Clarke PC4 User manual

Part No. 7630214
4-Tier Parts/Tool Carousel
Model No. PC4
This product is guaranteed against faults in manufacture for 12 months from
purchase date. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been abused or tampered with in
any way, or not used for the purpose for which it is intended.
The reason for return must be clearly stated.
This guarantee does not affect your statutory rights.
GUARANTEE
CLARKE International, Hemnall Street, Epping, Essex CM16 4LG
Part No. 7630214
4-Tier Parts/Tool Carousel
Model No. PC4
This product is guaranteed against faults in manufacture for 12 months from
purchase date. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been abused or tampered with in
any way, or not used for the purpose for which it is intended.
The reason for return must be clearly stated.
This guarantee does not affect your statutory rights.
GUARANTEE
CLARKE International, Hemnall Street, Epping, Essex CM16 4LG

Components
A Tray with Castors 1
B Tray 3
C Column 1
D Split Roll Pin 4
E Tray Support 3
F Plastic Cap 1
Assembly
If the castors are not fitted, slide them into the holes provided in the relevant tray
and secure with the screw supplied.
Slide the Column into thehole in the centre of the tray with castors and secure
with the screws provided.
Tap a Roll Pin into the lowest of the holes in the column until it is centralised, then
place the Column Support (large washer) so that it rests against the pin. Lower a
tray on top of the support.
Repeat this procedure fot the two remaining trays, and finally push the plastic
cap into the top of the column.
Your Carousel is now ready for use.
Components
A Tray with Castors 1
B Tray 3
C Column 1
D Split Roll Pin 4
E Tray Support 3
F Plastic Cap 1
Assembly
If the castors are not fitted, slide them into the holes provided in the relevant tray
and secure with the screw supplied.
Slide the Column into thehole in the centre of the tray with castors and secure
with the screws provided.
Tap a Roll Pin into the lowest of the holes in the column until it is centralised, then
place the Column Support (large washer) so that it rests against the pin. Lower a
tray on top of the support.
Repeat this procedure fot the two remaining trays, and finally push the plastic
cap into the top of the column.
Your Carousel is now ready for use.
