CAS LP-2G User manual

2001, CAS®(USA) CORPORATION EAST RUTHERFORD, NEW JERSEY 07073
LP-2G
Electronic Price Computing
Label/Receipt Printing Scale
REV: 2.00 Jan. 2002

Copyright©2001
, by CAS Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retri
eval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior expressed written permission
of this company.
Attention:
This c
ompany makes no representations or warranties, either expressed or implied, with respect
to the contents hereof and specifically disclaims any warranties of merchantability or fitness for
any particular purpose. Any software describes in this manual is so
ld or licensed “as is”. Should
the programs prove defective following their purchase, the buyer (and not this company, its
distributors, or its dealers) assumes the entire cost of all necessary servicing, repair, and any
incidental or consequential damage
s resulting from any defect in the software. Further, this
company reserves the right to revise this publication and to make changes from time to time in
the contents hereof without obligation to notify any person of such revision or changes.
Disclaimer:
Brand and product names are trademarks and/or registered trademarks of their respective companies.

1General
ii
1 General................................................................................................................................................... 1
1.1 Introduction.................................................................................................................................1
1.2 Model and Specifications.........................................................................................................2
2 Unpacking and Assembly.................................................................................................................... 4
2.1 Unpacking...................................................................................................................................4
2.2 Assembly of Display Column.....................................................................................................5
3 Proper Operation................................................................................................................................... 6
3.1 Environmental Considerations & Safety..................................................................................6
3.2 Leveling and Location...............................................................................................................7
3.3 Power Outlet and Requirements.............................................................................................. 8
4 Nomenclature........................................................................................................................................ 9
4.1 Scale Overview...........................................................................................................................9
4.2 Display and Indicators.............................................................................................................10
4.3 Printer..........................................................................................................................................11
4.4 The Program Mode Numeric Key Pad...................................................................................12
5 Getting Started.....................................................................................................................................16
5.1 Installation of the Label Roll....................................................................................................16
5.2 Menu and Data Entry System.................................................................................................18
6 Calibration Mode.................................................................................................................................20
6.1 Entering CalibrationMode...................................................................................................... 20
6.2 Entering Calibration Mode (NON-USA).................................................................................20
7 Calibration the Scale .......................................................................................................................... 21
7.1 Calibration Menu...................................................................................................................... 21
8 System Options.................................................................................................................................... 25
8.1 Weight Options.........................................................................................................................25
8.1.1 Capacity & Units............................................................................................................25
8.1.2 Tare Options...................................................................................................................26
8.1.3 Zero Range.....................................................................................................................26
8.1.4 Captions & Headings....................................................................................................27
8.2 Non-Weight Options.................................................................................................................29
8.2.2 Auto Print Threshold.......................................................................................................29
8.3 Report Settings..........................................................................................................................29
8.4 Decimal Place Setting.............................................................................................................30
8.5 Keypad Options........................................................................................................................30
8.6 ClearMemory...........................................................................................................................31
8.7 Select country...........................................................................................................................32
9 Digital Filtering...................................................................................................................................... 33
9.1 Digital Filter Settings..................................................................................................................33
10 Printer Hardware Settings.................................................................................................................. 34
10.1 Printer Hardware Settings Menu...........................................................................................34
10.2 Printer Sensors..........................................................................................................................34
10.2.1 Gap/Peel Calibrate....................................................................................................34
10.2.2 Gap Sensor Fine Adjust...............................................................................................35
10.2.3 Peel Sensor Fine Adjust...............................................................................................35
10.3 Print Speed.............................................................................................................................. 36
10.4 Printer Odometer....................................................................................................................36
10.5 Label Type...............................................................................................................................36

1General
iii
10.6 Feed Adjust.............................................................................................................................. 37
11 Network Options................................................................................................................................ 38
12 Self Test Mode....................................................................................................................................39
12.1 Self Test Menu..........................................................................................................................39
12.2 Display Test.............................................................................................................................. 39
12.3 Load Cell Test..........................................................................................................................39
12.4 Keyboard Test.........................................................................................................................40
12.5 Printer Test................................................................................................................................41
12.6 Peel Off Test.............................................................................................................................42
12.7 Flash Memory Size Test...........................................................................................................42
12.8 Flash Memory Test...................................................................................................................42
12.9 Serial Port Test..........................................................................................................................43
12.10 Firmware Versions Test.........................................................................................................43
13 Audit Trail............................................................................................................................................44
13.1 Reading the Audit Trail Counters.........................................................................................44
14 Servicing & Parts Replacement....................................................................................................... 45
14.1 Platform Safety Overload Adjustment.................................................................................45
14.2 Removing the Upper Case...................................................................................................45
14.3 Main PCB Replacement........................................................................................................47
14.4 Power Supply Replacement.................................................................................................47
14.5 Load Cell & AD Converter Replacement...........................................................................48
14.6 Printer Assembly Replacement ............................................................................................49
14.6.1 Rewind Motor Assembly Replacement....................................................................49
14.6.1 Stepper Motor Assembly Replacement...................................................................50
14.6.2 Thermal Print Head Replacement.............................................................................50
14.6.3 Gap Sensor Assembly Replacement........................................................................51
14.6.4 Peel Sensor Assembly Replacement........................................................................51
14.6.5 Label Roll Spool Replacement..................................................................................51
14.6.6 Width Adjuster Replacement....................................................................................52
14.7 Display Replacement ............................................................................................................52
14.8 Keyboard Replacement........................................................................................................52
14.9 Keyboard Servicing................................................................................................................53
15 Installing Options............................................................................................................................... 54
15.1 Installing the Network Memory Card...................................................................................54
15.2 Installing the Memory Expansion Card................................................................................54
15.3 Installing the Paper Cutter.....................................................................................................54
15.4 Memory Chart for PLU Capacity..........................................................................................55
16 Troubleshooting.................................................................................................................................56
16.1 Troubleshooting Chart...........................................................................................................56
16.2 Versioning & Changes...........................................................................................................58
17 Schematic Diagrams.........................................................................................................................59
17.1 System Block Diagram...........................................................................................................59
17.2 Connection Diagram.............................................................................................................60
17.3 Main PCB .................................................................................................................................61
17.4 Ethernet Memory Expansion PCB.........................................................................................62
17.5 Power Supply PCB ..................................................................................................................63
18 Exploded Views.................................................................................................................................64
18.1 Scale.........................................................................................................................................64

1General
iv
18.2 Printer Assembly...................................................................................................................... 65
19 Parts List............................................................................................................................................... 71
19.1 ELECTRONIC............................................................................................................................71
19.1.1 MEMORY OPTION BOARD PCB ASS'Y........................................................................71
19.1.2 ETHERNET MEMORY OPTION BOARD ASS'Y...............................................................71
19.1.3 PEEL OFF SENSOR PCB ASS'Y.......................................................................................71
19.1.4 ETHERNET OPTION BOARD ASS'Y................................................................................72
19.1.5ANALOGMODULEASS'Y.............................................................................................72
19.1.6 ANALOG PCB ASS'Y.....................................................................................................73
19.1.7 BODY ASS'Y...................................................................................................................73
19.1.8 MAIN PCB ASS'Y...........................................................................................................74
19.1.9 CAL PCB ASS'Y.............................................................................................................75
19.1.10DISPLAYPCBASS'Y.....................................................................................................75
19.1.11 GAP SENSOR PCB ASS'Y............................................................................................76
19.1.12KEYPCBASS'Y.............................................................................................................76
19.2 MECHANICAL..........................................................................................................................76
19.2.1 SET..................................................................................................................................76
19.2.2 MECHANISM .................................................................................................................78
19.2.3 C/T BOX ASS'Y.............................................................................................................. 79
Appendix A: Country Codes …………...…………….................................................. 81
Appendix B: Label Formats ..................................................................................... 83
AppendixC: Datasheet ..................................................................................... 85

CAS (USA) CORPORATION
LIMITED WARRANTY
CAS (USA) Corporation (“CAS”) warrants to the first end user customer of the CAS product enclosed with this limited warranty statement,
that the product if purchased and used in the United States or Canada, conforms to the manufacturer’s specifications and will be free from
defects in workmanship and materials for a period indicated on the space provided on the bottom of this form from the date of original
purchase or three months after product is shipped from CAS to the
CAS Authorized Dealer, which ever comes first. CAS warrants that the
CAS product is manufactured from new components and parts or like-
new components and parts which perform like new and meet the CAS
standard of quality. And only on CAS printing products,
CAS also warrants that the consumable labels enclosed will perform to the
manufacturer’s specific usage, which usage may expire before the expiration of the limited warranty for the CAS product.
Should your CAS product prove defective during the warranty period, please contact the CAS Dealer from which you purchased the CAS
product, or call the CAS Service Hot line at (201) 933-
9002 for warranty repair instructions and return authorization, if required. CAS or a
CAS Authorized Service Center will, at t
heir option, repair or replace on an exchange basis the defective unit, without charge for parts or
labor. When warranty service involves the exchange of the product or of a part, the item replaced becomes CAS property. The exchanged
product or part may
be new or previously repaired to the CAS standard of quality. Exchange or replacement products or parts assume the
remaining warranty period of the product covered by this limited warranty.
This warranty covers only normal consumer use in the United Stat
es and Canada. This warranty does not cover labels or third party parts,
components or peripheral devices added to the CAS product after its shipment from CAS, e.g., the dealer-
added boards or chips, or the
accuracy of the product after it is shipped fromCAS. CAS is not responsible for warranty service should the CAS label or logo or the rating
label or serial number be removed or tampered with or should the product fail to be properly maintained or fail to function properly as a result
of misuse, abuse,
improper installation, neglect, improper shipping, damage caused by disasters such as fire, flood, and lightning, improper
electrical current, software problems, interaction with non -CAS products, or service other than by CAS or a CAS Authorized Service C
enter.
Packaging and shipping cost to and from the CAS repair facility will be CAS’s responsibility. If a claimed defect cannot be identified or
reproduced in service, you will be held responsible for costs incurred.
THE WARRANTY AND REMEDY PROVIDED ABO
VE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
EXPRESS OR IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. SOME LAWS DO NOT ALLOW THE
EXCLUSION OF IMPLIED WARRANTIES. IF THESE LAW
S APPLY, THEN ALL EXPRESS AND IMPLIED
WARRANTIES ARE LIMITED TO THE WARRANTY PERIOD IDENTIFIED BELOW. UNLESS STATED HEREIN,
ANY STATEMENTS OR REPRESENTATIONS MADE BY ANY OTHER PERSON OR FIRM ARE VOID. EXCEPT
AS PROVIDED IN THIS WRITTEN WARRANTY, NEITHER
CAS (USA) CORPORATION NOR ITS AFFILIATES
SHALL BE LIABLE FOR ANY LOSS, INCONVENIENCE, LOSS OF ANY DATA OR PROGRAMMING, OR
DAMAGE, INCLUDING DIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, RESULTING
FROM THE USE OR INABILITY TO USE THE CAS PRODUCT, W
HETHER RESULTING FROM BREACH OF
WARRANTY OR ANY OTHER LEGAL THEORY.
In Canada, warranties include both warranties and conditions.
Some jurisdictions do not allow limitations on how long an implied warranty lasts and some jurisdictions do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitations and exclusions may not apply to you.
This warranty gives you specific legal rights, and you may have other rights that may vary from jurisdiction to jurisdiction.
This warranty applies ONLYto the LP-Series label printing scales.
WARRANTY PERIOD:
1 (ONE) YEAR
To locate theCAS Authorized Dealer orCAS Authorized Service Center nearest you call:
[phone]
or write to:
CAS (USA) Corporation • 99 Murray Hill Parkway • East Rutherford, NJ 07073

1General
1
1General
1.1 Introduction
Thank you for purchasing the CAS LP-2 price computing electronic printing scale. We have
designed this equipment with many advanced features, high quality construction, and user-friendly
menu driven programming. We are confident that you will find the CAS LP-2 scale will meet all of your
most demanding needs.
Sales data is easily acquired through many of the available reports which are quickly accessible
through the on-screen menus. Also available: 4 inch per second printing speed, 53 preset keys (106
using the SHIFT key), and several operation modes that enable you to control & limit access to the scale.
For larger operations, there is an in-store network that can have up to 32 scales. Another
powerful feature is RS-232 port, which can tie a scale to a personal computer (P.C.) for exporting or
importing program data. Because PLU and all other data files are kept locally in each scale’s RAM
memory, the scale’s speed is the same in a Network setting or as a stand-alone unit.
The LP-2 can be easily used with a wide variety of industry standard thermal labels. By simply
entering a label’s length and width dimensions, you can use practically any of them on the LP-2! You
can also use continuous strip labels or even thermal paper. You also can print logos, templates, Nutri-
Facts panels, ingredient messages, advertisement lines, and more.
Remember, for proper installation and maintenance please refer to the LP-2 Service Manual. A
wide variety of supplies, accessories, and expansion options are available through CAS (USA)
Corporation for whatever your new and increasing demands may require. Before attempting any
repairs or servicing please look over this manual careful or contact CAS (USA) Corp.
The LP-2 also comes with a trial version the SP-2 software package. This software runs on any PC
using the Windows95/98/2000 operating system. You can use the SP-2 program for as long as you
would like. You can design your own label formats on your computer screen and save them to your
hard drive. With this WYSIWYG interface, the labels you see on-screen appear exactly “as they will
print.” You can also manage all of the LP-2’s programs and options like pricing, PLU programming, etc.
You can upload data from an LP-2 or download data, perfect as an emergency backup system. All this
and many more features are packed into the SP-2 software package. The full version of the SP-2 system
will allow you to transmit and receive data from the scales. This makes the SP-2 software packagean
indispensable commodity for your business as.
To find the Authorized CAS Dealer nearest you, please visit our web-site at www.cas-usa.com.

1General
2
1.2 Model and Specifications
MODEL LP-2, (version 1.03)
CHARACTERS PER PLU Ingredients: 2000 characters, PLU Name: 114 characters
DISPLAYS WEIGHT: 5 digits (5 max)
UNIT PRICE: 6 digits (8 max)
TOTAL PRICE: 7 digits (9 max)
GENERAL
PROGRAMMABLE DATA §Scrolling Messages : 32 @ 80 Char §Sales Messages : 32 @ 40 Char
§Store Name : 150 Char
§Departments : 32 @ 20 Char
§Users/Clerks : 99 @ 20 Char
§Label Formats : 999 @ 30 Char
§Label Formats : Over 50 Built-In
§Origin : 400 @ 25 Char
INTERFACES RS-232 Serial Ports: COM1 (9 pin female), COM2 (25 pin female)
LABEL SIZES Width: 10mm~80 mm (0.40 in.~3.15 in.)
Length: 20mm~170 mm (0.94 in.~6.69 in.)
Length: 850 mm (33.46 in.) max length using linked formats.
MAX TARE FULL CAPACITY
MEASUREMENT TYPE LOAD CELL
MEMORY CAPACITY Over 800 PLUs Standard memory configuration.
MEMORY OPTION Over 4000 PLUs Expanded with optional memory card.
NETWORK
SPECIFICATIONS §32 Scales MAX §99 Clerks MAX
§100m (0.06 miles) max cable length
§4 Mbps Network Speed
§Optional Network card required
OPERATING TEMP. -10° C~ 40° C (14° F~ 104° F)
PLU PROGRAMMABLE
DATA §Department # : 1~32 §PLU # : 1~999999
§Commodity Name : 114 Char
§Label Format # : 1~999
§Sales Message # : 1~32
§Unit : lb, kg
§Group Code : 0~99
§Tax Rates : 0~3
§Country Code : 0~999
§Sell By Date : 0~999 days
§Cook By Date : 0~999 days
§Tare Weight : 0~Capacity
§Price : 0.00~999.99
§Sale Weight : 0~Capacity
§Sale Price : 0.00~999.99
§Net Weight : 0~9999
§Count : 1~99
§Sale Count : 0~99
§UPC : 0~999999
§Ingredients : 2000 Char
§Barcode Type/Format
§Nutritional Information
PLATTER SIZE Length: 403 mm (15.87 in.), Width: 260 mm (10.24 in.)
POWER SOURCE 85~240VAC 50/60Hz ±5%
PRINT SPEED 100 mm/sec (4 in./sec)
PRINTER TYPE DIRECT THERMAL PRINT
SALES PERIODS Dual totals for daily/monthly or user selectable reporting periods.
SALES REPORT MODES Read: X1/X2 Modes, Read & Reset: Z1/Z2 Modes
SALES REPORT TYPES §Daily PLU & Misc. PLU Report
§Daily Department Report
§Daily Scale Report
§Daily Group Report
§Daily Hourly Report
§Daily Detailed Report
§Monthly PLU & Misc. PLU Report
§Monthly Department Report
§Monthly Scale Report
§Monthly Group Report
§Monthly Hourly Report
§Monthly Detailed Report
§Clerk Report
SHIPPING WEIGHT 13 kg (29 lb)
WEIGHING CAPACITY 0~15 x 0.005 lb/ 0~30 x 0.01 lb, 0~30 x 0.01 lb / 30~60 x 0.02 lb
(0~3x0.001kg/3~6x0.002kg, 0~6 x 0.002 kg / 0~15 x 0.005 kg,
0~15 x 0.005 kg / 15~30 x 0.01 kg)
WEIGHING RANGE DUAL RANGE
WEIGHING UNITS Pound & Kilo push-button selectable.

1General
3
Note: Specifications are subject to change without notice.

2Unpackingand Assembly
4
2Unpacking and Assembly
2.1 Unpacking
#Description QTY
1 Desiccant, silica bag 3
2LP-2, Display assembly 1
3LP-2, Display assembly screws 2
4LP-2, Scale body 1
5Owner’s Manual, LP-21
6Packing box 1
7Packing lid 1
8Plastic bag, display column 2
9Plastic bag, scale 1
10 Fuse 1
11 Platter 1
12 SP-2 software package 1
13 Thermal labels, 1 roll 1
14 Top form-fitted packing foam 1
15 Bottom form-fitted packing foam 1
16 Manual plastic bag 1
17 Fuse Plastic bag 1
18 PLU pad 1

2Unpacking and Assembly
5
2.2 Assembly of Display Column
1) You must follow the instructions in this section in order to assemble the Display Assembly properly.
To begin the installation, make sure that the scale is unplugged from any electrical source. Your
scale body has a display column bracket in the rear that the display column slides into. (See
fig.)
2) Hold the display assembly in front of you such that the display assembly forms the figure “7”.
Next, with the scale’s keyboard facing you, insert the display column into the display bracket.
When the display column reaches the bottom of the display bracket, you will “feel” the
connectors “snap” together. (See fig.)
3) Underneath the display bracket you will find 2 screw holes for the display assembly screws. Insert
and fasten the 2 display assembly screws. You are done! (See fig.)

3Proper Operation
6
3Proper Operation
3.1 Environmental Considerations & Safety
1) Please avoid the following hostile conditions:
§Temperatures below or exceeding:
-10º C ~ 40º C (14º F ~ 104º F) §Ungrounded electrical outlet
§Excessive vibration §Unstable or flimsy surface
§Wind or fans functioning in direct
contact with weighing platform. §Shared electrical outlet
§Direct sunlight §Dust or dirt
§High humidity §Poor ventilation
2) Environmental Protection: The scale should be installed in a dry and liquid free environment. When
the scale is installed in a high humidity or wet-type environment, be sure to avoid spilling or spraying
directly on any surface of the scale.
3) Personal Safety: It is extremely important to be aware of personal safety whenever maintaining or
operating this equipment. Wherever possible, we have tried to place warning labels and other
indicators at the actual location on the equipment where the danger is most likely to occur. However, it
is not always possible to foresee all dangerous situations. Warnings and cautions that are necessary for
the safe operation of the scale are contained in this manual. Please, make sure to carefully read ALL
warnings and cautions before operating the scale.
4) Observe the following safety precautions:
§Shut the scale OFF and unplug the scale whenever you are changing the label
roll or whenever working in the printer bay.
§The outlet that the scale is plugged into, should be properly grounded.
§Whenever connecting or disconnecting ANY cables from the scale, be sure to
hold the cables by the end connector. Failure to do so may cause a short
circuit.
§Maintain a static free work area.
§Never use any other equipment on the same line: it should be a dedicated line.
§The outlet used must have the proper voltage ratings.

3Proper Operation
7
3.2 Leveling and Location
1) Location: This scale must be placed on a flat and stable surface. Please keep the scale away from
the direct path of oscillating fans, ventilation systems, or strong drafts as these air disturbances can be
picked-up by the scale’s very sensitive weighing platform and may cause incorrect weight readings.
2) Leveling: If the scale is not properly leveled, please adjust the 4 adjustable legs at the bottom of
the scale. Turn the legs clockwise or counterclockwise so as to center the bubble of the leveling gauge
inside the indicated circle. Turning the adjustable legs counter-clockwise (viewed from top of scale) will
lower that part of the scale. Turning the adjustable legs clockwise (viewed from top of scale) will raise
that part of the scale. (See Fig.)

3Proper Operation
8
3.3 Power Outlet and Requirements
1) The LP-2 is designed to be used almost anywhere in the world! Like the many appliances of today,
the LP-2 is designed with an automatically switching power supply. This allows operation when
connected to an AC source from 85V to 240V at 50/60Hz with 5% tolerance.
Remember: a switching power supply does not imply that bad, noisy, or improperly wired power
lines will be problem free. With that in mind, please make sure that the power lines used for the LP-2
are dedicated lines with no high-noise devices (such as compressors, motors, etc) running on it.
Also, make sure that the wiring to the electrical socket is correct. If yo u are uncertain as to the
state of your business’ electrical lines, please contact a certified electrician.
2) Once you are sure as to the safety of the electrical line, make sure to ONLY plug the scale into a 3-
prong outlet. The third prong is a safety ground and an electrician should properly wire this if it is
not correct or if you are unsure. Failure to this CAN result in electrical shock from use of this or any
electronic scale.
3) Do not use any 3-prong to 2-prong adapters or break-off the third prong from the LP-2 power cord.
The third prong is necessary and must be properly connected.
4) If you have any problems or questions regarding this matter, make sure to contact the CAS USA
Service Department.
Note: Be sure to check the LP-2’s serial number plate on the back of the scale for power specifications.

4Nomenclature
9
4Nomenclature
4.1 Scale Overview
1) Pictured below are important scale components and parts that you should be familiar with.
#Description #Description #Description
1Advertisement Insert, rear 8Fuse Cap 15 Power Switch
2Connector, COM1 9Gauge, Leveling 16 Printer
3Connector, COM2 10 Keyboard, Numeric 17 Serial Number Plate
4Connectors, network 11 Keyboard, Speed Keys 18 Side Access Door, Com port
5Display Column 12 Leveling Feet 19 Side Access Door, printer
6Display Window, customer 13 Platform 20 Template Sheet, Numeric
7Display Window, user 14 Platter 21 Template Sheet, PLU
22 Connector, Cash Drawer

4Nomenclature
10
4.2 Display and Indicators
1) VFDisplay: The front and rear displays on the LP-2 are dot matrix vacuum fluorescent displays.
They will display all information pertinent to operating the scale.
LP-2 Display Window: Sales
1234567
17
16 8
15
14 13 12 11 10 9
#Description Values
1Mode indicator REG, RPK, MGR, ADD, PLU, NET1, STR2,
LOC, SET, X1, X2, Z1, Z2
2Print Mode indicator Auto
3Auto Clearing status indicator PrePack, Save, (Blank)
4Speed key Shift status indicator Shift, (Blank)
5Override & Discount Status Ride, DISC, Disc, 1, 2, 3, (Blank)
6Multi-function indicator Time, date, scale #, department #,
Alt, Temporary Changes, (Blank)
7PLU Description line First non-blank line of PLU commodity
8Total price heading TOTAL PRICE and money symbol
9Total price indicator 7 digits USA: 0.00~9999.99
10 Unit price heading UNIT, money and weigh symbols
11 Unit price indicator 6 digits USA: 0.00~999.99
12 Weight indicator 5 digits
13 Weight heading WEIGHT and weigh symbol
14 Negative weight indicator -, (Blank)
15 Net-Weight indicator ◀, (Blank)
16 Stable weight indicator ○, (Blank)
17 Zero weight indicator ◀, (Blank)
A Gross Zero indication is reached when the Net -Weight indicator is OFF, the Zero-Weight indicator is ON,
the Stable indicator is ON, and the weight reads 0.00 or 0.000.
NOTE1: Only on networking scales.
NOTE2: Only on stand-alone scales.
WEIGHT kg
UNIT $ / kg
TOTAL PRICE $
◀
○
◀
<REG> Auto PrePack Shift Ride 12:12:00 PM
This is PLU Commodity Nam
I
0~30 lb x 0.01 lb / 30~60 lb x 0.02 lb, e=d=0.01 lb, 0.02 lb
0~15 kg x 0.005 kg / 15~30 kg x 0.01 kg, e=d=5g, 10g
CAPACITY:
ZERO
STABLE
NET

4Nomenclature
11
4.3 Printer
1) Pictured below are important printer components and parts that you should be familiar with.
#Description #Description #Description
1Label/Paper Roll 7Platen 13 Sensor Assembly, Gap
2Label Roll Spool 8Pressure plate & width adjuster 14 Sensor Assembly, Peel-Off
3Lock-Down Tab 9Pressure shaft 15 Shaft, Pick-Up Motor
4Paper Cutter 10 Release Lever, TPH 16 Side Access Door, printer
5Peel-Off Bar 11 Roller, return17 Thermal Print Head
6Pick-Up Spool Assembly 12 Brush 18 Paper Guide Plate
To clean the Thermal Print Head, turn the scale OFF. Open the printer’s side-access door and
release the print head using the release lever. Using theThermal Head Cleaner Pen, rub it gently from
left to right working your way from the front to the back of the print head. See diagrams below. Do this
until the thermal head is clean which should take no longer than 10 seconds. Allow the print head to
dry for 5 minutes and then lock it down, close the printer’s side-access door, and turn the scale ON.

4Nomenclature
12
4.4 The Program Mode Numeric Key Pad
Key Description
Numeric keys. Used to enter programming data.
Decimal key.
Clear key. Used to clear erroneous entries and error conditions. Also stops
multi-label printing that is in progress.
Copy key.
Up & Down arrow keys. Use to navigate through PGM mode.
Left & Right arrow keys. Use to navigate through PGM mode.
Backspace key. Used to backspace and delete text data.
0
~
9
C
COPY
▲ ▼
◀ ▶
BACK
SPACE
O P
COPY
▲
PAGE
UP
L
BACK
S PACE
◀ ▶
▼
SAVE
PAGE
DOWN
INSERT
OVER
DELETE PASTE
7 8 9
4 5 6
1
00
.
2 3
0 C
TEST
ESC
SHIFT
HELP
LABEL
FEED
ALT
ENTER
00
.
