Usage and Maintenance Instructions
www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
Standard Packing List:
• 1 Owner’s Manual
• 1 Battery Pack
• 1 Seat with Armrests
• 2 Keys
• Battery Charger
• Seat Post Nut and Bolt or Detent Pin
Thank you for purchasing your ZOOM Scooter.
We are delighted you have chosen CareCo (UK) Ltd for your mobility needs.
Product Code: MS01112
Zoom Product Code: MS01102 Zoom+

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
2
Disclaimer
We ask that you read this manual completely before operating your new ZOOM scooter.
CareCo (UK) Ltd cannot be held responsible for any damage or injury incurred due to improper or unsafe use of the CareCo
ZOOM scooter.
CareCo (UK) Ltd specifically disclaims responsibility for any bodily injury or property damage that may occur during any use
that does not comply with applicable laws.
Congratulations on the purchase of your new ZOOM scooter. The ZOOM combines cutting edge technology with attractive
design which is highly functional in today’s world. We at CareCo (UK) Ltd know that you have chosen a scooter that will give
you years of dependable operation and will also enhance the quality of your life by providing you with the mobility to experi-
ence an active daily lifestyle.
Even though your new ZOOM is both user-friendly and designed for maximum manoeuvrability in the tightest spaces, we ask
that you please read, understand and follow all of the instructions and suggestions in this manual before you operate your
scooter for the first time. The safe use of your new scooter is very important to us.
If you feel that you do not understand the instructions and suggestions presented in this Owner’s Manual, or if, for any reason,
you do not feel capable of performing the activities necessary to assemble, disassemble, operate, or maintain your ZOOM,
please contact CareCo Customer Services on 0845 611 8022.
CareCo (UK) Ltd cannot be held responsible for personal injury or property damage resulting from the unsafe or the improper
use of any of our broad range of health and personal mobility products. Also, CareCo (UK) Ltd cannot be held responsible for
personal injury or property damage resulting from attempts to follow instructions, suggestions, and guidelines presented in
this Owner’s Manual.
Our Research and Development Department, our Quality Control Department, and our Engineering Department have used
the latest product specifications and the latest product design information to manufacture your ZOOM scooter. CareCo (UK)
Ltd reserves the right to implement changes into our product lines when those changes become desirable or necessary. If such
changes are implemented into our product line, there may be minor differences between the product you purchased and the
illustrations and instructions in this Owner’s Manual.
We at CareCo (UK) Ltd would appreciate hearing about the dependability of your ZOOM and about the convenience of mobili-
ty it has provided for you. We would also appreciate hearing about the service you received from our Company.
CareCo (UK) Ltd. Customer Services Phone: [phone]
1 Turing Court
Great Notley
Braintree
Essex
CM77 7AT
www.careco.co.uk
For more information about our products and services, or to send us your comments, please visit our website at
www.careco.co.uk or email: [email protected]

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
3
Contents
1. Preface and introduction
2. Safety notice
2.1 Before driving
2.2 While driving
2.3 Labelling
2.4 EMI
3. Parts introduction
3.1 Parts description
4. Operation
4.1 Control panel
4.2 How to operate your scooter
4.3 Assembling and disassembliing
5. Battery charging and care
5.1 Charging the battery
5.2 Batteries
6. Inspection and maintenance
6.1 Inspection
6.2 Regular checking record
6.3 Battery, fuse and tyres
6.4 Storage
6.5 Moving about
7. Trouble shooting and specification
8. Warranty

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
4
Please carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could result in harm, injury
or traffic accidents. Therefore, for maximum benefit while using the vehicle, please read this owner’s manual.
• This owner’s manual includes operation instructions for every aspect of the vehicle and assembly instructions.
• The symbols used in this manual are explained below:-
Read especially the notes marked with these symbols:
• This manual includes a copy of repair and maintenance record chart and warranty information.
Please keep it in a safe place or in the scooter.
• If someone else uses the scooter, please make sure that you provide them with the instruction manual for their
consideration.
• As designs change some illustrations and pictures in the manual may not correspond to the vehicle that you
purchased. We reserve the right to make design modifications.
Our scooters have been designed and manufactured to provide a comfortable and secure yet affordable solution for some
mobility requirements.
Warning Improper usage could result in serious injury or death
Attention Improper usage could lead to injury and/or damage to your scooter.
Suggestion Follow these instructions to keep your vehicle in a good operating order.
1. Preface and introduction
Suggestion
To maximise the efficiency and service life of your batteries, please fully charge before their first use.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
5
2.1 Before driving
The user needs to be familiar with the usage and operation of this vehicle before driving. Please always keep the
following safety notices in mind:-
The same traffic rules apply to the use of this vehicle as apply to pedestrians
For your safety, please therefore follow the rules that apply to pedestrians.
• Ride on the pavement, single carriage roads, or pedestrian areas only. Never ride on motorways or dual
carriageways.
• Please do not drive your scooter after consuming alcohol or when you are tired.
• Please be careful when driving your scooter in low light; it has not been designed for use at night.
• Be extremely cautious when driving your scooter on busy streets or in shopping malls.
Practice operating your vehicle
Before using the scooter familiarise yourself with its operation. Practice in a wide and open area such as a park.
In order to avoid accidents whilst driving, please take care when accelerating, stopping, turning, reversing and
travelling up and down ramps.
• Please turn the speed dial to the low speed position for your initial practice.
• Be sure someone accompanies you for safety when driving for the first time.
• Only use higher speed setting when you are confident that you can easily operate and control your scooter.
The scooter is only to be used by one person at a time
Do not carry passengers on your scooter (including children)
Do not use this vehicle to carry or haul goods
• As the maximum weight can be carried please refer to ‘Max user weight’ in ‘7. Specification’
• Maximum loading weight for the basket is 3 kg (7lbs).
2.2 While driving
Do not alight from the vehicle while moving
• Such action may cause you to lose balance and risk injury from falling.
• Ensure that your clothes do not tangle in the wheels.
Do not use your vehicle under the following conditions:-
• On surfaces that are muddy, gravelly, bumpy, narrow, snowed over, icy, or canal towpaths not guarded by
a fence or hedge. Keep away from places where the wheels may get stuck.
• Do not drive at night or in rain, snow, fog or strong winds.
• Do not drive your vehicle in an ‘S’ pattern or make erratic turns.
• Do not take the scooter onto escalators.
Under no circumstances should the scooter be used as a seat in a motor vehicle (e.g. Cars, buses, trains, etc).
2. Safety notice

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
6
Mobile phones and other electrical equipment
• Do not use a mobile phone or other wireless communication devices while driving.
• Always switch off the scooter and remove the ignition key before using a mobile phone.
• Do not charge the mobile phone or any other electrical devices from your scooter’s battery.
Automatic Power Shut Down
In order to avoid accidentally draining the batteries, your scooter is equipped with an automatic power
shut down facility. If the scooter is left switched on, but remains undisturbed for a period of 30 minutes,
it will automatically turn off. When this happens, simply switch your scooter off and back on and it will
be ready to use once again.
Ramps, inclines and descents
• Do not drive onto ramps greater than the specified gradient. Refer to the section entitled ‘Climbing angle’ in
‘7. Specification’.
• Always use a low speed setting when ascending or descending a gradient.
• Do not drive on roads with uneven surfaces or potholes.
• Slow down when driving uphill.
• Do not make sudden turns when driving on gravel roads or ramps.
• Always lean forward when climbing a steep hill.
Starting and Driving
1. Make sure the seat is installed properly.
2. Make sure the tiller has been secured properly.
3. Fold down the armrests so you can rest your arms on them.
4. Turn the power switch to ‘ON’. If necessary, turn on the headlights.
5. Check battery indicator to see whether there is enough power for your journey. If you have any doubt
about the remaining power, please recharge the batteries before departure.
6. Set the speed dial to a position you feel safe and comfortable with.
7. Check the forward/reverse speed lever works correctly.
8. Make sure the electromagnetic brake works correctly.
9. Before driving, check your way is clear.
Warning !
• Do not set in the freewheel mode when driving on a gradient.
• Always re-engage the anti-freewheel device before use. Failure to do so may result in injury.
• To protect your safety, the power will automatically cut off and the electromagnetic brake system will activate
while you are driving down a steep slope. This will limit the speed to a safe level. Turn the power on again to
re-start your scooter.
• Maximum User Weight Limit
Refer to section entitled ‘Max. user weight’ in ‘7. Specification ‘. Overloading past the weight limit may
lead to damage of your scooter or cause it to malfunction which could endanger your safety. The warranty does
not cover this type of damage.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
7
Attention
1. Do not push both RH & LH sides of the speed control lever simultaneously – control of your scooter will be
affected.
2. Do not turn the power switch to OFF while driving as this will lead to an emergency stop and possible risk of
accident and injury.
3. Do not set to the highest speeds while driving indoors.
4. Do not adjust the speed dial while driving - a sudden change in speed may cause danger to you and others;
and may cause damage to your scooter.
5. Do not place magnetic devices near the area of the operation handle as this could affect the safe operation of
your scooter.
6. Do be careful whilst driving in heavy traffic or crowded areas.
7. When reversing the vehicle, beware of people or objects behind you.
Stopping
1. Release the speed control lever completely. The vehicle will naturally brake and stop.
2. Turn the power switch to OFF. Then pull out the key.
Driving on the pavement
• The max speed is 4mph, which is the legal limit for pavements
• You can set slower speeds for safer driving on busy pavements and indoors
2.3 Labelling
Please carefully read all labels on the scooter before driving it. For your future reference, do not remove them.
CE label Warning EMI Label Freewheel Label

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
8
3. Parts information
3.1 Parts description
1. Power Switch
2. Charger Socket Cover
3. Basket Bracket
4. Tiller Adjust Lever
5. Wheel Lock Knob
6. Seat Rotate Lever
7. Armrest
8. Width Adjustable Armrests Knob
9. Circuit Breaker
10. Freewheel Lever
11. Anti-tip Wheel
12. Connecting device
7
3
1
10
5
4
6
9
8
2
12
11

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
9
4.1 Control panel
1. Battery Level Indicator
2. Speed Dial
3. Horn
4. Wigwag Paddle
4.2 How to operate your scooter
Power switch
Turn the key to power ON or OFF
On: Power is turned on
Off: Power is turned off
Speed dial
Press the slowest or fastest setting to determine the
maximum speed of the scooter.
Forward, Reverse, and Braking
• Pull the speed control lever forwards with your right fingers and the vehicle will move forward.
• Pull the speed control lever forwards with your left fingers and the vehicle will move backward.
• The horn will beep when the vehicle is in reverse.
• Release the speed control lever freely while either going forward or reverse, and the electromagnetic brake in
the motor will be activated, and the vehicle will stop.
Horn Button
Press the horn button to sound the horn. Release the button to stop the horn.
How To Set Freewheel Mode
The motor on the scooter can be disengaged to allow the scooter to be pushed.
• Drive Mode
To put the scooter into “drive” mode, push the freewheel lever up completely.
• Freewheel Mode
To put the scooter into “freewheel mode”, push the freewheel lever down completely and the scooter can be
moved manually.
• Please note that this will put the scooter into freewheel mode, so the scooter’s motor and brake will be
disengaged.
4. Operation
Slowest Setting
1
3
24 4
Neutral
Drive
Fastest Setting

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
10
How to adjust the armrest width
Loosen the knobs at the back of the seat frame first, then adjust the armrest width by sliding the armrest.
Once satisfied with the width, tighten the knob.
Warning
When on a gradient NEVER switch the vehicle to the freewheel mode. The electromagnetic brakes will NOT be
applied and this may result in injury.
Light Button
Push the light button to switch the front and rear lights on.
Push the button again to turn the lights off.
Battery Indicator
The battery indicator on the tiller console uses a
colour code to indicate the approximate power
remaining in your battery. Green indicates (40-100%)
capacity, yellow a low charge (10-30%); and red
indicates that an immediate recharge is necessary.
• The remaining power suggested by the battery indicator will vary by the actual driving time incurred and how you
drive. Repeated starting, stopping, or climbing will consume the power more quickly.
Braking
Electro-magnetic brake: Release the speed control lever completely, and the electromagnetic brake will be
activated automatically, and the scooter will stop.
Manual Handbrake :
Emergency braking is possible using the manual handbrake. Squeeze the handbrake and use the button to lock it
(use it for parking).
Parking
After stopping, turn the main key to OFF and remove the key. The lights will turn OFF. The electromagnetic brake
is engaged (locked).
The handbrake lever can be locked by pushing the button while squeezing the handbrake lever. To release the
handbrake – squeeze lever gently.
RED | YELLOW | GREEN

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
11
Tiller Adjustment
The tiller can be adjusted into many different positions to suit each driver.
1. Loosen the lever to adjust the tiller to the position you require.
2. Once position is chosen, tighten the lever to secure the tiller.
Main Circuit Breaker (Reset Button)
When the voltage in your scooter’s battery becomes low, or the scooter is heavily strained because of
excessive loads or steep inclines, the main circuit breaker may trip to protect the motor and electronics from
damage.
Attention
• Return the seat to the forward position before driving.
• Ensure the limit switch is set to the slowest setting when using the scooter on the pavement. It is an offence
to exceed 4mph on the pavement.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
12
4.3 Assembling and disassembling
1. Place the freewheel mode lever in the drive position.
2. Set the rear section in the up position and make sure the hook for the front section is connected to the axle
of the rear section.
3. Put down the front and rear sections until the scooter is locked.
4. Set down the battery pack on the scooter, and make sure it is in the correct position.
5. Set down the seat on the seat post until the swivel lock engages and you hear a click.
6. Turn key switch to ‘ON’. Make sure the battery gauge indicates sufficient power.
Assembling the scooter
Warning
To avoid personal injury, ask for assistance, if necessary, while disassembling or assembling your scooter.
Disassembling The Scooter
The Zoom can be disassembled into four pieces, the seat (7.21 kg / 15.9 lbs), the front section
(15.74 kg / 34.7 lbs), the rear section (10.69 kg / 23.5 lbs) and battery pack 9.18 kg
(Zoom Plus – 13.38 kg / 29.5 lbs).
10.69kg
23.5lbs
15.74kg
34.7lbs
7.21kg
15.9lbs
9.18kg
20.23lbs

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
13
5. Push the Seat Rotate Lever whilst pulling up on the seat to remove.
1. Make sure the tiller is raised before reassembling the scooter.
Please follow the steps:
6. Unlock the battery lock part and rotate the battery lock part.
2. Turn key switch to ‘OFF’.
7. Pick up the battery pack and remove it from the scooter.
3. Place the freewheel mode lever in the drive position.
8. Loosen the tiller adjustment knob and fold down the tiller and retighten knob.
4. Take off the basket.
9. Lock the front wheel and tiller by turning and pulling the wheel lock catch down.
10. Pull the connecting device upward to the rear section and stand upright.
11. Take off the front section with both hands and lower the shaft.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
14
5. Battery charging and care
5.1 Charging the battery
Follow the procedure below step by step:
1. Turn the power switch to OFF.
2. Connect the charger’s power cord into the power outlet.
3. Open the charging socket cap on the scooter’s tiller; then
connect the charger’s round plug to the charging socket.
4. Turn on the switch on the charger.
5. Both the charger’s red and orange LEDs will be illuminated when beginning
to charge. The recommended charging duration is about 12 - 14 hours, to ensure
optimum performance. We do not recommend a charge of more than 24 consecutive hours.
6. Both the charger’s LEDs will be illuminated during the charging process. The orange LED will turn green
when charging is complete.
7. Turn off the charger; disconnect the power cord and the round plug from charger socket on the scooter.
Warning
• The fan inside the charger will be activated accordingly when you turn on the charger. If the fan does not work
when connected to the charger or the green light is not showing, DO NOT use this charger. The charger may
overheat and cause a fire as a result.
• There is a red LED present on the charger to illustrate operation. If this LED does not illuminate the charger is
defective - please contact CareCo Customer Service on 0845 611 8022 or email: [email protected]
Attention
• While gripping or folding the handle bar, beware of fingers or hands caught in the handle area.
• While returning the battery pack to the battery pack cavity in the shroud, beware of trapping fingers or hands.
Warning
1. Keep away from flammable objects while charging due to danger of fire or explosion of batteries.
2. Do not smoke while charging as the batteries may release hydrogen gas. Always charge your batteries in a
well-ventilated area.
3. Never connect or disconnect the plug or cord with wet hands while charging. Do not connect or disconnect the
plug or cord when they are wet as this may cause an electric shock.
NOTE: The immovable function will be activated when your scooter is in charging status; this will prevent the scooter
operating.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
15
5.2 Battery
• Do not expose the batteries to temperatures below 10°C or above 50°C when charging or storing the vehicle.
Under or above temperature range can cause the battery either to freeze or over heat. This will damage the
batteries and shorten their life.
• These batteries are maintenance free and there is no need to refill with water.
• You are required to recharge the batteries on a regular basis. Even if the scooter stands idle, you should charge
the batteries at least once a week.
• The batteries carry a six-month manufacturer's warranty. This warranty only covers issues relating to
manufacturing faults, and not faults relating to failure to recharge as instructed above.
Attention- Please follow the rules below to avoid accidents while charging.
1. Please use the CareCo charger only, and recharge the battery to its full capacity every time.
You may damage the battery and scooter if you use a charger, which is not to the correct specification.
2. Please charge in a well-ventilated space where it is not directly exposed to the sunlight. Do not charge in
humid, damp or wet surroundings.
3. Do not charge in temperatures less than -10°C or higher than +50°C as the charger may operate correctly and
the batteries may become damaged.
Suggestion – How to maximise your batteries efficiency and service life
1. Fully recharge your new batteries before their first time use.
2. Be sure to charge the batteries fully every time. The battery life will be seriously shortened or decayed if the
battery is repeatedly used without being fully charged.
3. Always complete the charging – the orange LED light may turn green after 1-4 hours but continue charging for
the specified time. NEVER stop charging before it is complete.
4. Keep your batteries fully charged whenever possible.
5. If you do not use your scooter for a long time, the batteries should be charged at least once a week to keep
them in a fully usable condition.
6. The ambient temperature will affect charging time. Charging time will be longer in the winter.
7. After charging, do not leave the charger socket plugged in to the scooter - this will cause a power drain on
the scooter and temporarily reduce its range.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
16
Cleaning the battery
If the battery is contaminated by water, battery acid, dust or other substances, it will discharge quickly. The
battery supplied with the CareCo scooter is sealed and is maintenance free with no risk of battery leakage.
Please follow the steps below to clean the battery.
1. Turn the scooter power switch to ‘OFF’.
2. Remove the seat and dust cover.
3. Remove the shroud and unplug the terminal of the tail-light and signal lights.
4. Use a clean cloth to wipe off the soiled area.
5. Take out the battery.
6. Clean the battery with a clean cloth. If the terminal is covered by white powder, please wipe it clean using warm
water.
Warning
1. The wiring system and charger are placed correctly in the battery pack during assembly by the manufacturer.
Do not attempt to re-locate the wiring system by yourself. The improper layout of wiring system may result
in the wires pinched by battery box, which could result in an electronic system failure.
2. Be sure the battery wires are connected to their correct battery terminal.
Suggestion
If necessary, ask for help from CareCo for advice about maintaining and replacing the battery. Contact Customer
Services on 0845 611 8022 or email: [email protected]
Suggestion
1. Make sure the terminals are installed properly and replace the cover.
2. Do not use the battery to charge telecom equipment or other items.
3. Battery efficiency will vary with outside conditions; the driving distances will be shorter in the winter.
If the vehicle is not used for a long time, please charge the batteries at least once a week.
4. Replace both batteries together.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
17
6.1 Inspection
• Clean the scooter with a damp cloth and dust down approximately once a week to preserve the appearance of
the scooter.
• Adjust the tiller height and return to the original position and swivel the seat once a week to ensure the parts
adjust and remove smoothly and easily when required.
• Check for signs of wear and tear on the tyres and the upholstery on a regular basis.
• For optimum performance and to increase the lifespan of your scooter, it is recommended that you have your
scooter serviced once a year.
6.2 Regular checking record
To make sure your scooter is correctly serviced, take it to CareCo for regular maintenance checks. This should be
at intervals of six months following the first inspection after one month. There may be a fee for this service.
6. Inspection and maintenance
YEAR 1 2 3 4 YEAR 1 2 3 4
Service Dates Service Dates
Controller Upholstery
On/ Off Switch Seat
Control Lever Back
Braking Armrests
Recharge Point Electrics
Batteries Connections Condition
Levels Lights
Connections Test Run
Discharge Test Forwards
Wheels and Tyres Reverse
Wear Emergency Stop
Pressure Left Turn
Bearings Right Turn
Wheel Nuts Slope Test
Motors Over Obstacles
Wirring List Items repaired
Noise
Connections
Brake
Brushes
Chasis
Condition
Steering

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
18
6.3 Battery, fuse and tyres
Battery
Refer to the section entitled ‘5.2 Battery’ in ‘5. Battery charging and care’.
Fuse
If the battery charger is turned on and no LEDs are lit, check the fuse.
Tyres
The condition of the tyres depends on how you drive and use your scooter.
• Inspecting tyre tread
• Please check the tread groove regularly. Replace the tyres when the tread groove is less than 0.5 mm.
Suggestions
Ask for help from CareCo to inspect or replace the fuse, as the tiller shroud has to be removed before the fuse
can be replaced. Contact Customer Services on 0845 611 8022 or email: [email protected]
Suggestions
• Do not splash water directly onto your scooter when washing as this could lead to malfunction of the system
electrics.
• Do not use petrol or solvents as these may damage the shrouds.
• Do not use wax.
Attention
1. When tread depth is below 0.5mm the scooter may not grip well making braking distances longer.
Therefore replace the tyres as soon as they are found to have insufficient tread depth.
2. The tyre pressure should be kept at about 26 PSI (approx. 1.8KG/cm) for the best ride and handling.
Attention
When carrying out maintenance of your vehicle, please turn the power switch to OFF and remove the
charger leads.
6.4 Storage
Make sure the vehicle is stored as follows:-
- The seat is set in the ‘Forward’ position
- The Power switch is turned to ‘OFF’

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
19
Suggestions
Store the scooter out of direct sunlight, rain, and damp conditions. When storing for a length of time, please charge the
batteries to full power and then disconnect the battery terminal. For details contact CareCo Customer
Services on 0845 611 8022 or email: [email protected]
6.5 Manually moving the scooter
• Turn the power switch to off before moving.
• Lift the scooter by the chassis, and not by the bumpers. Lifting the scooters by the bumpers could cause
damage or injury.
• For your safety, always ask for help. 2 or 3 persons will be needed when moving or lifting the vehicle.

www.careco.co.uk CareCo, 1 Turing Court, Great Notley, Braintree, Essex, CM77 7AT
Zoom Mobility Scooter - MS01010014
20
7. Trouble shooting and Specification
Symptom Remedy
The scooter will not switch on: • Try recharging the batteries.
• Check the fuse and circuit breaker in the scooter.
The scooter switches on, but the scooter will not move: • Ensure there is enough power in the batteries;
if not, recharge.
• Ensure the freewheel lever is engaged in the
‘DRIVE’ position.
The scooter appears slow: • Check the battery power level and recharge.
• Check the speed dial is not set to slow.
The seat turns when in operation: • Slowly rotate the seat until it drops into place
and is secure.
The handlebar appears loose: • Tighten the height adjustment handle to secure
the handlebar.
Horn sounds involuntarily: • Ensure that the wigwag paddle is released.
• Switch the scooter off and on.
• Recharge the batteries.
• If problem persists contact CareCo.
If you experience any technical problems, it is recommended that you check with CareCo before attempting to
resolve any issues.
The following symptoms could indicate a serious problem with your power scooter. Contact CareCo if any of the
following arise:-
1. Motor noise
2. Frayed harnesses
3. Cracked or broken connectors
4. Uneven wear on any tyre
5. Jerky motion
6. Pulling to one side
7. Bent or broken wheel assemblies
8. Scooter does not power up
9. Powers up, but does not move
