Car Solutions QPI_PCM4.0 User manual

[email protected]
www.car-solutions.com
Car-Solutions.com

•Specification
Car Compatibility : 2016 Porsche model with PCM4.0
Components : Interface* 1ea
Multimedia interface Input/output spec
Input : Analog RGB*1, A/V*1, CVBS(Rear Camera)*1
CVBS(Front Camera)*1
Output : To LCD*1
Power spec
Input power : 8VDC ~ 18VDC
Consumption : 5WATT
Switch input mode
External video sources skip function : able to control input
videos on and off via DIP switches.
Able to switch videos via the remote, button switch, and
original buttons.
2
•Features
Control external videos sources (DVD, DTV) via Multi Media
Touch GUI
Adjust external videos screen position
Check the improved Screen Display (User Friendly Interface)
Switch modes via original OEM button
Supply power to connect rear view camera (Back up
camera)
Assist your parking via Dynamic PAS(Parking Assistance
System), PDC(Parking Distance Control), moving parking line
according movement of steering wheel
[email protected]
www.car-solutions.com
Car-Solutions.com

3
•Product exterior
Length-90mm
Height-18mm
Width-140mm
•Components
POWER/UART(Power / UART Connection) | REAR-CAM(Rear camera connection)
| NAVI(Navigation connection) | AV(AV cable connection)
| DIP S/W(Dip switch setting) | LVDS-OUT(Original LVDS cable connection) |
LVDS IN(Supplied LVDS cable connection) |
T/S OUT | IR(IR cable connection) | TEST(No use) | MODE(Button cable connection) |LED
POWER * 1ea
(HPOWER0120)
NAVI * 1ea
(HRGBCA0020)
AV * 1ea
(HAVCAB0030)
IR * 1ea
(HIRCAB0002)
RC * 1ea
(REMOTE0001)
JACK BY JACK * 1ea
(HPOWER0121)
R-CAM * 1ea
(HAVCAB0032)
BUTTON * 1ea
(HARETC0001)
TOUCH OUT * 1ea
(HTOUCH0031)
[email protected]
www.car-solutions.com
Car-Solutions.com

PIN FUNCTION Dip S/W SETTING
1 RGB INPUT MUTE OFF : RGB DISPLAY
ON : RGB Skipping RGB Mode
2 AV1 MODE MUTE OFF : AV1 DISPLAY
ON : Skipping AV1 Mode
3 AV2 MODE MUTE OFF : AV2 DISPLAY
ON : Skipping AV2 Mode
4 AV3 MODE MUTE OFF : AV3 DISPLAY
ON : Skipping AV3 Mode
5 NO USE (OFF)
6
7 REAR MODE OFF : OEM Rear Camera
ON : External Rear Camera
8 NO USE (OFF)
※ON : DOWN / OFF : UP
4
•DIP SWITCH
•REMOTE CONTROL SETTING
Key FUNCTION
POWER & PIP NO USE
MENU Activating FACTORY MENU
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access
the factory mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all
the data about user environment.)
※Please make sure to disconnect the power cable of the interface
and reconnect the power cable again to apply the dip switch setting
whenever changing DIP switch. Otherwise, DIP switch setting will not
be applied.
[email protected]
www.car-solutions.com
Car-Solutions.com

PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
H-SIZE(NAVI)
Menu of FACTORY
MENU to Return SEL to Select/Save
5
•Factory setting
Adjust a current screen position and size.
PAS TYPE : Select type of parking guide line
- NOT USED : No use parking guide line
- PAS ON : Selecting Dynamic parking guide line
- PAS OFF : Selecting fixed parking guide line
PAS SETUP : Adjusting the position of the parking guide line
REAR TYPE : Choose rear camera recognition.
- CAN : By connecting to “CAN” cable of the car gear, changing to
rear camera mode when shifting into reverse. (Connect “CAN”
cable of the power cable to the “CAN” cable of the car gear.)
SAFE ENABLE : If it is enable, RGB, and A/V mode doesn’t show up while
driving. (Default : OFF)
RADAR ENABLE : Enable PDC(Parking Distance Control) Sensor
OFF –No PDC
OEM PDC ON –OEM PDC on
EXT PDC ON –PDC on
<H-POSITION> <V-POSITION>
Adjust rear view camera setting.
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
H-SIZE(NAVI) : Adjust the horizontal size of
Navigation
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
RADAR ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
<OEM PDC ON> <EXT PDC ON>
[email protected]
www.car-solutions.com
Car-Solutions.com

6
•Factory setting
Navigation & Car model setting up
.
NAVI MODEL : Setting up RGB Navigation.
Default
MYVI_WVGA
ICUBE_WVGA
QROI_WVGA
GI5000A_WVGA
GI8000N_WVGA
SMITH_PAD_WVGA
WP9200_WVGA
WP9320_WVGA
KD900_WVGA
ACLASS_WVGA )
AVOUT SELECT : Selecting background sound
through car AUX (AV1, AV2, AV3)
FACTORY RESET : Reset the factory setting
PARK
UTIL1
UTIL2
INFO
NAVI MODEL
AVOUT SELECT
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
Other options setting up
I-DRV REMOTE : Able to use remote control on
DVD, DTV by selecting “User”
after IR memory registered.
(Default, User)
I-DRV CONTROL : Turning on or off of Remote
control usage.
IR MEMORY : Registering IR memory (Remote
control values) of DTV, DVD.
CALIBRATE : Calibrate touch.
※Please refer to “IR Manual” for IR set up.
PARK
UTIL1
UTIL2
INFO
I-DRV REMOTE
I-DRV CONTROL
IR MEMORY
CALIBRATE
Menu of FACTORY
MENU to Return SEL to Select/Save
System version information
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
(MAIN-130723)
Menu of FACTORY
MENU to Return SEL to Select/Save
[email protected]
www.car-solutions.com
Car-Solutions.com

7
•OEM Buttons usage
BUTTON Press Function
HOME Long press (2 sec)
Switch modes
(OEM→NAVI→AV1→AV2→AV3)
BACK Activate front camera
OPT Long press (7 sec) RESET
HOME
Short press Back to OEM screen
OPT
TUNER
MEDIA
NAVI
MAP
SOURCE
PHONE
CAR
BACK
[email protected]
www.car-solutions.com
Car-Solutions.com

8
•Installation Diagram
A/V IN 1
A/V IN 2
F-CAM
DVD-IR
FRONT-DETECT
DTV-IR
SAFE
A/V OUT
REAR (12V OUT)
GND REAR-DETECT
VIDEO IN
NAVI IR
NAVI
NAVI SEL
ACC
CAN2-H(OUT)
GND
CAN2-L(IN)
CAN-H
CAN-L
CAN2-H(IN)
CAN2-L(OUT)
NC
NC
BUTTON CABLE IR CABLE
POWER CABLE
REAR CABLE
NAVI CABLE
RGB
NAVI BOX
Connection
Connection
TOUCH
CABLE
RGB
NAVI BOX
RX wire
RX
GND
TX
[email protected]
www.car-solutions.com
Car-Solutions.com

9
•Power / LVDS cable connection
Original power cable
Jack by jack cable
(HPOWER0121)
Original Command
Power cable
(HPOWER0120)
1) Disconnect the original power cable from the
command and connect to the jack by jack
cable.
2) Disconnect the original green LVDS cable and
connect it to “LVDS OUT” of Interface.
Original LVDS cable
From command
[email protected]
www.car-solutions.com
Car-Solutions.com

10
Take out the monitor from the
center fascia.
Disconnect all cables from the
command.
Connect a bunch of cables from
the command to a female
connector of Jack by jack cable.
Connect the other side of Jack by
jack cable (Male) to the command.
Connect the original LVDS cable (Green) from the
command green connector to “LVDS OUT” and
connect the provided LVDS cable to the command and
“LVDS IN” of interface.
Original LVDS Cable
Provided LVDS Cable
•Power / LVDS cable connection
