60-1504 (S)
 .#!)**
CAT SLP Series
STAINLESS LOW PRESSURE SPRAY GUN
PRODUCT INFORMATION
[phone]
Fax[phone]
www.sprayCAT. com
Coating Atomi ation Technologies
P.O.Box 17820, Boulder CO 80308

Operation and Maintenance Instructions for CAT SLP Spray Guns
Operation
1. Connect air su ly hose at handle of gun.
2. Connect a ressurized fluid su ly or aint si hon cu to the gun fluid inlet.
3. Fluid flow can be controlled using the fluid control knob, this restricts flow by limiting needle travel. It
is best to control fluid flow by ro er selection of fluid orifice size and use the fluid control knob to fine
tune flow rate.
4. Fan width can be adjusted using the fan control knob. Turning the knob clockwise narrows the fan.
Maintenance
IMPORTANT! Routine cleaning and maintenance is essential to insure ro er gun o eration.
Several states rohibit s raying solvent into the atmos here and require the use of covered gun cleaner.
1. If a gun cleaner is being used, connect and clean the gun in the gun cleaner according to the
manufactures instructions.
2. If a gun cleaner is not being used:
For ressure setu s, remove air ca and clean se arately using clean solvent.
Connect a ressurized solvent su ly to the fluid inlet, trigger the gun allowing solvent to flow thru the gun until clean.
For si hon setu s, first clean the si hon cu thoroughly then s ray clean solvent thru the gun until clean.
NOTE: Gun head disassembly is not recommended for normal
cleaning and maintenance.
Gun head disassembly and reassembly instructions:
Gun head disassembly
To remove the nozzle carrier (4) and air ca ada ter (6):
1. Remove the air ca (1), fluid nozzle ti (2), fluid nozzle body (3), and needle (13)
2. Remove the needle seal cartridge (23)
3. Loosen the locknut (8) and remove fluid inlet (9) using a 5/8 o en-end wrench
4. The nozzle carrier and air ca ada ter will now slide forward from the gun body (11).
Gun head reassembly
1. Install a new o-ring (7) on the air ca ada ter.
2. Install a new o-ring 98-8026 (5) onto the air ca ada ter.
3. Install the thread locknut (8) onto the fluid inlet as far as ossible.
4. Slide the nozzle carrier (4) into air ca ada ter (6) and insert into the gun body as far as ossible. Be sure the
nozzle carrier extends into the hole at the back of the gun head. Install the needle seal (23) but do not tighten.
5. Rotate the nozzle carrier until the fluid inlet ort in the nozzle carrier is aligned with the threaded hole in the body.
While in this osition, insert the fluid inlet (9) and tighten firmly.
6. Tighten the needle seal (23) to a rox. 12 ft.-lb. torque.
7. Tighten the fluid inlet (9) to a rox. 25 ft.-lb. torque.
8. Tighten the locknut (8) to a rox. 33 ft.-lb. torque.

ITEM
NUM BER PART NUM BER DESCRIPT ION
1 See A ir Cap Char t A ir Cap Cap
2 See A ir Cap Chart Fluid Noz z le Tip
3 33-1202 Fluid Nozzle Body
4 60-L31H Nozzle Carrier
5 98-8026 O-Ring
6 60-34H Air Cap Adapter
760-131 O-Ring
8 60-128 Locknut
9 60-126 Fluid Inlet
10 60-124 Fluid Inlet Seal
11 60-1120 Gun body
12 60-1504 Fan Control Assembly
13 See Air Cap Chart Fluid Needle
14 60-202 Fluid Control Knob
15 See KIT NO. 10-106 Spring Seat*
16 See KIT NO. 10-106 Needle Return Spring*
17 60-201 Rear Bushing
18 See KIT NO. 10-106 Seal*
19 60-1520 Air Valve Assembly
20 60-302** Air Valve Poppet
21 See KIT NO. 10-106 Seal*
22 See KIT NO. 10-106 Air Valve Spring*
23 60-1400* Needle Seal Cartridge
24 60-2101 Trigger
25 60-1033 Trigger Pivot Set
26 60-122 Plug (optional)
27 60-104 Air Inlet Fitting
28 98-0109 Allen Plug
29 60-1510 Inlet Air Control
* Included in KIT NO. 10-106
** Included w ith Air Valve Assembly 60-1520
HVLP AIR CAP TEST GAGES
23-1310-G
23-1313-G
23-1314-G
FOR
CA T SLP
GUNS
23-1315-G
23-1317-G
23-1319-G
23-1322-G

Material Orifice Size
Filler 1.5
Primer, Washprimer,
Epoxy 1.3 - 1.5
Sealer 1.3
Single Stage 1.0 - 1.2
Base Coat 1.0
Clear Coat 1.0 - 1.2
High Solids Clears 1.0 - 1.3
Stains 1.0
HVLP Kits Orifice Size Air Cap Orifice (Tip) Needle
JK1308 0.8 23-1308 33-0208 40-1308
JK1310 1.0 23-1310 33-0210 40-1310
JK1312 1.2 23-1312 33-0212 40-1312
JK1313 1.3 23-1313 33-0213 40-1313
JK1314 1.4 23-1314 33-0214 40-1314
JK1315 1.5 23-1315 33-0215 40-1315
JK1317 1.7 23-1317 33-0217 40-1317
JK1319 1.9 23-1319 33-0219 40-1319
JK1322 2.2 23-1322 33-0222 40-1322
29 psi @ 13.5 cfm
29 psi @ 13.5 cfm
KITS FOR CAT SLP GUNS
29 psi @ 13.5 cfm
29 psi @ 13.5 cfm
29 psi @ 13.5 cfm
29 psi @ 13.5 cfm
CAT SLP NOZZLE SELECTION CHART
Air Consumption
29 psi @ 13.5 cfm
29 psi @ 13.5 cfm
