Burkert 8025 Series User manual

Quickstart
Type 8025 - 8035 - SE35
Flowmeter
Flow Transmitter
English

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© Bürkert SAS, 2013-2019
Quickstart 1903/05_EU-ML 00565666 / Original FR
1. ABOUT THE QUICKSTART.........................................................................3
2. INTENDED USE ..............................................................................................4
3. BASIC SAFETY INFORMATION ...............................................................4
4. GENERAL INFORMATION ...........................................................................6
5. DESCRIPTION OF THE RATING PLATE ...............................................6
6. TECHNICAL DATA ...........................................................................................7
7. INSTALLATION ...............................................................................................21
8. WIRING ...............................................................................................................28
9. INSTALLATION AND COMMISSIONING ...........................................58
10. MAINTENANCE AND TROUBLESHOOTING ................................64
11. PACKAGING, TRANSPORT ...................................................................64
12. STORAGE .......................................................................................................64
13. DISPOSAL OF THE DEVICE .................................................................65

3
About the Quickstart
Type 8025 - 8035 - SE35
WARNING
Warns against a potentially dangerous situation.
▶Failure to observe this warning can result in serious injury or even death.
CAUTION
Warns against a possible risk.
▶Failure to observe this warning can result in substantial or minor injuries.
NOTICE
Warns against material damage.
Indicates additional information, advice or important
recommendations.
Refers to information contained in this Quickstart or in other
documents.
▶Indicates an instruction to be carried out to avoid a danger, a
warning or a possible risk.
→Indicates a procedure to be carried out.
Indicates the result of a specific instruction.
1. ABOUT THE QUICKSTART
The Quickstart describes the life cycle of the device. Please keep this
Quickstart in a safe place, accessible to all users and any new owners.
Important safety information.
Failure to comply with these instructions can lead to hazardous
situations. Pay attention in particular to the chapters Basic safety
information and Intended use.
▶Whatever the version of the device, this Quickstart must be read
and understood.
The Quickstart explains how to install, set, and start-up the device.
A detailed description of the device can be found in the related ope-
rating instructions available on the internet at www.burkert.com
1.1. Definition of the word "device"
The word "device" used within this Quickstart always refers to the
flowmeter type 8025 compact version, the flow transmitter type 8025
panel version or wall-mounted version, the flowmeter type 8035 or the
flow transmitter type SE35.
1.2. Symbols used
DANGER
Warns against an imminent danger.
▶Failure to observe this warning results in death or in serious injury.
English

4
Intended use
Type 8025 - 8035 - SE35
2. INTENDED USE
Use of the device that does not comply with the instructions could
present risks to people, nearby installations and the environment.
The flowmeter type 8025 compact version, the flowmeter type 8035 and
the flow transmitter SE35 associated with a sensor-fitting are designed
to measure the flow rate of a liquid and to totalise the volume of a liquid.
The flow transmitter type SE35 must be mounted on a sensor-
fitting type S030, S070 or S077.
The flow transmitter type 8025 panel version or wall-mounted
version is a transmitter that must be connected to:
- an 8020 flow sensor with a sinus or a pulse output, only in
"Low Power" version,
- an 8030 flow sensor with a sinus or a pulse output, only in
"Low Power" version.
▶Use this device in compliance with the characteristics and
commissioning and use conditions specified in the contractual
documents and in the operating instructions.
▶Never use this device for security applications.
▶Protect this device against electromagnetic interference, ultraviolet
rays and, when installed outdoors, the effects of climatic conditions.
▶Only operate a device in perfect working order.
▶Requirements for the safe and proper operation of the device
are proper transport, storage and installation, as well as careful
operation and maintenance.
▶Only use the device as intended.
3. BASIC SAFETY INFORMATION
This safety information does not take into account any contingencies
or occurrences that may arise during installation, use and mainte-
nance of the product.
The operating company is responsible for the respect of the local
safety regulations including for the staff safety.
Danger due to electrical voltage.
▶If a 12...36 V DC powered version is installed either in a wet
environment or outdoors, all the electrical voltages must be of
max. 35 V DC.
▶Disconnect the electrical power for all the conductors and isolate
it before carrying out work on the system.
▶All equipment connected to the wall-mounted or panel version
of the flow transmitter 8025 must be double insulated in relation
to the mains in accordance with IEC standard 61010-1:2010.
▶Observe all applicable accident protection and safety regulati-
ons for electrical equipment.
Risk of injury due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Stop the circulation of fluid and drain the pipe before loosening
the process connections.
English

5
Basic safety information
Type 8025 - 8035 - SE35
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the
pipe before loosening the process connections.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and
safety relating to the use of hazardous products.
Various dangerous situations
To avoid injury take care:
▶not to use the device in explosive atmospheres.
▶not to use the device in an environment incompatible with the
materials it is made of.
▶not to subject the device to mechanical loads.
▶not to make any modifications to the device.
▶to prevent any unintentional power supply switch-on.
▶to carry out the installation and maintenance work by qualified
and skilled staff with the appropriate tools.
▶to guarantee a defined or controlled restarting of the process,
after a power supply interruption.
▶to use the device only if in perfect working order and in compli-
ance with the instructions provided in the operating instructions.
▶to observe the general technical rules when installing and using the device.
NOTICE
The device may be damaged by the fluid in contact with.
▶Systematically check the chemical compatibility of the compo-
nent materials of the device and the fluids likely to come into
contact with it (for example: alcohols, strong or concentrated
acids, aldehydes, alkaline compounds, esters, aliphatic com-
pounds, ketones, halogenated aromatics or hydrocarbons,
oxidants and chlorinated agents).
NOTICE
Elements / Components sensitive to electrostatic discharges
This device contains electronic components sensitive to electro-
static discharges. They may be damaged if they are touched by
an electrostatically charged person or object. In the worst case
scenario, these components are instantly destroyed or go out of
order as soon as they are activated.
▶To minimise or even avoid all damage due to an electrosta-
tic discharge, take all the precautions described in standard
EN 61340-5-1.
▶Also ensure that you do not touch any of the live electrical
components.
English

6
General information
Type 8025 - 8035 - SE35
4. GENERAL INFORMATION
4.1. Manufacturer's address and
international contacts
To contact the manufacturer of the device, use following address:
Bürkert SAS
Rue du Giessen
BP 21
F-67220 TRIEMBACH-AU-VAL
You may also contact your local Bürkert sales office.
The addresses of our international sales offices are available on the
internet at: www.burkert.com
4.2. Warranty conditions
The condition governing the legal warranty is the conforming use of
the device in observance of the operating conditions specified in this
Quickstart.
4.3. Information on the Internet
You can find the Operating Instructions and Technical Data Sheets
regarding the type 8025, 8035 or SE35 at: www.burkert.com.
5. DESCRIPTION OF THE RATING
PLATE
FLOW SE35/8035 HALL SUPPLY: 12-36V ... 70 mA
Output: 1x4-20mA IP65
2xRel: 30V and 42V peak or 60V ... max.
S/N 11 026
00553433 W44MG
Made in France
12
671112
4
10
3
5
98
1. Measured quantity and type of the device
2. Type of sensor
3. Characteristics of the current output
4. Power supply and maximum of current consumption
5. Protection class of the device
6. Manufacturing code
7. Conformity logo
8. Certification
9. Warning: Before using the device, take into account the tech-
nical specifications described in the Operating Instructions.
10. Specification of the relay outputs
11. Serial number
12. Article number
Fig. 1 : Rating plate of the device (example)
English

7
Technical data
Type 8025 - 8035 - SE35
6. TECHNICAL DATA
6.1. Technical data of the 8025
compact version
6.1.1. Conditions of use
Ambient temperature
• 12...36 V DC version • –10...+60°C
• 115/230 V AC version • –10...+50°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class
according to IEC/
EN 60529
IP65 1), device wired, cover lid screwed
tight and cable glands tightened or
female connector plugged in and
secured with screws (depending on the
version)
1) not evaluated by UL
6.1.2. Conformity to standards and
directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
Conformity to the Pressure Equipment Directive
→Make sure the device materials are compatible with the fluid.
→Make sure the pipe DN and the PN are adapted for the device.
The device conforms to Article 4, Paragraph 1 of the Pressure
Equipment Directive 2014/68/EU under the following conditions:
• Device used on a piping (PS = maximum admissible pressure;
DN = nominal diameter of the pipe)
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.i DN≤25
Fluid group 2, Article 4, Paragraph 1.c.i DN≤32
or PSxDN≤1000
Fluid group 1, Article 4, Paragraph 1.c.ii DN≤25
or PSxDN≤2000
Fluid group 2, Article 4, Paragraph 1.c.ii
DN≤200
or PS≤10
or PSxDN≤5000
UL-Certification
English

8
Technical data
Type 8025 - 8035 - SE35
Finished products with variable key PU01 or PU02 are UL-certified
products and comply also with the following standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.1.3. Fluid data
10
9
8
7
6
5
4
3
2
1
0-15 0 +20 +40 +60
PVDF
PVDF (PN10)
PVC (PN10)
PP (PN10)
PVC + PP
11
P (bar)
T (°C)
+80
A
Metal
A: range of use
Fig. 2 : Fluid temperature/fluid pressure dependency curves for
the 8025 compact version, depending on the material the
S020 fitting is made of
Type of fluid neutral or slightly aggressive liquids
Fluid viscosity max. 300 cSt
Rate of solid particles max. 1%
Fluid temperature The fluid temperature may be restricted
by the fluid pressure and the material the
S020 fitting used is made of (see Fig. 2)
English

9
Technical data
Type 8025 - 8035 - SE35
Fluid pressure PN10 1) max
The fluid pressure may be restricted by
the fluid temperature and the material the
S020 fitting used is made of (see Fig. 2)
1) not evaluated by UL
6.1.4. Materials
Part Material
Housing /cover, lid, nut PC
Frontfoil Polyester
Screws Stainless steel
Male fixed connector or cable glands PA
Identification label Polyester
Wetted parts
Sensor holder / Paddle-wheel PVDF
Axis and bearings of the paddle-wheel Ceramics
Seal FKM (optional EPDM)
Fitting S020 Refer to the Operating
Instructions of the fitting
6.1.5. Electrical data
12...36 V DC power supply • filtered and regulated
• oscillation rate: ±10%
• Connection to main supply:
permanent (through external
SELV (safety extra-low voltage)
and through LPS (limited power
source))
Power source (not supplied)
for versions supplied with
12..36 V DC
• Limited power source according
to UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
115/230 V AC power supply
• frequency • 50/60 Hz
• supplied voltage • 27 V DC, regulated
• Maximum current • 125 mA
• integrated protection • 125 mA time-delay fuse
• power • 3 VA
Maximum current
consumption version
12...36 V DC without relais
25 mA
Maximum current
consumption version
12...36 V DC with relais
70 mA
English

10
Technical data
Type 8025 - 8035 - SE35
Max. current consumption
version 115/230 V AC
125 mA max. at 27 V DC
Pulse output (transistor) polarized, potential-free
• type • NPN/PNP (wiring dependant)
• electrical data • 5...36 V DC, 100 mA max.,
voltage drop 2,5 V DC at 100 mA
Relay output
• operating • hysteresis, adjustable thresholds,
normally open
• electrical data of the load
(non UL recognized devices)
• 230 V AC / 3 A or
40 V DC / 3 A (resistive load)
• electrical data of the load
(UL recognized devices)
• max. 30 V AC and 42 V peak /
3 A or max. 60 V DC / 1 A
To use the relay outputs in a wet
location, observe the following
DANGER safety instruction.
Current output 4...20 mA, sinking or sourcing mode
(wiring dependant)
DANGER
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22,6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
6.2. Technical data of the flow
transmitter 8025, panel version
The following technical data are relevant for the flow transmitter
8025 panel version, connected to a Bürkert flow sensor 8020, 8030
or SE30 in a "Low Power" version only.
6.2.1. Conditions of use
Ambient temperature –10...+60°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
English

11
Technical data
Type 8025 - 8035 - SE35
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class according to IEC/EN 60529
• front parts • IP65 1), installation completed and
closed cabinet
• non front parts • IP20 1) in the closed cabinet
1) not evaluated by UL
6.2.2. Conformity to standards and directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
UL-Certification
Finished products with variable key PU01 or PU02 are UL-certified
products and comply also with the following standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.2.3. Materials
Part Material
Housing /cover PC
Frontfoil Polyester
Screws (4) Stainless steel
Cable glands PA
Identification label Polyester
6.2.4. Electrical data
12...36 V DC power supply • filtered and regulated
• oscillation rate: ±10%
• Connection to main supply:
permanent (through external
SELV (safety extra-low voltage)
and through LPS (limited power
source))
English

12
Technical data
Type 8025 - 8035 - SE35
Power source (not supplied) • Limited power source according
to UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
Maximum current con-
sumption version
12...36 V DC without relais
25 mA
Maximum current con-
sumption version
12...36 V DC with relais
70 mA
Pulse output (transistor) polarized, potential-free
• type • NPN/PNP (wiring dependant)
• electrical data • 5...36 V DC, 100 mA max., voltage
drop 2,5 V DC at 100 mA
Relay output
• operating • hysteresis, adjustable thresholds,
normally open
• electrical data of the load
(non UL recognized devices)
• 230 V AC / 3 A or
40 V DC / 3 A (resistive load)
• electrical data of the load
(UL recognized devices)
• max. 30 V AC and 42 V peak /
3 A or max. 60 V DC / 1 A
To use the relay outputs in a wet
location, observe the following
DANGER safety instruction.
Current output 4...20 mA, sinking or sourcing
mode (wiring dependant)
DANGER
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22,6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
6.2.5. Specifications of a flow sensor
connected to a 8025 panel version
Sensor input
• signal frequency • 2.5...400 Hz
• pulse signal (Hall) • NPN, open collector
• sinus signal (coil) • typical sensitivity of 35 mV peak-peak, at
252 Hz
Sensor output
• power supply • 10...34 V DC (V+ minus 2 V DC), 1 mA max.
6.3. Technical data of the 8025 wall-
mounted version
The following technical data are relevant for the flow transmitter
8025 wall-mounted version, connected to a Bürkert flow sensor
8020, 8030 or SE30 in a "Low Power" version only.
English

13
Technical data
Type 8025 - 8035 - SE35
6.3.3. Materials
Part Material
Housing, cover ABS
Frontfoil Polyester
Screws (4) Stainless steel
Cable glands / Cable clips PA
Identification label Polyester
6.3.4. Electrical data
12...36 V DC power supply • filtered and regulated
• oscillation rate: ±10%
• Connection to main supply:
permanent (through external
SELV (safety extra-low voltage)
and through LPS (limited power
source))
Power source (not sup-
plied) for versions sup-
plied with 12..36 V DC
• Limited power source according to
UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
115/230 V AC power supply
• frequency • 50/60 Hz
• supplied voltage • 27 V DC, regulated
• Maximum current • 250 mA
6.3.1. Conditions of use
Ambient temperature –10...+60°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class
according to IEC/
EN 60529
IP65 1), device wired, cover lid screwed
tight and cable glands tightened
1) not evaluated by UL
6.3.2. Conformity to standards and
directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
English

14
Technical data
Type 8025 - 8035 - SE35
• integrated protection • 250 mA time-delay fuse
• power • 6 VA
Maximum current
consumption version
12...36 V DC without relais
25 mA
Maximum current
consumption version
12...36 V DC with relais
70 mA
Maximum current
consumption version
115/230 V AC
250 mA max. at 27 V DC
Pulse output (transistor) polarized, potential-free
• type • NPN/PNP (wiring dependant)
• electrical data • 5...36 V DC, 100 mA max., voltage
drop 2,5 V DC at 100 mA
Relay output
• operating • hysteresis, adjustable thresholds,
normally open
• electrical data of the load
(non UL recognized
devices)
• 230 V AC / 3 A or
40 V DC / 3 A (resistive load)
• electrical data of the load
(UL recognized devices)
• max. 30 V AC and 42 V peak / 3 A
or max. 60 V DC / 1 A
To use the relay outputs in a wet
location, observe the following
DANGER safety instruction.
Current output 4...20 mA, sinking or sourcing mode
(wiring dependant)
DANGER
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22,6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
6.3.5. Specifications of the flow sensor
connected to a 8025 wall-mounted
version
Sensor input
• signal frequency • 2.5...400 Hz
• pulse signal (Hall) • NPN, open collector
• sinus signal (coil) • typical sensitivity of 35 mV peak-peak, at 252 Hz
Sensor output
• power supply • 10...34 V DC (V+ minus 2 V DC), 1 mA max.
English

15
Technical data
Type 8025 - 8035 - SE35
6.4. Technical data of the flow
transmitter SE35
The technical data of the flow transmitter SE35 may be
restricted by the sensor-fitting used.
▶Please refer to the Operating Intstructions of the related
fitting or sensor-fitting.
6.4.1. Conditions of use
Ambient temperature
• 12...36 V DC version • –10...+60°C
• 115/230 V AC version • –10...+50°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class
according to IEC/
EN 60529
IP65 1), device wired, cover lid screwed
tight and cable glands tightened or
female connector plugged in and
secured with screws (depending on the
version)
1) not evaluated by UL
6.4.2. Conformity to standards and directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
UL-Certification
Finished products with variable key PU01 or PU02 are UL-certified
products and comply also with the following standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
English

16
Technical data
Type 8025 - 8035 - SE35
6.4.3. Materials
Part Material
Housing / cover / lid / nut PC
Frontfoil / screws Polyester
Screws Stainless steel
Male fixed connector or cable glands PA
Identification label Polyester
6.4.4. Electrical data
12...36 V DC power supply • filtered and regulated
• oscillation rate: ±10%
• Connection to main supply:
permanent (through external
SELV (safety extra-low voltage)
and through LPS (limited power
source))
Power source (not supplied)
for versions supplied with
12..36 V DC
• Limited power source according
to UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
115/230 V AC power supply
• frequency • 50/60 Hz
• supplied voltage • 27 V DC, regulated
• Maximum current • 125 mA
• integrated protection • 125 mA time-delay fuse
• power • 3 VA
Maximum current
consumption version
12...36 V DC without relais
25 mA
Maximum current
consumption version
12...36 V DC with relais
70 mA
Maximum current
consumption version
115/230 V AC
125 mA max. at 27 V DC
Pulse output (transistor) polarized, potential-free
• type • NPN/PNP (wiring dependant)
• electrical data • 5...36 V DC, 100 mA max.,
voltage drop 2,5 V DC at 100 mA
Relay output
• operating • hysteresis, adjustable thresholds,
normally open
• electrical data of the load
(non UL recognized devices)
• 230 V AC / 3 A or 40 V DC / 3 A
(resistive load)
• electrical data of the load
(UL recognized devices)
• max. 30 V AC and 42 V peak /
3 A or max. 60 V DC / 1 A
To use the relay outputs in a wet
location, observe the following
DANGER safety instruction.
Current output 4...20 mA, sinking or sourcing mode
(wiring dependant)
English

17
Technical data
Type 8025 - 8035 - SE35
DANGER
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22,6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
6.5. Technical data of the flowmeter
8035
The flowmeter 8035 comprises an S030 sensor-fitting including the
paddle-wheel flow sensor and a flow transmitter type SE35.
The technical data of the flowmeter 8035 may be restricted
by the S030 sensor-fitting used.
▶Please refer to the Operating Intstructions of the related
sensor-fitting S030.
6.5.1. Conditions of use
Ambient temperature
• 12...36 V DC version • –10...+60°C
• 115/230 V AC version • –10...+50°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
Protection class
according to IEC/
EN 60529
IP65 1), device wired, cover lid screwed
tight and cable glands tightened or
female connector plugged in and
secured with screws (depending on the
version)
1) not evaluated by UL
6.5.2. Conformity to standards and directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
Conformity to the Pressure Equipment Directive
→Make sure the device materials are compatible with the fluid.
→Make sure the pipe DN and the PN are adapted for the device.
The device conforms to Article 4, Paragraph 1 of the Pressure
Equipment Directive 2014/68/EU under the following conditions:
English

18
Technical data
Type 8025 - 8035 - SE35
• Device used on a piping (PS = maximum admissible pressure;
DN = nominal diameter of the pipe)
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.i DN≤25
Fluid group 2, Article 4, Paragraph 1.c.i DN≤32
or PSxDN≤1000
Fluid group 1, Article 4, Paragraph 1.c.ii DN≤25
or PSxDN≤2000
Fluid group 2, Article 4, Paragraph 1.c.ii
DN≤200
or PS≤10
or PSxDN≤5000
UL-Certification
Finished products with variable key PU01 or PU02 are UL-certified
products and comply also with the following standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.5.3. Materials
Part Material
Housing / cover / lid / nut PC
Frontfoil Polyester
Screws Stainless steel
Male fixed connector or cable glands PA
Identification label Polyester
Wetted parts
Sensor-fitting S030 Refer to the Operating Inst-
ructions of the sensor-fitting
6.5.4. Fluid data
Type of fluid neutral or slightly aggressive liquids
Fluid viscosity max. 300 cSt
Rate of solid particles max. 1%
Fluid temperature The fluid temperature may be restricted by
the fluid pressure and the material the S030
sensor-fitting used is made of (see Fig. 3)
Fluid pressure The fluid pressure may be restricted by the
fluid temperature and the material the S030
sensor-fitting used is made of (see Fig. 3)
• with sensor-fitting
S030 in plastic
PN10 1)
• with sensor-fitting
S030 in metal
PN16 1) (PN40 1) on request)
1) not evaluated by UL
English

19
Technical data
Type 8025 - 8035 - SE35
10
9
8
7
6
5
4
3
2
1
0
-30 -10 +10 +30 +50 +70 +90 +110
PVDF (PN10)
PVC (PN10)
PP (PN10)
PVC + PP
PVDF
16
15
14
13
12
11
A
P (bar)
T °C
A
Metal
A: range of use
Fig. 3 : Fluid temperature/fluid pressure dependency curves for
the flowmeter 8035, depending on the material the S030
sensor-fitting is made of
6.5.5. Electrical data
→Please refer to the electrical data of the flow transmitter SE35,
chap. 6.4.4, page 16.
6.6. Technical data of the flow
transmitter SE35 associated with
a sensor-fitting S070 or S077
The technical data of the flow transmitter SE35 associated
with a sensor-fitting S070 or S077 may be restricted by the
S070 or S077 sensor-fitting used.
▶Refer to the Operating Intstructions of the related sensor-
fitting S070 or S077.
6.6.1. Conditions of use
Ambient temperature
• 12...36 V DC version • –10...+60°C
• 115/230 V AC version • –10...+50°C
Air humidity < 80%, non condensated
Height above see level max. 2000 m
Operating conditions Continuous operation
Mobility of the device Fixed device
Use Indoor and outdoor
(Protect the device against electroma-
gnetic interference, ultraviolet rays and,
when installed outdoors, against the
effects of climatic conditions)
Installation category Category I according to UL/EN 61010-1
Degree of pollution Degree 2 according to UL/EN 61010-1
English

20
Technical data
Type 8025 - 8035 - SE35
Protection class
according to IEC/
EN 60529
IP65 1), device wired, cover lid screwed
tight and cable glands tightened or female
connector plugged in and secured with
screws (depending on the version)
1) not evaluated by UL
6.6.2. Conformity to standards and
directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
Conformity to the Pressure Equipment Directive
→Make sure the device materials are compatible with the fluid.
→Make sure the pipe DN and the PN are adapted for the device.
The device conforms to Article 4, Paragraph 1 of the Pressure
Equipment Directive 2014/68/EU under the following conditions:
• Device used on a piping (PS = maximum admissible pressure;
DN = nominal diameter of the pipe)
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.i DN≤25
Fluid group 2, Article 4, Paragraph 1.c.i DN≤32
or PSxDN≤1000
Fluid group 1, Article 4, Paragraph 1.c.ii DN≤25
or PSxDN≤2000
Type of fluid Conditions
Fluid group 2, Article 4, Paragraph 1.c.ii
DN≤200
or PS≤10
or PSxDN≤5000
6.6.3. Fluid data
→Refer to the technical data sheet or to the Operating Instructions
delivered with the related sensor-fitting S070 or S077.
6.6.4. Materials
Part Material
Housing / cover / lid / nut PC
Frontfoil Polyester
Screws Stainless steel
Male fixed connector or
cable glands PA
Identification label Polyester
Wetted parts
• Sensor-fitting S070 • Refer to the Operating Instructions
of the related sensor-fitting
6.6.5. Electrical data
→Please refer to the electrical data of the flow transmitter SE35,
chap. 6.4.4, page 16.
English
