰘵ipulations of the : European directive 2006/42 EC concerning machinery
and is in accordance with the essential safety & health requirements of the directive.
and also with the following 󰘵andards : EN 14764 : City Trekking
EN 15194: EPAC
This bike is in conformity with the requirements of the directive on electromagnetic compatibility (EMC)
Done at ................................................................................ , the .....................................................................................
Name, function and adress of the signer and 󰘵amp :
..............................................................................................................
..............................................................................................................
Universe Director
Decathlon SA
4, Boulevard de Mons 59665 VILLENEUVE D’ASCQ Cedex Tel : [phone] - Fax : [phone]
DECATHLON SA Société anonyme à Directoire et Conseil de Surveillance - Capital de 10 250 000 € - R.C.S Lille Metropole 306 138 900

19

b
DECATHLON - 4 Boulevard de Mons - BP 299 59650
Villeneuve d’Ascq cedex - France
