Cardinal Health CHB-AGS Manual

Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
CHB-AGS
Cardinal Health™
Single Slide Automated Gram Stainer
Instructions for Use Manual
CHBAGS_GramStainer_IFU.indd 1 7/3/18 1:31 PM

Table of Contents
Specifications..................................................................................................................................................................5
1.0 INTRODUCTION..........................................................................................................................................................6
2.0 WORK AREA REQUIREMENTS.....................................................................................................................................7
3.0 RECEIVING AND UNPACKING......................................................................................................................................7
4.0 MATERIALS REQUIRED BUT NOT PROVIDED ...............................................................................................................7
5.0 GRAM STAIN KITS......................................................................................................................................................7
5.1 General Information..................................................................................................................................................7
5.2 Ordering Information................................................................................................................................................7
5.3 Reagent Kit Installation ............................................................................................................................................7
6.0 OPERATIONS INSTRUCTIONS......................................................................................................................................8
6.1 Instrument Anatomy.................................................................................................................................................8
6.2 Specimen Slide Preparation......................................................................................................................................8
6.3 Instrument Preparation ............................................................................................................................................9
6.4 Stain Operation.........................................................................................................................................................10
7.0 QUALITY CONTROL.....................................................................................................................................................12
7.1 Quality Control Checks ..............................................................................................................................................12
7.2 Self Calibration Errors................................................................................................................................................12
8.0 CONSUMABLES..........................................................................................................................................................12
8.1 Gram Stain Kit Registration.......................................................................................................................................12
8.2 Pump Replacement Tube Procedure.........................................................................................................................13
8.3 Register New Pump Replacement Tube Kit...............................................................................................................14
CHBAGS_GramStainer_IFU.indd 2 7/3/18 1:31 PM

9.0 MAINTENANCE ..........................................................................................................................................................14
9.1 Wash Cycle................................................................................................................................................................14
9.2 Bleach Cycle ..............................................................................................................................................................15
9.3 Scrub Cycle................................................................................................................................................................16
9.4 Cuvette Swabbing.....................................................................................................................................................17
9.5 Deionized Water Disinfectant....................................................................................................................................17
9.6 Refilling the Water Supply........................................................................................................................................18
9.7 Maintenance Summary.............................................................................................................................................18
10.0 IDLE DELAYS............................................................................................................................................................18
10.1 Setting the Sleep Delay...........................................................................................................................................19
11.0 UNIT SHUT DOWN....................................................................................................................................................19
11.1 Unit Shut Down Instructions...................................................................................................................................19
12.0 SERVICES AND SUPPLIES..........................................................................................................................................20
13.0 SAFETY DATA SHEETS ..............................................................................................................................................20
14.0 REFERENCES ............................................................................................................................................................21
15.0 Single Slide Automated Gram Stainer Warranty.....................................................................................................21
16.0 Maintenance Logs...................................................................................................................................................22
Single Slide Automated Gram Stainer Training Checklist................................................................................................23
CHBAGS_GramStainer_IFU.indd 3 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
4
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
Congratulations!
You have made an excellent choice for your Lab. Cardinal Health™ thanks you for the trust you have placed in our
products and services.
This operating manual has been designed to help you gain an understanding of the operation and application of our
Single Slide Automated Gram Stainer. For optimal utilization of all functions, we recommend that you thoroughly study
this manual prior to beginning operation.
This manual has been prepared as an aid for all operations and maintenance, which can be carried out in your facility.
The Cardinal Health™ Quality Management System
This product is manufactured by Hardy Diagnostics for Cardinal Health in accordance with its quality management
system, which complies with the U.S. Food and Drug Administration’s (FDA’s) Quality Systems Regulation (QSR) and
current Good Manufacturing Practices (cGMP) contained in Title 21 Part 820 of the Code of Federal Regulations (CFR).
The company’s manufacturing establishments are registered, and its medical devices are listed with the FDA.
In addition, Hardy Diagnostics’ quality management system is certified to ISO 13485 for medical devices
Unpacking and Inspecting
Carefully unpack the Single Slide Automated Gram Stainer and accessories. Check for damage incurred during transit.
Keep all packing material until you are sure the unit operates properly. Any damage to the shipping box should be
reported to the responsible carrier. These instructions must be followed for us to guarantee our full support of your
claim for protecting against loss from concealed damage. The form required for filing such a claim will be provided by
the carrier.
Important: Keep this operating manual for future use.
CHBAGS_GramStainer_IFU.indd 4 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
5
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
SPECIFICATIONS
Dimensions/Weight Width 30.5 cm (12.0 in.)
Height 40.6 cm (16.0 in.)
Depth 33.0 cm (13.0 in.)
Weight 12.24 Kg (27.0 lbs.)
Power Requirements Input: 100-240 VAC, 8-4A, 47-63Hz
Temperature, Ambient Operation 15-30C
Humidity 0 to 95%, without condensation
Operator Adjustments Individual adjustable stain times on both short and long cycles
Adjustable sleep mode
Adjustable audible sound volume control
Operator Entry Moisture proof, touch screen
Standards IEC-61010-1:2010 (Third Edition)
EN55022; CISPR 22:2005/A1: 2005: Class A
CFR 47, Part 15, Subpart B, Class A, 2008
ICES-003 Issue 4, 2004 CAN/CSA-CEI/IEC CISPR 22;02, Class A
EN55024: 2010
EN 61326-1: 2006
Warranty One Year Standard
CHBAGS_GramStainer_IFU.indd 5 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
6
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
1.0 INTRODUCTION
This Operation Manual is provided to guide the user in all aspects of unit set-up, operational use, and user-level maintenance of the Cardinal Health™ Single Slide
Automated Gram Stainer unit.
The Single Slide Automated Gram Stainer is a microscope slide stainer capable of automatically performing a Gram stain sequence on a slide containing biological
specimen for in vitro diagnostic use. An on-board computer, running software specially designed to accomplish correct Gram stain results for any type of sample,
controls the entire staining process.
The Single Slide Automated Gram Stainer software provides a series of menus for operator control of the unit. By pressing a key corresponding to a menu item,
the operator directs program flow to the various logic paths of the software. All program functions are accessed in this manner.
Operator Responsibility – Safety Instructions
The Single Slide Automated Gram Stainer ensures safe operation when installed, operated, and maintained according to common safety regulations.
This section describes the potential dangers that may arise when operating the Single Slide Automated Gram Stainer.
It is the operator’s responsibility to be properly qualified to operate the Single Slide Automated Gram Stainer. The operator and personnel are also advised to
refer to this Operating Manual and the set-up letter that is packaged with the unit. If you require additional assistance, please call [phone] (ext. 2) to be
connected with Cardinal Health™ Technical Support serviced by QuickSlide™.
In addition, the operator is to be familiar with good laboratory practices and safety precautions.
Explanation of Symbols
I- Power On
O- Power Off
- Caution: Refer to marked paragraphs
- Not Made with Natural Rubber Latex
- In Vitro Diagnostic Medical Device
Background – Gram’s Staining Technique
The Gram staining method, named after Hans Christian Gram, the Danish bacteriologist who originally devised it in 1882, is one of the most important
staining techniques in microbiology. It is usually the first test performed for the presumptive identification of bacteria. The primary stain of the Gram’s method
consists of staining with crystal violet which is then fixed with iodine. The microorganisms that retain the crystal violet-iodine complex appear purple under
microscopic examination and are commonly classified as Gram positive. Others that are not stained by crystal violet, due to a decolorization, step are referred to
as Gram negative, and appear red as a result of counter-staining with safranin.
Gram staining is based on the ability of the bacteria cell wall to retain the crystal violet dye during treatment with acetone-alcohol. The cell wall for Gram positive
microorganisms have a higher peptidoglycan and lower lipid content than Gram negative bacteria. Bacteria cell walls are stained by the crystal violet. Iodine is then
added as a mordant to form the crystal violet-iodine complex so that the dye cannot be removed easily. Subsequent treatment with an acetone-alcohol decolorizer,
which is a solvent, dissolves the lipid layer from the Gram negative cells. The removal of the lipid layer enhances the leaching of the primary crystal violet stain
from the cells into the surrounding solvent. In contrast, the solvent dehydrates the thicker Gram positive cell walls, closing the pores as the cell wall shrinks during
dehydration. As a result, the diffusion of the violet-iodine complex is blocked, and the bacteria remain stained purple. The length of the decolorization step is
critical in differentiating the Gram positive bacteria from the Gram negative bacteria. A prolonged exposure to the decolorizing agent will remove all the stain
from both types of bacteria. Some Gram positive bacteria may lose the stain easily and, therefore, appear as a mixture of Gram positive and Gram negative bacteria
(Gram variable). Finally, a counter-stain of safranin is applied to the smear to give decolorized Gram negative bacteria a red or pink color.
The decolorization step is especially critical and must be timed correctly; the crystal violet stain is removed from both Gram positive and negative cells if the
decolorizing agent is left on too long. This can be particularly problematic for smears of varying thickness – thicker smears require longer exposure for proper
decolorization than thinner smears. This is the most sensitive and variable step of the procedure, and requires experience to know just how much to decolorize
manually. Many labs performing manual Gram stains have considerable quality control problems for this reason.
CHBAGS_GramStainer_IFU.indd 6 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
7
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
2.0 WORK AREA REQUIREMENTS
IMPORTANT!
The Single Slide Automated Gram Stainer unit requires a level counter top surface of a minimum of 12 inches wide by 13 inches deep with a height clearance of 16
inches. The Gram Stain Kit (Cat. No. CHB-AGS-SK) and a container filled with deionized water should be positioned at the same level as the instrument immediately
on the left side connected by the tubing coming out of the machine. Do not place reagents below the instrument.
The Single Slide Automated Gram Stainer has one tube that drains all of the waste fluids. The Single Slide Automated Gram Stainer unit drain line can be placed
down a drain or into another disposal container to accommodate the waste fluids according to your facility and local regulations.
The Single Slide Automated Gram Stainer consumes less than 400 watts of power and uses an external power supply module that is supplied with 47- 63 Hz,
100-240V, 8-4A line power. The unit requires power from a grounded outlet. The Single Slide Automated Gram Stainer overvoltage category is II, the transient
overvoltage is 1440 volts, and the pollution category is 2. The IP protection is IP20.
The Single Slide Automated Gram Stainer is installed with tubing sets to connect the instrument to the reagents. The reagent supply line is equipped with
a cannula (rigid tube) to immerse in the reagent supply container. Labels attached to those lines indicate which reagent is to be used with each line.
The line labeled as DI Water needs to be immersed in the water supply container to supply the machine with available water.
3.0 RECEIVING AND UNPACKING
Unpacking and set-up assistance for the Single Slide Automated Gram Stainer may be obtained by calling the Cardinal Health™ Technical Support Department
serviced by QuickSlide™ at [phone] (ext. 2) during the hours of 8a.m. – 5p.m, Pacific Time, Monday through Friday.
The external power supply is a Class I supply that must be connected to an earthed (grounded) main power outlet. Failure to connect the Single Slide Automated
Gram Stainer as specified will prevent the electrical safety protection features to function as designed.
The power supply is equipped with one attached power cord and one removable power cord. The attached power cord is equipped with a connector that
plugs into the Single Slide Automated Gram Stainer rear panel receptacle near the power switch. The removable power cord adapts the IEC style connector
on the power supply to the local standard AC outlet. The cord supplied by Cardinal Health™ is appropriate for the country of operation.
4.0 MATERIALS REQUIRED BUT NOT PROVIDED
Standard microbiological supplies, such as Gram’s Iodine, Stabilized Dropper Bottle (Cat. No. CHB-GS-DI), Microscope Slide Charged Adhesion Frosted 25mmX75mm
1mm (Cat. No. M6143), Cuvette Swabs (Cat. No. CHB-GS-CS), and Gram Stain QC Slides (Cat. No. CHB-GS-QC), Gram Stain Kit (Cat. No. CHB-AGS-SK),
System Cleaner (Cat. No. CHB-AGS-SC), and Replacement Tubing (Cat. No. CHB-AGS-RT)
5.0 GRAM STAIN KITS
5.1 General Information
The Single Slide Automated Gram Stainer accomplishes automatic Gram staining by a systematically staining, rinsing, decolorizing, and counter-staining the
provided biological specimen. It is critical for the success of this automated process that the unit utilizes the Gram Stain Kit (Cat. No. CHB-AGS-SK)
from Cardinal Health™.
NOTE: For quality control purposes, Gram Stain Kits are labeled with a Kit Number, Lot Number, and Expiration Date. These values are used to track and identify the
Gram Stain Kit used in the unit, and are entered into the system as part of the Gram Stain Kit Registration procedure as explained in section 8.1.
5.2 Ordering Information
The Single Slide Automated Gram Stainer software monitors consumption of the Gram Stain Kit. When starting each Stain Cycle, the system displays a count of
the remaining number of stain cycles available in the current kit. This remaining count should be carefully monitored so that fresh reagents may be ordered and
available when needed.
5.3 Gram Stain Kit Installation
The Single Slide Automated Gram Stainer reagents are supplied to the unit through tubes connected to the individual reagent containers. Each tube is clearly
labeled with a color coded tag, and the tube cannula must be inserted into the correct reagent container. Tubes are also provided for connection to a deionized
water container and to a waste fluid drain. Use care to ensure that these lines are properly connected before use of the Single Slide Automated Gram Stain unit.
CHBAGS_GramStainer_IFU.indd 7 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
8
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
6.0 OPERATION INSTRUCTIONS
6.1 Instrument Anatomy
The basic anatomy of the Single Slide Automated Gram Stainer consists of four parts as described below:
Display screen – the screen that prompts which buttons to select for procedure steps.
Key Pad – the twelve button key pad used to select process options on the instrument.
Cuvette – holds the slide during the staining process.
Front panel – covers the reagent supply pumps and waste drain pumps.
6.2 Specimen Slide Preparation
6.2.1 If the culture is to be taken from a Petri dish or a slant culture tube, first add a drop or a few loops full of water on the slide and aseptically transfer a
minute amount of a colony on the Petri dish. Transfer a drop of the suspended culture to be examined on a slide with an inoculation loop. Note that only a
very small amount of culture is needed; a visual detection of the culture on an inoculation loop already indicates that too much is taken. If staining a clinical
specimen, smear a very thin layer onto the slide, using a wooden stick. Do not use a cotton swab as the cotton fibers may appear as artifacts. The smear should
be thin enough to dry completely within a few seconds. The stains will not penetrate thickly applied specimens, making interpretation very difficult.
6.2.2 Spread the culture with an inoculation loop to an even thin film over a circle of 1.5 cm in diameter, approximately the size of a dime.
Position the smear at least 3/4” below the frosted area. Labels should not extend below the frosted area.
6.2.3 Fixing the specimen causes the cells to adhere to the glass slide to make possible the subsequent rinsing of the smear with water without a significant loss
of cells. This can be accomplished by methanol fixation. For best results, it is required that the methanol method be used, rather than heat, since it
is superior in preventing lysis, distortion, or damage to the cells in clinical material. Red and white cells will not be harmed, whereas heat will distort
or disrupt the cells. Passing the slide over a flame is also not recommended.
Methanol fixed slides have been shown to retain two to ten times as many cells than with heat fixation.(1) In addition, Gram positive bacteria are much less
likely to become over-decolorized when fixed with methanol rather than heat.(2)
Methanol Fixation Procedure: Air-dry the specimen. If a heat block must be used, do not set the temperature above 40°C, and do not leave the slides on the
block for over an hour. It is extremely important that the specimen does not get damaged by excessive heat. Once fully dried, fix by submerging the slide into a
Coplin jar filled with methanol. Please ensure that the methanol covers the whole smear. Drain off remaining methanol without rinsing by tapping the bottom
edge of the slide to paper towel and allow slide to air dry. Do not apply heat after the methanol dries.
NOTE: Because the slide preparation technique can vary from institution to institution and technique is not always controllable (i.e., differences in smear
thickness, fixation techniques, drying time, specimen adherence to different types and brands of slides, etc.) rare instances of carryover from slide to slide have
been reported. The chance of this can be minimized by carefully following the instructions in this manual.
NOTE: For best results with this instrument use glass slides that are positively charged such as Cardinal Health™ Microscope Slide Charged Adhesion Frosted
25mm x 75mm 1mm (Cat. No. M6143) to increase specimen adhesion to the glass slide. The adhesion of the specimen can be variable, depending on the
specimen type, volume and its thickness. Lack of adhesion is most notable in blood or bloody culture smears, so it is mandatory to use chemically treated slides
that produce a positive electrical charge in order to enhance the specimen’s attachment to the slide. Excessively thick smears can lead to a sloughing off of cells
from the slide. So it is important to prepare smears that are relatively thin with some transparency. Software and fluid flow design have been engineered to
minimize the occurrence, but rare occasions of carryover may still be possible depending on the differences in the user’s slide and slide preparation techniques.
It is recommended to reconfirm the presence of low numbers of bacteria in traditionally sterile specimens (such as spinal or joint fluid) with manual staining and
culture results.
LABEL CANNOT BE WRAPPED
AROUND SLIDES OR BELOW
FROSTED PORTION BUT MAY BE
WRAPPED OVER TOP IF FLUSH.
CHBAGS_GramStainer_IFU.indd 8 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
9
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
6.3 Instrument Preparation
6.3.1 Remove the screws to open the front panel that is covering the pump tube rollers, and attach all eight orange pump tubes around their pump rollers.
When installing a new pump Replacement Tube kit (Cat. No. CHB-AGS-RT) refer to section 8.2 for detailed instructions.
6.3.2 Ensure all reagent supply tubes are properly inserted into the correct reagent containers. Once your machine is powered on, refer to section 8.1 for Gram
Stain Kit registration instructions.
NOTE: For quality control purposes, Gram Stain Kits are labeled with a Kit Number, Lot Number, and an Expiration Date. These values are used to track and
identify the Gram Stain Kit used in the unit as Single Slide Automated Gram Stainer software monitors the consumption of the Gram Stain Kit.
6.3.3 Position the waste line for proper disposal of waste fluids into a designated waste container that is empty.
NOTE: Waste disposal regulations vary according to jurisdiction. Please dispose of waste according to your facility and local regulations.
6.3.4 Confirm that deionized water is present in the supply container and make sure that the DI Water supply tube is submerged.
In order to prevent contamination, the deionized water must have stabilized gram’s iodine disinfectant (Cat. No. CHB-GS-DI) added to the container following
this schedule, whichever comes first:
1. Every time the water container is refilled with deionized water.
2. Every 20 days of operation.
This is completed by adding 10 drops of disinfectant per gallon of deionized water into the water container.
6.4 Stain Operation
6.4.1 Plug the power cord into the back of the machine next to the power switch.
6.4.2 Turn the system power switch ON.
During the power up process, the system identification screen is briefly displayed.
Once the system completes loading, the Self-Test procedure validates the operational parameters and prepares the unit for use.
Upon normal completion of the Self-Test, the Main Menu is displayed and the machine is ready to use.
6.4.3 Press [1] on the key pad to select the RUN menu.
The Main Menu displays the current date and time as well as the total lifetime number of cycles that have been run on the unit.
CHBAGS_GramStainer_IFU.indd 9 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
10
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
6.4.4 Press [1] on the key pad to select GRAM STAIN.
Reagent volume and expiration dates are checked at this time to assure staining operation may be completed.
Detection of reagent shortage or expiration yields a warning message describing the reagent status.
NOTE: The Gram Stain command will fail to start if the instrument is due for a required Bleach or Scrub cleaning cycle.
6.4.5 Select a Stain Delay Option.
Select one of the two stain delays 1- Gram Stain (SHORT) or 2- Gram Stain (LONG) by pressing the [1] or [2] key on the key pad to choose the desired stain
delay times for the run.
There are two sets of pre-programmed stain delay times, a short or a long option. The soak times for crystal violet, Gram’s iodine, and safranin are determined
by this selection. Note that the three soak times (for CV, GI and SAF) of each of the three sets may be altered as desired by the facility administrator.
The default settings are:
Short Long
Crystal Violet (CV) 40 60
Gram’s Iodine (GI) 40 60
Safranin (SAF) 40 60
NOTE: The decolorize only option omits all staining entirely, and provides a means for decolorizing ONLY.
CHBAGS_GramStainer_IFU.indd 10 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
11
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
6.4.6 Loading the slide.
When the screen prompt reads Load Slide, lower the slide gently into the cuvette. Load the slide with the specimen side facing out (towards the operator).
NOTE: Do not allow the slide to drop and abruptly hit the “Slide Stop” within the cuvette because the slide can chip or break. Broken glass in the instrument
is not covered under warranty and the customer will be responsible for repairs and shipping. For assistance in the case of a broken slide, call Cardinal Health™
Technical Support serviced by QuickSlide™ at [phone] (ext. 2) before attempting to remove any broken glass.
The Single Slide Automated Gram Stainer employs one cuvette for the entire Gram stain process, the crystal violet staining, Gram’s iodine fixing, decolorizing,
and safranin counter-staining all takes place within this cuvette.
6.4.7 Press any key on the key pad, except [ *], to commence the Automated Gram staining. The unit may now be left unattended as the slide is stained.
When the final rinse step has finished, the machine will make an audible alert to notify the operator that the stain is complete and the slide can be removed.
NOTE: Pressing the [ *] key will abort the Gram stain process and return immediately to the Run Menu.
7.0 QUALITY CONTROL
7.1 Quality Control Checks
The quality and validity of the Gram stain process of the Single Slide Automated Gram Stainer may be periodically verified by staining a slide prepared with any
known sample material. This slide may be stained using exactly the same procedures used for any specimen slide. The processed specimen slide may then be
viewed to confirm proper Gram stain technique and results. Quality Control slides may be purchased from Cardinal Health™ under catalog number CHB-GS-QC.
7.2 Self Calibration Errors
The Single Slide Automated Gram Stainer employs a “self-calibration” test during every staining cycle to verify proper system operation. This test confirms that the
optical sensor response is within a valid specified range. Out-of-Range measurements automatically cause interruption of a staining cycle and operator notification
of the error condition. After problem resolution, staining operations will resume from the point of interruption. This self-check provides additional assurance of
accurate system performance.
8.0 CONSUMABLES
8.1 Gram Stain Kit Registration
The Single Slide Automated Gram Stainer software monitors consumption of the Gram Stain Kit, each kit will last for 110 cycles.
Follow the steps listed below to install a new Kit when needed.
8.1.1 Press [ 1 ] on the key pad to select Run
8.1.2 Press [ 4 ] on the key pad to select Purge
8.1.3 Press [ * ] on the key pad to exit back to the Main Menu
8.1.4 Remove the cannulas from the reagent bottles and wipe them with an alcohol pad.
CHBAGS_GramStainer_IFU.indd 11 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
12
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
8.1.5 Open the new Gram Stain Kit and insert the labeled cannula into the corresponding reagent bottles.
8.1.6 From the Main Menu, Press [ 2 ] on the key pad to select SET-UP.
8.1.7 Press [ 2 ] on the key pad to select Consumables
8.1.8 Press [ 1 ] on the key pad to select Review Reagents.
This display will show the current kits information.
8.1.9 Press [ 1 ] on the key pad to select Change Kit
The display will now should the preregistration menu. At this menu, the instrument reminds the operator that a Scrub Cycle is required before the
installation of a new reagent kit. Refer to section 9.3 for details on how to run a Scrub Cycle. Once the Scrub has completed, the old reagent bottles may be
replaced with new ones.
8.1.10 Once the blinking cursor appears next to the Kit Number, use the key pad to enter in the Kit Number as it reads on the new reagent kit label.
8.1.11 Using the key pad, enter in the Lot Number and Expiration Date into the appropriate fields as it reads on the new reagent kit label.
8.1.12 Press [ # ] on the key pad to select Accept and save the kit registration information.
8.1.13 Press [ * ] on the key pad once
8.1.14 Press [ 1 ] on the key pad to Update Reagent Log and activate the kit.
Entry of invalid numbers or numbers from a previously used Gram Stain Kit, will result in the display of an error message.
8.2 Pump Replacement Tube Procedure
All eight pump tubes must be replaced to ensure proper function of the Single Slide Automated Gram Stainer at least every six months, depending on
frequency of use. The Single Slide Automated Gram Stainer keeps track of the number of tubing cycles remaining, and will notify when a new pump tube
kit is necessary. Each replacement tubing kit will last 1,100 cycles, see section 9.0 for routine maintenance.
8.2.1 Press [ 1 ] on the key pad to select Run
8.2.2 Press [ 4 ] on the key pad to select Purge, repeat this step twice to make sure all of the reagents are emptied from the tubes.
8.2.3 Turn the unit OFF
8.2.4 Open the front panel by removing the four thumb screws.
All eight pump tubes and rollers will be displayed. It is recommended to replace one tube at a time from left to right to keep correct tube placement.
CHBAGS_GramStainer_IFU.indd 12 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
13
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
8.2.5 Remove the two white nylon elbows from each of the orange pump tubes.
8.2.6 Remove the orange pump tube from the pump roller and bracket.
8.2.7 Install the new orange pump tube into the bracket and onto the roller.
8.2.8 Insert the two nylon elbows into the new pump tube.
8.2.9 Turn the unit ON and replace the front panel.
8.3 Register New Pump Replacement Tube Kit
8.3.1 From the Main Menu, Press [ 2 ] on the key pad to select SET-UP.
8.3.2 Press [ 2 ] on the key pad to select Consumables
8.3.3 Press [ 2 ] on the key pad to select Review Tubing
8.3.4 Press [ 1 ] on the key pad to select Change Kit
8.3.5 Enter the Kit Serial Number and press [ # ] on the key pad to Accept
8.3.6 Enter the Kit Batch Number and press [ # ] on the key pad to Accept
8.3.7 Press [ * ] on the key pad once
8.3.8 Press [ 1 ] on the key pad to Update Tubing Log
8.3.9 Press [ * ] on the key pad to return to the Main Menu
8.3.10 Press [ 1 ] on the key pad to select Run
8.3.11 Press [ 3 ] on the key pad to select Prime
The unit is now ready to run samples.
Nylon Elbows
Nylon Elbows
CHBAGS_GramStainer_IFU.indd 13 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
14
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
9.0 MAINTENANCE
9.1 Wash Cycle
The Wash feature for the Single Slide Automated Gram Stainer is required every 20 slides or every 8 days.
The unit runs water and decolorizer through the cuvette and with agitation cleans the internal surface of the cuvette and tubing.
9.1.1 Press [ 1 ] on the key pad to select Run
9.1.2 Press [ 2 ] on the key pad to select Clean Cuvette
9.1.3 Press [ 1 ] on the key pad to select Wash Cuvette
9.1.4 Press any key on the key pad to run the Wash Cycle
When complete, there will be an audible alert notifying the technician that the machine is ready to resume staining.
9.2 Bleach Cycle
The Bleach feature for the Single Slide Automated Gram Stainer is required every month or 600 cycles, whichever occurs first. The unit runs a 10% bleach solution
through the reagent and water lines to clean the internal surface of the tubing and to prevent debris build up in the waste line.
9.2.1 Press [ 1 ] on the key pad to select Run
9.2.2 Press [ 4 ] on the key pad to select Purge
9.2.3 Remove the reagent lines (Crystal Violet, Gram’s Iodine, and Safranin) from their stain containers, and wipe off the residual reagents
from the ends of the cannulas or rinse them off in water.
9.2.4 In the same water container that supplies the instrument with water, make a 10% bleach solution.
9.2.5 Submerge all three of the reagent lines and the D.I. Water line into the DI water container that is full of a 10% bleach solution.
9.2.6 Press [ * ] on the key pad to return to the Main Menu
9.2.7 Press [ 1 ] on the key pad to select Run
9.2.8 Press [ 3 ] on the key pad to select Prime
9.2.9 Press [ * ] on the key pad to return to the Main Menu
9.2.10 Press [1] on the key pad to select Run
9.2.11 Press [1] on the key pad to select GRAM STAIN
CHBAGS_GramStainer_IFU.indd 14 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
15
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
9.2.12 Press [ 2 ] on the key pad to select Gram Stain (LONG)
9.2.13 Place a clean, blank slide in the cuvette when the screen prompt reads Load Slide
9.2.14 Press any key on the key pad, except [ *], to commence the Bleach Cycle
9.2.15 When the cycle is complete, Press [ *] on the key pad to return to the Main Menu
9.2.16 Press [ 1 ] on the key pad to select Run
9.2.17 Press [ 4 ] on the key pad to select Purge
9.2.18 Press [ * ] on the key pad to return to the Main Menu
9.2.19 Empty the 10% bleach solution from the DI Water container, and refill the water container with fresh,
supplemented deionized water (refer to section 9.5).
9.2.20 Wipe off and place all of the cannulas into the water container now full of fresh deionized water.
9.2.21 Press [ 1 ] on the key pad to select Run
9.2.22 Press [ 3 ] on the key pad to select Prime
9.2.23 Press [ *] on the key pad to return to the Main Menu
9.2.24 Press [1] on the key pad to select Run
9.2.25 Press [1] on the key pad to select GRAM STAIN
9.2.26 Press [ 2 ] on the key pad to select Gram Stain (LONG)
9.2.27 Place a new blank slide in the cuvette when the screen prompt reads Load Slide
9.2.28 Press any key on the key pad, except [ *], to commence the Rinse Cycle
9.2.29 Press [ *] on the key pad to return to the Main Menu
9.2.30 Press [ 1 ] on the key pad to select Run
9.2.31 Lift all of the cannulas out of the water container and place them into the waste container before the next step.
9.2.32 Press [ 4 ] on the key pad to select Purge
9.2.33 Wipe off and replace all of the cannulas back into their respective reagent and/or water containers.
9.3 Scrub Cycle
The Scrub feature for the Single Slide Automated Gram Stainer is required every 15 days or 600 cycles, whichever occurs first.
The unit will automatically prompt the operator when scrub cycle needs to be run. The total time to run a Scrub Cycle is five minutes.
9.3.1 From the main menu, Press [ 1 ] on the key pad to select Run.
CHBAGS_GramStainer_IFU.indd 15 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
16
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
9.3.2 Press [ 2 ] on the key pad to select Clean Cuvette.
9.3.3 Press [ 2 ] on the key pad to select Scrub Stain Lines
9.3.4 Press [ 1 ] on the key pad to select Purge, this will empty the lines of stains.
9.3.5 Move the Crystal Violet, Gram’s Iodine, and Safranin cannulas into one bottle of System Cleaner (Cat. No. CHB-AGS-SC), or a bottle containing at least
500 mL of Decolorizer. The cleaner is used to clean the internal portions of the reagent lines, ports, cuvette, and photo optics of the unit.
9.3.6 Press [ 1 ] on the key pad to select Scrub
The unit will automatically prime the system cleaner into the reagent lines and then begin the scrub sequence.
9.3.7 During the scrub sequence use the Cuvette Swabs (Cat. No. CHB-GS-CS) to manually scrub any residue build up, off the side of the cuvette chamber.
NOTE: When swabbing the cuvette, be cautious not to cause an overflow, as that can affect the integrity of the machine.
9.3.8 Once the scrub cycle has completed, wipe off the reagent cannulas with an alcohol pad and return the three stain lines to the proper stain bottles.
9.3.9 Press any key on the key pad to prime the reagent lines with reagents. The unit will make an audible alert when the Scrub Cycle is
complete and ready to resume use.
NOTE: To return to the main menu, Press [ *] on the key pad.
CHBAGS_GramStainer_IFU.indd 16 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
17
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
9.4 Cuvette Swabbing
The cuvette may build up stain residue over time. To clean it, use a foam cleaning swab (Cat. No. CHB-GS-CS) soaked in alcohol to scrub the walls of the cuvettes.
This should be done while the instrument is not in Run Mode, but while a Scrub Cycle is in process. Scrub the cuvette walls with a clean foam swab while
decolorizer and water is rinsing the chamber. Note: Be careful not to accidentally overflow the cuvette with the submerged swab when performing the wash cycle.
9.5 Deionized Water Disinfectant
In order to prevent contamination, the deionized water must have stabilized gram’s iodine disinfectant (Cat. No. CHB-GS-DI) added to the container following this
schedule, whichever comes first:
1. Every time the water container is refilled with deionized water.
2. Every 20 days of operation.
This is completed by adding 10 drops of disinfectant per gallon of deionized water into the water container.
9.6 Refilling the Water Supply
The water can be refilled at any time before the staining process has begun if the water supply is getting low.
NOTE: The new water supply must be disinfected using iodine before continuing use, refer to section 9.5 above.
To refill the water supply, do the following:
9.6.1 Remove the water cannula from the water container and place it onto a fresh paper towel or alcohol swab.
9.6.2 Fill the water container with fresh deionized water and mix in the drops of Gram’s Iodine.
9.6.3 Sanitize the water cannula using an alcohol swab and place it back into the water container and screw the lid on tightly.
Note: When removing the water cannula, if a column of air is sucked into the cannula, an error message can occur. In order to avoid possible sensor errors caused
by air entering into the water cannula, replace the water in the water container before staining a slide.
Note: If a separate sterile water container is available, it can be used to pour more deionized water into the original water container without removing the cannula.
Be sure to add the drops of Gram’s Iodine into the separate sterile water container full of deionized water, before pouring it into the original water container.
9.7 Maintenance Summary
Frequency Maintenance Procedures
Every time the deionized water is refilled (or every 20 days) • Supplement the fresh deionized water with drops of
Gram’s Iodine disinfectant (see Section 9.5).
Monthly Every 600 slides • Run a Bleach Cycle (see Section 9.2).
Every 8 Days Every 20 slides • Run a Wash Cycle (see Section 9.1).
Every 15 days Every 600 slides • Run a Scrub Cycle (see Section 9.3).
• Swab the cuvette during the Scrub Cycle (see Section 9.4).
Six Months Every 1,100 slides • Replace the orange pump tubes (see Section 8.2).
Please utilize the Maintenance Logs to make sure these periodic tasks are completed as scheduled. See section 16.0.
CHBAGS_GramStainer_IFU.indd 17 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
18
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
10.0 IDLE DELAYS
The Single Slide Automated Gram Stainer contains an internal clock that is used to monitor system operations and start a timer to manage the instruments “sleep”
time to conserve energy. The software monitors the idle time by observing the elapsed time since the last key on the key pad was pressed. To set a sleep time
that works best for your lab, refer to Section 10.1 below. When the machine enters into Sleep Mode the LCD display will turn off and the pump motors will be
de-energized.
To exit the Sleep Mode press any key twice on the key pad. This will illuminate the LCD screen and display the Main Menu within 10 minutes as the pump motors
are re-energized and the operating system is activated.
The Stir operation helps maintain the integrity of the machines cuvette. While the machine is in Sleep Mode or while it is idling, the stir function rotates the pump
motors and processes a small amount of decolorizing reagent into and out of the cuvette.
The Auto-Prime feature includes a purge of all reagents, followed by a complete prime of the reagent lines. This prevents reagent evaporation in the supply lines
and maintains the unit in a ready state without wasting reagents, as each of the reagents is expelled back into the respective reagent container.
10.1 Setting the Sleep Delay
10.1.1 Press [ 2 ] on the key pad to select Set- Up
10.1.2 Press [ 4 ] on the key pad to select Options
10.1.3 Press [ 2 ] on the key pad to select Idle Delays
10.1.4 Next to the Sleep Delay, where the blinking cursor is, use the key pad to enter in the desired number of minutes for the instrument
to enter the Sleep Mode.
10.1.5 Press [ # ] on the key pad to enter the desired delay time and move to the next setting.
10.1.6 Next to the Stir Delay, where the blinking cursor is, use the key pad to enter in the desired number of minutes for the instrument to run a Stir Cycle
while the machine is idling.
NOTE: It is recommended that the Stir Delay be set to no more than 60 minutes.
10.1.7 Press [ # ] on the key pad to enter the desired delay time and move to the next setting.
10.1.8 Next to the Auto Prime, where the blinking cursor is, use the key pad to enter in the desired number of hours after idling that the instrument should
automatically prime the reagent lines.
NOTE: It is recommended that the Auto Prime be set to no more than 24 hours.
10.1.9 Press [ *] on the key pad to return to the Options Menu and save the delay times.
CHBAGS_GramStainer_IFU.indd 18 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
19
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
11.0 UNIT SHUT DOWN
11.1 Unit Shut Down Instructions
Refer to section 9.3.1 - 9.3.7 for step by step instructions of how to run a Scrub cycle, but omit the final Prime step.
11.1.1 Run a Scrub Cycle
NOTE: When the screen prompt reads “Replace tubes into proper stains” pull all of the cannulas out of the system cleaner bottle and place them onto a paper
towel. Then, press any key to continue.
NOTE: For the Scrub procedure it is recommended that the System Cleaner for Single Slide Automated Gram Stainer (Cat. No. CHB-AGS-SC) is used.
Alternatively, decolorizer can be used if there is no available system cleaner.
11.1.2 Return to the Main Menu
11.1.3 Press [ 1 ] on the key pad to select Run then Press [ 4 ] on the key pad to select Purge.
11.1.4 Turn the system power switch OFF
11.1.5 Remove all eight orange pump tubes from the pump tube rollers
11.1.5.1 Open the front panel by removing the four thumb screws.
11.1.5.2 Gently stretch the tubes off of the pump rollers without disconnecting the white nylon elbows.
11.1.6 Replace the front panel using the four thumb screws.
CHBAGS_GramStainer_IFU.indd 19 7/3/18 1:31 PM

Single Slide Automated Gram Stainer User Manual
20
Art specications:
IFU/Manual - 8"Wx10"H
Do not alter art or size.
All art prints PMS 185 Red and
100% Black.
AMS1800062
Rev. 0 2018-06
12.0 SERVICES AND SUPPLIES
If a problem is encountered that is beyond the scope of this manual or additional assistance is required, contact our Cardinal Health™ Technical Support Team
serviced by QuickSlide™ at [phone] (ext. 2). Additional supplies for your Single Slide Automated Gram Stainer can be purchased through Cardinal Health.
Catalog Number Description
CHB-AGS-SK Gram Stain Kit, 5 x 16 fl. oz.
CHB-GS-QC QC Slides 50/pack
CHB-AGS-SC System Cleaner, 2 x 500ml
CHB-AGS-RT Replacement Tubing Kit, 8 tubes/kit
CHB-GS-CS Cuvette Cleaning Swabs, 100swabs/kit
CHB-GS-DI Gram’s Iodine for DI Water, 1 bottle
M6143 Microscope Slide Charged Adhesion Frosted 25mmx75mm 1mm
13.0 SAFETY DATA SHEETS
Safety Data Sheets (SDS) for any associated reagents kits can be found at www.mycardinalmsds.com.
14.0 REFERENCES
1. Minnerath, J., et al. A Comparison of Heat Versus Methanol Fixation for Gram staining Bacteria,
Department of Biology, Santa Mary’s University of Minnesota, Winon, MN.
2. Mangels, et al. 1984. Methanol Fixation: An Alternative to heat Fixation of Smears Before Staining. Diagnostic Microbiology and Infectious Disease; 2: 129-137.
CHBAGS_GramStainer_IFU.indd 20 7/3/18 1:31 PM
