Btwin ELOPS 900E User manual

1
EN
User manual
Elops 900E

2
Dear Cu󰘵omers,
Thank you for purchasing a B’TWIN electrically-assi󰘵ed bike. It will introduce you to the joys of travelling
on 2 wheels for your leisure, it will be the mo󰘵 practical and economical way for you to get around in
town and will allow you to burn calories to keep 󰘰t.
We invite you to read this in󰘵ruction manual to get the mo󰘵 out of your B’TWIN electrically-assi󰘵ed
bike.
Never forget that an electrically-assi󰘵ed bike is not a moped. It needs your help to go further, fa󰘵er and
longer.
We sugge󰘵 that you learn how to use your electrically-assi󰘵ed bike in an open area in order to get used
to the feel of the motor kicking in and thus ensure optimum control of your bicycle.
Only use sport mode for your 󰘰r󰘵 kilometres if you are sure that you are able to control your bike.
Here are the 10 commandments to get the be󰘵 use of your B’TWIN electrically-assi󰘵ed bicycle.
Electrically assi󰘵ed bicycles are heavier than classic pushbikes. Without assi󰘵ance, pedalling can be
harder.
You mu󰘵 always make sure you are capable of riding the entire journey without assi󰘵ance, in case your
battery runs 󰘱at.
Important, this in󰄋ruction manual only applies to the electrical characteri󰄋ics of your bicycle.
You mu󰄋 refer to the B’TWIN user guide and warranty in󰄋ructions that are shared by all of our
bikes and which are provided with this document. They can also be found on our website at
www.btwin.com or reque󰄋ed at our DECATHLON 󰄋ores.

3
10 be󰄋 practices for getting the mo󰄋 out of your electrically-assi󰄋ed bicycle.
1
You need to pedal to go further
23,5 ─ 5 bar
In order to improve battery life and e󰘲ciency, pump the tyres to
between 3.5 and 5 bar
3< 3 bar
pfff
Under-in󰘱ated tyres are more prone to punctures
4
20° 5°
cold weather reduces battery life
5
Overloading the bicycle will reduce the battery life
6
Battery life will drop when cycling uphill
< 3 months
7
The battery mu󰘵 be fully charged at lea󰘵 once every 3 months
8
> mode 1 < mode 1
It is advisable to reduce the power assi󰘵ance mode when the battery
charge is low
9
the battery level indicator is more accurate when the bike is at a
complete 󰘵op
10
Remove the battery before conducting any maintenance work

4
PRODUCT DESCRIPTION ................................... 5
Electrically-assi󰄋ed bike technical features ......................5
SCREEN AND CONTROL ELEMENTS ............... 6
Screen data and function .....................................................6
BATTERY AND CHARGER ................................. 7
Precautions for use ..............................................................8
In󰄋alling and removing the battery ..................................10
Recharging the Battery ......................................................11
Maintenance and lifetime (warranty conditions) ..............11
Battery self-diagno󰄋ic .......................................................12
Putting the battery into hibernation mode........................13
Additional precautions for use ..........................................13
Maintenance ........................................................................14
Error codes ........................................................ 15
Displays error code on the control screen .......................15
Contents of the commercial warranty for your electrical-
ly-assi󰄋ed bike ...................................................................16
TABLE OF CONTENTS

5
PRODUCT DESCRIPTION
Electrically-assi󰄋ed bike technical features
A
B
C
D
E
F
I
G
H
ARear LED light
BBattery and controller
CBeam + connectors: brakes / control screen
DControl screen
EBraking detector
FFront LED light
GMotor wiring harness
HMotor
IPedalling detector
General operation of the electrical assi󰄋ance
The electrically-assi󰘵ed bike can be used with or without assi󰘵ance by pressing the ON/OFF button. Always lock the battery with the key when in use. The
electrical assi󰘵ance will only operate if you pedal. The assi󰘵ance will switch o󰘯 the moment either of the two brake levers is depressed or the speed reaches
more than 25 km/h. It will then re󰘵art automatically when below 23 km/h. In order to preserve battery life, the bike is equipped with a «power» limiter that li-
mits assi󰘵ance when the motor is under heavy 󰘵rain. During intensive use and in exceptional weather conditions, the assi󰘵ance may switch o󰘯 to safeguard
the entire sy󰘵em.

6
SCREEN AND CONTROL ELEMENTS
Screen data and function
1
Power assi󰄋ance mode (0-1-2-3):
»0» no power assi󰘵ance.
»1» is the default power assi󰘵ance mode.
Each mode corresponds to the maximum assi󰘵ance speeds set out below:
Mode 0 1 2 3
Maximum assi󰄋ance speeds** 0 km/h 15 km/h 20 km/h 25 km/h
Average autonomous range*** / 40 - 70 km
2ON/OFF button:
Switch the electrically-assi󰘵ed bicycle on and o󰘯 by holding the button down for a few seconds.
3
«+» button:
Step up to the higher power assi󰘵ance mode by brie󰘱y pressing the button
Switch to «walk assi󰘵» mode by holding the button down for a few seconds.
4»-» button:
Step down to the lower assi󰘵ance mode
5
Lighting button
The lighting on the bicycle can be switched on and o󰘯 by brie󰘱y pressing the button
Go to the settings by holding the button down for a few seconds
6Speed indicator**
7
»Walk assi󰄋» mode:
For walking beside the bicycle in walk assi󰘵 mode, up to 6 km/h, without pedalling. Please note that this mode should not be
used when riding the bicycle
8
ODO: Records the total di󰘵ance travelled. It cannot be reset to zero.
TRIP: Records the partial di󰘵ance travelled. It can be reset to zero by pressing the «-» button for 10 seconds.
TRIPtoGO: Remaining di󰘵ance that may be covered with the power assi󰘵ance mode.
This is automatically displayed on the control screen.
9Di󰄋ance indicator
10 Units:
kilometres or miles
11 Lighting indicator:
Appears on the screen when the lights are on
12 Five battery levels.
When the battery level is low, the indicator 󰘵arts to 󰘱ash.

7
BATTERY AND CHARGER
All our electric bike batteries use lithium-ion technology and are not subject to the memory e󰘯ect. Recharging the battery after each use is recommended.
Charge the battery to 100% prior to its 󰄈r󰄋 use.
Battery Charger
Battery 36 V / 11,6 Ah *
Input: 100-
240 V
Output: 29.4 V
* At the time of purchase, your 36 V battery is inactive. Plug in your charger to activate it.
Your battery is guaranteed for up to 500 charging and discharging cycles (1 cycle = 1 charge and discharge) subject to compliance with the conditions of
correct usage and 󰘵orage.
13
Additional battery and sy󰘵em information:
Indicates the battery charge level as a percentage
«Error»: Sy󰘵em error, see page 17
Setting
Hold the «Lighting» button down for a few seconds to enter or quit the settings
Brie󰘱y press the «Lighting» button to display the di󰘯erent settings
Brie󰘱y press the «+» and «-» buttons to display the di󰘯erent adju󰘵ments.
SET 1: Indication of the maximum power assi󰘵ance speed. This setting cannot be adju󰘵ed. SET 2: Adju󰘵ment of the circumfe-
rence of the wheels.
SET 2 : Regulation of the circumference of wheels.
SET 3: Choice of units (km/h or mph)
SET 9: Information on the battery (charge percentage, voltage, number of charging/discharging cycles
*Check the battery charge indicator when 󰘵ationary. In the event that heavy assi󰘵ance is required, disparities may be noticed.
** The speed display accuracy is +/-2%.
*** Under the conditions of te󰘵 protocols for a 75kg user, tyre pressures at 4 bar and respecting the 10 good habits

8
Precautions for use
+50°
Do not expose to temperatures exceeding 50°C.
< +10°C +10°C / +50°C > +50°C
+10°C
+25°C
Storage conditions: It is essential to 󰘵ore the battery charged and in a dry, cool place (between +10°C and
+25°C), out of sunlight.
< +10°C +10°C / +25°C +25°C
+10°C
+40°C
Charge your battery in a dry environment at a temperature of between +10°C and 40°C.
< +10°C +10°C / +40°C +40°C
Important: Under certain exceptional conditions, the controller may reach high temperatures.
Never dismantle it.
Do not dispose of the battery in non-suitable containers. Return the used battery to your Decathlon 󰘵ore for
recycling.
Risk of 󰘰re.
Risk of electrocution.
To be handled with care. Product is sensitive to impacts.
Never short-circuit the battery by connecting the positive and negative terminals.

9
Never permit children to play with or handle the battery.
Do not immerse in water.
Do not clean using a high-pressure washer.
Rain resi󰘵ant.
x : 1..... 500
Your battery can be completely charged and drained 500 times. Hereafter, the capacity and autonomy of the
battery is reduced.
Always make sure that the battery and charger are compatible.
+100 V / +240 V
Always ensure the charger is compatible with the local electrical grid: Voltage: 100 V, 240 V maximum.
+50 Hz / +60 Hz
Frequency: 50 Hz minimum, 60 Hz maximum.
Only charge the battery indoors.
Transport by aeroplane is prohibited.
Any failure to comply with the precautions for use will void the manufacturer warranty.

10
In󰄋alling and removing the battery
Insertion:
Prior to inserting your battery into its slot, unlock it using the key and check that there are no foreign objects or matter in the battery sheath. Then turn on
the power switch.
Removal:
Prior to removing your battery from its slot, unlock it using the key. Toggle o󰘯 the power switch. Then remove your battery by pulling it.
Important notes:
Do not attempt to insert or remove your battery when the lock is locked (vertical position). You risk breaking the security lock on your battery.

11
Recharging the Battery
The LED is red as charging 󰘵arts.
Green LED when charging is complete. LED 󰘱ashes
red, charging
problem, contact
the after-sales
service.
Maintenance and lifetime (warranty conditions)
Do not 󰘵ore the discharged battery to prevent deep discharge that may cause malfunction.
3 months
In cases of extended 󰘵orage, recharge the battery once every 3 months.
6 months
To guarantee an accurate indication of your battery 󰘵atus (when the 󰘵atus indication button is pressed), we advise you
to fully charge it every 6 months and then completely discharge it (this operation «calibrates» the battery 󰘵atus).
When 󰘵oring the bicycle for a prolonged period, put the battery in extended 󰘵andby mode (see details p. 14)

12
Battery self-diagno󰄋ic
6 months
11% - 20%
21% - 40%
41% - 60%
61% - 80%
81% - 100%
Battery re-
charge is nee-
ded urgently
<10%
Undervoltage protection
Temperature protection
Return your battery to your af-
ter-sales service
Short-circuit protection
Other protection
LED o󰘯 LED on LED 󰘱ashing

13
Additional precautions for use
Always carry out maintenance operations in su󰘲cient light.
Warning, in the event of wheel removal, you mu󰘵 ensure the direction of rotation of your wheel is correct.
Before each use you mu󰘵 make sure that your brakes and electric sy󰘵em are working properly
The weight, power, manufacturing year and maximum speed are indicated on your bicycle’s frame. As the
weight of your bike with electric assi󰘵ance exceeds 15kg, we recommend that 2 persons transport it.
Always wear a helmet when riding your bike.
These electric bikes are designed for persons aged 14 and over.
Putting the battery into hibernation mode
The battery can be put into hibernation in case of prolonged 󰘵orage (maximum 1 year).
Press for 10 seconds on the button of the battery until the battery LEDs go out. The battery is now in hiberna-
tion mode.
Charge the battery with its charger at a power socket to awaken it.

14
Maintenance
Warning - the maintenance of electrical components requires special skills and is not carried in 󰘵ores but in
Decathlon regional workshops and can take several days.
All cleaning and electrical or mechanical maintenance mu󰘵 be carried out with the power switched o󰘯 and the
battery removed from the bike! Maintenance operations speci󰘰c to the electric sy󰘵em mu󰘵 be performed by
trained, quali󰘰ed 󰘵a󰘯. If the chain comes o󰘯, turn the power o󰘯 before attempting any repairs.
NB: the weight of the bicycle may exceed that of your assembly 󰘵and or bicycle rack.
6 months
We advise you to bring your electrically-assi󰘵ed bike back to your DECATHLON 󰘵ore for its 6-month service.
You mu󰘵 refer to the B’twin user guide and warranty in󰘵ructions that are shared by all of our bikes and which
are provided with this document. They can also be found on our website www.btwin.com or by reque󰘵 from
our DECATHLON 󰘵ores.
Prohibited: cleaning using a high-pressure jet.
Not recommended: cleaning under running water.
Recommended: cleaning using a damp sponge.
Caution: in rain, fro󰘵, or snow, you may have less tyre traction.
The bicycle mu󰘵 be parked with its kick󰘵and on 󰘱at, 󰘵able ground or using a parking device.

15
The rims are subject to wear which mu󰘵 be checked to ensure they are intact.
The motorised wheel is also subject to higher 󰘵ress than a 󰘵andard bike wheel, and although it is reinforced,
it is possible that spokes may break. If a spoke breaks, contact your DECATHLON 󰘵ore.
If the bike or battery su󰘯ers a fall, check that your battery is intact. Caution: the watertightness of your battery
is no longer guaranteed following a fall.
Error codes
Displays error code on the control screen
Fault code De󰄈nition Solutions
1 Undervoltage protection Battery charger. If the situation does not improve, go to your local Decathlon
󰘵ore.
2 Motor fault Press in the motor connector properly
3Motor fault Press in the motor connector properly
4 6 months We advise you to bring your electrically-assi󰘵ed bike back to your DECATH-
LON 󰘵ore for its 6-month service.
5 Brake sensor fault Check that the brake connectors are pressed in properly
6 Battery on Battery charger. If the situation does not improve, go to your local Decathlon
󰘵ore.
7 Motor fault Press in the motor connector properly
8 Controller communication error Check that all connectors are pressed in properly
9Bad connection between the control screen and
the controller Check that all connectors are pressed in properly
Pedalling sensor connector
Cable accessories connector
Motor cable connector
Control screen connector
Brakes connector

16
Contents of the commercial warranty for your electrically-assi󰄋ed bike
Please ensure that you keep your invoice as proof of purchase.
The bike frame is covered under a lifetime warranty and a 2-year warranty covers parts subject to normal wear.
The warranty does not cover damage resulting from misuse, from a failure to respect the precautions for use, from accidents, from improper use or from
commercial use of the bike.
This bike is for personal use only and not for professional use.
The warranty does not cover damage resulting from repairs carried out by persons not authorised by Decathlon.
Each electronic component is permanently sealed. Opening one of these components (battery, battery sheath, controller, screen, motor) may cause physical
injury to persons or damage to the sy󰘵em. Opening or modifying a component in the sy󰘵em will void the warranty for the bike. The warranty does not cover
cracked or broken screens showing visible signs of impacts.
FURTHER DETAILS REGARDING THE LIFETIME WARRANTY ON B’twin BIKES, purchased as of 1 June 2013.
B’twin brand bikes are products designed to provide complete satisfaction to their users. For this reason,
B’twin wishes to commit to the quality and durability of its bikes.
Within this context, B’twin o󰘯ers its clients a lifetime warranty which exclusively covers the following noncarbon parts: frames, rigid forks (non-suspension
forks), handlebars and 󰘵ems 󰘰tted to B’twin brand bikes. This warranty begins on the date of purchase of (a) B’twin brand bike(s).
It is speci󰘰ed that, for the lifetime warranty to be valid, the buyer mu󰘵:
either have a DECATHLON 󰘵ore loyalty card and regi󰘵er his/her purchase on it at the time of checkout,
or complete the warranty certi󰘰cate available online on the www.btwin.com site within one month of the purchase date. During this regi󰘵ration, the buyer mu󰘵
provide the following information: la󰘵 name, 󰘰r󰘵 name, purchase date, e-mail address, and bicycle tracking number.
By virtue of this warranty, B’twin o󰘯ers either the replacement by an equivalent of the frame, rigid fork, handlebars or 󰘵em, or their repair, within a reasonable
time period, after being brought to a DECATHLON retail 󰘵ore repair shop. It is speci󰘰ed that travel and transportation co󰘵s remain the responsibility of the
cu󰘵omer.
However, this contractual obligation will not apply in the event of poor maintenance or misuse of B’twin bikes, as de󰘰ned in the user manual of the product in
que󰘵ion.
To bene󰘰t from the warranty covering one of the parts li󰘵ed above, you mu󰘵 simply visit the repair shop of a DECATHLON retail 󰘵ore, bringing either your
DECATHLON 󰘵ore loyalty card or your warranty certi󰘰cate with you.
B’twin reserves the right to verify that all conditions of the lifetime warranty have been met and to implement all due necessary measures to verify this.
It is also speci󰘰ed that the lifetime warranty does not exclude the application of the legal guarantee(s) provided for under the French Consumer Code (Code
de la consommation) and Civil Code (Code civil), namely:
Article L. 211-4 of the Consumer Code: «The seller mu󰘵 deliver goods in conformity with the contract and take responsibility for any lack of conformity pre-
sent at the time of delivery. The seller is also held liable for any lack of conformity caused by the packaging, the assembly in󰘵ructions or the in󰘵allation if he/
she was made responsible for the latter under the contract or if it was conducted under his/her responsibility».
Article L. 211-5 of the Consumer Code: «To be compliant with the contract, goods mu󰘵:
Be suitable for the use normally expected for similar goods and, if necessary:
match the description provided by the seller and possess the qualities that he/she presented to the buyer in the form of a sample or a model;
display the qualities that a buyer can legitimately expect in view of public 󰘵atements made by the seller, the producer, or his/her representative, notably in
advertising or labelling;
Or display the features de󰘰ned by a mutual agreement between the parties or be suitable for any special use sought by the buyer, made known to, and
agreed upon by, the seller».
Article L. 211-12 of the Consumer Code: «Legal action prompted by lack of conformity lapses two years after the date of delivery of the goods.»
Article 1641 of the Civil Code: «The seller is bound to the warranty on account of hidden defects of the item sold which render it un󰘰t for the use for which it
was intended, or which so impair that use that the buyer would not have acquired it, or would only have paid a lesser price for it, had he/she been aware of
them.
Article 1648 paragraph 1 of the Civil Code: «Legal action prompted by unacceptable defects mu󰘵 be brought by the buyer within a period of two years from
the date of discovery of the defect».

17
b
DECLARATION OF CONFORMITY CE
i
Company Name DECATHLON SA
Adress 4 Bd de Mons
BP 299
F-59665 VILLENEUVE D’ASCQ
Declares to be authorised to e󰘵ablish the technical 󰘰le
Declares the product hereafter described :
Commercial name : Elops 900E
Model code : 8379380 / 8379381
Type : Electrically Power Assi󰘵ed Cycle
Brand : B’twin
Functions : to move with an electric assi󰘵ance
Description of the product : Electrically Power Assi󰘵ed Cycle
Rear wheel motor : 250W max.
Battery : lithium ion 36V-11.6Ah
Switch : LCD Display
Sensor : Speed Sensor
is in accordance with the 󰘵ipulations of the : European directive 2006/42 EC concerning machinery
and is in accordance with the essential safety & health requirements of the directive.
and also with the following 󰘵andards : EN 14764 : City Trekking
EN 15194: EPAC
This bike is in conformity with the requirements of the directive on electromagnetic compatibility (EMC)
Done at , the
Name, function and adress of the signer and 󰘵amp :
Universe Director
Decathlon SA
4, Boulevard de Mons 59665 VILLENEUVE D’ASCQ Cedex Tel : [phone] - Fax : [phone]
DECATHLON SA Société anonyme à Directoire et Conseil de Surveillance - Capital de 10 250 000 € - R.C.S Lille Metropole 306 138 900

b
DECATHLON - 4 Boulevard de Mons - BP 299 59650 Villeneuve d’Ascq cedex -
France
To use your electric bike to its full potential, see our complete user guide on the Decathlon website.
8379380 / 8379381 |
