C.A. Technologies FE-Line Fine Finish User manual

HVLP AIR CAP AND FLUID NOZZLE CHART
MODEL
NO. AIR CAPS
PRESS.
OR
SIPHON
*MAX GUN
INLET PRESS.
FOR HVLP
FAN
CONTROL
SCFM @
MAX GUN
INLET
STANDARD
IN CAT
PACK
AVAILABLE FLUID
NOZZLES TIPS
NEEDLES /
marking on needle
23-1308 Pressure Included 33-0208 0.8mm (.022") 40-1808 (08)
23-1310 Pressure 33-0210 1.0mm (.040") 40-1810 (1810)
23-1312 Pressure 33-0212 1.2mm (.046") 40-1812 (1812)
23-1313 Pressure Included 33-0213 1.3mm (.052") 40-1813 (1813)
23-1314 Pressure 33-0214 1.4mm (.055") 40-1814 (1814)
23-1315 Pressure 33-0215 1.5mm (.059") 40-1815 (1815)
23-1317 Pressure Included 33-0217 1.7mm (.070") 40-1817 (1817)
Actual fluid nozzle and air cap combinations are determined by application (see application chart page 4)
*Note: Air cap test gages are available to confirm HVLP compliance.
*Gun inlet pressures may vary as required by application
FE-LINE
FINE
FINISH
(FEFF)
60-131729* 13.5
FE-Line Fine Finish
PRESSURE FEED SPRAYGUN
PRODUCT INFORMATION
DISTRIBUTED BY COATING EQUIPMENT TECHNOLOGY, INC
PHONE: [phone]
WEB: www.cetinc.com

Operation and Maintenance Instructions for FE-FF Spray Guns
Operation
1. Connect air supply hose at handle of gun.
2. Connect a pressurized fluid supply to the gun fluid inlet.
3.Fluidflowcan be controlledusingthefluidcontrolknob, thisrestricts flow bylimitingneedletravel.Itisbesttocontrol
fluid flow byproper selection of fluid orifice size and use the fluid control knob to “fine tune flow rate”.
4. Fan width can be adjusted using the fan control knob. Turning the knob clockwise narrows the fan.
Maintenance
IMPORTANT! Routine cleaning and maintenanceis essential toinsure propergun operation.
Severalstatesprohibitsprayingsolvent intothe atmosphere and requirethe use ofcoveredgun cleaner.
1. If a gun cleaner is being used, connect and clean the gun in the gun cleaner according to the manufactures
instructions.
2. If a gun cleaner is not being used:
Removeair cap andclean separatelyusingcleansolvent.
For pressure setups, connect a pressurized solvent supply to the fluid inlet, trigger the gun allowing solvent to flow
thru the gun until clean.
NOTE:Gun head disassembly is not recommended for normal cleaning and maintenance.
Not recommended to soak entire spray gun in solvent.
Gun head disassembly and reassembly instructions:
Haverepairkit#10-140availablebefore gundisassembly.
Disassembly
1.Remove the triggerbyremovingbothscrews(19).
2.Removefluidcontrolknob (11).
3.Removeneedlereturnspring(13)and needle(12).
4. Removeair valve assembly(9) using a 9/16”wrench.
5.Using a 7/16” wrench removethe needle sealcartridge (20).
6. Using a 13 mm wrench remove the side port control (10) and air control (15).
7. Using a 11/16” wrench loosen locknut (18), using a 5/8” wrench remove fluid inlet (17).
8. Remove air cap (1), remove fluid tip (2) using a 3/8” socket.
9.Using a 1”wrenchremove head insert(3).
Reassembly
1. Install a new o-ring (7 and 8) on air valve assembly, lightly lubricate o-rings with vasoline and reinstall air valve (9) into
the gun body(6).
2.Installa newseal(5)in gun body(6).Installnewo-ring(4) onhead insert (3).Reinstallheadinsert intogunbodyand
tighten. Reinstall fluid tip (2) and tighten.
3. Install new seal (5) in gun body. Reinstall and tighten fluid inlet (17). Tighten locknut (18) after fluid inlet has been
tightened.
4.Remove the shippingpinfrom a newneedle sealcartridge(20). Install newneedleseal cartridge(20).
5. Reinstall side port control (10) and air control (15).
6.Reinstallneedle (12), needlereturn spring (13)and fluid control knob (11).
7. Reinstall air cap (1).

*
*
*
*
*
*
ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION
1See Air Cap Chart Air Cap** 11 60-1312 Fluid Control Knob
2See Air Cap Chart Fluid Nozzle Tip** 12 See Air Cap Chart Fluid Needle**
3 60-35 Head Insert 13 60-211 Needle Return Spring*
498-8026 O-Ring* 14 60-104 Air Inlet Fitting
560-137 O-Ring* 15 60-1319 Air Control
6 60-1301-CL Gun Handle 16 60-2111 Trigger
7 98-5125 O-Ring* 17 60-126 Fluid Inlet
898-5225 O-Ring* 18 60-128 Locknut
9 60-1320 Air Valve Assembly 19 60-1315 Trigger Pivot Set (2)
10 60-1317 Side Port Control 20 60-1329 Needle Seal Cartridge*
**See air cap selection chart on page 1
*Indicates part included in repair kit # 10-140
HVLP AIR CAP TEST GAGES
23-1308-G
23-1310-G
23-1312-G
FOR
FE-FF
GUNS
23-1313-G
23-1314-G
23-1315-G
23-1322-G
23-1317-G
23-1319-G

FE-FF HVLP SPRAY GUN
MATERIAL TYPE FLUID ORIFICE x
AIR CAP MAXIMUM PATTERN WIDTH PRESS. / SIPHON
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
1.5 mm x 1315
1.7 mm x 1317 12 12 P P
FLUID NOZZLE / AIR CAP SELECTION CHARTS
FE-FF Series - Pressure Feed Guns
1.0 mm x 1310 12 P
1.0 mm x 1310
1.3 mm x 1313 12 12 P P
1.3 mm x 1313
1.5 mm x 1315
1.7 mm x 1317
12
12
12
P
P
P
Revised12/23/15
CP-FEFF-303R2 CP-FEFF-PPSR2
CP-FEFF
CP-FEFF Smart Pack Includes:
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CP-FEFF-303R2 Includes:
51-303 1 QT Aluminum Pressure Cup
52-5R2 Pressure Cup Regulator
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CP-FEFF-PPSR2 Includes:
91-460 950 mL 3M™ PPS™ Pressure Cup
91-462 Lids and Liners (Available in 25 Pack)
91-475 #18 PPS Adapter
52-5R2 Pressure Cup Regulator
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
