Clevertronics FBKLED Series Instruction Manual

1949357 V2.0 August 2020
Maintenance:
Lamp Replacement:
•Use only the LED panel inside the Bunkalite
and listed on this instruction
•To replace the LED panel, remove the
screws, disconnect the signal wires and install
the new LED panel.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Models: FBKLED-vv-xx-yy-zz
Options:
xx = MS
Microwave Sensor
yy = DD
DALI LED Driver
zz = BLK
Black in Colour
vv = WW
Warm White
Spare Parts:
8002801 - PCA: CLE 220mm 2500lm 840 ADV4 EM SO
8002802 - PCA: CLE 220mm 2500lm 830 ADV4 EM SO (For use with -WW option)
1190310 - SENSOR:M/Wave Motion Remote MC015S/D
1330049 - LED Driver - LC 20w 350/500/700mA flexC SR ADV
1330045 - LED Driver –17w 250-700mA Dimmable (For use with –DD option)
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before
installation, ensure that the electricity supply has been switched off and isolated. Installation must be
carried out in accordance with the relevant Australian and International Standards.
240V LED Bunkalite
Installation & Maintenance Instruction Leaflet

1949357 V2.0 August 2020
Installation:
The LED Bunkalite (FBKLED) can be installed either Ceiling or Wall Mounted.
•Remove the four (4) screws holding the ring to the fitting.
•Remove the four (4) screws holding the gear tray to the base.
•At this point you must decide if the supply cable entry will be via the entry point provided, in the
channel recess between the outer-rim and the base, or if a new cable entry is to be drilled into the
rear of the base. NOTE: if you choose to use the cable entry point provided the luminaire cannot be
positioned/centred over the supply cable point on the wall or ceiling. The supply cable must line up
with the recessed channel as shown below.
•Using the base as a guide, mark 2 holes for mounting and one for mains access.
•Mount the base using appropriate fixings and seal these fixings with silicone (fill any additional entry
points with silicone also)
•Route the power inside the base.
•Connect the 240VAC (A, E, N) supply to the terminal block of the gear tray.
•Connect the DALI Lines to the terminals marked “DA DA” on the gear tray.
•Install the gear tray to the base.
•Apply power to the fitting and test per the instructions.
