CareCo Adventurer X8 User manual

MOBILITY SCOOTER
PRODUCT CODE:
MS03010021 USER MANUAL

P. 2
1. PREFACE AND INTRODUCTION 3
2. SAFETY NOTICE 4
2.1 BEFORE DRIVING 4
2.2 WHILE DRIVING 5
2.3 EMI 9
3. PARTS INTRODUCTION 12
4. OPERATION 13
4.1 CONTROL PANEL 13
4.2 HOW TO OPERATE YOUR SCOOTER 14
5. BATTERY CHARGING AND CARE 19
5.1 CHARGING THE BATTERY 19
5.2 BATTERY 21
6. INSPECTION AND MAINTENANCE 23
6.1 INSPECTION 23
6.2 REGULAR CHECKING RECORD 23
6.3 BATTERY, FUSE AND TYRE 24
6.4 STORAGE 25
6.5 MOVING ABOUT 25
7. TROUBLE SHOOTING AND SPECIFICATION 26
8. WARRANTY 30

P. 3
ATTENTION!
Improper use could lead to injury and or damage to the scooter.
1. PREFACE AND INTRODUCTION
Please carefully read this owner’s manual before using the scooter. Improper use may cause
damage, injury, or trac accidents.
We recommend that you read and understand this owners manual fully to ensure you get the
most out of the scooter.
• This owners manual contains operating instructions for all aspects of the scooter,
including assembly instructions and how to deal with possible accidents.
• Pay attention to areas of the owners manual marked with these symbols: The symbols
used in this manual are explained below: Read especially the notes marked with these
symbols:
WARNING!
Improper use could result in serious
injury or death.
Suggestion
Follow these tips to keep your scooter
in good working order.
Suggestion
To maximize battery eciency and life, fully charge the battery before using the
scooter for the rst time.
• This owners manual contains a repair and maintenance log and useful warranty
information. We recommend that you keep this manual in a safe place.
• If someone else uses the scooter, please provide them with this owners manual.
• Due to design changes, some illustrations and illustrations in the owners manual may
not match the scooter purchased. We reserve the right to make design modications.
This scooter has been designed and manufactured to provide a comfortable, safe and
aordable solution for your mobility needs.
Class of Scooter – Class C / 3

P. 4
2. SAFETY NOTICE
2.1 BEFORE DRIVING
The user must be familiar with the use and operation of this scooter before driving. Always
observe the following safety precautions.
The same trac rules apply to the use of this scooter as apply to pedestrians.
For the users safety, please follow the rules that apply to pedestrians.
• Drive only on pavements, single carriage roads and pedestrian areas. Never drive on
motorways or dual carriageways.
• Do not drive a scooter after consuming alcohol or when tired.
• Be careful when driving the scooter in the dark. (This scooter has not been designed for
night use)
• Please observe local laws and regulations regarding speed limits of these vehicles and
ensure that you do not exceed these limits
Practice operating the scooter.
Familiarize yourself with the operation of the scooter before using it in heavy trac or
dangerous areas. Practice in a wide open area such as a park. To avoid accidents when
driving the scooter, pay attention to your driving actions such as accelerating, stopping,
turning, reversing and going up or down ramps.
• Set the scooter speed to “3” when practicing for the rst time.
• For safety reasons, we recommend the user is accompanied by someone when driving
on the road for the rst time.
• The user should only use the high speed setting when they feel condent enough to
manoeuvre and control the scooter.
The scooter is only to be used by one person at a time.
Do not carry passengers on the scooter.
For maximum carry weight, please refer to “MAX USER WEIGHT” in “7. SPECIFICATION”
The scooter is designed to support those with limited mobility to get around both indoors
and outdoors.

P. 5
Tyres
Correct tyre pressure is essential for optimum steering and stability of the scooter.
• Check the air pressure every two weeks. Inate to 30psi.
• The maximum tyre pressure is 40psi.
2.2. WHILE DRIVING
Please carry out daily inspections. Refer to “DAILY CHECKING” for more information.
Do not move your body outside of the scooter while driving.
• Such action may cause loss of balance and risk of injury.
• Be careful not to get clothes caught in the wheels.
Do not use the scooter under these circumstances:
• Keep away from areas where the wheels of the scooter may get stuck.
• Do not drive at night or when it is heavily raining, snowing, misty or windy.
• Do not drive the scooter in an “S” pattern or make erratic turns.
• Do not take the scooter onto escalators.
• UNDER NO CIRCUMSTANCES SHOULD THE SCOOTER BE USED
AS A SEAT IN A MOTOR SCOOTER (E.G. CARS, BUSES, TRAINS, ETC).
• Surface temperatures can and may increase if exposed to external
sources of heat e.g. sunlight.
Mobile Phones and other electrical equipment:
• Do not use a mobile phone or other wireless communication device when driving.
• Always switch o the scooter and remove the ignition key before using a mobile phone.

P. 6
Automatic Power Shut Down
To prevent accidental battery discharge, the scooter is equipped with an automatic switch-o
function. If the scooter is on, it will automatically power o after 30 minutes of inactivity.
In this case, turn the scooter o and on again to use it again.
Ramps, inclines and drops
• Do not drive on steep ramps that exceed the specied gradient. Refer to
“CLIMBING ANGLE” in “8. SPECIFICATION”
• Always use a low speed when ascending or descending a gradient.
• Do not drive on roads with large drops or potholes.
• Slow down when driving on roads with inclines
• Do not make sudden turns when driving on gravel roads or ramps.
• Always lean forward when climbing a steep gradient.
Starting and Driving
• Ensure the seat is installed properly
• Ensure the tiller is secure.
• Fold the armrests down.
• Turn the power switch to “ON”. If necessary, turn on the headlights.
• Check the battery indicator to make sure there is enough power for the journey. If the
user is concerned about the battery level, charge the scooter before departure.
• Set the speed dial to a position that the user feels safe and comfortable with.
• Ensure the forward/reverse speed lever works correctly.
• Ensure the electromagnetic brake works correctly.
• Always make sure it is safe before driving on the street. Engage the 12.8km/h switch
when driving on the pavement.

P. 7
WARNING!
• Do not engage freewheel mode when driving on a gradient.
• Always re-engage the anti-freewheel device before use. Failure to do so may
cause injury to the user.
• When descending a steep slope, the power is automatically cut o and the
electromagnetic brake is activated for safety purposes. This will limit your speed
to a safe level. Power cycle to restart the scooter.
• Overloading past the weight limit may lead to damage of your scooter or
cause it to malfunction and will endanger your safety. The warranty does not
cover this type of damage. Refer to section entitled “MAX. USER WEIGHT” in “ 8.
SPECIFICATION “.
ATTENTION!
1. Do not pull the left and right cruise control levers at the same time. This can cause
loss of control.
2. Do not turn o the power while driving. Sudden braking may result in an accident or
injury.
3. Do not set the speed to maximum when driving indoors.
4. Do not adjust the speed while driving. Sudden speed changes can endanger you,
others and can damage the scooter.
5. Do not place magnetic devices near the control handle as they may aect the safe
operation of the scooter.
6. Be careful when driving in heavy trac or crowded areas.
Stopping
1. Release the speed control lever completely. The scooter will naturally brake and stop.
2. Turn the power switch to (OFF) then remove the key.

P. 8
Driving on the pavement
• When using the scooter on pavement, ensure the 12.8 km/h limit switch is set to the
slowest setting.
• This limits the scooters top speed to 12.8 km/h. It is illegal to drive on paved roads at a
speed of 12.8 km/h or more.
• Limit switches can be set to the fastest level for road and property use.
Seat Belt
• Always wear a seat belt when driving the scooter.
• Use the seat belt only as a seat positioning device.
• Any other use may result in serious injury or death.
• Belts should be replaced immediately if they show signs of wear.
Maximum recommended incline
This scooter has undergone extensive incline testing. Angles and weights shown for this
scooter indicate the safe working angles for the user and equipment.
0 degree as 400 lbs
10 degree as 210 lbs

P. 9
2.3. EMI
This portion of the content will provide the user with basic information that describes the
problems with EMI, known sources of EMI, protective measures either to lessen the possibility
or exposure or to minimize the degree of exposure, and suggested action should unexpected
or erratic movement occur.
ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES
Powered scooter may be susceptible to electromagnetic interference (EMI), which is
interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV
stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. The
interference (from radio wave sources) can cause the powered scooter to release its
brakes, move by itself, or move in unintended directions. It can also permanently damage
the powered scooter’s control system. The intensity of the interfering EM energy can be
measured in volts per meter (V/m). Each powered scooter can resist EMI up to a certain
intensity. This is called its “immunity level”. The higher the immunity level, the greater the
protection. At this time, current technology is capable of achieving at least a 20 V/m immunity
level, which would provide useful protection from the more common sources of radiated EMI.
This powered scooter model as shipped, with no further modication, has an immunity level
of 20 V/m without any accessories.
There are a number of sources of relatively intense electromagnetic elds in the everyday
environment. Some of these sources are obvious and easy to avoid. Others are not apparent
and exposure is unavoidable. However, we believe that by following the warning listed below,
your risk to EMI will be minimized.
CAUTION:
It is very important that you read this information regarding the possible eects of
electromagnetic interference on your electric scooter.

P. 10
The sources of radiated EMI can be broadly classied into three types:
1. Hand-held portable transceivers ( transmitter-receivers with the antenna mounted
directly on the transmitting unit. Examples include: citizens band (CB) radios, “ walkie
talkie”, security, re, and police transceivers, cellular telephones and other personal
communication devices.
2. Medium-range mobile transceivers, such as those used in police cars, re trucks,
ambulances and taxis. These usually have the antenna mounted on the outside of the
Scooter,
3. Long-range transmitters and transceivers, such as commercial broadcast transmitter
(radio and TV broadcast antenna towers) and amateur (HAM) radios;
POWERED SCOOTER ELECTROMAGNETIC INTERFERENCE (EMI)
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM elds from hand-held radio wave sources ( transceivers) are of
special concern. It is possible to unintentionally bring high levels of EM energy very closer
to the powered scooter’s control system while using these devices. This can aect powered
scooter movement and braking. Therefore, the warnings listed below are recommended to
prevent possible interference with the control system of the powered scooter.
Note:
Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM
radios, TV sets, CD player, and cassette players, and small appliances, such as electric
shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your
powered scooter.

P. 11
WARNINGS
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones can aect powered scooters
and motorized scooter. Following the warnings listed below should reduce the chance of
unintended brake release or powered scooter movement which could result in serious injury.
1. Do not operate hand-held (transceivers-receivers), such as citizens band (CB) radios, or
turn ON personal communication devices, such as cellular phones, while the powered
scooter is turned ON;
2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them;
3. If unintended movement or brake release occurs, turn the powered scooter OFF as
soon as it is safe;
4. Be aware that adding accessories or components, or modifying the powered scooter,
may make it more susceptible to EMI ( Note: There is no easy way to evaluated their
eect on the overall immunity of the powered scooter);
5. Report all incidents of unintended movement or brake release to the powered scooter
manufacturer, and note whether there is a source of EMI nearby;
IMPORTANT INFORMATION
1. 20 Volts per meter ( V/m) is a generally achievable and useful immunity level against
EMI ( the higher the level, the greater the protection);
2. This product has an immunity level of 20 V/m without any accessories and connected
to it.

P. 12
3. PARTS INTRODUCTION
1. Speed Dial
2. Rear Mirror
3. Indicator Lamp
4. Charger Socket Cover
5. Tiller Adjust Lever
6. Head Lamp
7. Seat
8. Seat Rotation Lever
9. Hand Brake Lever
10. Side Reector
11. Rear Lamp
12. Freewheel Lever
13. Anti-tip Wheel
14. Reset Button
2
9
1
5
4
3
6
7
10
8
14 12
11
13

P. 13
4. OPERATION
4.1 CONTROL PANEL
1. Battery level indicator
2. Speed control (slow)
3. Speed control (fast)
4. Speed switch
5. Horn
6. Emergency lights
7. Lights (front and rear)
8. Indicator (left)
9. Indicator (right)
Mileage Display
High / Slow Speed
Mode Display
Battery Indicator
Controller Fault
Code
Temperature
Display
Speed Bar
Speed Display
Time Display
• The time setting is linked to the battery system. Time settings should be reset as soon as
a new set of batteries is replaced or connected.
• The system has a mileage memory for driving distance. The distance display will not
need to be reset after changing batteries.

P. 14
Setting:
Press to change mode,
SET to modify time and display.
Normal
SET(3 seconds)
AM/PM
SET
hour Temp°C/°C
SET
minute
SET
SET
(speed)kmh/mph`(distance)km/mile
SET
Normal
4.2 HOW TO OPERATE YOUR SCOOTER
Power switch
• Turn the key to power ON or OFF.
»(ON) - Power is turned on
»(OFF) - Power is turned o
Speed Button
• Press this button to set the speed range of the scooter. Press the slow button to slow
down, press the fast button to speed up.
Forward, Reverse, and Braking
• If the speed control lever is pulled backwards with the right hand, the scooter will move
forward.
• Pull back the speed control lever with your left hand to reverse the scooter.
• The horn will sound when the scooter is in reverse.
• If you release the speed control lever while moving forwards or backwards, the motor’s
electromagnetic brake will operate and the scooter will stop.

P. 15
Indicator Lamp Switch
• When the switch is turned left or right, the lamp ashes and the buzzer sounds.
• Move the switch back to the middle to turn o the display.
Horn Button
• Press the horn button to sound the horn. The horn stops when the button is released.
Temperature Sensor
• The temperature sensor is built into the control panel. The temperature is for reference only.
USB charger
• Charge your phone on the go with the convenient USB power adapter.
Light Button
• Push the light button to turn on the front and rear lights. Press the
button again to turn o the light.
Battery Indicator
• When the power switch is turned on, the battery indicator will light
up and display red squares indicating the remaining battery power.
“1” means full power, “0” means no power.
• The remaining battery power indicated by the battery indicator will
vary depending on the driving time, driving style, repeated starting,
stopping and climbing. Battery
Indicator

P. 16
Suggestion
1. The battery should be charged each time the scooter is used to ensure
maximum range. The battery should be charged at least once a week, even when
the scooter is not in use.
2. After charging or replacing a new battery, drive the scooter for 2-3 minutes to
make sure the battery capacity is sucient.
3. In winter, the battery response may be slower and the battery range may be
shortened.
4. When driving on a slope, the battery indicator may move up and down. This is
normal.
5. Even if the battery is used properly, the battery capacity will decrease over
time, resulting in a shorter range than a new battery. If the user notices that
the battery has only 50% of its range compared to when it was new, it may
need replacing. For battery replacement, contact your dealer. Continued use
of the battery when it is time to replace it will result in rapidly deteriorated
performance.
6. Frequent driving on slopes and rough terrain will increase power consumption
and reduce battery range.
7. The battery has a 6 month warranty covering manufacturing defects. This
warranty does not apply to improper charging of the battery.
Braking
Electro-Magnetic Brake: When the speed control lever is released, the electromagnetic brake
automatically activates and the scooter stops.
WARNING!
When on a gradient NEVER switch the scooter to the freewheel mode. The
electromagnetic brakes will not be applied. This may result in injury.
Seat
• The seat can be rotated to 45 degrees or 90 degrees.
• Pull the seat adjustment lever forward and swivel seat.
• Release the lever, then continue swivelling the seat until it locks in position.

P. 17
How to adjust the armrest height
• Adjust the height using the knob
located at the rear of the armrest.
ATTENTION!
• Return the seat to the forward facing position before driving the scooter.
• Ensure the limit switch is set to the slowest setting when using the scooter on the
pavement. It is an oence to drive faster than 4mph on the pavement.
How to reposition the seat
• The seat can be adjusted forwards/
backwards using the lever at the front
of the seat.
How to set freewheel mode
• Engaged Mode:
»Push the lever forwards - The
scooter will only move using the
motor.
• Freewheel Mode:
»Pull the lever backwards - The
scooter will only move by
manually pushing.
Rotation Lever
Slide Lever

P. 18
Tiller Adjustment
The tiller can be adjusted to several dierent positions.
1. Push the lever to adjust the tiller position.
2. Release the lever to secure the position.
Push
Manual Brake
Squeeze the brake lever to apply the manual
brake, and release the lever to release the
brake.
The manual brake can be adjusted by the
brake cable adjuster on the left side.
Main Circuit Breaker (Reset Button)
When the voltage in the scooter’s batteries
becomes low or the scooter is under
excessive load, the circuit breaker may
activate to protect the motor and electronics
from damage.
If this happens, turn o the scooter, press the
button(s) and turn on the scooter to reset it.

P. 19
5. BATTERY CHARGING AND
CARE
5.1 CHARGING THE BATTERY
Follow the below procedure step by step.
1. Turn the power switch to [OFF]
2. Connect the charger’s power cord to a
power outlet.
3. Open the charging socket cap on the
scooter tiller and connect the charger to
the socket.
4. Switch [ON] the charger.
WARNING!
• The fan inside the charger will be activated accordingly when you turn on the
charger. If the fan does not work when connected to the charger or the green
light is not showing, DO NOT use this charger. It may lead to overheating of
the charger and cause a re as a result.
• There is a red LED present on the charger to illustrate operation. If this LED
does not illuminate the charger is defective, please contact your dealer.
5. The charger’s red and orange LED’s will be illuminated when charging begins. The
minimum charging duration is 6 hours however it is recommended to charge for at least
10 hours for optimum performance. Do not charge for more than 24 hours.
6. The charger’s LED’s will turn green when charging is complete.
7. Switch [OFF] the charger, disconnect the power cord and the round plug from the
charging socket on the scooter.

P. 20
ATTENTION!
• Beware of ngers or hands getting caught in the handle area when gripping or
adjusting the handle bars.
WARNING!
1. Keep away from ammable objects while charging as it may lead to re or
explosion of battery.
2. Do not smoke while charging as the battery may release hydrogen gas.
Always charge your battery in a well-ventilated space.
3. Never connect or disconnect the plug or cord with wet hands while charging.
Note:
• The scooter will be immobilised when the charger is connected.
ATTENTION!
Please follow the below to avoid accidents when charging.
1. Please use only the charger supplied with the scooter unless provided with an ocial
replacement. Recharge the battery to its full capacity every time. The scooter can
become damaged if the incorrect charger is used.
2. Charge in a well ventilated space that is not directly exposed to sunlight. Do not
charge in humid environments.
3. Do not charge in temperatures less than -10 C or higher than +50 C as the charger
will not work correctly and the batteries will become damaged.
