CKD ECS Series User manual

INSTRUCTION MANUAL
INSTRUCTION MANUAL
•Be sure to read this instruction manual before using the product.
•Pay extra attention to the instructions concerning safety.
•After reading this instruction manual, keep it in a safe and convenient place.
Electric Actuator
(compatible with stepper motors)
ECS Series
Food manufacturing processes
ECS FP Series
Compatible with Secondary Battery
ECS P4 Series
SM-A48287-A

SM-A48287-A Introduction
i 2021-11-09
Introduction
Thank you for purchasing our “ECS Series,” “ECS FP Series” or “ECS P4 Series” Electric
Actuator. This Instruction Manual describes basic instructions particularly on mounting and operation
methods so that the product can perform at its full potential. Please read it carefully and use the product
properly.
Please keep this instruction manual in a safe place where it will not get lost.
Specifications and appearance described in this manual may be changed without prior notice.
•This product is intended for people who have basic knowledge of materials, wiring, electricity,
mechanism, etc. CKD is not responsible for accidents caused by the selection and use of the
product by persons without knowledge or sufficient training.
•Since our customers use this product for a very wide range of applications, CKD cannot keep
track of all of them. Depending on the application and usage, the product may not be able to
perform at its full potential due to fluid, wiring or other conditions, or it may lead to an accident. It
is the customer's responsibility to check the specifications of the product and decide how to use it
according to the intended application and usage.

SM-A48287-A For Safe Operation
ii 2021-11-09
For Safe Operation
When designing and manufacturing equipment using this product, it is obligatory to manufacture safe
equipment. To do so, make sure that the mechanism of the equipment and the system that controls it
electrically are safe.
In order to use CKD products safely, it is important to appropriately select, use, handle and maintain
products.
To secure product safety, be sure to observe the warnings and precautions described in this Instruction
Manual.
This product incorporates many functions and mechanisms to ensure safety. However, mishandling of
the product by a customer may lead to accidents. In order to avoid such accidents,
Be sure to read this Instruction Manual carefully and understand its contents before use.
Precautions are divided into 3 categories: "DANGER," "WARNING" and "CAUTION," in order to indicate
the level of potential hazard.
DANGER
If mishandled, dangerous situations leading to fatal or serious injuries may
occur and there is a high degree of emergency.
WARNING
If mishandled, dangerous situations leading to fatal or serious injuries may
occur.
CAUTION
If mishandled, dangerous situations leading to injuries or damage to property
may occur.
Note that even some precautions described as “CAUTION” may lead to serious results depending on a
situation.
Any of these precautions contain important information, so be sure to follow them.
In addition, general notes and usage tips are indicated with the following icon.
General notes and usage tips are described.

SM-A48287-A For Safe Operation
iii 2021-11-09
Precautions related to the product
DANGER
Do not use this product for the following purposes.
•Medical equipment related to sustainment and control of human life or body
•Mechanical devices and mechanisms designed for the purpose of moving or transporting
people
•Critical security parts in mechanical devices
WARNING
Use the product within product specifications.
Precautions related to disposal
CAUTION
When disposing of this product, follow the Law on Waste Disposal and Cleaning, and have it
disposed of by a specialized waste disposer.

SM-A48287-A Table of Contents
iv 2021-11-09
Table of Contents
Introduction....................................................................................................................... i
For Safe Operation .......................................................................................................... ii
Precautions related to the product.................................................................................iii
Precautions related to disposal .....................................................................................iii
Table of Contents ........................................................................................................... iv
1. Product Overview..................................................................................................... 1
1.1 System Overview................................................................................................ 1
1.1.1 System Configuration ................................................................................... 1
1.2 Model number ....................................................................................................... 2
1.2.1 ECS Series (compatible with stepper motors) ............................................... 2
1.3 Specifications ........................................................................................................5
1.3.1 Specifications ................................................................................................. 5
2. Installation ................................................................................................................ 7
2.1 Installation environment ......................................................................................10
2.2 Unpacking ...........................................................................................................10
2.3 Installation method...............................................................................................11
2.3.1 Accessories ...................................................................................................11
2.3.2 Motor installation method ............................................................................. 12
2.3.3 Dimensions of Motor Attachment .................................................................18
2.3.4 Installation of main body and transfers ........................................................ 26
3. How to Use.............................................................................................................. 27
3.1 Precautions on Use.............................................................................................27
4. Maintenance and inspection................................................................................. 29
4.1 Periodical inspection ...........................................................................................30
4.1.1 Inspection Items ......................................................................................... 30
4.1.2 Greasing ....................................................................................................... 31
4.1.3 Replacement and adjustment of dustproof plate ....................................... 31
5. Warranty provision................................................................................................. 32
5.1 Warranty conditions ............................................................................................32
5.2 Term of Warranty.................................................................................................32

SM-A48287-A 1. Product Overview
1 2021-11-09
1. Product Overview
1.1 System Overview
1.1.1 System Configuration
Left side/belt
drive
PLC
Driver
Motor installation direction
Four models available for different installation positions
ECS Series
Home position and limit sensors
Sensors can be added by
choosing specific models.
(Motor/control)
Power supply
(Control)
Power
supply
(Please obtain the above
devices and cables by yourself.)
Stepper motor
(Please obtain, install, and
adjust the motor by yourself.)
Left side/belt drive
Right side/belt drive
Bottom/belt drive
Motor Exposed
Inside sensor
Inside sensor dog
Outside sensor
Outside sensor dog

SM-A48287-A 1. Product Overview
2 2021-11-09
1.2 Model number
1.2.1 ECS Series (compatible with stepper motors)
<Example of model number>
ECS-06-05010-EAANCBNP-M
E) Specifications of the installed motor
［FP series］
［P4 series］
Symbol Description
M: Anti-rust treatment
N None
U Yes
P4
- -
-
05
-
ECS
05
040
C
B
A
B
A
E
A B C D E F G H I
--
N
J
P
K
P
K
U
M
P
L
M
Compatible with Secondary Battery
05
-
ECS
05
040
C
B
A
B
A
E
A B C DE F G HI
--
N
J
P
K
P
K
P
L
M
Food manufacturing processes
FP1
--
Symbol Description
A: Body size (mm)
05 Width 51 × height 54
06 Width 65 × height 56
10 Width 102 × height 78.5
12 Width 102 × height 82.5
14 Width 135 × height 91
B:
02
2 mm
05
5 mm
10 10 mm
16 16 mm
20 20 mm
C:
005 50 mm to 1050 mm
- 105 ( 50-mm pitch ) Indication is 1/10
D:
E Motor Exposed
D Bottom/belt drive
L Left side/belt drive
R Right side/belt drive
E:
A
B
C
F:
A
□42
B
□56
C
□60
G: Brake
N Without
H:
N Without
A Inside: Motor side
B Inside: Opposite side to motor
C
D
I:
N Without
A Inside (Installed at shipment)
B Outside (Installed at shipment)
J:
N
D
R Right direction
L Left direction
K:
N
P
L: Magnet slider type *2
M
Thread lead (See Table 1 in the next section)
Stroke length (See Table 1 in the next section)
Motor installation direction (See Table 2in the next section)
Specif ications of the installed motor (See Table 3 in the next section)
Motor size(See Table 2 in the next section)
Adopted
For details on specifications of the
installed motor, see the table below
None (body mounting direction: standard )
None ( body mounting direction: bottomside)
None
Yes
Standard
Home position sensor ( 1 pc, seeTable 4 inthenext section)
Outside: Opposite side to motor (Installed at shipment)
Outside: Motor side (Installed at shipment)
Limit sensor(2 pcs, see Table 4 in the next section)
Grease nipple (See Table 5 in the next section)
Positioning pin hole (See Table 6 in the next section)
Model No.
06
-
ECS
05
010
C
B
1
N
M
E
A B C D E F G H I
--
N
J
P
K
M
-
L
A B C
記号 メーカ ＜□42> ＜□56> ＜□60>
－
－
－
－
－
取付モータ仕様
〇
〇
株式会社ダイアディック
システムズ
B
C
〇
〇
〇
〇
－
オリエンタルモータ―
株式会社
ミネベアミツミ
株式会社
A
ORIENTAL
MOTOR Co., Ltd.
MinebeaMitsumi Inc.
Dyadic Systems
Co.,Ltd.
Specifications of the installed motor
Symbol
Manufacturer
A) Body size: Width 65 x height 56 mm
B) Thread lead: 5 mm
C) Stroke length: 100 mm
D) Motor installation direction:
Motor Exposed
E) Specifications of the installed motor: A
F) Motor size: □42
G) Brake: Without
H) Home position sensor: Outer motor side
I) Limit sensor: Outside
J) Grease nipple: None (body mounting direction:
standard)
K) Positioning pin hole: YES
L) Magnet slider type: Adopted
