Chiayo Q-818 User manual

Operation manual
CHIAYO ELECTRONICS CO.,LTD.
Q-818/815/215/1005
Handheld Microphone
M-818/815/215/1005
Belt-pack Transmitter

1
Handheld microphone & Belt-pack transmitter
Parts and functions
■Q-818 / Q-815 / Q-215 / Q-1005 handheld microphones
1. Cartridge
2. Battery power indicator
3. Power switch
4. Battery compartment
5. Color cap
■M-818 / M-815 / M-215 / M-1005 belt-pack transmitters

M-818 / M-815 M-1005 / M-215
1. Antenna
2. Cover release button
3. Power switch
4. Battery power indicator
5. Mini XLR connector
6. High-impedance gain control (GT)
7. Low-impedance gain control (MT)
8. Battery compartment
9. Charging contacts
2 3 4 51
1
2 2
8
6 7
9
4
3 5
1
435
2
9 9
6 7
8

2
Instructions
Battery installation & indicator
●►○
●
When the transmitter is switched ON, the
battery power indicator (handheld microphone
②, belt-pack transmitter ④) will blink once to
denote the batteries installed are in good
condition.
If the LED remains illuminated, it means the
batteries are weak and require replacement.
This microphone / transmitter requires 2 x AA
batteries to operate.
To install, remove the battery cover and slide
the batteries into the battery compartment &
replace the battery cover.
Note: Batteries contain a corrosive acid that may leak and damage the transmitter when stored for a long
period. Batteries should be removed from the transmitter before storing without use for more than 4 weeks.
GAIN setting on M-818 / M-815 / M-215 / M-1005
Gain control enables the user to set different output levels.
M-215 / M-1005 M-818 / M-815 
GT (LEFT) is for the use of instrument with
high impedance, such as guitar.
MT (RIGHT)is for the use of low impedance
such as lapel or headset microphones
GT MT
GT MT
GT MT
GT MT
