Cisco 7920 - Unified Wireless IP Phone VoIP User manual

Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706 USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
Customer Order Number: DOC-7816888=
Text Part Number: 78-16888-01
Phone Guide
Cisco Wireless
IP Phone 7920 for
Cisco CallManager 4.0
and Later
INCLUDING LICENSE AND WARRANTY

CCSP, the Cisco Square Bridge logo, Cisco Unity, Follow Me Browsing,
FormShare, and StackWise are trademarks of Cisco Systems, Inc.;
Changing the Way We Work, Live, Play, and Learn, and iQuick Study are
service marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX, Catalyst,
CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, Cisco, the Cisco Certified
Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco
Systems Capital, the Cisco Systems logo, Empowering the Internet
Generation, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast
Step, GigaDrive, GigaStack, HomeLink, Internet Quotient, IOS, IP/TV, iQ
Expertise, the iQ logo, iQ Net Readiness Scorecard, LightStream, Linksys,
MeetingPlace, MGX, the Networkers logo, Networking Academy,
Network Registrar, Packet, PIX, Post-Routing, Pre-Routing, ProConnect,
RateMUX, Registrar, ScriptShare, SlideCast, SMARTnet, StrataView Plus,
SwitchProbe, TeleRouter, The Fastest Way to Increase Your Internet
Quotient, TransPath, and VCO are registered trademarks of Cisco
Systems, Inc. and/or its affiliates in the United States and certain other
countries.
All other trademarks mentioned in this document or Website are the
property of their respective owners. The use of the word partner does not
imply a partnership relationship between Cisco and any other company.
(0502R)
Cisco Wireless IP Phone 7920 for Cisco CallManager
Copyright © 2005 Cisco Systems, Inc. All rights reserved.

Copyright © 2005 Cisco Systems, Inc. All rights
reserved. Cisco, Cisco IOS, Cisco Systems, and the Cisco
Systems logo are registered trademarks of Cisco Systems,
Inc. or its affiliates in the United States and certain other
countries. All other brands, names, or trademarks
mentioned in this document or Website are the property
of their respective owners. The use of the word partner
does not imply a partnership relationship between Cisco
and any other company. (0502R)
78-16888-01
Printed in China PRC DOC-7816888=
Quick Reference
Cisco Wireless
IP Phone 7920
Cisco CallManager Release 4.0 and Later
Using the Phone
Power on the phone—Press (red key)
and hold until phone powers on.
Dial a number—Press numbers on the keypad
and then press . (There is no dial tone).
Answer a call—Press (green key).
Hang up a call—Press (red key).
Power off the phone—Press and hold
until phone powers off.
Basic Phone Features
Access phone features—Press or
(softkey) that corresponds to the feature. Use
or to see other features during a call.
Access Menu options—Press (Menu)
and use or to switch to the desired
menu option.
Put a call on Hold—Press Hold.Press
Resume to reconnect to the call.
Answer another incoming call—Press Hold
for current call. Press to select the second
call and press to answer the call.
Transfer a call—Press Trnsfer.Dial the
number to which you want to transfer the
call. After the party answers or the phone
rings, press Trnsfer, then hang up.
Reconnect to a call—If your call fails to
transfer or you want to reconnect to a held
call, press Resume.
Move a shared line call between desk phone
and wireless phone—From your phone with
the active call, press Hold.From your other
phone, press Resume to connect to the call.
Mute the microphone—Press MuteOn. To
turn the microphone on, press MuteOff.
Make a Conference Call
During a call, press Confrn to put the first
party on hold. (Press or to locate
Confrn if not visible.) Dial the number for the
second party. After the second party answers,
press Confrn again to complete the action.
To add another party, press Confrn and
repeat the steps.
Forward Your Calls to Another Number
Locate CFwdAll and press it. Dial the number
to which you want to forward all calls.
“Forwarded to <number>” displays.
Cancel forwarding by pressing CFwdAll.

Shortcut Keys
Lock keypad—Press and hold (# key).
indicates the keypad is locked.
Unlock keypad—Press and hold then
press OK to toggle keylock off.
Toggle ring to vibrate—Press and hold
(* key). “Vibration On” displays and appears
on the screen. (Ringer becomes silent)
Toggle vibrate to ring—Press and hold .
“Vibration Off” displays; disappears.
Adjust speaker volume—Press to access
the volume screen. Press to increase or
to decrease the volume.
Access voice messages—Press and hold
for a moment. The phone connects to your
voice-messaging system.
Redial number—Press to view a list of
dialed calls. Press to locate the number
and press to redial the number.
Access Speed Dial number—Press and hold
(2-9) for the Speed Dial number that
you want to use. The phone displays and dials
the number that is stored for that hot key.
#
#
1
2
ABC
Softkey Definitions
CallBack—Receive notification when a busy
extension becomes available.
Barge and cBarge—Join a call on a shared
line.
Conflist—View a list of conference
participants.
DirTrfr—Transfer two calls to each other.
iDivert—Send a call to the voice-messaging
system.
GPickUp—Answer a call on another
extension in another pickup group.
Join—Join two calls on a single line.
MeetMe—Host a conference call that has a
dial-in number.
Park—Store an active call at a specific
number. Retrieve the call by dialing the Park
number from any phone.
PickUp—Answer a call on another extension
that is in your Call Pickup group.
RmLstC—Drop the last party added to a
conference call
Setting Up Speed Dial Numbers
Access Speed Dial setup—Choose Menu >
Directory > Phone Book. Scroll to and select
Speed Dial. The Speed Dial hot keys display.
Check marks indicate those hot keys that
have assigned phone numbers.
Add or change a Speed Dial number—Scroll
to a Speed Dial hot key and press Detail. Press
Edit to enter or change the number by using
the keypad. Press OK to save the Speed Dial.
Making Phone Book Entries
Add or change a Phone Book entry—Choose
Menu > Directory > Phone Book > Add.
Scroll to the entry item and press Select. Enter
the name or phone number by using the
keypad.
Enter text—Press the numeric key once, twice
or three times to enter the appropriate
character. To enter a number, press the key
four times. For spaces, press or .
Enter uppercase—Press to switch
between uppercase and lowercase. or
displays at the right of the screen.
Enter symbols—Press to display the
symbol table. Use arrows to navigate to
desired symbol and press Use to insert it.
#

Cisco Wireless IP Phone 7920 for Cisco CallManager v
Contents
Cisco Wireless IP Phone 7920
Quick Reference Card
CHAPTER 1Getting Started 1
How to Use this Guide 2
Document Conventions 4
Safety and Performance Information 5
Battery Safety Notices 7
Accessories for the Cisco Wireless
IP Phone 7920 10
Installing or Removing the Phone Battery 11
Charging the Phone Battery 13
CHAPTER 2Overview of the Cisco Wireless
IP Phone 7920 15
Powering On the Phone 18
Main Screen and Display Indicators 19
Shortcut Keys for Phone Functions 20
Using the Phone Menus 22
Setting Passwords 23
Entering and Editing Text 25

vi 78-16888-01
CHAPTER 3Basic Call Handling 27
Placing Calls 27
Answering and Ending Calls 32
Muting Calls 33
Adjusting the Speaker Volume 34
Placing Calls on Hold 35
Transferring Calls 36
Making Conference Calls 37
Starting a Standard Conference Call 38
Starting or Joining a Meet-Me
Conference Call 40
Forwarding Your Calls to Another Number 41
CHAPTER 4Advanced Call Handling 43
Parking and Retrieving Parked Calls 43
Picking Up a Redirected Call on Your Phone 44
Using a Shared Line 45
Maximum Supported Calls on a Shared
Line 46
Sharing Call Information and Barging 47
Preventing Others from Viewing or Joining a
Shared-Line Call 49
Tracing Suspicious Calls 50
Prioritizing Critical Calls 50
CHAPTER 5Using the Phone Book and Speed Dial
Features 53
Using the Phone Book 54
Adding or Changing Entries in the Phone Book 55

Cisco Wireless IP Phone 7920 for Cisco CallManager vii
Configuring Speed-Dial Hot Keys 58
CHAPTER 6Using Voice Messaging and Call History
Logs 63
Playing Voice Messages 63
Viewing and Placing Calls from the Call History
Menu 64
CHAPTER 7Using and Changing Profiles 67
User Profiles 67
Options for User Profile Settings 68
Configuring User Profiles 69
Network Profiles 72
Choosing a Network Profile 72
CHAPTER
8Using Cisco IP Phone Services 75
Logging In to the User Options Web Pages 76
Subscribing to IP Phone Services 77
Accessing IP Phone Services 78
CHAPTER 9Customizing Phone Settings and Viewing
Phone Status 79
Change Phone Settings 80
Changing Ring Tone Settings 80
Changing Phone Display Settings 81
Changing Phone Access Settings 82
Viewing Phone Status 84
Viewing the Network Configuration 85
Cisco One-Year Limited Hardware Warranty
Terms 87

viii 78-16888-01

Cisco Wireless IP Phone 7920 for Cisco CallManager 1
CHAPTER
1
Getting Started
Before getting started with your Cisco Wireless IP
Phone 7920, make sure that the following items are in
the box and inform your system administrator or
supplier if any items are missing:
•Cisco Wireless IP Phone 7920
•Standard battery
•Power supply
•Cisco Wireless IP Phone 7920 Guide
•Regulatory Compliance and Safety Information
for the Cisco Wireless IP Phone 7920
•Cisco Wireless IP Phone 7920 Accessory Guide
Note The radio frequency (RF) for this phone is
configured for a specific regulatory domain.
If you use this phone outside of its regulatory
domain, the phone will not function
properly, and you might violate local
regulations.

2 78-16888-01
How to Use this Guide
This guide provides you with an overview of the
features that are available on your phone. For
information about common tasks, refer to the
following table. Contact your system administrator if
you have problems or need more information about
your phone.
If you want to... Then...
Install the battery See the “Installing or Removing
the Phone Battery” section on
page 11.
Charge the battery See the “Charging the Phone
Battery” section on page 13.
Turn on or turn off
your phone
See the “Powering On the Phone”
section on page 18.
Use your phone Start with the “Overview of the
Cisco Wireless IP Phone 7920”
section on page 15.
Set LEAP password See the “Setting LEAP Password”
section on page 24.
Understand the
phone screen
See the “Main Screen and Display
Indicators” section on page 19.
Make calls See the “Placing Calls” section on
page 27.
Change the
speaker volume
See the “Adjusting the Speaker
Volume” section on page 34.

Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 3
Lock the keypad See the “Shortcut Keys for Phone
Functions” section on page 20.
Put calls on hold See the “Placing Calls on Hold”
section on page 35.
Transfer calls See the “Transferring Calls”
section on page 36.
Mute calls See the “Muting Calls” section on
page 33.
Make conference
calls
See the “Making Conference
Calls” section on page 37.
Listen to voice
messages
See the “Playing Voice Messages”
section on page 63.
Set up speed dial See the “Configuring Speed-Dial
Hot Keys” section on page 58.
Choose rings for
different conditions
See the “Configuring User
Profiles” section on page 69.
Set up a personal
phone book
See the “Using the Phone Book”
section on page 54.
Change ring tones See the “Changing Ring Tone
Settings” section on page 80.
Subscribe to phone
applications and
services
See the “Subscribing to IP Phone
Services” section on page 77.
Get information
about phone
accessories
See the “Accessories for the Cisco
Wireless IP Phone 7920” section
on page 10.
If you want to... Then...

4 78-16888-01
Document Conventions
To simplify the instructions for using phone features
and for changing phone settings, this guide uses the
following navigational conventions and terms.
Action Keys Navigation Instructions in This Guide
Using or
softkeys
with labels
When you must press the softkey for a
menu, feature, or action label, this
guide states: Press (softkey label).
Example: Press PhBook
Using the
or arrows
To move left or right between menu
tabs or softkey labels, this guide states:
Use or to switch to (item name).
Example: Use or to switch to the
Directory
Using the
or arrows
To move up or down between menu
options or list items, this guide states:
Scroll to (item name).
Example: Scroll to Speed Dial
Using the
“Select”
softkey
When you must press the “Select”
softkey to use a menu option or item
that you have highlighted, this guide
states: Select (item name).
Example: Select Speed Dial
Using menus
and options
To advance through several menu
options, the guide states: Choose Menu
> (menu option) > (menu option)
Example: Choose Menu > Directory >
Phone Book > Speed Dial

Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 5
Safety and Performance Information
Before installing and using your phone Cisco Wireless
IP Phone 7920, read the following safety notices.
Warning This warning symbol means danger. You
are in a situation that could cause bodily
injury. Before you work on any equipment,
be aware of the hazards involved with
electrical circuitry and be familiar with
standard practices for preventing
accidents.
Warning Read the installation instructions before
connecting the system to the power
source.
Warning The plug-socket combination on the
battery charger must be accessible at all
times, because it serves as the main
disconnecting device.

6 78-16888-01
Warning This equipment will not be able to access
emergency services during a power
outage because of reliance on utility
power for normal operation. Alternative
arrangements should be made for access
to emergency services. Access to
emergency services can be affected by
any call-barring function of this
equipment.
Warning Do not use the Cisco Wireless IP
Phone 7920 in hazardous environments
such as areas where high levels of
explosive gas may be present. Check with
the site safety engineer before using any
type of wireless device in such an The
battery charger requires short-circuit
(overcurrent) protection to be provided as
part of the building installation. Install
only in accordance with national and
local wiring regulations.

Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 7
Battery Safety Notices
These battery safety notices apply to the batteries that
are approved by the Cisco Wireless IP Phone 7920
manufacturer.
Warning There is the danger of explosion if the
battery is replaced incorrectly. Replace
the battery only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s
instructions.
Warning Do not dispose of the battery pack in fire or
water. The battery may explode if placed
in a fire.
Caution The battery pack is intended for use only
with this device.
Caution Do not disassemble, crush, puncture, or
incinerate the battery pack.

8 78-16888-01
Caution To avoid risk of fire, burns, or damage to
your battery pack, do not allow a metal
object to touch the battery contacts.
Caution Handle a damaged or leaking battery with
extreme care. If you come in contact with
the electrolyte, wash the exposed area
with soap and water. If the electrolyte has
come in contact with the eye, flush the eye
with water for 15 minutes and seek
medical attention.
Caution Do not charge the battery pack if the
ambient temperature exceeds 104 degrees
Fahrenheit (40 degrees Celsius).
Caution Do not expose the battery pack to high
storage temperatures (above 140 degrees
Fahrenheit, 60 degrees Celsius).

Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 9
Caution When discarding a battery pack, contact
your local waste disposal provider
regarding local restrictions on the disposal
or recycling of batteries.
Caution To obtain a replacement battery, contact
your local dealer. Use only the batteries
that have a Cisco part number.
Standard battery—CP-BATT-7920-STD
Extended use battery—CP-BATT-7920-EXT
Caution Use only the Cisco power supply that was
provided with your phone. If you need to
replace your power supply, refer to the list of
Cisco part numbers.
North America—CP-PWR-7920-NA
Central Europe—CP-PWR-7920-CE
United Kingdom—CP-PWR-7920-UK
China—CP-PWR-7920-CN
Japan—CP-PWR-7920-JP
To see translations of the warnings that appear in this
publication, refer to the Regulatory Compliance and
Safety Information for the Cisco Wireless
IP Phone 7920 document that accompanied this
product.

10 78-16888-01
Accessories for the Cisco Wireless
IP Phone 7920
The following phone accessories are available for
your phone:
•Standard and extended batteries
•Power supplies for various regions
•Desktop charger
•Standard wired earphone
•Carrying cases
For a complete list of accessories, refer to the
Cisco Wireless IP Phone 7920 Accessory Guide that is
included in the phone box.

Getting Started
Cisco Wireless IP Phone 7920 for Cisco CallManager 11
Installing or Removing the Phone
Battery
You must install and charge the battery before you
can use the Cisco Wireless IP Phone 7920. To install
or remove the battery, follow these steps.
1. To install the battery, insert the battery catches
(as shown in Figure 1-1) in the corresponding
slots at the bottom of the Cisco Wireless
IP Phone 7920. Make sure that the metal
contacts on the battery and the phone are facing
each other.
2. Press the battery to the body of the phone until it
locks into place.
3. To remove the battery, press down on the locking
catch, then lift and remove the battery.

12 78-16888-01
Figure 1-1 Installing or Removing the Battery
1Locking catch—Press to release the battery.
2Battery catches—Insert these into the slots near
the bottom of the phone at battery installation.
3Metal contacts—Match the contacts on the
battery to the contacts on the phone.
22
79675
1
3
