Chauvin Arnoux C.A 6416 User manual

C.A 6416
C.A 6417
GROUND TESTER
User’s manual
ENGLISH

2
Thank you for purchasing a C.A 6416 or C.A 6417 ground tester. For best
results from your instrument:
■read these operating instructions carefully,
■comply with the precautions for use.
Symbol
Meaning
WARNING, risk of DANGER! The operator must refer to these
instructions whenever this danger symbol appears.
Equipment protected throughout by double or reinforced insulation.
Application or withdrawal authorized on uninsulated or bare
conductors at dangerous voltages.
The product has been declared recyclable after analysis of
its life cycle in accordance with the ISO14040 standard.
Chauvin Arnoux has adopted an Eco-Design approach in order to
design this appliance. Analysis of the complete lifecycle has
enabled us to control and optimize the effects of the product on the
environment. In particular this appliance exceeds regulation
requirements with respect to recycling and reuse.
The CE marking indicates conformity with European directives, in
particular LVD and EMC.
The rubbish bin with a line through it indicates that, in the European
Union, the product must undergo selective disposal in compliance
with Directive WEEE 2002/96/EC. This equipment must not be
treated as household waste
Useful information or tip.
Definition of measurement categories:
■Measurement category IV corresponds to measurements taken at the source
of low-voltage installations.
Example: power feeders, counters and protection devices.
■Measurement category III corresponds to measurements on building
installations.
Example: distribution panel, circuit-breakers, machines or fixed industrial
devices.
■Measurement category II corresponds to measurements taken on circuits
directly connected to low-voltage installations.
Example: power supply to domestic electrical appliances and portable tools.

3
PRECAUTIONS FOR USE
This instrument and its accessories comply with safety standards EN 61010-1, EN
61010-030, and EN 61010-2-032 for voltages of 600V in category IV at an altitude
of less than 2000m, indoors, with a degree of pollution of not more than 2.
Failure to observe the safety instructions may result in electric shock, fire,
explosion, and destruction of the instrument and of the installations.
■The operator and/or the responsible authority must carefully read and clearly
understand the various precautions to be taken in use. Sound knowledge and
a keen awareness of electrical hazards are essential when using this
instrument.
■If you use this instrument other than as specified, the protection it provides
may be compromised, thereby endangering you.
■Do not use the instrument on networks of which the voltage or category
exceeds those mentioned.
■Do not use the instrument if it seems to be damaged, incomplete, or poorly
closed.
■Before each use, check the condition of the insulation on housing. Any item of
which the insulation is deteriorated (even partially) must be set aside for repair
or scrapping.
■Use personal protection equipment systematically.
■When handling the instrument, keep your fingers behind the physical guard.
■All troubleshooting and metrological checks must be performed by competent
and accredited personnel.
■Avoid impacts on the measurement head, in particular the air gap.
■Keep the surfaces of the air gap clean; even a little dirt can cause the clamp to
malfunction.
Note: Bluetooth®is a registered trade mark.

4
CONTENTS
Page
1. GETTING STARTED .........................................................................................7
1.1 UNPACKING ................................................................................................7
1.2 INSERTING THE BATTERIES.....................................................................7
1.3 Setting the date and time.............................................................................. 7
1.4 EXAMPLE OF DISPLAY .............................................................................. 8
2. DESCRIPTION OF THE DEVICE ...................................................................... 8
2.1 FUNCTIONS OF THE DEVICE ....................................................................9
2.2 FRONT PANEL .......................................................................................... 10
2.3 DEVICE–REAR PANEL ............................................................................. 12
2.4 DISPLAY UNIT........................................................................................... 13
2.5 AUDIBLE SIGNALS.................................................................................... 15
3. MEASUREMENT PRINCIPLE ......................................................................... 16
4. USE.................................................................................................................. 17
4.1 INSERTING THE BATTERIES................................................................... 17
4.2 COMMISSIONING THE DEVICE ............................................................... 17
4.3 SETTING THE INTERNAL CLOCK............................................................17
4.4 STANDARD OR ADVANCED MODE.........................................................18
4.5 USE OF THE FUNCTIONS ........................................................................ 18
4.6 USE OF THE Hold KEY ............................................................................. 18
4.7 USE OF Pre-Hold ....................................................................................... 18
4.8 STORAGE OF THE DATA ......................................................................... 19
4.8.1 Conditions......................................................................................... 19
4.8.2 EFFECTIVE STORAGE.................................................................... 19
4.8.3 INFORMATION CONCERNING THE STORED DATA..................... 19
4.8.4 MEMORY FULL ................................................................................ 19
4.8.5 READING THE STORED DATA ....................................................... 20
4.9 MANAGEMENT OF THE ALARMS ............................................................20
4.9.1 NO ALARM DETECTION.................................................................. 20
4.9.2 VOLTAGE ALARM............................................................................ 20
4.9.3 CURRENT ALARM ........................................................................... 21
4.9.4 IMPEDANCE ALARM ....................................................................... 21
5. Ω+A POSITION................................................................................................ 23
5.1 USE IN Standard MODE ............................................................................ 23
5.1.1 OBJECT............................................................................................23
5.1.2 PARAMETERIZING THE MEASUREMENT ..................................... 23
5.1.3 MEASUREMENT .............................................................................. 23
5.1.4 MEASUREMENT RESULT ............................................................... 24
5.1.5 STORAGE OF THE MEASUREMENTS ...........................................24
5.1.6 PRESENCE OF ALARMS................................................................. 24

5
5.2 USE IN ADVANCED MODE....................................................................... 24
5.2.1 OBJECT............................................................................................24
5.2.2 SELECTION...................................................................................... 24
5.2.3 PARAMETERIZING THE MEASUREMENT ..................................... 24
5.2.4 MEASUREMENT .............................................................................. 25
5.2.5 MEASUREMENT RESULT ............................................................... 25
5.3 COMPLEMENTARY INFORMATION......................................................... 26
5.3.1 PRODUCT ZXI GREATER THAN 50V .............................................26
5.3.2 IMPEDANCE GREATER THAN 1500Ω............................................ 27
5.3.3 PERTURBING LEAKAGE CURRENT .............................................. 27
5.3.4 CURRENT GREATER THAN 10A .................................................... 27
5.3.5 STORAGE OF THE MEASUREMENTS ...........................................28
5.3.6 PRESENCE OF ALARMS................................................................. 28
6. POSITION A ....................................................................................................29
6.1 OBJECT ..................................................................................................... 29
6.2 PARAMETERIZING THE MEASUREMENT............................................... 29
6.3 MEASUREMENT........................................................................................ 29
6.4 MEASUREMENT RESULT ........................................................................ 29
6.5 PRESENCE OF ALARMS ..........................................................................29
6.6 MANAGEMENT OF THE ALARMS ............................................................30
7. MEMORY READ (MR) ..................................................................................... 31
7.1 OBJECT ..................................................................................................... 31
7.2 SELECTION OF THE memory read MODE ............................................... 31
7.3 DATA DISPLAYED.....................................................................................31
7.3.1 DATA DISPLAYED IN Standard MODE ........................................... 31
7.3.2 DATA DISPLAYED IN ADVANCED MODE ...................................... 32
7.3.3 USE OF THE KEYS.......................................................................... 33
7.3.4 ERASURE OF THE STORED DATA ................................................ 33
7.3.5 EXITING FROM THE READ MODE ................................................. 34
7.3.6 EXPORTING DATA TO A PC ........................................................... 34
8. SET-UP............................................................................................................36
8.1 OBJECT ..................................................................................................... 36
8.2 ACCESS TO THE SET-UP MENUS........................................................... 36
8.3 DISPLAY OF THE SET-UP MENUS .......................................................... 36
8.4 SELECTING A SPECIFIC MENU...............................................................37
8.5 DETAILS OF THE SET-UP MENUS .......................................................... 37
9. OFF POSITION................................................................................................ 43
9.1 MANUAL SWITCHING OFF....................................................................... 43
9.2 AUTOMATIC SWITCHING OFF................................................................. 43
9.3 BACKUP OF THE CONFIGURATION........................................................ 43
9.4 PROLONGED STOP.................................................................................. 43
10. TECHNICAL CHARACTERISTICS ................................................................ 44

6
10.1 REFERENCE CONDITIONS.................................................................... 44
10.2 ELECTRICAL CHARACTERISTICS......................................................... 44
10.2.1 LOOP RESISTANCE MEASUREMENT ...........................................44
10.2.2 LOOP INDUCTANCE MEASUREMENT...........................................45
10.2.3 ESTIMATE OF THE CONTACT VOLTAGE...................................... 45
10.2.4 CURRENT MEASUREMENT............................................................ 45
10.3 VARIATIONS IN THE DOMAIN OF USE .................................................46
10.4 POWER SUPPLY..................................................................................... 46
10.5 ENVIRONMENTAL CONDITIONS ........................................................... 47
10.6 MECHANICAL CHARACTERISTICS ....................................................... 47
10.7 COMPLIANCE WITH INTERNATIONAL STANDARDS ........................... 47
10.8 Electromagnetic compatibility................................................................... 47
11. SERVICING AND MAINTENANCE................................................................ 48
11.1 Cleaning ................................................................................................... 48
11.2 Replacement of the batteries.................................................................... 48
11.2.1 PROCEDURE ...................................................................................48
11.2.2 PRESERVATION OF STORED DATA .............................................49
11.3 CHECK OF ACCURACY.......................................................................... 49
11.3.1 OBJECT AND EQUIPMENT NECESSARY...................................... 49
11.3.2 EQUIPMENT..................................................................................... 49
11.3.3 PROCEDURE ...................................................................................49
11.4 ADJUSTMENT .........................................................................................49
11.4.1 OBJECT AND EQUIPMENT NECESSARY...................................... 49
11.4.2 EQUIPMENT..................................................................................... 49
11.4.3 PROCEDURE ...................................................................................50
11.5 Metrological check.................................................................................... 50
11.6 Repair....................................................................................................... 50
12. WARRANTY .................................................................................................. 50
13. TO ORDER .................................................................................................... 51

7
1. GETTING STARTED
1.1 UNPACKING
Rep.
Designation
1
Carrying case.
2
C.A. 6416 or C.A. 6417 earth clamp.
3
Set of 4 AA batteries (1.5V).
4
CD containing the GTC application and the operating instructions.
5
Verification certificate.
6
Safety data sheet (20 languages)
7
Quick Start guide
Fig. 1
1.2 INSERTING THE BATTERIES
Refer to §11.2.
1.3 SETTING THE DATE AND TIME
Set the function switch to Ω+A. All icons of the display unit light for approximately 2
seconds. The device waits for the date and time of the device to be set using the ▲,
▼, and ► keys; refer to § 4.3 for a detailed description of the procedure.

8
1.4 EXAMPLE OF DISPLAY
The figure opposite shows a
display, upon first use, with the
device set to Ω+A. The measured
current is 30.0mA and the
impedance is 7.9Ω.
The buzzer is active and the
memory is empty.
Note: This display corresponds to
the Standard mode. In the
Advanced mo
de, 2 additional
screens are available; see §5.2.
Fig. 2
The figure opposite shows a
display, upon first use, with the
device set to A
. The current
measured is 30.0mA.
The buzzer is active and the
memory is empty.
Fig. 3
2. DE SCR IPTION OF THE DE VICE
The earth clamp is intended for testing the resistances of any conducting system
having the characteristics of a conducting loop. It is used to perform:
■Earth resistance measurements if the earth is in series in a loop with its
continuity conductor;
■Other earth measurements: earth extended, for example by means of a guard
wire between power transmission or telecommunication poles;
■Or the distributed earths of a single earth plane.

9
2.1 FUNCTIONS OF THE DEVICE
■Easy-to-use device intended for measurement of the loop impedance in a
parallel earth network, by a simpler method than the traditional method with 2
auxiliary rods.
Loop ohmmeter: measurement of loop impedances from 0.01Ω to 1,500Ω.
The ohmmeter function makes allowance for the presence of inductances
in the loop, making impedance measurements more accurate at low
values.
Ammeter: current measurements from 0.2mA to 40A.
Contact voltage: the contact voltage is estimated by calculating the product of
the loop impedance by the leakage current. The value found is an upper
bound on the voltage between the measurement point and earth, since the
impedance taken into account is that of the whole loop.
■Large multi-function OLED display unit.
■Display in Standard mode (only 1 screen) or Advanced mode (3 screens).
■Clamping diameter 35mm.
■Storage of measurements (Ωand/or A, with time-stamping).
C.A. 6416: up to 300 measurements stored.
C.A. 6417: up to 2000 measurements stored.
■Possibility of reading out the stored measurements on the clamp itself.
C.A. 6417: Read-out also possible via Bluetooth®
■Measurement hold by the HOLD key and/or by opening the clamp (PRE-
HOLD mode).
■Weight limited by the use of powerful magnetic materials.
■Opening the clamp made easy by a trigger with a force compensation system.
■Advanced ergonomics (grip and reading of the display unit).
■Small influence of spurious currents.

10
2.2 FRONT PANEL
Measurement
head
1
HOLD key, to freeze
the display
4
Rotary switch used to
select a measurement
function, SET-UP, or
memory read
3
Guard
2
OLED display unit
5
Trigger
6
Display backlight key
7
MEM key, to store
measurements
8
► key, for validation and
browsing in the
measurement screens
9
Fig. 4

11
Rep.
Designation
See §
1
Measurement head.
-
2
Guard. The user's hand must be below this zone and not
touch the measurement head (item 1).
-
3
Function switch.
4.5
OFF: device off.
9
Ω+A: simultaneous selection of the Loop impedance
measurement and the Leakage current measurement.
5
A: selection of the Current measurement.
6
MR: (Memory Read) display of the data stored when MEM
(item 8) was pressed.
7
SET-UP: access to configuration of the parameters and to
erasure of the stored measurements.
8
4
HOLD key: freezes the measured and displayed values, at
any time, along with the various functional indications.
4.6
: Model C.A. 6417 only. When the function switch is set
to MR or SET-UP
, pressing this key activates or
deactivates the Bluetooth® connection.
5
OLED display unit.
2.4
6
Measurement head opening trigger.
-
7
Dual-function key:
-
(when device is set to Ω+A or A): increases the
brightness of the OLED display unit; makes it easier
to read the display unit in an environment with strong
background illumination. Highlighting activated for 30
seconds.
-
▲(when device is set to SET-UP or MR): serves as up
arrow when browsing in the menus and values. The
brightness of the display unit does not change when
device is set to SET-UP or MR.
-
8
Dual-function key.
-
MEM (when device is set to Ω+A or A): records the
measured value. All of the data are recorded, in the
Standard or Advanced mode.
4.8
▼(when device is set to SET-UP or MR): serves as
down arrow
when browsing in the menus and
values.
-

12
Rep.
Designation
See §
9
► Function that depends on the setting of the function
switch, as follows:
When the device is set to Ω+A (Advanced Mode)
Short press:
switches the display through the
following 3 modes, in order:
5.2.5
■Display of the impedance recalculated at the
selected frequency.
■Display of the contact voltage (product Z*I).
■Display of R and L.
Long press: activates or deactivates the audible
alarms.
2.5
when device is set to SET-UP
Validation when browsing in the menus and values.
-
when device is set to MR (Advanced Mode)
Switches the display through the measurement
screens and the measurement date/time.
2.3 DEVICE–REAR PANEL
Fig. 5
Rep.
Designation
See §
10
Battery compartment cover locking screws.
11.2
11
Battery compartment cover.
11.2
12
Batteries (4 AA – LR6, 1.5V).
11.2

13
2.4 DISPLAY UNIT
Fig. 6
Rep.
Designation
See §
1
■Display of the buzzer active state; the icon is masked when
the buzzer is inactive.
8.5
■Selection of the buzzer operating mode via SET-UP menu 2.
8.5
2
Indicator of freezing of the measurement display when the HOLD
key is pressed or in the Pre-Hold mode
4.6
4.7
3
Indicates that the main display shows the date (with the function
switch set to MR or SET-UP).
7
4
Symbol reporting the presence of perturbations (current) in the
loop making it impossible to be sure of the impedance
measurement.
-
5
Upper display unit. 4,000-counts current measurement and 500-
counts loop inductance measurement (Advanced mode).
-
6
Signalling indicating incorrect closing of the clamp; the
measurement cannot be made in this case. If the Pre-hold mode
is activated, the Hold icon blinks and the measurement is frozen.
4.6
Selection of the Pre-Hold mode via SET-UP menu 11.
8.5
7
Permanent operation of the clamp (automatic switching off
disabled).
Selection of the automatic switching off mode in SET-UP menu 3.
8.5
8
Battery charge indicator with 3 states:
■Not displayed: batteries charged.
■Blinking:
batteries low. The device remains functional, but the
batteries will have to be replaced soon.
■Steady: batteries discharged. The display unit indicates Lo
bat. It is impossible to make measurements, read records, or
configure parameters.
11.2.1
9
Units of the top measurements display unit:
■mH: loop inductance measurement unit.
■mA or A: current measurement unit (mA or A).
-

14
10
Units of the central measurements display unit:
■V: contact voltage measurement unit.
■Ω: impedance measurement unit. Symbol used for
impedances at the measurement frequency, for impedances
referred to the network frequency, or for the resistive
component.
-
11
Unit of the alarm displayed. The alarm can be defined on an
impedance, a voltage, or a current, depending on the
measurement chosen (Ω+A or A).
■A: current measurement alarm.
■Ω: resistance measurement alarm.
■V: voltage measurement alarm.
8.5
12
Alarm threshold display unit:
■Display of one of the alarms (1000-counts display unit) with
the various units.
8.5
■These 3 digits are also used when configuring the time display
mode (A. for A.M., P. for P.M. or 24H) in SET-UP menu 8.
13
Alarm threshold over(under-)shoot indicator (operational use or
parameterizing):
▲
Alarm threshold overshoot indicator.
AL
Alarm threshold adjustment mode or Alarm function.
▼
Alarm threshold undershoot indicator.
8.5
14
Signal indicating potentially hazardous voltage. Blinks when the
contact voltage exceeds 50V.
-
15
C.A. 6417: Remains displayed while the Bluetooth connection is
being established. Blinks for the duration of the communication.
-
16
Memory index display unit. 4-digit digital display (0 to 9999
counts):
■Of the measurement sequence number, of the current memory
in normal operation associated with the Read (MR) or Storage
(MEM) indications.
■Of the date stamp (year) when the device is parameterized.
-
17
Memory read mode.
7
18
Data storage mode.
4.8
19
In the Advanced mode, these symbols identify the value
displayed (resistance or impedance).
5.2
20
Main display unit:
■Measurement of the impedance or voltage.
■Display of the date and time (month-day and hour-minute) in
parameterizing and stored values read mode.
-
21
In Advanced mode, indication displayed when the inductive
component is negligible with respect to the resistive component.
5.2.5
22
Indicates selection of the Advanced mode.
5.2
Remark: when switched on, the device performs a rapid self-test of the entire
display unit. All available segments are displayed briefly. During this stage, a
sustained press on HOLD prolongs the display of all segments.

15
2.5 AUDIBLE SIGNALS
The device can generate audible signals of four types:
Type of
sound
Duration Meaning
Low-pitched
Short
Normal use (key pressed).
Permanent
Over(under-)shoot of a measurement alarm
threshold
(Ω, A).
High-pitched
Short
Abnormal use (for example, memory full).
Permanent
Overshoot of a safety alarm threshold (V).
The audible signal can be activated or deactivated in SET-UP (see chapter 8,
menu 2). The icon (Fig. 6, item 1) behaves as follows:
icon
Meaning
Visible
Buzzer activated; an alarm or a key press causes an audible
signal to be emitted.
Missing
No audible signal is emitted.
This programming is backed-up and retrieved at each reset. The audible alarm
can be de-activated in the SET-UP menu (see chapter 8, menu 2).
During a measurement, a long press on the ► key toggles between activation and
deactivation of the buzzer.
Since the measurement freque
ncy is audible, the operator hears a
discontinuous audible signal (beep-beep). This is neither an operating fault nor
an alarm, and it cannot be eliminated. This audible signal is amplified by the
presence of current in the loop.

16
3. ME AS UR E ME NT P R INC IP L E
The schematic diagram below illustrates the general case of measurement of the
resistance of a loop comprising:
■The earth electrode Rx;
■The earth;
■Several earth electrodes of resistance Ri;
■A guard wire looping all of these earths, introducing an inductive component.
The clamp combines two functions in the measurement head:
■The generator winding of the clamp emits an alternating voltage having a
constant level E.
■The receiver winding (current measurement) senses I=E/Zloop.
Knowing Eimposed by the generator and Imeasured, the value Zloop can be
deduced and displayed on the device. The Advanced mode makes it possible to
distinguish the resistive and inductive parts and to refer the impedance to the
network frequency.
More generally, this principle can be used to search for a defective earth. This is
because the loop resistance comprises:
■Rx (the value sought);
■Zearth (a value that is normally very low, less than 1Ω);
■R1//R2...// Rn(a negligible value: case of multiple earths in parallel);
■Zguard wire (a value that is normally very low, less than 1Ω).
■Rloop=Rx+Zearth+(R//R...//R )+Zguard wire;
As an approximation, Zloop can therefore be treated as equivalent to Rx.
If this value is very high, an inspection of this earth electrode is strongly
recommended.
Z
earth
Z
guard wire
Fig. 7

17
4. USE
4.1 INSERTING THE BATTERIES
Refer to §11.2.
4.2 COMMISSIONING THE DEVICE
With the clamp closed and not clamping any conductor, set the function switch to a
position other than OFF. All icons of the display unit light for approximately 2 seconds,
before possible entry of the date and time (see next section).
During the first few seconds of operation, the clamp automatically adjusts correction
factors serving to optimize the impedance measurement. This correction makes it
possible to allow for the variations of the measurement head air gap that may occur in
some particular conditions of temperature and humidity.
During this adjustment, the screen displays CAL GAP. If the clamp detects a problem,
it indicates Err CAL when the switch is set to Ω+A. It is then necessary to check the
cleanliness of the air gap, check that no conductor is encircled, and switch off and
back on.
When this adjustment is done, the clamp displays the screen corresponding to the
switch setting.
Note: the switching off of the device is described in chapter 9.
4.3 SETTING THE INTERNAL CLOCK
Setting the clock, which allows time-stamping of the measurements with a view to their
storage, is done only the first time the device is used or after the device has been
without battery power for more than 2 minutes.
Note: if time-stamping is not necessary, because for example a user has no need of time-
stamped measurement records, this operation can be skipped. To skip setting the date and time,
press the ► key until the measurement screen corresponding to the switch setting (Ω+A, A,
MR or SET-UP) is displayed. The date and time can be set later in the SET-UP position and
the Hour and Date screens; see chapter 8, menus 7 and 8.
Set the date and time. The year, month, date, display mode (AM/PM - display from
01:00 to 12:00, symbol A. or P. or 24-hour, symbol 24H), and time. Modify the
blinking value with ▲ or ▼ and validate by ►. At the end of the procedure, the
display unit displays the screen associated with the function selected (Ω+A, A,
MRor SET-UP).
The operator must change between standard and daylight saving time manually.

18
4.4 STANDARD OR ADVANCED MODE
The earth clamp can be used in two ways.
■The Standard mode makes the standard loop ohmmeter clamp measurements.
■The Advanced mode is used to refine and complete the measurements:
- Impedance referred to the selected frequency.
- Contact voltage.
- Resistive and inductive fractions of the loop impedance.
The choice of the Standard or Advanced mode and the alarm thresholds are
parameterized in the SET-UP menu. See §8.5, menus 4, 5, 6, and 9 for details.
4.5 USE OF THE FUNCTIONS
Setting of the function switch See §
OFF
9
Ω+A
5
Use in Standard mode
5.1
Use in Advanced mode
5.2
Complementary information
5.3
Management of the alarms
4.9
A
6
MR
7
SET-UP
8
4.6 USE OF THE HOLD KEY
This function, available in the Ω+Aand Ameasurement modes, freezes the
display of the measurement as soon as the HOLD key is pressed. The NOISE,
clamp open ( ), and alarm overshoot ( ) icons are visible if they were active.
With the HOLD state active:
■The ► key is active and can be used, in Advanced mode, to display the
various measurement screens.
■The MEM key is active and can be used to record the values displayed.
■The HOLD key is used to exit from the HOLD state. The icon goes off
and the device returns to the previous function.
4.7 USE OF PRE-HOLD
If the Pre-Hold mode was activated in the configuration (see §8.5, menu 11),
opening the clamp places the device in a state identical to the HOLD mode for as
long as the clamp is open. The utility of this function is that it makes it easy to
freeze the measurement with one hand, in particular when access to the HOLD

19
key is difficult. If necessary, then press the HOLD key to freeze the device and
release the handle.
If the HOLD key is not pressed, closing the clamp automatically causes an exit
from the Pre-hold mode.
4.8 STORAGE OF THE DATA
The values displayed during the measurements can be stored and read out later.
4.8.1 CONDITIONS
Storage of the data is available in both the Ω+A and Ameasurement modes,
provided that memory locations are free.
4.8.2 EFFECTIVE STORAGE
The data are stored as soon as the MEM key is pressed. A long audible signal
confirms the storage.
4.8.3 INFORMATION CONCERNING THE STORED DATA
All calculated impedance and/or current values, together with the values
accessible in the secondary screens in the Advanced, mode, are stored as soon
as the MEM key is pressed, namely:
■Current measurement (A);
■Measurement of the resistance, inductance, and impedance (Z);
■Contact voltage measurement (V);
■Present configuration of the clamp;
■Sequence number of the record;
■Time and date of the record.
The display unit indicates the sequence number of the last measurement
recorded, or 0if the memory is empty. The data are preserved when the device is
off or without a battery.
4.8.4 MEMORY FULL
When 300 values have been stored and the memory is full (model C.A 6416), the
sequence number is replaced by FULL. The next time the MEM, key is pressed, a
disablement beep is emitted and the FULL indication blinks. Storage is rejected; it
is then necessary to erase the whole memory before recording again. Refer to
chapter 8, menu 1.
The communicating model C.A 6417 has a larger recording capacity, 2000
measurements. The PC interface can be used to activate a circular recording
mode in which the 2000 most recent values are kept, with a maximum sequence
number of 9999. If the circular recording mode is activated, as soon as the
threshold of 2000 values is exceeded, the sequence number is displayed
alternately with FULL in order to report the overwriting of the oldest records. When
the threshold of 9999 records is reached, the sequence number is replaced by

20
FULL. The next time the MEM key is pressed, a disablement beep is emitted and
the FULL indication blinks.
4.8.5 READING THE STORED DATA
The data can be looked up using the MR function. See chapter 7.
4.9 MANAGEMENT OF THE ALARMS
The device has 3 distinct alarms that can be parameterized.
The (Ω, V, A) alarm thresholds are defined in the SET-UP menu, lines 4, 5, and
6; see §8.5. The alarms can be activated or deactivated in these same menus.
4.9.1 NO ALARM DETECTION
If no alarm is activated, the alarm icons
are not displayed.
When no alarm is triggered, the alarm
display
displays the alarm threshold,
along with the direction of triggering (
,) of the impedance, voltage, or
current alarm.
Fig. 8
4.9.2 VOLTAGE ALARM
If the voltage (product ZxI) exceeds the
threshold set, the alarm symbol and
the alarm threshold are displayed and
blink.
If the buzzer is active, the high-pitched
audible warning signal is emitted.
Fig. 9
