Cleveland ConvectionPro XVI 36-CGM-16-300 User manual

Cleveland
™
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site: www.ClevelandRange.com
Email: [e-mail]
CLASSIC CONVECTION STEAMERS
15 PSI BOILER BASE STYLE
MODEL: 36-CGM-16-300
Cle eland Standard Features
IICooking Capacity for up to eight 12˝ x 20˝ x 21⁄2˝ deep
Cafeteria Pans per compartment, or four 18˝ x 26˝ Buns Pans.
IIPressureless cooking with forced convection steam, permitting
doors to be opened while cooking continues.
II
Solid State Controls operate water level and safety functions.
II
Each compartment is equipped with a 60 minute mechanica l
timer, separate bypass switch for constant steaming.
IIInstant Steam Standby Mode: Holds generator at steaming
temperature. Allows unit to start cooking instantly.
IIDurable 10 Gauge Stainless Steel Construction:
For Compartment Door and Steam Cooking Cavity.
IISeparate Main Power Switch for “On/Off”
IIExclusive Steam Cooking Distribution System:
The exclu-
sive Convection Jets produce a high velocity convection steam
without fans. Coved Corner design in cooking compartment dis-
tributes heat evenly and is easy to keep clean. Creased bottom
enhances drainage. Cold Water Condenser for each compart-
ment maintains a dry steam. Fully insulated cooking compart-
ment for thermal efficiency. Removable Stainless Steel Slide
Racks for easy cleaning.
IIHeavy duty, one piece, solid compartment door design
with replaceable door gasket
IILeft Hand Door Hinging: Compartment Doors hinged left,
controls on the right.
IIModular Cabinet Base with Hinged Door.
IIHeavy duty Stainless Steel Base Frame.
IIHigh Efficiency Gas Steam Generator with NickelGuard,
Electronic Spark Ignition and Automatic Water Fill on start up.
IIAutomatic Generator Drain at shutdown: Contains a “Water
Jet” Spray Rinse Cleaning Cycle to keep drain clear.
IIAutomatic Water Level Control System with Low Water
Power Cut-off Circuit.
IISteam generator equipped with High Limit Pressure Safety
Switch, 15 psi Safety Valve, and Steam enerator Pressure
auge.
IINSF Certified 6˝ Stainless Steel Legs with adjustable
flanged feet for a one inch level adjustment.
IIas Pressure Regulator and Control Valve.
IIStandard Voltage for Control: 115 volts, 60 Hz, single phase.
IIAll Controls are serviceable from the front.
IICompartment Door Steam Shut Off Switch.
Options & Accessories
ËElectronic Timer with Compensating Load Feature. (ETC)
ËON/OFF Steam Switch only for compartment controls (MC)
ËCafeteria pans in depths of 1˝, 21⁄2˝, 4˝ and 6˝
Shall be Two Large Compartments, CLEVELAND Convection Steamer, Gas
fired Steam Generator, Model 36 CGM 16 300, NickelGuard, 300M BTU,
_____ gas, _____ volts, _____ Hz, single phase. Solid State Controls operate
timing, water level and safety functions.Type 304 Stainless Steel cooking
compartment. Insulated cooking compartments. One 60 minute Mechanical
Timer with Touch Control per compartment. Audible and Visual Signals for
cycle completion and steam shut off.
Ë18˝ x 26˝ Bun Pans
ËStainless Steel Insulated Flue Cover (SSF)
ËQuick Disconnect for gas line (QDC)
ËCorrectional Packages
ËSecondary Low Water Cut-Off, factory installed (CAL )
(Required for AZ. AR. CA. CO. CT. DE. FL. A. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
ËBoiler Descaling Pump Kit (107142)
ËWater Filters
ËRear as Connection (R T)
Short Form Specifications
Shown with optional
Electronic Timer
Con ectionPro XVI ®
TWO LARGE COMPARTMENTS, PRESSURELESS
00M BTU GAS FIRED STEAM GENERATOR
6” WIDE CABINET BASE DESIGN, with NICKELGUARD™
CONVECTION
STEAMERS
1
0
0
%
5
Y
e
a
r
B
o
i
l
e
r
W
a
r
r
a
n
t
y
N
i
c
k
e
l
G
u
a
r
d
™
SECT. III PA E 27
1007

(NOT TO SCALE)
SECT. III PA E 28
1007
Litho in U.S.A
Right - 6”, Left - 6”, Rear - 6” (12”
on control side if adjoining wall or
equipment is over 30” high for
service access)
For use in non-
combustible locations.
Contact factory for
variances to clearances
Do not use PVC pipe for drain.
Each compartment has capacity for:
•Eight, 12˝ x 20˝ x 21⁄2˝ deep Cafeteria Pans. Can
accomodate 18˝ x 26˝ Bun Pans.
WATER UALITY RE UIREMENT
The recommended minimum water quality standards
whether untreated or pre-treated, based upon 10 hours of
use per day, and a Daily Blowdown, are as follows:
TOTAL DISSOLVED SOLIDS less than 60 parts per million
TOTAL ALKALINITY less than 20 parts per million
SILICA less than 13 parts per million
pH FACTOR greater than 7.5
CHLORINE less than 30 parts per million
Consult a local water treatment specialist for an on site
water analysis for recommendations concerning steam
generator feed water treatment (if required), in order to
remove or reduce harmful concentrations of minerals. The
use of highly mineralized water will mean that more
frequent servicing of the steam generator will be
necessary. The fact that a water supply is potable is not
proof that it will be suitable for the generator.
NOTES:
**DO NOT CONNECT TO FI OUTLET. CLEVELAND RAN E RECOMMENDS AS FIRED 120 VOLT STEAMERS BE HARD WIRED DIRECTLY TO ELECTRICAL SYSTEM.
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are ASME/N. Bd, UL/NSF#4 and CSA (A A, C A).
** Do not connect to FI
outlet. See note below.
