Clarke CWB1700P Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS1119
WORKBENCH
MODEL NO: CWB1700P
PART NO: 4501510
CWB1700P.fm Page 1 Wednesday, November 27, 2019 11:49 AM

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE WorkBench.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
SAFETY NOTICE
PLEASE NOTE THAT DUE TO THE WEIGHT OF THIS
PRODUCT, IT IS RECOMMENDED THAT TWO PEOPLE
LIFT IT IN TO POSITION.
Model Number CWB1700P
Part Number 4501510
Weight 72 kg
Dimensions (L x W x H) 1700 x 600 x 850 mm
CWB1700P.fm Page 2 Wednesday, November 27, 2019 11:49 AM

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CARTON CONTENTS
The following items should be supplied in the carton. If any parts are missing or
damaged, please see your CLARKE dealer where you purchased the
workbench.
DRAWER SLIDE IDENTIFICATION
Left Left Drawer Slide (Type A) x 4 Drawer Bottom x 5
Middle Leg Drawer Slide (Type B) x 3 Shelf x 1
Right Leg Drawer Slide (Type C) x 3 Door x 1
Upper Panel Foot x 6 Door Lock x 1
Lower Panel Drawer Front x 5 Rear Angle Bracket x 1
Divider Drawer Side x 10 Front Angle Bracket x 1
Rear Panel Drawer Back x 5 Bag of Nuts /Bolts and Washers
1. There are three types of drawer slide supplied 4 x Type ‘A’, 3 x Type ‘B’
and 3 x Type ‘C’
CWB1700P.fm Page 3 Wednesday, November 27, 2019 11:49 AM

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLE THE DRAWERS
1. Fit the drawer sides to the drawer bottom as shown and use two M4x8
bolts, washers and nuts in the central 2 holes to secure in place.
NOTE: The nuts and washers must be fitted to the inside of the drawer.
2. Connect the drawer back to the assembly as shown using 5 M4x8 Bolts,
washers and nuts.
CWB1700P.fm Page 4 Wednesday, November 27, 2019 11:49 AM

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Connect the drawer front to the assembly as shown using 5 M4x8 Bolts,
washers and nuts.
4. Repeat steps 1-3 for the remaining four drawers, giving you a total of five
drawers
5. Locate the 4 upper drawer slides Type ‘A’ there should be two left and
two right.
CWB1700P.fm Page 5 Wednesday, November 27, 2019 11:49 AM

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
Place all drawers to one side for now, you will fit them later.
6. Fit the drawer slides (Type ‘A’) to two of the drawers as follows
• Extend the drawer slide by hand
• Line up the drawer slide with the top of the drawer as shown.
• Secure each slide using three M4 screws, washers and nuts,
NOTE: The nuts and washers must be fitted to the inside of the drawer.
CWB1700P.fm Page 6 Wednesday, November 27, 2019 11:49 AM

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLE THE MAIN FRAME
1. Locate and identify the three legs as shown.
2. Connect the upper panel to the left leg as shown using 3 M5x8 Bolts,
washers and nuts.
CWB1700P.fm Page 7 Wednesday, November 27, 2019 11:49 AM

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Connect the lower panel to the left leg as shown using 3 M5x8 Bolts,
washers and nuts.
4. Fit the divider between the upper and lower panels using 4 M5x8 Bolts,
washers and nuts.
CWB1700P.fm Page 8 Wednesday, November 27, 2019 11:49 AM

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. Connect the middle leg to the upper and lower panels as shown using 6
M5x8 Bolts, washers and nuts.
6. Carefully stand the workbench up and fit the back panel as shown using
12 M5x8 Bolts, washers and nuts.
CWB1700P.fm Page 9 Wednesday, November 27, 2019 11:49 AM

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
7. Remove the 3 M5x8 Bolts, washers and nuts that connect the middle leg
to the upper panel, this is nessecery to enable you to fit the door.
8. Fit the door as shown and then replace the 3 M5x8 Bolts, washers and nuts
that you removed in the previous step.
CWB1700P.fm Page 10 Wednesday, November 27, 2019 11:49 AM

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
9. Place the shelf into position.
10. Tighten up all the nuts and bolts.
11. Fit the adjustable feet to the bottom of the legs including the right leg
which will be fitted later.
CWB1700P.fm Page 11 Wednesday, November 27, 2019 11:49 AM

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING THE TOP AND RIGHT LEG
1. Lay the top upside down on the frame with the front towards you.
2. Lay the two completed drawers (with slides fitted on page 6) into position
and secure using 8 wood screws supplied.
CWB1700P.fm Page 12 Wednesday, November 27, 2019 11:49 AM

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. With assistance, flip the top over and into postion as shown
4. Secure to the frame with 6 wood screws.
5. Place the right leg into postion and secure with 3 wood screws.
CWB1700P.fm Page 13 Wednesday, November 27, 2019 11:49 AM

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
6. Fit the support brackets as shown using wood screws and M5x8 bolts,
washers and nuts
• The larger bracket is fitted to the rear of the bench
CWB1700P.fm Page 14 Wednesday, November 27, 2019 11:49 AM

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING DOOR LOCK
IMPORTANT: Ensure the key remains in the lock until lock is fully fitted.
1. Remove the locking lever securing screw and lock washer from the lock
assembly, remove the lever, spring washer and washer noting which way
round they are fitted for reassembly.
• Take care to ensure the barrel does not fall out of the lock body.
2. Unscrew and remove the large securing nut, insert the lock into the hole in
the door, refit the large securing nut and tighten with spanner,
• DO NOT overtighten.
3. Turn the key fully anticlockwise (locked position), fit the lever as shown
4. Secure the lever with the spring washer, washer and securing screw.
5. Check that the lock works properly i.e. anticlockwise = locked and
clockwise = unlocked.
CWB1700P.fm Page 15 Wednesday, November 27, 2019 11:49 AM

16
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING THE LOWER DRAWERS
1. Insert the tongues into the slots on the legs and allow the drawer slide to
swing down and rest on the leg, no fixings are requires
2. Starting with the bottom drawer, pull out the drawer slides as far as
possible.
3. Lay the drawer into position as shown and secure each slide to the
drawer using countersunk screws, washers and nuts,
CWB1700P.fm Page 16 Wednesday, November 27, 2019 11:49 AM

17
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Make sure that you tighen all bolts and screws
5. Before using the bench for the first tme, we recommend the application
of a waterproof wood preservative to the bench top to prevent staining
from oil spills etc.
6. The bench is now ready to use.
