Canvas Vernon CTCKC-4 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
VERNONVERNON
KITCHEN ISLAND WITH BUTCHERKITCHEN ISLAND WITH BUTCHER
BLOCK TOPBLOCK TOP
PRODUCT NO. 168-0144-0

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS® collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS® makes it easy to refresh your space
to reect your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS® products
to life. We can’t wait to see!

Parts List 4
Before You Begin Assembly 9
Step-by-step Guide 11
Technical Data 18
Troubleshooting 20
Caring for Your Item 20
Warranty 21
TABLE OF CONTENTS
TOOLS REQUIRED
No. 2 Cross-head Screwdriver
Tip Shown Actual Size Rubber
Mallet
NOTE: Do not over-drill/
be aware of over-drilling
VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 3
• Pleasereadandunderstandthisentiremanualbeforeattemptingtoassemble,
operate,orinstalltheproduct.
• Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
• Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
• Topreventdamage,placeallpartsonalevelsurfaceduringassembly.Adda
layer of protective surface if needed.
• Donotallowyourchildrentoclimborjumponfurnitureduetopossible
accident,injuryordeath.Achildclimbingonapieceoffurniturecanmakeit
top-heavy and cause the furniture to tip over.
• Keepchildrenandpetsawayduringassembly.
• Repairingandreplacingpartsshouldbedonebyaqualiedtechnician.
• Thisunitisintendedforuseonlywithinthemaximumweightindicated.Use
withloadsheavierthanthemaximumweightindicatedmayresultininstability
causingpossibleinjury.
• Failuretofollowthesewarningscouldresultinseriousinjury.
WARNING!TOREDUCETHERISKOFSERIOUSINJURY,
READTHEFOLLOWINGSAFETYINSTRUCTIONSBEFORE
ASSEMBLING AND USING THE PRODUCT.
2 People

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
7Drawer Left 1
8Drawer Right 1
9Drawer Bottom 1
10 Drawer Stretcher 1
11 DrawerFront 1
12 Castor 2
13 CastorWithBrake 2
1Top Panel 1
2 BackStretcher 1
3Side Panel Left 1
4Side Panel Right 1
5Shelf 2
6 DrawerBack 1

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 5
14 Leveller 4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
15 Hanger 1

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
6
EXPLODED PARTS
1
2
3
4
5
5
6
7
8
9
10
11 15
14
12 13
L

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 7
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
A CamLock 8
BCam Bolt 8
G 1/4’’LockWasher 18
H 1/4’’FlatWasher 18
C M8x25mmWoodDowel 18
D Bolts1/4’’x32mm 18
E M4x32mmScrew 4
FGlue 1
I Bolts5/32’’x23mm 4
J 5/32’’FlatWasher 4
K HexKey 1

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
8
HARDWARE LIST
EXTRA HARDWARE BAG
ITEM DESCRIPTION THUMBNAIL QUANTITY
LHandle 1
NOpen Wrench 1
MTip-restraint Hardware 1

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 9
BEFORE YOU BEGIN ASSEMBLY
MAKE SURE ALL PARTS ARE PRESENT
Compareallpiecestothepartsandhardwarelists,and
makesureyouhavealltoolsrequiredforassembly.
REMOVE PACKAGING MATERIALS
Placepackingmaterialsbackinthebox.Donotdisposeof
packagingmaterialsuntilassemblyiscomplete.
READ EACH STEP CAREFULLY
Makesureyouunderstandeachstep.Ifyouhaveanyquestions,
contact CANVAS®customer service at 1-888-670-6684 (toll free).
ASSEMBLE IN A CLEARED AREA
Placeallpartsfromtheboxontheoorinfrontofyouonaclean,
dry,levelsurfacetoprotecttheproductasitisbeingbuilt.
?

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
10
BEFORE YOU BEGIN ASSEMBLY
CAM LOCK SYSTEM OPERATION
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE
WIPEDOFFWITHDAMPCLOTH.
InsertdowelatleasthalfwaybytappinglightlywitharubbermalletIFNECESSARY.
GLUE
X
X
1 4
3
2
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1.Screwcamboltintothepre-drilledsmallholesonpanel.Alignthepanelstobejoined
so that the cam bolt goes into the pre-drilled hole on the edge of the second panel and
protrudesintotheholethatwillhousethecamlock.
2.Insertthecamlockintopre-drilledlargeholeonpanel.Makesurearrowonthecam
lockispointedtowardthecambolt.
3.Oncethecamboltisconnectedinsidecamlock,takeacross-headscrewdriverand
tightenthecamlockbyturningclockwise.
You are now ready to assemble the product.

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 11
STEP-BY-STEP GUIDE
7X19X111 X1 6X18X1
11
7
8
6
6
9
E
BX8EX4
B
B
Install cam bolts BB into drawer front 1111anddrawerback66.
Attach drawer left 77,drawerback66,anddrawerright88,usingM4x32mmscrewsEE
tosecure.Then,insertdrawerbottom99.
NoteNote:Makesurecambolts BB are completely seated.
STEP 1

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
12
Attach drawer front 1111 and drawer stretcher 1010todrawerbox,usingcamlocksAA.
Install drawer handle LL to drawer front 1111 andsecurewith5/32”atwasherJJand
bolts5/32”x23mmII. Set aside
STEP-BY-STEP GUIDE
10 X1
11
11
7
8
A
I
L
STEP 2
AX8IX2JX2LX1
10
JA

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 13
Attachbackstretcher22 and shelves55,tosidepanelsleft33and right 44,using
M8x25mmwooddowelsCCwith1/4’’atwashersHH,1/4’’lockwashersGG with
bolts1/4’’x32mmDD;tightenwithhexkeyKK.
Insert hanger 1515 into side panel right 44andsecurewith5/32”atwashersJJand
bolts5/32”x23mmII.
NoteNote:MakesureboltsDD and II are completely seated.
STEP-BY-STEP GUIDE
5X2
2X1
DX10 CX12
STEP 3
GX10 HX10 IX2JX2
15 X1
KX1
4X1 3X1
4
3
5
2
5
15
D
C
I
J
G H
K

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
14
STEP-BY-STEP GUIDE
2
4
3
1
D
K
14
G
H
KX1NX1
Attach side panel left 33,backstretcher22,sidepanelright44 to top panel 11 using
M8x25mmwooddowelsCCand1/4’’atwashersHH,1/4’’lockwashersGG with bolts
1/4’’x32mmDD;tightenwithhexkeyKK.
Option #1Option #1
Attach levellers 1414 to the bottom insert nut of side panel left 33and side panel right 44.
NoteNote:MakesureboltsDD are completely seated.
14 X4
13 X2 12 X2
STEP 4
DX8 CX6GX8H
1X1
X8
C

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 15
N
12
13
Option #2Option #2
Attach castors 1212andcastorswithbrake1313 to the bottom insert nutinsert nut of side panel
left 33and side panel right 44; tighten with open wrench NN.
STEP-BY-STEP GUIDE
4
3

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
16
Insert the drawer into the assembly by pressing down the release levers on the slide
runnersandslidingthedrawerintothetracksofslides.
STEP-BY-STEP GUIDE
STEP 5

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 17
STEP-BY-STEP GUIDE
MX1
STEP 6
This is an optional step to be used if this island is going to be stationary against a
wall. This design is meant to be free standing. Screw hole for the tip-restraint hard-
ware is not pre-drilled on this unit.
Followtheinstructionsprintedontheplasticbagcontainingthetip-restraint
hardware to attach the tip-over restraints to the unit and the wall.
NOTENOTE: The tip-restraint hardware included is for wooden stud wall construction. It
mustbeattachedtoawallstud.Dependinguponyourwallconstruction,dierent
anchorhardwaremayberequired.Pleasecontactyourlocalhardwarestorefor
assistance.Youngchildrencanbeseriouslyinjuredbytippingfurniture.Youmust
installthetip-restrainthardwarewiththeunittopreventtheunitfromtipping,which
maycauseaccidentsordamage.Thetiprestraintsareintendedonlyasabackup,
they are not a substitute for proper adult supervision. The tip restraints are not
earthquakerestraints.Ifyouwishtoaddtheextrasecurityofearthquakerestraints,
they must be purchased and installed separately.
Steel Cable
Wall
Wall
Wooden Stud
Short Screw
Metal Bracket
Long Screw

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
18
Maximum load
110 lb (50 kg)
Maximum load
30 lb (13.6 kg)
Maximum load
30 lb (13.6 kg)
Maximum load
30 lb (13.6 kg)
TECHNICAL DATA
SPECIFICATIONS
ASSEMBLED DIMENSIONS (W x D x H) 30x251/2x34”
 76.2x64.8x86.4cm
ASSEMBLED WEIGHT 61 lb
 2 7 . 7  k g 
MAXIMUM WEIGHT CAPACITY 200 lb
 9 0 . 9  k g 
Option #1Option #1
30”
(76.2 cm) 251/2”
(64.8 cm)
34”
(86.4 cm)

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP 19
TECHNICAL DATA
SPECIFICATIONS
ASSEMBLED DIMENSIONS (W x D x H) 30x251/2x37”
 76.2x64.8x94cm
ASSEMBLED WEIGHT 63lb15oz
 2 9  k g 
MAXIMUM WEIGHT CAPACITY 200 lb
 9 0 . 9  k g 
Option #2Option #2
30”
(76.2 cm)
37”
(94 cm)
251/2”
(64.8 cm)

VERNON KITCHEN ISLAND WITH BUTCHER BLOCK TOP
20
CARING FOR YOUR ITEM
ASSEMBLY TROUBLESHOOTING
PRODUCT TROUBLESHOOTING
CALL US;
WE CAN HELP
BEFORE RETURNING
YOUR PRODUCT Ifyouhavequestionsregardingyourproductorrequire
warrantyassistance,pleasecallourcustomerservicehelpline.
TOLL-FREE:
1-888-670-6684
HAVING TROUBLE?
LET US HELP YOU!
1Useasoft,cleancloththatwillnotscratchthesurfacewhendusting.
2Wipe clean using a damp cloth and a mild cleaner. Wipe dry with a clean cloth.
4Checkallnutsandboltsperiodicallyfortightness.Whenrequired,tightenthemagain.
3Regular application of food-grade oil to the surface will help prevent and treat light
scratches. This treatment does not apply to deep scratches.
PROBLEM POSSIBLE CAUSES SOLUTION
Drawer slides do not go
smoothly.
Drawer gaps are not
even.
Takeoutandrepeat
drawer installation.
Use the pilot holes on
the support rail as a
guide to level the slide
runners.
The slide runners do not align
withtheslidetracksproperly.
Slide runners are not
level with each other.
