Car Solutions QPI W213 User manual

Car-Solutions.com
[email protected]
www.car-solutions.com

•Specification
Compatible car model : 2016 Mercedes Benz New E-Class
Components : Interface* 1ea
Multimedia interface input/output spec
Input : Analog RGB*1, A/V*1, CVBS(Rear view camera)*1
CVBS(Front camera)*1
Output : To LCD*1
Power Spec
Input power : 8VDC ~ 18VDC
Consumption : 5WATT
Switch input mode
- Skip External video sources : Able to skip or display input
videos by switching Dip switches
- Able to switch videos by the remote, button switch
and OEM button
- Able to detect the rear view camera by CAN
2
•Features
Control external video sources(DVD,DTV) via Multi Media Touch
Adjust external videos screen position
Check the improved Screen Display (User Friendly Interface)
Switch modes via original OEM button
Supply power from an interface to rear view camera
(Back up camera)
Assist your parking via Dynamic PAS(Parking Assistance System)
Car-Solutions.com
[email protected]
www.car-solutions.com

3
•Product Exterior
•Components
POWER * 1ea
(HPOWER0088)
RGB(Q-ROI)* 1ea
(HRGBCA0024)
RGB * 1ea
(HAVCAB0002)
AV * 1ea
(HAVCAB0047)
IR * 1ea
(HIRCAB0002)
Remote * 1ea
(REMOTE0001)
CAN IN/OUT * 1ea
(HARETC0091)
CAP Touch * 1ea
(HTOUCH0028)
BUTTON * 1ea
(HARETC0001)
IR OUT * 1ea
(HIRCAB0007)
연장케이블 * 1ea
(HAGPS0003)
Uart Touch * 1ea
(HTOUCH0031)
TOUCH IN* 1ea
(HTOUCH0009)
Car-Solutions.com
[email protected]
www.car-solutions.com

※ ON : DOWN / OFF : UP
4
•DIP SWITCH
•REMOTE CONTROL SETTING
PIN Function Dip S/W
1 RGB INPUT OFF : RGB DISPLAY
ON : Skipping RGB Mode
2 AV1 MODE OFF : AV1 DISPLAY
ON : Skipping AV1 Mode
3 AV2 MODE OFF : AV2 DISPLAY
ON : Skipping AV2 Mode
4 AV3 MODE OFF : AV3 DISPLAY
ON : Skipping AV3 Mode
5 MONITOR SIZE OFF : 12.3inch
ON : 8.4inch
6 CAR MODEL OFF : Others
ON : Analog gauge 12.3 inch (USA Ver)
7 REAR CAMERA OFF : OEM REAR CAMERA
ON : EXTERNAL REAR CAMERA
8 N. C (OFF)
※Please make sure to disconnect the power cable of the interface
and reconnect the power cable again to apply the dip switch setting
whenever changing DIP switch. Otherwise, DIP switch setting will not
be applied.
KEY FUNCTION
POWER & PIP NO USE
MENU Activating FACTORY MENU
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can
access the factory mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can
reset all the data about user environment.)
Car-Solutions.com
[email protected]
www.car-solutions.com

5
•Factory setting
Adjust a current screen position and size
PAS TYPE : Select type of parking guide line
- NOT USED : No use parking guide line
- PAS ON : Selecting Dynamic parking guide line
- PAS OFF : Selecting fixed parking guide line
PAS SETUP : Adjusting the position of the parking guide line
REAR TYPE : Choose rear camera recognition.
- CAN : By connecting to “CAN” cable of the car gear, changing to
rear camera mode when shifting into reverse. (Connect “CAN”
cable of the power cable to the “CAN” cable of the car gear.)
- LAMP : By connecting to the rear lamp of the car, switch to rear
camera mode when shifting into rear. (Connect “Rear-C” cable of
the power cable to the rear lamp of the car.)
SAFE ENABLE : If it is enable, HDMI, RGB, and A/V mode doesn’t show up
while driving. (Default : OFF)
RADAR ENABLE : Setting up parking distance alarm sensor. (ON/OFF)
F-CAM ENABLE : Front camera setting
- OEM CAMERA : Select OEM front camera
- EXT CAMERA : Select aftermarket front camera
- NOT USED
<H-POSITION> <V-POSITION>
Adjust rear view camera setting.
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
H-SIZE(NAVI) : Adjust the size of navigation
display horizontally
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
H-SIZE(NAVI)
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
RADAR ENABLE
F-CAM ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
Car-Solutions.com
[email protected]
www.car-solutions.com

6
•Factory setting
Navigation & Car model setting up
NAVI MODEL : Choose RGB navigation
AVOUT SELECT : Selecting background sound
through car AUX.
FACTORY RESET : Reset FACTORY setting
Other options setting up
I-DRV REMOTE : Able to use remote control on
DVD, DTV by selecting “User”
after IR memory registered.
(Default, User)
I-DRV CONTROL : Selecting whether or not to use
touch function
IR MEMORY : Enter Remote values of DTV, DVD
※ Refer to IR manual for IR settings
CALIBRATE : Activate Touch calibration
Able to check the version of product
PARK
UTIL1
UTIL2
INFO
NAVI MODEL
AVOUT SELECT
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
I-DRV REMOTE
I-DRV CONTROL
IR MEMORY
CALIBRATE
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
(MAIN -130723)
(TRIP -130723)
Menu of FACTORY
MENU to Return SEL to Select/Save
Car-Solutions.com
[email protected]
www.car-solutions.com

7
•How to use OEM buttons
※ Able to switch the modes or activate the function
※ NAVI button
Long press : Switch mode
Short press: Back to OEM mode
※BACK(HOME) button on the wheel :
Long press : Switch mode
Short press : Back to OEM mode
※ BACK button
Long press: Switch mode
Short press: Back to OEM mode
Car-Solutions.com
[email protected]
www.car-solutions.com

Monitor Joy shuttle
Direction Mode Pushing Joy shuttle Mode
12.3inch Rear, Front
Camera mode Short Full Screen → OEM CAM+AFTERMARKET CAM
8inch Rear, Front
Camera mode Short Full Screen → OEM CAM+AFTERMARKET CAM
8
•How to use OEM buttons
1. Image size setting
2. DVD, DTV OSD control
( OSD control remote will appear if the joy shuttle is moved to the left
for a short time in DVD, DTV mode)
Monitor Direction Mode Pushing
Joy shuttle Movement
12.3inch/
8inch
DVD
DTV
Short UP,DOWN,LEFT,RIGHT
Long Select
Car-Solutions.com
[email protected]
www.car-solutions.com

9
•Installation Diagram
F
C
A
M
1
2
V
F
C
A
M
R
C
A
M
G
N
D
R
C
A
M
1
2
V
R
C
A
M
F
C
A
M
G
N
D
V
I
N
1
V
I
N
2
V
I
N
3
Mode button
A
R
1
A
L
1
A
R
2
A
L
2
A
O
U
T
L
A
O
U
T
R
R
E
A
R
S
A
F
E
REAR
CANERA
FRONT
CANERA
IR cable
OEM cable
CAN IN/OUTcable
CAN2USB ※ Connect CAN2USB to
use OEM touch pad
CAN2USB
Power cable
RGB
NAVIGATION
※ Remove white OEM
connector and connect it to
white CAN2USB connector
OEM
connector
Capacitive touch screen
connection
Power cable
RES touch
Cable
Resistive
Touch screen
Uart
Cable
Pin assign
RX
TX
Ground
Car-Solutions.com
[email protected]
www.car-solutions.com

10
•LVDS IN/OUT connection
Find the beige color connector
behind the command
Remove the right wire from the beige
color connector and connect it to
QDIS adapter
Then, connect QDIS adapter to LVDS
out of the interface
Connect the supplied LVDS IN wire to the
right side of beige color connector.
Then, another side of connector shall be
connected to the LVDS IN of the interface
OEM
QDIS LVDS IN
cable
12.3inch monitor command
8.4inch monitor command
QDIS adapter
In Case of 8.4”,
Please remove the left
wire
Car-Solutions.com
[email protected]
www.car-solutions.com

11
•CAN Connection
Find a bunch of cables
from the command
behind
Take away the black connector
cover
Connect the OEM connector
to the supplied CAN IN/OUT
Remove the black
connector marked
with a red circle
Put the black connector cover
onto the supplied CAN IN/OUT
cable
Reconnect the supplied cable
where the black connector
was removed.
※ CAN IN/OUT connection
- Find a bunch of wires from the command behind the monitor as shown below
•B+ / GND connection
GROUND
B+
※ Connect the black ground wire of
the supplied power cable to
the brown OEM wire
※ Connect the red B+ wire of
the supplied power cable to
the orange/blue OEM wire
